Title: The Entity-Relationship (ER) Model


1
The Entity-Relationship (ER) Model
  • Lecture 2
  • INFS614, Fall 2008

2
Purposes of DBMS
  • Provide support for easy-to-use data
  • Data model (data)
  • Transaction model (operation)
  • Provide efficient storage and access of the data
    in terms of the data model and transactional
    model.

3
Data Models
  • Tools to obtain data abstraction.
  • Necessary to be general and intuitive.
  • Data model A class of mathematical structures,
    with description and operations
  • Conceptual data model Just structural description

4
Overview of Database Design
  • Conceptual design
  • Use ER Model E- Entities and R-Relationships
  • Decide the entities and relationships in the
    enterprise.
  • Decide what information about these entities and
    relationships should we store in the database.
  • Decide the integrity constraints or business
    rules.
  • Implementation
  • Map an ER model into a relational schema.

5
Entity Relationship Model
  • The E-R Model is used in the conceptual design
  • An E-R Model can be represented pictorially
    Result is an ER Schema or an ER Diagram
  • An E-R Model can be mapped into a Relational
    Database Schema.

6
ER Model Basics
  • Entity A real-world object distinguishable from
    other objects.
  • Distinguishable via its description (data).
  • Example specific student, faculty, department,
    event.
  • Attribute a mapping that maps an object to a
    value (called the attribute value). E.g. Age is
    an attribute of students objects.
  • An entity is described (in DB) using a set of
    attributes values.
  • Example student-sid, name, address, phone, age,
    ssn.

7
ER Model Basics
  • Entity Set A collection of similar entities.
    E.g., all students, all faculties.
  • Similar All entities in an entity set have the
    same set of attributes.

8
ER Diagram Entity Set Example
Diagram rule Entity set Box (rectangle) Attribu
te bubble (oval) Primary key underlined
9
ER Model Basics
  • Entity Set Properties
  • All entities in an entity set have the same set
    of attributes
  • Each attribute has a Domain a set of possible
    values for the attribute
  • Domain (age) 0,1,..,100
  • Domain (gender) female, male
  • Domain (sname) any string of at most 20
    characters
  • Null versus non-null

10
Keys of Entity Sets
  • A superkey of an entity set is a (sub)set of the
    attributes such that no two entities in the set
    is allowed to have the same values on all these
    (key) attributes.
  • Candidate key A superkey that does not have a
    redundant attribute, i.e., if any attribute is
    removed, the set is not a superkey anymore.
  • Primary key One of the candidate keys
    designated to be so.
  • Every entity set must have a key.

11
Keys of Entity Sets
  • Example
  • Candidate keys for Employees
  • SSN
  • EmployeeID
  • Primary key for Employees
  • SSN

12
ER Model Basics (Contd.)
  • Relationship Association among two or more
    entities. E.g., Mary works in the Pharmacy
    department.
  • Relationship Set Collection of similar
    relationships.
  • Similarity is in terms of entity sets where the
    entities are from.
  • E.g. A person (from Employees entity set) works
    in a department (from Departments entity set).
  • An n-ary relationship set R relates n entity sets
    E1 ... En each relationship in R involves
    entities e1 in E1,...,en in En
  • Same entity set could participate in different
    relationship sets, or in different roles in
    same set.

13
Relationship Set Example
since
dname
name
ssn
lot
budget
did
Works_In
Departments
Employees
Relationship set Works_In
14
Descriptive Attributes
  • Relationships can have attributes.
  • These attributes are called descriptive
    attributes, because they only describe
    relationships, but do not distinguish
    relationships.
  • A relationship can only be distinguished by the
    participating entities.

