Title: prEN 8131 Accessible Goods Only Lifts


1
prEN 81-31Accessible Goods Only Lifts
  • Presentation to
  • CEN / TC 10 / WG 1
  • L. Faletto

22/02/2005
2
prEN 81-31 Background
  • The draft of this standard has been completed
  • WG1 is asked to evaluate the work done and give
    permission to initiate the Public Inquiry Phase
  • This presentation highlights
  • the general structure of the standard
  • the overall boundaries of the product
  • The specific requirements, where different from
    those for lifts
  • The documentation to be provided together with
    the machine hardware
  • The verifications and tests to be carried out
  • Vendor information for use

3
prEN 81-31 Background
  • The Goods Only lifts Accessible for the
    operations of loading and unloading, are
    equipments for the transportation of goods, that
    fall under the Machinery Directive
  • They shall be actuated by the drives covered by
    EN 81-1 and EN 81-2 standards
  • Traction Drum
  • Hydro
  • Other drives might be added in future by
    including the requirements in a specific Annex

4
prEN 81-31 Structure
  • The structure of the draft is according to CEN
    Guide 414
  • Foreward
  • 0 Introduction
  • 0.1 General
  • 0.2 Principles
  • 0.3 Assumptions
  • 1 Scope
  • 2 Normative references
  • 3 Terms, definitions, units and symbols
  • 4 List of significant hazards
  • 5 Safety requirements and/or protective measures
  • 6 Verification of the safety requirements and/or
    protective measures
  • 6.1 Verification and tests
  • 7 Information for use
  • 7.1 Notices, markings and operating instructions
  • 7.2 Vendor information for use

5
prEN 81-31 Structure
  • Annex A (n) List of the electric safety devices
  • Annex B (n) Unlocking triangle
  • Annex C (n) Technical dossier
  • Annex D (n) Examinations and tests before
    putting into service
  • Annex E (i) Periodical examinations and tests,
    examinations and tests after an important
    modification or after an accident
  • Annex F (n) Safety components - Test procedures
    for verification of conformity
  • Annex G (n) Driving systems taken into account
  • Annex H (i) Walls and landing doors facing a LCU
    entrance
  • Annex I (n) Calculations of rams, cylinder and
    pipes
  • Annex J (i) Information to the user/owner
  • Annex K (n) Electronic components - Failure
    exclusion
  • Annex L (n) Headrooms and pits
  • Annex ZA (i) Clauses addressing other provisions

6
prEN 81-31 Assumptions
  • Negotiations have been made, between the parties
    involved and decisions have been taken at least
    particularly about
  • The intended use of the AGO lift and its limits
  • Environmental conditions, including surrounding
    lighting
  • Compliance of the civil engineering with the
    requirements of this standard for those parts of
    the installation, which belong to the building
    and are not provided by the manufacturer
  • The location of the AGO lift to be such that
    users using the AGO lift have means conveniently
    available to them, to access the different
    landing levels served, either a staircase or a
    means for the transportation of persons, within a
    reasonable distance.
  • Design of the load bearing elements includes
    provisions for taking into account possible
    overloading.

7
prEN 81-31 Assumptions
  • For horizontal forces,
  • Usual 300N and 1000N
  • Higher values to be taken into account where
    powered or hand powered means for loading and
    unloading are intended to be used
  • A mechanical device built according to good
    practice and the requirements of the standard
    will not deteriorate to a point of creating
    hazard without the possibility of detection as
    long as regular and periodical examinations,
    tests and maintenance are carried out according
    to the instruction manual delivered with the
    installation.
  • AGO lifts are used only by authorised and
    instructed users
  • key operated control buttons,
  • key card operated control or similar devices or
  • the AGO lifts in an area where only trained
    persons have access

8
prEN 81-31 Scope
  • This standard applies for new electric AGO lifts
  • with traction, positive or hydraulic drive
  • permanently installed in restricted areas
  • and/or only used by authorised and instructed
    persons,
  • serving fixed and permanent landing levels,
  • with a LCU made of a single load carrying area,
  • designed for the transportation of goods only,
  • moving along a fixed path (e.g. scissor lifts,
    lifts with guide rails, etc.)
  • and inclined not more than 15 to the vertical,
  • with rated speed not exceeding 1 m/s.

