CAST Overview

1
CAST Overview

• Fall 2003

2
Who is CAST?

• An experienced IP provider/partner
• Founded 1993, shipping cores since 1996
• Smart business model
• Employee-owned, bootstrapped, lean operations
• Focus on customer success
• Leveraging skills and economies of international
  partners
• Financially successful
• Revenue grew 28 in 2002
• Expanding resources and customer base
• With a successfully-focused product line

3
General purpose IP cores gpIP

• Broad range of 80 popular andstandards-basedfun
  ctions

• Designed for easy integration and reuse
• Soft cores synthesizable HDLs for ASICs
• Firm cores optimized netlists for FPGAs

4
gpIP cores
8051-Compatible Microprocessors C8051 legacy
microcontroller D80530 fast, Dallas
architecture R8051 high-speed, RISC-like,
Intel peripherals R80515 high-speed,
RISC-like, Infineon peripherals FS2 on-chip
Debugging Option for 8051s Other Processors
and Controllers 8-bit controllers PIC -
C165X, C1655X RISC CZ80CPU, CZ80PSC intelligent
peripheral controller C6805, C6811 16-bit
processors - C68000, C80186TX, C80187 DSPs
(Digital Signal Processors) 16-bit C32025,
C32025TX 24-bit C56000 Bit-slice
processors 4-bit C2901 16-bit C29101,
C29116A, C49402, C5901 Encryption Functions
AES encrypt/decrypt, encrypt only DES and
Triple DES encrypt/decrypt MD5 message
digest algorithm SHA-1 secure hash algorithm
MODEXP1 Mod. Exp. Acc. for RSA
Multimedia Functions JPEG high-performance
encoder, decoder, codec JPEG 2000 encoder,
decoder MoPro motion estimation/compensation
processor MPEG-4 encoder DCT (Discrete
Cosine Transform) forward, inverse,
forward/inverse DWT (Discrete Wavelet
Transform) forward/inverse, line-based
forward. block-based forward CSC color space
converter Huffman encoder and decoder Bus and
Network Interfaces CAN bus controller
Ethernet MAC 10/100, 10/100 Lite,
10/100/1000 EPP Extended Parallel Port slave
I2C serial bus interface master/slave,
slave, high-speed PCI 32-bit, 33 MHz target,
master/target, multifunction 64-bit, 66 MHz
target, master/target 32-bit, 33/66 MHz host
bridge SPI Serial Protocol Interface
master/slave, slave LIN Bus Controller
USB device controller version 1.1, version 2.0
Microprocessor Peripherals Microprogram
controllers C2910A, C3910, C49410 DMA
controllers C8237, C82380 32-bit, DMA32A
32-bit with AMBA interface C6845 CRT
controller C8254 programmable timer/counter
C8255A programmable peripheral interface
Programmable interrupt controllers C8259A,
C8259AS synchronous C8279 programmable
keyboard/display interface GPIO8-APB General
I/O Unit for AMBA Processor support CZ80CTC
programmable counter/timer CZ80PIO programmable
parallel I/O controller CZ80SIO serial I/O
controller Serial Communications
UARTs H16450, H16450S synch. interface H16550
with FIFOs H16550S with FIFOs and
synchronous interface H16750 with FIFOs and
IrDA H16750S with FIFOs, IrDA, and synch.
interface H8250 SDLC global serial channel
controller Basic Functions TTL standard parts
and devices
5
Advantages of Using IP

• Faster time to market
• Reduced component and manufacturing costs
• Higher design quality
• Reduced engineering cost

6
(No Transcript)
7
IP Enables Better Products
8
CAST SuccessGrowing Customer Base

• Over 100 model sales
• More than 80 customers

• Over 250 core sales
• More than 200 core customers

9
The CAST Approach Business

• Combine experienced management with leading-edge
  organizational tools and practices
• Bootstrap control expenses and grow as a
  function of earnings

• Remain independent from EDA companies and semi
  manufacturers, but develop strong partnerships
  with both

• Develop a global network to tap regional benefits
  and provide a local presence

10
The CAST Approach Products

• Keep a singular focus on practical, affordable,
  IP for mainstream designers
• Develop a broad range to serve as a single-source
  provider
• Integrate best in class IP development from
  across the globe to a common high standard
• Provide superior technical support to end users
• Support Reusability Initiatives and related open
  architectures
• Provide highly competitive, cost-effective cores
  with flexible licensing terms

11
High-Quality, Low-Risk IP

• Professional development process builds in
  expertise
• Cores created by application-specific experts
• Rigorous standards applied throughout
• Industry standards supported as appropriate

• Verification and testing reduce unexpected
  problems
• High code coverage targets
• Hardware modeler verifiesagainst physical device

• Complete deliverables get you started fast
• Source code or netlist, test bench and vectors,
  synthesis scripts, detailed documentation, etc.