15
Relationship Set Example
since
dname
name
ssn
lot
budget
did
Works_In
Departments
Employees
Each Works_In relationship is uniquely identified
by the combination of employee ssn and
department did.
Thus, for a given employee-department pair, we
cannot have more than one associated since value.
16
Another Relationship Set
Each Reports_To relationship is uniquely
identified by subordinate_ssn and supervisor_ssn.
17
Instance of a Relationship Set
  • An instance of a relationship set is a specific
    set of relationships.
  • Snapshot of the relationship set at some instant
    in time.
  • E.g., Instance of relationship set Works_In
  • (123-22-3666,51), (213-55-1234,57),
    (232-32-6363,61)
  • (123-22-3666,51), (213-55-1234,57),
    (213-55-1234,57), (232-32-6363,61)

18
Relationship Sets
  • Example Instance of relationship set Works_In
  • Phil Collins works for A-Dept since 3/3/96
  • Brad Johnson works for B-Dept since 11/3/98
  • Martha Stewart works for C-Dept since 11/3/98
  • Will Smith works for C-Dept since 7/30/95

3/3/96
11/3/98
123-22-366
A
11/3/98
B
534-55-928
11/3/98
633-90-9767
C
231-89-6598
7/30/95
7/30/95
Employees
Departments
Works-In
19
Key Constraints
Works_In
since
  • Consider Works_In An employee can work in many
    departments a dept can have many employees.
  • In contrast, each dept has at most one manager,
    according to the key constraint on Manages.

20
1N Relationship Set
  • Manages Each dept has at most one manager,
  • An entity in Departments is associated with at
    most one entity in Employees via the relationship
    Manages
  • There is a Key Constraint on Dept w.r.t Manages

1 N
3/3/96
123-22-366
23
11/3/98
534-55-928
37
633-90-9767
51
7/30/95
231-89-6598
Departments
Employees
Manages
21
Key Constraints (Contd.)
  • Works_In relationship set many-to-many (MN).
  • Manages relationship set one-to-many (1N).

22
Key Constraints
  • We add the restriction that each employee can
    manage at most one department.

23
Key Constraints
budget
did
Departments
  • We add the restriction that each employee can
    manage at most one department.
  • We obtain a one-to-one (11) relationship set.

24
11 Relationship Set
  • Manages Each dept has at most one manager, and
    each employee can manage at most one dept.

1 1
3/3/96
123-22-366
23
11/3/98
534-55-928
37
633-90-9767
51
7/30/95
231-89-6598
Employees
Departments
Manages
25
Types of Binary Relationship Sets (Cardinality
Constraints)
1-to-1
1-to Many
Many-to-1
Many-to-Many
26
Key Constraints for Ternary Relationships
since
dname
name
ssn
lot
budget
did
Works_In2
Departments
Employees
Locations
addresses
capacity
Each employee works in at most one department and
at a single location.
27
Key Constraints
  • An entity set may participate in a relationship
    set as a key participant.
  • What it means is that each entity of the key
    entity set can only participate at most once in
    the relationship set.
  • More than one entity set can be key participant
    (e.g. one-to-one relationship set).

28
Participation Constraints
  • Does every department have a manager?
  • If so, this is a participation constraint the
    participation of Departments in Manages is said
    to be total (vs. partial).
  • Every did value in Departments table must appear
    in a row of the Manages table (with a non-null
    ssn value!)

since
since
name
dname
name
dname
ssn
lot
budget
did
budget
did
Departments
Employees
Manages
Works_In
since
29
Participation Constraints
  • Does every department have a manager?
  • If so, this is a participation constraint the
    participation of Departments in Manages is said
    to be total (vs. partial).
  • Every did value in Departments table must appear
    in a row of the Manages table (with a non-null
    ssn value!)

since
since
name
dname
name
dname
ssn
lot
budget
did
budget
did
Departments
Employees
Manages
Works_In
since
30
Participation Constraints
3/3/96
123-22-366
23
11/3/98
534-55-928
37
633-90-9767
51
7/30/95
231-89-6598
Employees
Departments
Manages
Total Participation
Partial Participation
31
Weak Entities
  • Consider the following situation employees can
    purchase insurance policies to cover their
    dependents.