9
prEN 81-31 Scope
  • Two types of AGO lifts are addressed
  • Type A, where the intended use is bound to the
    following three simultaneous conditions
  • Maximum levels served 4
  • Maximum rated speed 0,30 m/s
  • Maximum travelling height 12 m
  • Type B, where one of the conditions mentioned
    above is not fulfilled.
  • This standard is not applicable to AGO lifts
  • with more than one machine
  • where loading and unloading is automated or the
    LCU floor is fitted with mobile devices for
    loading and unloading
  • intended to carry bulk loads (e.g. loose sand,
    gravel)
  • making use of
  • translucent material for the walls of the well
    and machinery spaces, for the LCU and for the
    landing doors
  • Programmable Electronic Systems (PESSRAL).

10
prEN 81-31 Definitions
  • - accessibility
  • for the purpose of this standard, a goods only
    lift is regarded as accessible where one of the
    following conditions is satisfied
  • Floor area of the LCU is greater than 1,0 m2
  • Depth of the LCU is greater than 1,0 m
  • Height of the LCU is greater than 1,2 m.
  • In case of a platform, it is considered
    accessible when the height of the landing doors
    is more than 1,20 m.
  • - platform
  • a LCU including the floor, and which may have
    wall(s) and entrance(s)
  • - restricted area
  • area in which only trained and/or authorized
    persons may have access

11
prEN 81-31 Specific requirements
  • Where the AGO lift is located in a restricted
    area and the well is not required to contribute
    against the spread of fire, the well enclosure
    can be perforated and
  • It shall comply with EN 294, Table 2
  • It shall not be possible to interfere with the
    operation of the lift by reaching lift equipment
    within the well.
  • The well shall be totally enclosed by imperforate
    walls, floor and ceiling in the following cases
  • Type B AGO lifts
  • Type A AGO lifts not placed in a restricted area
  • In sections of the building where the well is
    required to contribute against the spread of fire

12
prEN 81-31 Specific requirements
  • Top clearances (LCU no roof in its ultimate
    position)
  • The free vertical distance between the lowest
    parts of the ceiling of the well and
  • The highest pieces of equipment fixed on the LCU
    enclosure, except for those below, shall be at
    least 0,30 m
  • The highest part of the guide shoes, of the rope
    attachments and of the header or parts of
    vertically sliding doors and of an upward
    travelling part of the machinery assembly (ram
    head, etc.) shall be at least 0,10 m
  • The clearance above the LCU floor shall be at
    least 0,10 m more than the highest landing door,
    with a minimum of 1,80 m.

13
prEN 81-31 Specific requirements
  • Top clearances

14
prEN 81-31 Specific requirements
  • Top clearances (LCU with roof in its ultimate
    position)
  • no inspection control station on the LCU roof
  • a stop switch on the LCU roof and
  • minimum clearance 0,10 m
  • inspection control station on the LCU roof
  • requirements of EN 81-12 apply and free spaces
    shall be provided, either
  • Obtained by means of well dimensions, or
  • Achieved with the application of the requirements
    listed in Annex L.1 or L.2 as applicable (derived
    from prEN 81-21)
  • Type B AGO lifts shall comply with the
    requirements of EN 81-12 or prEN 81-21
  • For AGO lifts with positive drive and a speed
    less than 0,3 m/s the guided travel of the car
    from the top floor until it strikes the upper
    fixed stop(s) shall be at least 0,20 m.

15
prEN 81-31 Specific requirements
  • Pit clearances
  • presence of people in the pit shall be detected
    (such as a manually operated safety switch
    accessible from outside of the well pit) and
  • For maintenance purposes, mechanical means,
    electrically checked with a safety switch, shall
    be provided to limit the travel of the LCU as
    fixed stops, to assure a clearance of min 2,0 m
    height between the floor of the pit and the
    lowest part of the LCU or its supporting
    structure
  • This means can be the same as the one used to
    prevent the LCU from leaving the landing.
  • If the effort required to position the
    mechanical means exceeds 200 N or the lower
    effort applicable according to EN 1005, Part 3,
    its actuation has to be powered
  • The operation of the mechanical means shall cause
    the illumination of an indicating light under the
    LCU and visible from the pit

16
prEN 81-31 Specific requirements
  • Lighting of the well
  • At least a socket outlet shall be provided in the
    well for lighting by means of portable lamp
  • If the LCU is intended to be used as a working
    platform for maintenance and service operation,
    there shall be a lighting in the well giving a
    minimum light intensity of 50 lux at the working
    places