• Customer support keeps your project moving
• Most rapid response youll find
• Customization available to meet your specific
  needs

12
International Development Team
13
Making Acquisition Easier

• Simple licensing for a straightforward purchase
• Sensible, easy-to-understand terms
• Accommodating license terms
• Flexibility to meet specific customer situations
• Arrange single legal approval foropen ended CAST
  purchases
• Competitive pricing for cost-effective
  reusability

14
International Sales Team
15
CASTs gpIP Cores Highlights
Eightydifferentfunctionsandgrowingevery month

• Broadest range of 8- and 16-bit processors
  available
• Most relevant system interfaces
• Full suite of encryption functions
• Strong family of multimedia solutions
• Large array of general purpose I/O and Bus
  Controllers

16
8051-Compatible Cores

• C8051
• Legacy speed
• small (lt9K gates)
• D80530
• Dallas architecture 2.5x speed up
• power management
• R8051
• RISC-like architecture 8x speed up
• small (lt8.5K gates)
• power management, Intel peripherals
• R80515
• RISC-like architecture 8x speed up
• power management, extra features, Infineon
  peripherals

A range of choices forembedded
processorapplications
average improvement over legacy architecture
based on fewer clocks/cycle and fewer
cycles/operation
17
Other Compatible Processor Cores

• 8-bit processors
• 6805 and 6811
• PIC 165X, 1655X
• Z80CPU
• Z80PSC intelligentperipheral controller
• Bit slice processors
• 4-bit 2901
• 16-bit 29101, 29116A, 49402, 59016

• 16-bit processors
• 68000
• 80186TX
• 80187
• DSP processors
• 16-bit 32025, 32025TX
• 24-bit 56000

18
Bus and Network Cores

• CAN bus controller
• Ethernet MAC (Media Access Controller)
• 10/100, 10/100 Lite, Gigabit (10/100/1000)
• EPP Extended Parallel Port interface
• I2C serial bus interface
• Slave, master/slave, high-speed
• PCI
• 32-bit 33 MHz and 64-bit 66 MHZ
• Target, master/target, multifunction, host bridge
• SPI Serial Peripheral Interface
• LIN Bus Controller
• USB Universal Serial Bus
• Versions 2.0, 1.0, 2.0 On-the-Go

Easily addstandard interfacesto make your
productscompatible andcompetitive
19
Multimedia Cores

• MPEG-4 motion processing series
• Encoder (decoder and codec in Q3, Q403)
• MoPro motion estimation/compression processor
• JPEG 2000 Encoder and Decoder
• Advanced compression algorithm
• Avnet Avalon Reference design board available
• JPEG Compression Encoder and Decoder
• easy to integrate, programmable, among fastest
  available
• Specific functions
• Color Space Converter fast bridge between video
  capture and compression
• Huffman Encoder and Decoder image processors
  JPEG-compatible, easy to program, fast
• Discrete Cosine Transform image processors
  small, very configurable, very fast
• Discrete Wavelet Transforms most capable and
  configurable available

Choose complete solutions or flexible building
blocks
20
Encryption Cores

• AES
• Advanced Encryption Standard(Rijndael)
• DES and Triple-DES
• Data Encryption Standard
• MD5
• Message Data Algorithm
• SHA-1
• Secure Hash Algorithm
• MODEXP1
• Modular Exponentiation Accelerator for RSA

A range of provenalgorithms forhigh-securityapp
lications
21
Choose Source Code or Netlist
22
So Why Choose CAST IP?

• Quality
• Expert development, rigorous testing, and
  complete deliverables help ensure smooth IP
  integration
• Support
• Responsive, knowledgeable help plus customization
  services make CAST IP work for you
• Breadth
• A wide range of cores from a single provider
  reduces IP selection headaches
• Simplicity
• Simple terms, blanket license, and competitive
  prices make it easier to get the IP you need
• Experience
• An IP pioneer who knows how to deliver
