Title: NEXIS


1
(No Transcript)
2
NEXIS
  • NEXIS
  • The Generation of Hinges from Grass

3
Grass NEXIS Design Studies.
In future, Grass will be attaching an
increasing level of importance to professional
industrial design. In the case of NEXIS,
collaboration with a professional industrial
designer, Stefan Ambrozus, was intensified and
this collaboration will be extended in further
projects.
4
Grass NEXIS Design Concept.
The unique design of NEXIS unites form and
function in one.
5
Grass NEXIS Logo Position.
The harmonised logo position rounds off the
perfect design.
6
NEXIS The New Generation of Hinges from Grass.
NEXIS The Family
NEXIS
NEXIS Baseplates
NEXIS IMPRESSO
NEXIS SILEO
  • Straight and wing baseplates
  • Comprehensive range
  • Ecc. screw adjustment - depth
  • Ecc. screw adjustment - height
  • Simple adjustment
  • Screw-on press-in cup
  • Comprehensive range
  • Unique design
  • Grass drilling pattern
  • Snap-on technology
  • Tool-free cup fastening
  • Fast and reliable installation
  • Combined Grass Blum drilling pattern
  • Perfect seating in doors
  • Snap-on technology
  • Optional cushioning system
  • For complete range
  • Optional tool-free
  • Can be retrofitted
  • Adjustable cushioning

7
NEXIS The New Generation of Hinges from Grass.
NEXIS The Family
NEXIS
NEXIS Baseplates
NEXIS IMPRESSO
NEXIS SILEO
  • Straight and wing baseplates
  • Comprehensive range
  • Ecc. screw adjustment - depth
  • Ecc. screw adjustment - height
  • Simple adjustment
  • Screw-on press-in cup
  • Comprehensive range
  • Unique design
  • Grass drilling pattern
  • Snap-on technology
  • Tool-free cup fastening
  • Fast and reliable installation
  • Combined Grass Blum drilling pattern
  • Perfect seating in doors
  • Snap-on technology
  • Optional cushioning system
  • For complete range
  • Optional tool-free
  • Can be retrofitted
  • Adjustable cushioning

8
NEXIS1 Screw-on and Press-in Cup.
  • NEXIS Comprehensive range
  • The NEXIS series offers you added value through a
    large number of individual applications found in
    the kitchen, bathroom and living room furniture
    industries. The door-side installation of NEXIS
    hinges is both screw-on and press-in. The NEXIS
    series is designed for tool-free fitting onto
    snap-on baseplates.

Grass drilling pattern There is one Grass
drilling pattern for the entire NEXIS series.
NEXIS Design moves. The unique design of NEXIS
unites form and function in one.
1 NEXIS (from Nexus link snap on)
9
NEXIS.
  • USP/Features
  • Comprehensive range
  • Unique cup design
  • Hinge cup rim cover
  • Cup depth 11 mm, except of special hinges 11,8
    mm
  • Cup fastening with 8 mm dowels and for screwing
    on
  • Latest snap-on technology for all NEXIS hinges
  • Grass drilling pattern

NEXIS Design bewegt
10
Snap-on Technology Fast and Simple.
NEXIS IMPRESSO positionieren,
press in and
press down cup cover.
Position hinge arm and
snap hinge arm into place!
NEXIS fast and simple!
  • Latest snap-on technology zero-play connection
    between hinge and baseplate
  • Tool-free installation and removal of door
  • Snap-on sound means a reliable, firm connection
    between hinge and baseplate
  • Simply snap on and off, even if the hinge is
    maladjusted
  • Door installation and removal according to the
    zipper principle