17
prEN 81-31 Specific requirements
  • Access to machinery
  • General
  • The clear dimensions of openings shall allow the
    possible replacement of the AGO lift components.
    This might include the dismantling of machine
    room enclosure panels.
  • The dimensions shall be at least 0,60 m x 0,60 m,
    or other openings can be adapted to suit
    replacement of components.
  • The clear height for moving shall be at least
    1,80 m
  • The clear height in the working areas shall be at
    least 2,0 m
  • Non accessible machinery spaces
  • Where maintenance is to be carried out from
    outside of the machinery spaces, the distance
    from the sill of doors or traps to any components
    requiring maintenance, adjustment or inspection
    shall not exceed 0,60 m.
  • Suitable provisions shall be taken where the
    maximum forces to be exerted during maintenance
    exceed the values given in EN 1005, Part 3.

18
prEN 81-31 Specific requirements
  • Landings
  • Height of openings
  • The clear height of the openings at landings
    shall be more than 1,20 m.
  • When the clear height is less than 1,80 m,
    loading and unloading of the LCU is intended to
    be carried out from outside of the well, e.g. by
    use of containers or pallets.
  • "LCU here" indication
  • An indication of the presence of the LCU at the
    landing shall be given by means of
  • An illuminated signal, which can only light up
    when the LCU is about to stop or has stopped at
    the particular landing. The signal shall remain
    illuminated whilst the LCU remains there, or
  • One or more transparent door vision panels and
    the LCU shall be continuously electrically
    illuminated

19
prEN 81-31 Specific requirements
  • Doors
  • Doors of AGO lifts, including their frame, shall
    be imperforate
  • Landing doors made of glass shall not be used
  • Automatic power operated doors shall not be used
  • The door locking device is regarded as a safety
    component. Annex F.1 gives a method to test the
    locking device.
  • Each landing door with a locking device shall be
    fitted with an emergency unlocking device
  • In case of type B AGO lifts with reduced headroom
    only the lowest and highest landing doors shall
    be provided with the manual unlocking device

20
prEN 81-31 Specific requirements
  • Load carrying unit
  • General
  • The LCU structure can range from a platform with
    protection means up to a fully enclosed car.
  • The rated load shall be linked to the weight of
    the goods to be transported.
  • The rated load shall not be less than 300 kg.
  • To prevent an overloading of the LCU by goods,
    the relation between the rated load and available
    area of the LCU shall not be less than 200 kg/m².
  • Where the rated load exceeds 1000 kg, an overload
    device shall be provided.
  • In addition, design calculations for the LCU
    shall take into account not only the load carried
    but also the weight of handling devices, which
    may enter the LCU

21
prEN 81-31 Specific requirements
  • LCU Enclosure
  • to prevent the risk of persons falling off the
    LCU at its sides there shall be provided a
    guarding consisting of
  • a handrail at 1,10 m height, a toe guard of 0,15
    m height and an intermediate bar or
  • a well enclosure, provided the distance between
    the outer edge of the LCU and the continuous
    surface of the well enclosure does not exceed 35
    mm.
  • a complete LCU wall
  • to prevent movable goods from falling outside of
    the LCU during travel, devices, e.g. walls,
    ceiling, retainers, barriers, roller blinds,
    doors, etc., shall be provided. They shall be
    part of the LCU and appropriate in strength and
    design to the goods to be transported.

22
prEN 81-31 Specific requirements
  • The entrances to the LCU and its interior clear
    height shall be at least 1,80 m except if loading
    and unloading do not require the LCU to be
    entered, e.g. by use of container or pallet.
  • Where the LCU is not fitted with a ceiling,
  • the minimum clear height the minimum clear
    height of the landing doors
  • the maximum clear height related to the goods
    to be transported
  • Lighting
  • The load carrying unit shall be continuously
    illuminated with a light intensity of at least 50
    lux at floor level when the landing door is open.
  • The lighting of the landing can contribute to the
    lighting of the load carrying unit if it is
    always available when the lift is used

23
prEN 81-31 Specific requirements
  • Equipment on top of the load carrying unit
  • If the load carrying unit, including its
    roof, is intended to be used as a working
    platform for maintenance and service operations,
    the following shall be provided
  • Stopping device
  • Socket outlet at the working area
  • A lighting in the well giving a minimum light
    intensity of 50 lux at the working places
  • An inspection control station box if the
    maintenance operations are intended to be carried
    out with movement of the load carrying unit.
  • This provision shall always apply to type B
    AGO lifts.