name
pname
age
ssn
lot
Dependents
Policy
Employees
The attribute pname does not identify a dependent
uniquely.
32
Weak Entity Sets
  • A weak entity can be identified uniquely only by
    considering the primary key of another (owner)
    entity.
  • Owner entity set and weak entity set must
    participate in a one-to-many relationship set
    (one owner, many weak entities).
  • Weak entity set must have total participation in
    this identifying relationship set.

name
cost
pname
age
ssn
lot
Dependents
Policy
Employees
33
Another example
  • Note the primary key of the strong entity set is
    not explicitly stored with the weak entity set,
    since it is implicit in the identifying
    relationship.

34
Strong vs. Weak entity sets
  • Strong entity set
  • Has sufficient attributes to form a primary key
  • Weak entity set
  • Lacks sufficient attributes to form a primary key
  • Hence, it lacks enough attributes to form any
    key.
  • But every entity needs a key what do we do?
  • Must import attributes from strong entity set(s)
  • Importation is done via one-to-many relationships
  • A weak entity is subordinate to the dominant
    entity(-ies) from strong entity set(s) providing
    (reliably) attributes to complete its key.

35
Class Hierarchies
  • We may want to classify the entities in an entity
    set into subclasses.
  • E.g. classify the entities in Employees as
    Hourly_Emps or Contract_Emps.
  • Semantics every entity in Hourly_Emps and
    Contract_Emps is also an Employees. Thus, must
    have all attributes of Employees defined.

36
ISA (is a) Hierarchies
  • As in C, or other PLs, attributes are
    inherited.
  • If we declare A ISA B, every A entity is also
    considered to be a B entity.

37
Example
38
name
ssn
lot
ISA (is a) Hierarchies
Employees
hours_worked
hourly_wages
ISA
contractid
Contract_Emps
Hourly_Emps
  • Overlap constraints Can Joe be an Hourly_Emps
    as well as a Contract_Emps entity?
    (Allowed/disallowed)
  • Covering constraints Does every Employees
    entity also have to be an Hourly_Emps or a
    Contract_Emps entity? (Yes/no)

39
ISA (is a) Hierarchies
  • Reasons for using ISA
  • To add descriptive attributes specific to a
    subclass
  • E.g., hourly_wages does not make sense for
    Contract_Emps.
  • To identify entities that participate in a
    relationship
  • Define Senior_Emps ISA Employees
  • Define Manages relationship between entity sets
    Senior_Emps and Departments to ensure that only
    senior employees can be managers.

40
Aggregation
  • Entity set Projects.
  • Each Projects entity is sponsored by one or more
    departments.
  • A department that sponsors a project might
    assign employees to monitor the sponsorship.
  • HOW?

41
Aggregation
  • Used when we have to model a relationship
    involving (entity sets and) a relationship set.
  • Aggregation allows us to treat a relationship set
    as an entity set for purposes of participation
    in (other) relationships.

name
ssn
lot
Monitors
until
since
started_on
dname
pid
pbudget
did
budget
Sponsors
Departments
Projects
42
Aggregation
  • Aggregation vs. ternary relationship
  • Monitors is a distinct relationship,
  • with a descriptive attribute.
  • Also, can say that each sponsorship
  • is monitored by at
  • most one employee.

name
ssn
lot
Monitors
until
since
started_on
dname
pid
pbudget
did
budget
Sponsors
Departments
Projects
43
Aggregation another example
Suppose we want to record managers for tasks
performed by an employee at a branch
44
Example (cont.)
  • Relationship sets works-on and manages represent
    overlapping information
  • Every manages relationship corresponds to a
    works-on relationship
  • However, some works-on relationships may not
    correspond to any manages relationships
  • So we cant discard the works-on relationship
  • Eliminate this redundancy via aggregation
  • Treat relationship as an abstract entity
  • Allows relationships between relationships
  • Abstraction of relationship into new entity
  • Without introducing redundancy, the following
    diagram represents
  • An employee works on a particular job at a
    particular branch
  • An employee, branch, job combination may have an
    associated manager

45
With aggregation
46
Conceptual Design Using the ER Model
  • Design choices
  • Should a concept be modeled as an entity or an
    attribute?
  • Should a concept be modeled as an entity or a
    relationship?
  • Identifying relationships Binary or ternary?
    Aggregation?
  • Constraints in the ER Model
  • A lot of data semantics can (and should) be
    captured.
  • But some constraints cannot be captured in ER
    diagrams.