11
Compatible with Touch Latch Senso for Doors.
NEXIS hinges without closing springs with Touch
Latch Senso for doors.
12
NEXIS Range Overview I.
Hinge
Opening angle
Application
Standard door
100
Standard door
Standard door
100
Thick door
13
NEXIS Range Overview II.
Hinge
Opening angle
Application
Corner cabinet 30
Corner cabinet 45
100
Corner cabinet -45
Blind corner
14
NEXIS Range Overview III.
Hinge
Opening angle
Application
PCC-hinge
Aluminium frame door
100
Glass door
15
NEXIS NEXIS IMPRESSO 170 Hinge.
  • USP/Features
  • 0-protrusion with opening angle 90
  • For cabinets with interior pull-outs
  • Time saving as no spacers are required when
    installing interior pull-outs,
  • Finger protection not possible to nip your
    fingers
  • Mitred applications are possible with opening
    angle restricted to 120

Mitred cut on the left and right-hand sides of
the cabinet, not top and bottom.
0-protrusion with baseplate height H00 with
opening angle of 90
16
170 Hinge Opening Angle Restriction to 120.
120
  • Opening angle restrictor for 170wide-angle
    hinges
  • With the opening angle restrictor, the opening
    angle is limited to 120. This can be used for
    the 170wide-angle hinges of NEXIS and NEXIS
    IMPRESSO.

Installation of opening angle restrictor The
opening angle restrictor clip made of black
plastic is fitted quickly and simply to the
wide-angle hinge with no tools required.
17
Competitor Comparison - 170Hinge.





18
NEXIS Aluminium Frame Door.
  • Features
  • Hinge for slender aluminium frame doors
  • Opening angle 95
  • 3-dimensional adjustment with appropriate
    baseplate
  • Optional cushioning

All dimensions in mm.
19
NEXIS Glass Door.
  • Features
  • Hinge for glass doors, 26mm cup (as with
    competitor products)
  • Opening angle 95
  • For 4-6 mm glass thickness
  • 3-dimensional adjustment with appropriate
    baseplate

Decorative cap finishes in nickel, brass, black
und matt stainless steel
Fastening with screwsØ2.9 x 10.5 mm
All dimensions in mm.
20
NEXIS The New Generation of Hinges from Grass.
NEXIS The Family
NEXIS
NEXIS Baseplates
NEXIS IMPRESSO
NEXIS SILEO
  • Straight and wing baseplates
  • Comprehensive range
  • Ecc. screw adjustment - depth
  • Ecc. screw adjustment - height
  • Simple adjustment
  • Screw-on press-in cup
  • Comprehensive range
  • Unique design
  • Grass drilling pattern
  • Snap-on technology
  • Tool-free cup fastening
  • Fast and reliable installation
  • Combined Grass Blum drilling pattern
  • Perfect seating in doors
  • Snap-on technology
  • Optional cushioning system
  • For complete range
  • Optional tool-free
  • Can be retrofitted
  • Adjustable cushioning

21
NEXIS IMPRESSO1 Tool-free Installation
Removal.
  • NEXIS IMPRESSO Fast and reliable tool-free
    installation
  • The NEXIS IMPRESSO series is rapidly installed
    and removed thanks to tool-free cup fastening in
    the door front. In the case of flat-pack
    furniture, the hinges can be included loose with
    the predrilled doors. The hinges are then quickly
    and securely installed on site.

Combined Grass and Blum drilling pattern The
complete NEXIS IMPRESSO series features a
combined Grass and Blum drilling pattern. One
NEXIS IMPRESSO hinge housing fits two drilling
patterns Grass drilling pattern and Blum
drilling pattern.
NEXIS IMPRESSO Perfect seating in doors Thanks
to the frictional and positive fit of the hinge
housing, NEXIS IMPRESSO is firmly and reliably
seated in door materials such as e.g. chipboard.
The unique design of NEXIS IMPRESSO unites form
and function in one.
1 NEXIS IMPRESSO (Impressio from the Latin
meaning press, while presso also implies
speed)
22
NEXIS IMPRESSO.
  • USP/Features
  • Steel band of spikes
  • Hinge housing in zinc diecasting
  • Perfect seating in door materials such as
    chipboard, MDF and solid wood
  • Positive fit at critical points thanks to
    horizontal tensioning
  • Hinge cup rim cover
  • Cup depth 11,5 mm, except of special hinges 12
    mm
  • Latest snap-on technology for all NEXIS IMPRESSO
    hinges
  • Combined Grass and Blum drilling pattern in one
    hinge