24
prEN 81-31 Specific requirements
  • Rope/chain and sheave, pulley, drum ratios to
    rope diameter
  • The ratio between the minimum breaking load, in
    Newton, of one suspension rope/chain and the
    maximum force, in Newton, in this rope/chain,
    when the load carrying unit is stationery at the
    lowest landing with its rated load, shall be at
    least 8
  • The ratio between the pitch diameter of sheaves,
    pulleys or drums and the nominal diameter of the
    suspension ropes shall be at least 30.

25
prEN 81-31 Specific requirements
  • Means to prevent uncontrolled movement of the LCU
  • from those positions where it needs to be
    accessed

26
prEN 81-31 Specific requirements
  • Means against uncontrolled movements

27
prEN 81-31 Specific requirements
  • Detecting device for uncontrolled movement from
    stopped position
  • A device which detects that a LCU is moving away
    uncontrolled from a stopped position shall be
    provided.
  • This device shall have detected the uncontrolled
    movement of the LCU when the LCU has moved away
    up to a maximum of 0,10 m in either direction
    from the stopped position.
  • After detection of the uncontrolled movement,
    this device shall operate the mechanical safety
    device either mechanically or by means of an
    electric safety circuit

28
prEN 81-31 Specific requirements
  • Mechanical safety device for stopping
    uncontrolled movement of the load carrying unit
  • A mechanical safety device shall be provided to
    stop uncontrolled movement of the load carrying
    unit.
  • It shall cause the LCU to stop within a distance
    of 0,20 m maximum
  • It shall not be tripped by devices that are
    operated electrically, hydraulically or
    pneumatically
  • The following devices are considered as complying
    with such requirements
  • Safety gears
  • Clamping devices
  • Pawl devices.

29
prEN 81-31 Specific requirements
  • Overspeed detection device
  • Tripping speed of the overspeed detection device
    for the LCU and/or the counterweight safety gear
    shall occur at least at 115 of the rated speed
    and shall not exceed
  • 150 of the rated speed, or
  • 0,80 m/s
  • whichever is the higher
  • The overspeed detection device is regarded as a
    safety component. Annex F.4 gives a method for
    testing the rope driven overspeed detection
    device.
  • Rupture valve
  • Restrictor, also one-way-restrictor
  • Protection for traction sheaves, pulleys and
    sprockets
  • Guarding of machinery

30
prEN 81-31 Specific requirements
  • General provisions concerning guiding system
  • To limit to 10 mm horizontal movements of the LCU
    in the landings during loading and unloading
  • To resist to loads and forces during intended use
    of the AGO lift and caused by the application of
    the safety devices with a minimum safety factor
    of 3 to the breaking load Rm of the material or
    with a safety factor of 2,5 against buckling.
  • Loads, stresses and deflections
  • Stresses shall be limited taking into account the
    distribution of the rated load in the LCU
    according to the intended use as negotiated
  • EN 81-1, annex G (G.2, G.3 and G.4) gives a
    method for determining the distribution of the
    load.
  • Guiding of the LCU, counterweight/balancing
    weight
  • The guiding means shall be made from drawn steel,
    or the rubbing surfaces shall be machined, if the
    speed exceeds 0,40 m/s.

31
prEN 81-31 Specific requirements
  • Fixed stops and buffers for LCU and
    counterweight, balancing weight
  • For type B AGO lifts with rated speed higher than
    0,30 m/s the fixed stop shall be a buffer.
  • Final limit switches
  • Lift machine
  • Use may be made of belts for coupling the motor
    or motors to the component on which the
    electro-mechanical brake operates. In this case a
    minimum of two belts shall be used.
  • Where electric positive and traction drives are
    not equipped with overspeed detection device and
    safety gear, at least one supplementary belt
    shall be provided

32
prEN 81-31 Specific requirements
  • Electric installations and appliances
  • Degree of protection
  • In the machinery and pulley spaces protection
    against direct contact shall be provided by means
    of casings providing a degree of protection of at
    least IP 2X.
  • Main switches
  • Electric wiring
  • Protection against electric faults controls
    priorities
  • Controls
  • Control of re-levelling with landing doors open
  • Control of inspection operation

