Nibin Varghese

1
Reverse Engineering for Exploit Writers

• Nibin Varghese
• iViZ Security, Kolkata

2
Agenda

• Exploitation Overview
• Reverse Engineering Tools
• Case Study MS08-067

3
Exploitation Overview

• Software vulnerabilities exist
• Reliable exploitation techniques exist
• Stack overflow
• Heap overflow
• Exploit mitigation
• Prevent or impede a class of vulnerabilities
• Patch the vulnerability
• Disable the service
• Generic mitigations

4
Reverse Engineering Tools

• IDA Pro
• Bindiff Plugin for IDA
• Ollydbg or Immunity Debugger or Windbg
• Debugging Symbols
• Sysinternals tool suite
• Any scripting language to write PoC (Python, Ruby
  etc)

5
MS08-067

• Windows Server Service Vulnerability
• Out of band release
• Details
• Error in netapi32.dll when processing directory
  traversal character sequence in path names. This
  can be exploited to corrupt stack memory by
  example sending RPC requests containing specially
  crafted path names to the Server service
  component secunia.com

6
(No Transcript)
7
Structure of X86 stack frame
Stack grows towards lower addresses
8
Classical Overflow
Return address overwritten with address of
shellcode
9
Reverse engineering the patch

• Demo

10
The Bug

• Decompiled by Alexander Sotirov
• Visual demo of the bug

11
The Bug(contd..)
ptr_current_slash
ptr_previous_slash
\\computername\\..\\..\\AAAAAAAAAAAAAAAAAAAAAAAAA
\\..\\AAAAAAAAAAAAAAAAAAAAAAAAA
Lower Address
Higher Address

• ptr_path points to the beginning of the buffer
• Parses to find current slash and previous
  slash\\
• Finds .., so the current slash pointer moves
  forward
• Data from Current slash pointer is copied to
  ptr_path
• If the pointer is at the beginning of the buffer,
  a pointer moves backward to find previous
  slash\\.
• 5a. Results in access violation if no \\
  are found
• 5b. Copies to the new destination if \\ is
  found

ptr_path
12
Netapi32!NetpwPathCanonicalize
vulnerable_function( wchar path )
wcscpy(dst,src)
AAAA
Saved EBP
AAAA
Return Address of wcscpy
AAAA

• ptr_path points to the beginning of the buffer
• Parses to find current slash and previous
  slash\\
• Finds .., so the current slash pointer moves
  forward
• Data from Current slash pointer is copied to
  ptr_path
• If the pointer is at the beginning of the buffer,
  a pointer moves backward to find previous
  slash\\.
• 5a. Results in access violation if no \\
  are found
• 5b. Copies to the new destination if \\ is
  found

(ptr1 1)
ptr2
\\..\\AAAAAA
ptr1
ptr_path
Saved EBP
Shell Code
Return Address of vulnerable_function
\\..\\AAAAAAAAAAA
\\c\\..\\.. \\AAAAAAAAAAA
path
13
The Bug (contd..)

• Not a classical buffer overflow
• The destination buffer is large enough to copy
  the contents from source
• The hunt for \\ if the pointer points to the
  beginning of the buffer makes it a BUG

14
Ready for PoC

• Identify the vector of exploitation
• 3 possible ways
• wcslen of path
• Predictable location of \\ in the stack after
  repeated interaction
• Metasploit way of calculating the device_length

15
Mass Exploitation

• If no NX, return to stack and execute shellcode
• If NX enabled, disable DEP/NX by abusing Win32
  API NtSetInformationProcess and return to stack
  and execute shellcode.
• Refer Skape and Skywing paper on Uninformed
  Journal Bypassing Windows Hardware-enforced Data
  Execution Prevention
• In Vista, ASLR makes return addresses
  unpredictable.

16
Thank You

• Thanks to Research Team_at_iViZ Security
• Thanks to Clubhack 08 organizers
• Thanks to all the attendees

17

• Ready for Phase 2 ?