Steel band of spikes frictional and positive
seating in doors
23
Tool-free Installation Fast and Simple.
Position NEXIS IMPRESSO,
press in and
press down cup cover.
Position hinge arm and
snap hinge arm into place!
NEXIS IMPRESSO fast and simple!
24
Competitor Comparison - Tool-free Cup Fastening.
25
NEXIS IMPRESSO Range Overview I.
Hinge
Opening angle
Application
Standard door
100
Standard door
100
Thick door
26
NEXIS IMPRESSO Range Overview II.
Hinge
Opening angle
Application
Corner cabinet 30
Corner cabinet 45
100
Blind corner
27
NEXIS The New Generation of Hinges from Grass.
NEXIS The Family
NEXIS
NEXIS Baseplates
NEXIS IMPRESSO
NEXIS SILEO
  • Straight and wing baseplates
  • Comprehensive range
  • Ecc. screw adjustment - depth
  • Ecc. screw adjustment - height
  • Simple adjustment
  • Screw-on press-in cup
  • Comprehensive range
  • Unique design
  • Grass drilling pattern
  • Snap-on technology
  • Tool-free cup fastening
  • Fast and reliable installation
  • Combined Grass Blum drilling pattern
  • Perfect seating in doors
  • Snap-on technology
  • Optional cushioning system
  • For complete range
  • Optional tool-free
  • Can be retrofitted
  • Adjustable cushioning

28
NEXIS Baseplates Range Overview I.
Baseplates
Fastening
Features
? Screw-on? 10mm dowels
1-D eccentric plate
? Simple adjustment of door ? Parallel height
adjustment ? Height adjustment 2mm by means
of eccentric screw
1-part steel baseplate


(32/37)
? Prefitted Euro screws? Screw-on
? Height adjustment 2mm by means of slot
29
NEXIS Baseplates Range Overview II.
Baseplates
Fastening
Features
2-part wing baseplate


(32/37)
? Simple adjustment of door ? Height adjustment
2mm ? 3-point fastening
? Prefitted Euro screws? Screw-on
2-D wing baseplate


(32/37)
? Prefitted Euro screws? 10mm dowels
? Height adjustment 2mm by means of eccentric
screw ? Parallel height adjustment (no damage
to surface) ? Depth adjustment 1.5mm by
means of eccentric screw ? Simple adjustment of
door
30
NEXIS Baseplates Range Overview III.
Baseplates
Fastening
Features
? Screw-on
Baseplate for face frame construction
? Height adjustment 2mm by means of slot ?
Can be used as special plate
Spacer plate



? Screw-on? Also for Euro screws
? Can be used for 2-part wing baseplate ?
Height 3mm ? Stackable, plastic
31
NEXIS 3-Dimensional Adjustment of Door.
  • Adjustment ranges
  • All adjustments can be performed independently of
    one another.
  • The height adjustment is dependent on the
    baseplate used.

3
Height adjustable 2mm by means ofeccentric
screw
2
3
Depth adjustable 2mm by means of eccentric
screw
Height adjustable 2mm by means of slot
1
3
Side adjustment 1/-3 mm
2
Depth adjustment 3/-1 mm
3
Height adjustment 2 mm
1
2
Height adjustable 2mm by means of eccentric
screw
32
NEXIS The New Generation of Hinges from Grass.
NEXIS The Family
NEXIS
NEXIS Baseplates
NEXIS IMPRESSO
NEXIS SILEO
  • Straight and wing baseplates
  • Comprehensive range
  • Ecc. screw adjustment - depth
  • Ecc. screw adjustment - height
  • Simple adjustment
  • Screw-on press-in cup
  • Comprehensive range
  • Unique design
  • Grass drilling pattern
  • Snap-on technology
  • Tool-free cup fastening
  • Fast and reliable installation
  • Combined Grass Blum drilling pattern
  • Perfect seating in doors
  • Snap-on technology
  • Optional cushioning system
  • For complete range
  • Optional tool-free
  • Can be retrofitted
  • Adjustable cushioning

33
NEXIS SILEO1 Design Moves.
  • NEXIS SILEO Gentle and soundless door closure
  • because closing doors fitted with Grass NEXIS
    SILEO is something special. The excellent hinge
    cushioning system from Grass unites form and
    function in one.