33
prEN 81-31 Specific requirements
  • Control of normal operation
  • by the aid of buttons or similar devices, such as
    touch control, magnetic cards, etc. placed in
    boxes, such that no live parts are accessible to
    the user.
  • No control shall be possible from the inside of
    the load carrying unit.
  • A landing doors open or an opening of any landing
    doors shall respectively not permit or cancel any
    registration of calls.
  • Control devices shall be protected against
    unauthorised use. In areas such as public areas,
    shopping areas, restaurants, hotels,
    condominiums, etc., where unauthorised or non
    trained persons have free access or can access to
    the controls, they shall be fitted with key
    switches, key cards, locked access cabinet,
    removable hand held controls, etc. (see 0.2.4 and
    0.3.14).
  • Stopping devices

34
prEN 81-31 Verification and tests
  • Verification of the safety requirements and/or
    protective measures
  • Verification and tests
  • The technical dossier (see Annex C) prepared and
    kept by the manufacturer shall contain the
    necessary information to show that the
    constituent parts are correctly designed and the
    installation is in conformity with this standard.
  • Verification of design
  • Table 9 indicates the methods by which the safety
    requirements and measures described in clause 5
    shall be verified by the manufacturer for each
    new model of AGO lift, together with a reference
    to the corresponding subclauses in this standard.
  • All verification records shall be kept by the
    manufacturer.

35
prEN 81-31 Verification and tests
  • Verification tests before putting into service
  • Static and dynamic tests to ensure that the AGO
    lift has been correctly manufactured and
    assembled in order to check that all the devices
    provided are present and operating correctly.
  • These tests may be carried out at the
    manufacturer's premises or those of his
    authorised representative or at the place of use.
  • Annex D gives the details of the procedures to be
    followed for carrying out the tests.
  • A test report shall be prepared with a brief
    description and the result of the tests made and
    recorded by the manufacturer/vendor.

36
prEN 81-31 Verification and tests
  • In particular it shall be verified
  • Proper function of all limit switches
  • Proper function of all controls
  • Function of the overspeed safety device within
    specified limits, if provided
  • Function of the safety gear, if provided
  • Function of the pawl devices, if provided
  • Function of the rupture valve/one way restrictor,
    if provided
  • Triggering of overload detection device between
    1,0 and 1,2 times rated load
  • Proper value of counterweight/balancing weight
    mass to suit manufacturer's design
  • Braking distance of brake system within specified
    limits
  • Proper function of landing doors locks
  • Functional test of the alarm device
  • Dynamic test
  • With overload detection device 1,2 times rated
    load
  • Without overload detection device 1,3 times
    rated load
  • Electrical tests as specified in EN 60204-32.

37
prEN 81-31 Verification and tests
  • Periodical examinations
  • Periodical examinations and tests on AGO lifts
    shall be carried out after they are put into
    service to verify that they are in good
    condition.
  • Annex E.1 gives some guidance for carrying out
    these periodical examinations and tests.
  • Examinations and tests after important
    modifications or accidents
  • Guidance shall be given about examinations and
    tests to be carried out after important
    modifications or accidents to ascertain that AGO
    lifts continue to conform to this standard.
  • Annex E.2 gives some guidance for carrying out
    these examinations and tests.

38
prEN 81-31 Information for use
  • Notices, markings and operating instructions
  • Information for use of the machine shall be
    provided in accordance with clause 6 of EN ISO
    12100-22003 Rating plate
  • The manufacturer shall provide the following
    information on one or more durable labels fixed
    in a prominent place on the AGO lift
  • name and address of the manufacturer or his
    representative
  • type designation
  • serial number
  • year of construction
  • rated load kg
  • lifting height
  • wire rope data, where applicable
  • rated speed.

