Formability in Deep Drawing Steel

1
Formability in Deep Drawing Steel

• Christopher Melvin
• Washington State University
• 2008

2
Steel Coil
3
Some Applications Include

• Automotive
• Motor casings
• Building supplies
• Household items

4
Deep Drawing

• Drawability- high degree of plastic flow in
  plane, resistance to flow in thickness
• r-value ew/ et (e-true strains)
• r e22/ e33
• q -e22/e11 ew/el
• Where e11 e22 e33 are the normal strains in the
  x, y, and z directions respectively

5
Cup Drawing Die
6
Cup Drawing Sequence
7
Variations of R-Value

• raveFormability parameter
• (normal anisotropy)
• rave rm (r02r45r90)/4
• ?rEaring parameter (planar anisotropy)
• ?r (r0r90-2r45)/2

8
Methods to Determine R-Value
Tensile Test rm 1.656 (cntr) ?r 0.9188
VHM Method rm 1.690 (cntr) ?r 0.92365
Company Methods (Module-R) rm 1.662 (ave) ?r
0.703
9
Textures

• Most important cause of anisotropic plastic
  properties
• Rolling steel creates a preferred orientation
  (Texture)
• R-value changes with different textures

10
Euler Space-ODF
Gamma
Goss
Phi 45º
11
ODF-Texture Plot
12
Coil Edge (across width)
13
Coil Center (across width)
14
Edge vs. Center
Edge
Center
15
Head vs. Tail (Phi 45)
Head (center)
Tail (center)
16
Experimental Cup Profile
17
VanHoutte Model
18
Cup vs. R-Value Profiles
19
Methods to Determine R-Value
Tensile Test rm 1.656 (cntr) ?r 0.9188
VHM Method rm 1.690 (cntr) ?r 0.92365
Company Methods (Module-R) rm 1.662 (ave) ?r
0.703
20
Hot Band Microstructure Gradient
21
Center vs. Edge Microstructures
Center
Edge
22
Conclusion

• Designed cup die to measure earing
• Compared direct measurements to model
• Edge properties differ from center
• Gradient in hot band carries over to cold rolled
• Indications of Goss

23
Thanks

• Dr. David Field
• Alankar Alankar
• Dr. Leo Kestens
• Dr. Paul VanHoutte

24
Future research

• Obtain model to calculate r-value
• Increase accuracy of where the coupons were
  obtained
• Obtain new samples to test after proposed process
  changes are made