NEXIS SILEO from Grass Perfectly cushioned
design NEXIS SILEO of Grass unifies unique design
and perfect cushioning of doors.
NEXIS SILEO Aesthetic design plus perfect
functionality The movement of the door is gently
braked and the door closes softly and quietly
the design harmonises with the perfect
functionality.
1 NEXIS SILEO (Sileo from the Latin meaning to
be silent)
34
NEXIS SILEO Design Moves.
NEXIS SILEO The Family
Cushioning for NEXIS
Cushioning for the 170hinge
Cushioning for NEXIS IMPRESSO
Cushioning for alum. frame hinge
  • Solution for wide-angle hinge
  • Works for wide-angle hinge
  • Completely tool-free
  • Optional
  • Elegant design
  • Solution for standard cup
  • Works for all crank types
  • Completely tool-free
  • Optional
  • Elegant design
  • Solution for RTA cup
  • Works for all crank types
  • Completely tool-free
  • Optional
  • Elegant design
  • Solution for alum. frame hinge
  • Works for frame 20x20mm
  • Simple installation
  • Not visible from the outside
  • Elegant design

35
Application NEXIS SILEO with Standard Cup.
  • The application
  • Cushioning for all crank types
  • Completely tool-free
  • Cushioning optional
  • Can be retrofitted
  • No additional drilling in the cabinet or door
  • Individual, tool-free adjustment to suit
    different opening anglesand crank types by
    turning the adjusting screw

The shock absorber adapter is fitted at the
recesses with no tools required.
36
Tool-free Installation with Standard Cup.
Remove door from cabinet and place on solid
surface.
Position the two small hooks on the underside of
the adapter in the recesses and
insert the adapter at a slight angle into the
hinge housing .
Press down both sides of the adapter
simultaneously
until you hear it snap into place.
NEXIS SILEO fast and simple!
37
Number and Position for NEXIS SILEO.
  • Door dimensions
  • 900 x 600 mm (4-5 kg) 1 shock absorber
  • 1600 x 600 mm (6-9 kg) 2 shock absorbers
  • 2200 x 600 mm (13-17 kg) 2 shock absorbers
  • 2500 x 600 mm (18-22 kg) 2 shock absorbers

Position of Nexis Sileo
Position for additional Nexis Sileo (if necessary)
38
Application NEXIS SILEO with RTA Cup.
  • The application
  • Cushioning for all crank types
  • Completely tool-free
  • Cushioning optional
  • Can be retrofitted
  • No additional drilling in the cabinet or door
  • Individual, tool-free adjustment to suit
    different opening angles and crank types by
    turning the adjusting screw

Location holes on the hinge housing for NEXIS
SILEO adapter
39
Tool-free Installation with RTA Cup.
Remove door from cabinet and open hinge housing.
Set adapter in both location holes on the housing
without wedging and press down.
The adapter must lie flat against the door. Press
the housing cover down as far as it will go.
Insert shock absorber into adapter with the flat
side down.
Attach door and, if necessary, adjust the
cushioning by means of the adjusting screw.
NEXIS SILEO fast and simple!
40
Number and Position for NEXIS SILEO.
  • Door dimensions
  • 900 x 600 mm (4-5 kg) 1 shock absorber
  • 1600 x 600 mm (6-9 kg) 2 shock absorbers
  • 2200 x 600 mm (13-17 kg) 2 shock absorbers
  • 2500 x 600 mm (18-22 kg) 2 shock absorbers