39
prEN 81-31 Information for use
  • Inside the load carrying unit it shall be
    displayed
  • The rated load of the goods only lift in
    kilograms together with a warning indicating
  • TRANSPORT OF PERSONS FORBIDDEN
  • A warning notice, clearly visible, stating
  • "IMMOBILISE THE LOAD"
  • where the the goods might move inside the LCU
    during transport
  • At landings
  • The control devices shall be clearly identified
    by reference to their function e.g. -2, -1, 0,
    1, 2, 3, etc.
  • Instructions to ensure safe usage of the goods
    only lift shall be placed near the landing
    control station, saying at least
  • The use of the AGO lift is restricted to
    authorised person only
  • After using the goods only lift, it is necessary
    to close manually operated doors and manually
    controlled power operated doors

40
prEN 81-31 Information for use
  • Safety components
  • Overspeed detection device
  • Buffer
  • Locking devices
  • Safety gear
  • Ascending LCU overspeed protection means
  • Rupture valve/One-way restrictor
  • On the safety components a data plate shall be
    fixed indicating
  • The name of the manufacturer of the component
  • The relevant adjustment (tripping speed or
    tripping flow, as applicable)
  • Data identifying the type of safety component.

41
prEN 81-31 Information for use
  • Vendor information for use
  • It shall be provided an instruction manual
    according to EN 13015
  • Contents of the instruction manual
  • General information
  • Manufacturer's name and address or that of his
    authorised representative
  • Year and country of manufacture
  • Model designation and serial number
  • General description of the AGO lift, including
  • The intended use and its limits,
  • Restrictions to use,
  • The intended specific health/safety requirements
    as consequence of the negotiations
  • Information about use in special environments,
    e.g. potentially explosive atmosphere.

42
prEN 81-31 Information for use
  • Capacity and design information
  • Rated load
  • Rated speed
  • Environmental restrictions as temperature range
  • Sound pressure level (dB(A))
  • Dimensions and weights
  • Power supply data
  • Safety devices
  • Type of safety devices, e.g. overspeed detection
    device, safety gear, pawl devices, final limit
    switches, landing door locks, etc.)
  • Additional safety equipment for erection,
    dismantling and maintenance.
  • Instructions for erection and dismantling
  • Instructions for tests before putting into
    service
  • Instructions for operating and usage
  • Breakdown procedures

43
prEN 81-31 Information for use
  • Regular inspection and maintenance
  • the items to be checked and their suitability for
    use
  • which parts of the lift can be replaced, which
    are subject to wear, their identification means
    and the criteria for replacement,
  • Minimum documents that need to be provided
  • Drawings and documents necessary to install the
    AGO lift
  • Drawings and diagrams necessary for putting into
    service
  • Drawings and diagrams necessary for maintenance,
    inspection, checking of correct operation,
    repair.
  • Logbook
  • The logbook of an AGO lift shall be drawn up at
    the latest at the time the installation is put
    into service.

44
prEN 81-31 Annexes
  • Annex A (normative)List of the electric safety
    devices
  • Annex B (normative)Unlocking triangle
  • Annex C (normative)Technical dossier
  • Annex D (normative)Examinations and tests before
    putting into service
  • Annex E (informative)Periodical examinations and
    tests, examinations and tests after an important
    modification or after an accident
  • Annex F (Normative)Safety components - Test
    procedures for verification of conformity

45
prEN 81-31 Annexes
  • Annex G (normative)Driving systems taken into
    account in this standard
  • G.1 Traction and positive drive
  • G.2 Hydraulic drive
  • Annex H (informative)Construction of walls of
    AGO lift well and landing doors facing a LCU
    entrance
  • Annex I (normative)Calculations of rams,
    cylinder and pipes
  • Annex J (informative)Information to the
    user/owner of an AGO lift
  • J.1 Means of access to machinery space entrance
    of the AGO lift
  • J.2 Maintenance work carried out from a step of
    a ladder
  • J.3 Lighting and socket outlets
  • J.4 Local lighting of openings at landings

46
prEN 81-31 Annexes
  • Annex K (normative)Electronic components -
    Failure exclusion
  • Annex L (normative)Headrooms and pits
  • (To be revised according to the latest
    requirements of prEN 81-21)
  • L.1 Top clearances for traction drive AGO lifts
  • L.2 Top clearances for electric lifts with
    Positive Drive and Hydraulic lifts
  • L.3 Clearances in the pit for electric and
    hydraulic lifts
  • Annex ZA (informative)Clauses of this European
    Standard addressing essentialrequirements or
    other provisions of EU Directives
  • Bibliography (to be completed)

47
prEN 81-31 Annexes
  • Annex H (informative)
  • Construction of walls of AGO lift well and
    landing doors facing a LCU entrance

48
prEN 81-31 Q A
  • Are there
  • any
  • Questions?

49
prEN 81-31
  • Thank you for your kind attention
Write a Comment
User Comments (0)
About PowerShow.com