47
Entity vs. Attribute
  • Should address be an attribute of Employees or an
    entity (connected to Employees by a
    relationship)?
  • Depends upon the use we want to make of address
    information, and the semantics of the data
  • If we have several addresses per employee,
    address must be an entity (since attributes
    cannot be set-valued).
  • If the structure (city, street, etc.) is
    important, e.g., we want to retrieve employees in
    a given city, address must be modeled as an
    entity (since attribute values are atomic).

48
Entity vs. Attribute (Contd.)
to
from
  • Works_In2 does not allow an employee to
    work in a department for two or more
    periods.
  • Similar to the problem of wanting to record
    several addresses for an employee we want to
    record several values of the descriptive
    attributes for each instance of this
    relationship.

budget
Departments
Works_In2
49
Entity vs. Relationship
  • First ER diagram OK if a manager gets a separate
    discretionary budget for each dept.
  • What if a manager gets a discretionary budget
    that covers all managed depts?
  • Redundancy of dbudget, which is stored for each
    dept managed by the manager.
  • Misleading suggests dbudget is tied to managed
    dept.

since
dbudget
name
dname
ssn
did
lot
budget
Employees
Departments
Manages2
50
Binary vs. Ternary Relationships
pname
age
  • If each policy is owned by just 1 employee
  • Key constraint on Policies would mean policy can
    only cover 1 dependent!
  • What are the additional constraints in the 2nd
    diagram?

Dependents
Covers
Bad design
51
Binary vs. Ternary Relationships (Contd.)
  • Previous example illustrated a case when two
    binary relationships were better than one ternary
    relationship.
  • An example in the other direction a ternary
    relation Contracts relates entity sets Parts,
    Departments and Suppliers, and has descriptive
    attribute qty.

52
Binary vs. Ternary Relationships (Contd.)
No combination of binary relationships is an
adequate substitute S can-supply P, D needs
P, and D deals-with S does not imply that D
has agreed to buy P from S. How do we record qty?
53
Summary of Conceptual Design
  • Conceptual design follows requirements analysis,
  • Yields a high-level description of data to be
    stored
  • ER model popular for conceptual design
  • Constructs are expressive, close to the way
    people think about their applications.
  • Basic constructs entities, relationships, and
    attributes (of entities and relationships).
  • Some additional constructs weak entities, ISA
    hierarchies, and aggregation.
  • Note There are many variations on ER model.

54
Summary of ER (Contd.)
  • Several kinds of integrity constraints can be
    expressed in the ER model key constraints,
    participation constraints, and overlap/covering
    constraints for ISA hierarchies.
  • Some constraints (notably, functional
    dependencies) cannot be expressed in the ER
    model
  • salary depends on the rank of an employee
  • The number of employees who works for a project
    is never greater than 15
  • Constraints play an important role in determining
    the best database design for an enterprise.

55
Summary of ER (Contd.)
  • ER design is subjective. There are often many
    ways to model a given scenario! Analyzing
    alternatives can be tricky, especially for a
    large enterprise. Common choices include
  • Entity vs. attribute, entity vs. relationship,
    binary or n-ary relationship, whether or not to
    use ISA hierarchies, and whether or not to use
    aggregation.
  • Ensuring good database design resulting
    relational schema should be analyzed and refined
    further. FD information and normalization
    techniques are especially useful.

56
Summary of symbols
57
Summary of symbols (cont.)
58
Alternative notations in E-R
Write a Comment
User Comments (0)
About PowerShow.com