Position of Nexis Sileo
Position for additional Nexis Sileo (if necessary)
41
NEXIS SILEO Technology.
  • Specially developed hydraulic shock absorber
  • Millionfold tried
  • High impact resistance
  • Dynamic cushioning characteristics
  • Special, non-toxic oil
  • Closing behaviour not affected by variations in
    temperature

42
NEXIS SILEO Design Moves.
  • USP
  • Tool-free installation
  • Optional can be retrofitted
  • Adaptive cushioning system
  • No additional drilling in cabinet or door
  • Time saving in handling fast and simple to
    install
  • No installation errors
  • The side, depth and height adjustment can still
    be performed with the shock absorber mounted
  • 4 items in stock to equip all crank and hinge
    types with NEXIS SILEO

43
Proof of Quality NEXIS SILEO.
  • The requirements
  • 100,000 cycles with 2x20 N additional load
  • Door size 700x600 mm
  • Crash test performed 100 times before and after
    end of test
  • After the end of the test, the hinge and the
    shock absorber should still operate perfectly
  • User friendliness

44
Competitor Comparison - NEXIS SILEO.





45
Application NEXIS SILEO with 170-Wide-Angle
Hinge.
  • The application
  • Completely tool-free
  • Cushioning optional
  • Can be retrofitted
  • No additional drilling in the cabinet or door
  • Works for all crank types

46
Tool-free Installation with 170-Wide-Angle
Hinges.
Insert the two small hooks on the adapter at the
front on the wide-angle hinge.
Press adapter down until the rear hook on the
adapter snaps into place.
NEXIS SILEO fast and simple!
47
Application NEXIS SILEO with Aluminium Frame
Doors.
  • The application
  • For aluminium frames 20x20 mm
  • Cushioning can be individually adjustedby means
    of eccentric screw
  • Simple installation
  • Not visible from the outside
  • Elegant design

48
Installation of NEXIS SILEO for Aluminium Frame
Doors.
49
Number Position for NEXIS SILEO for Aluminium
Frames.
  • Door dimensions
  • 900 x 500 mm (4-6 kg) 1 shock absorber
  • 1600 x 500 mm (7-12 kg) 2 shock absorbers
  • 2200 x 500 mm (13-17 kg) 2 shock absorbers
  • 2450 x 500 mm (18-22 kg) 2 shock absorbers

Position of Nexis Sileo
50
Competitor Comparison - NEXIS SILEO.







Salice has no solution for aluminium frame doors
except with Smove.
51
NEXIS Installation Technology
  • Insertion dies
  • for hinges
  • for baseplates
  • compatible with existing machines

52
NEXIS Market Launch/Phase-out of G300 Series.
  • Timetable
  • Inventory ramp-up NEXIS Sept. 2007
  • Sales start NEXIS Oct. 2007
  • Last order G300 series 31 March 2008
  • Latest shipment G300 series 30 June 2008

53
Important Principles for Implementation.
  • Within Grass
  • Existing G300 customers should change over to
    Nexis.
  • It is also the goal to win new customers with
    Nexis.
  • Existing SO 3000 / TL 4000 customers should be
    retained as long as possible.
  • For the replacement of G300 by Nexis, precise
    phase-out management is absolutely essential.
    Grass Höchst is not in a position to accept
    returned goods.
  • Competitive prices

54
Important Principles for Implementation.
  • Two hinge lines one goal
  • With Snap On 3000 and Nexis, Grass will be
    supplying two hinge systems which each have their
    benefits. It will be important to ensure that
    both hinge systems are sold in the short to
    medium term so that we have a perfectly smooth
    changeover to the successor hinge line.
  • Snap On 3000
  • Greatest amount of material - highest strength
  • Integrated shock absorber possible
  • Good possibilities for combination with Airmatic
    Pin
  • NEXIS
  • Unique design
  • Cushioning system snaps on without the need for
    tools
  • With eccentric high and depth adjustment
  • Good price / performance ratio
Write a Comment
User Comments (0)
About PowerShow.com
