Title: Mount St Helens by Alice Graham


1
Mount St Helensby Alice Graham
2
Location of the volcano and background history
  • A volcanic peak, 2,549 m (8,363 ft) high
  • The mountain is 6 miles (9.5 km) across at its
    base
  • Location South West Washington, USA
  • The mountain is part of the Cascade volcanoes and
    the Cascade Range
  • Type Composite
  • Mount St. Helens is a part of the Pacific Ring of
    Fire that includes over 160 active volcanoes.
  • It only formed within the last 40,000 years, and
    the pre-1980 summit cone began rising around
    2,200 years ago.

3
What were the main causes of the volcano erupting
The Mt St Helens volcano results from subduction
zone created between the Juan de Fuca plate and
the North American plate. The oceanic Juan de
Fuca plate is denser so subducts below the North
American plate.
4
What were the main events and times of the
eruptions
  • March 20 1980 Earthquake measuring 4.2 magnitude
  • March 27 Steaming vent
  • April A bulge on the north side of Mountain
  • May18 A second earthquake- Massive collapse of
    North face of Mountain (Little warning).
  • The magma burst out causing large pyroclastic
    flow flattening vegetation and buildings for over
    230 square miles ( 600 km²).
  • Plinian eruption.
  • Volcanic Mudflows- Due to collapse of northern
    side mixed with ice, snow and water. These flowed
    many miles down the Toutle and Cowlitz Rivers.
  • 3million m³ of material transported 7 miles (27
    km) south into Columbia river by mudflows
  • For 9 hours ash erupted
  • By 539 became less severe outbursts continued
    through the night.

5
What were the main short term impacts of the
eruption?
  • The eruption killed 57 people
  • Nearly 7,000 big game animals (deer, elk and
    bear)
  • An estimated 12 million fish from a hatchery.
  • Many tens of thousands of acres of prime forest
    destroyed
  • It destroyed or extensively damaged over 200
    homes
  • Destroyed/ damaged 185 miles (300 km) of road
  • Destroyed/ damaged 15 miles of railways.
  • Airports closed (from 2days ? 2 weeks). Over a
    thousand commercial flights were cancelled
    following airport closures.
  • Unemployment rose rapidly after eruption. However
    returned to normal when the timber salvaging and
    ash-cleanup began.

6
What were the main long term impacts of the
eruptions?
  • Economic Trees amounting to more than 4 billion
    board feet of salable timber were damaged or
    destroyed, primarily by the lateral blast
  • Economic Many agricultural crops, such as wheat,
    apples, potatoes, and alfalfa, were destroyed
  • Economic Ash removal cost 2.2 million and took
    10 weeks in Yakima
  • Economic 1.1 billion cost overall
  • Social Several months after May 18, a few
    residents reported suffering stress and emotional
    problems, even though they had coped successfully
    during the crisis. The counties in the region
    requested funding for mental health programs to
    assist such people.
  • Social Homelessness- More than 200 houses and
    cabins were destroyed and many more were damaged
    in Skamania and Cowlitz Counties.

7
In what way was the volcano being monitored was
the eruption predicted
  • The volcano was being monitored to detect early
    signs of an impending eruption.
  • No one knew what types of monitoring techniques
    would prove most reliable because knowledge about
    the behaviour of Cascade volcanoes in general was
    limited and because Mount St. Helens had not been
    active recently.
  • University and USGS studies in the 1970's had
    monitored the volcano intermittently using three
    approaches
  • 1. seismometers that could detect earthquakes
    caused by the movement of molten rock
  • 2. precise ground-surface measurements that could
    detect swelling of the volcano
  • 3. aerial infrared surveys and surface
    temperature measurements of the two "hot spots"
    high on the mountain to detect any changes in
    heat emission.
  • The volcano was also photographed routinely from
    the air to detect changes in snow and ice as part
    of a USGS glaciology research project.
  • At the beginning of March 1980 the only
    instrument directly monitoring Mount St. Helens
    was a seismometer on the western flank of the
    volcano. This station (SHW) automatically
    transmitted earthquake data by radio
    (telemetered) to seismic recorders at the
    University of Washington in Seattle.

8
How did people respond to the eruption?
  • The first response to the May 18, 1980 eruption
    of Mount St. Helens was to make sure that people
    and communities were safe.
  • People then needed to restore the area
  • Debris such as saleable logs were retrieved so as
    to try to restore the economy of the area

9
Has there been any activity since the main
volcanic eruption
  • Five smaller explosive episodes occurred during
    the summer and fall of 1980.
  • Beginning with the October 1980 eruption, 17
    eruptive episodes built a new lava dome that
    reached 876 feet above the crater floor
  • During a 12-month-long episode beginning in 1983
    magma moved into the dome's molten interior,
    pushing its east side outward by at least 250
    feet.
  • Since late 1986 several periods of increased
    seismicity have occurred.
  • Between 1989 and 1991 there were about 30 bursts
    of brief but intense seismic activity lasting
    minutes to hours some also had small explosions
    from the dome
  • The explosions formed a new vent on the north
    side of the dome and produced small eruption
    columns that rose a few miles above the volcano.
  • A few explosions also hurled hot rocks three feet
    in diameter at least 1/2 mile northward from the
    dome, generated small pyroclastic flows in the
    crater, and formed small lahars.
  • During 1995 and 1998 seismicity increased for
    several months, but there were no accompanying
    explosions.
