Deploying Shibboleth

1
Deploying Shibboleth

• Michael R Gettes
• Duke University
• Seminar 08P

2
What is Shibboleth? (Biblical)

• A word which was made the criterion by which to
  distinguish the Ephraimites from the Gileadites.
  The Ephraimites, not being able to pronounce
  sh, called the word sibboleth. See --Judges
  xii.
• Hence, the criterion, test, or watchword of a
  party a party cry or pet phrase.
• Webster's Revised Unabridged Dictionary (1913)

3
What is Shibboleth? (modern era)

• An initiative to develop an architecture and
  policy framework supporting the sharing between
  domains -- of secured web resources and services
• A project delivering an open source
  implementation of the architecture and framework
• Deliverables
• Software for Identity Provider
• Software for Service Providers
• Operational Federations (scalable trust)

4
So What is Shibboleth?

• A Web Single-Signon System (SSO)?
• An Access Control Mechanism for Attributes?
• A Standard Interface and Vocabulary for
  Attributes?
• A Standard for Adding Authn and Authz to
  Applications?

5
Shibboleth Goals

• Use federated administration as the lever have
  the enterprise broker most services
  (authentication, authorization, resource
  discovery, etc.) in inter-realm interactions
• Provide security while not degrading privacy.
• Attribute-based Access Control
• Foster inter-realm trust fabrics federations and
  virtual organizations
• Leverage campus expertise and build rough
  consensus
• Influence the marketplace develop where
  necessary
• Support for heterogeneity and open standards

6
Attribute-based Authorization

• Identity-based approach
• The identity of a prospective user is passed to
  the controlled resource and is used to determine
  (perhaps with requests for additional attributes
  about the user) whether to permit access.
• This approach requires the user to trust the
  target to protect privacy.
• Attribute-based approach
• Attributes are exchanged about a prospective user
  until the controlled resource has sufficient
  information to make a decision.
• This approach does not degrade privacy.

7
How Does it Work?

• Hmmmm. Its magic. -)

8
The Environment
Apps / Resources
Identity Mgmt System
AuthN
Systems of Record
AuthN
Log
Reflect
Provision
Join
Credential
AuthZ
Pass Attributes
Mng. Affil.
Mng. Priv.
Log
Grouper
Signet
Shibboleth
9
(No Transcript)
10
High Level Architecture

• Federations provide common Policy and Trust
• Service and Identity Provider site collaborate to
  provide a privacy-preserving context for
  Shibboleth users
• Identity Provider site authenticates user,
  asserts Attributes
• Service Provider site requests attributes about
  user directly from Identity Provider site
• Service Provider site makes an Access Control
  Decision
• Users (and Identity Provider organizations) can
  control what attributes are released

11
Technical Components

• Identity Provider Site Required Enterprise
  Infra
• Authentication
• Attribute Repository
• Identity Provider Site Shib Components
• Handle Server
• Attribute Authority
• Service Provider Site - Required Enterprise Infra
• Web Server (Apache or IIS)
• Service Provider Site Shib Components
• Assertion Consumer Service - ACS
• Attribute Requester - AR
• Where Are You From Service - WAYF
• Resource Manager

12
WAYF
Identity Provider
Service Provider Web Site
Resource
13
Demo!

• http//stc.cis.brown.edu/stc/Projects/Shibboleth/
  Demo/Brown-demo.html

14
Shibboleth Architecture (still photo, no moving
parts)
15
Shibboleth Architecture -- Managing Trust

TRUST
Shib engine
Attribute Server
Service Provider Web Server
Browser
16
(No Transcript)
17
Shibboleth DeploymentCommon Threads

• Michael Gettes
• Duke University
• Seminar 08P (part 2)

18
Shibboleth as Part of the MACE IAM Model

Verb Objects
Reflect Data of interest from systems of record into registry, identity databases and maybe directories
Join Identity information across systems
Manage Credentials, group memberships, affiliations, privileges, services, policies
Provide Identity and Access info via - run-time request/response - provisioning into App/Service stores
Authenticate (AuthN) Claimed identities
Authorize (AuthZ) Access or denial of access
Log Usage for audit
19
Key Concepts - Shibboleth in Your Environment

• Federated Administration
• Identity Provider Site
• Service Provider Site
• Standards Based
• Based on OASIS SAML specification
• Interoperates with Many Vendor Products
• Attribute-Based Single Sign-On
• Attributes Describe the Browser User, used for
  Access Control
• Identity may be an attribute, but is optional
• Location Independent -- NOT IP Based
• But location can be an Attribute
• Management of Privacy
• Done via Attribute Release Policies (ARPs)
• Site, Groups, and the User can control release of
  Attributes

20
Key Concepts - Shibboleth in Your Environment

• Framework for a Variety of Policy and Management
  Models
• Federations
• Bilateral
• Extensible Authentication and Attribute Sharing
• Federation defines syntax and semantics of common
  Attribute/Value pairs
• Two parties can define custom attributes

21
The Shibboleth System is

• an open source SAML-based Web SSO package
• Provides both intra- and inter-campus Web SSO
• Implements the SAML Browser/POST and
  Browser/Artifact profiles
• Is software that the campus installs -- NOT a
  service
• Consultants are available to provide support
• relies on pre-existing authentication and
  attribute sources.
• Authentication done against existing system
• Attributes obtained from existing System
• portable to a variety of platforms and web server
  environments.
• designed to SAML-enable applications.
• minimal rather than all-encompassing in its scope
  to make integration with existing environments
  and technology possible.
• free to use and customize.

22
The Shibboleth System is NOT

• Usable in non-Browser scenarios (without a lot of
  hard thinking)
• an identity management system.
• a directory or database.
• a complete soup-to-nuts solution for
  authentication and attribute management.
• a world-class SSO system (largely because its
  SAML 1.x-based at this stage).
• hard to deploy once you have a general template
  for how to proceed.

23
Shibboleth vs SAML

• The Shibboleth implementation includes a trust
  fabric implementation based on PKI
• The Shibboleth implementation includes a
  framework and metadata for identifying IdPs and
  SPs
• The Shibboleth implementation includes a
  mechanism (ARPs) to manage the release of
  attribute information to SPs

24
Shibboleth as Web Single SignOn System

• Originally described as solution for cross-domain
  Single SignOn
• Library Use Case
• Just as useful for intra-domain SSO
• Provides single solution
• Shibboleth/SAML currently is not defined for use
  outside of Web SSO

25
Shibboleth - Interoperating with Vendor Products

• Interop testing done at Burton Catalyst summer
  2005
• Successfully interoped
• Using SAML 1.1
• With several vendor products
• IBM (SAML 1.0 only), Sun, HP and Trustgenix (same
  code), CA/Netegrity, and BMC
• But NOT using the Shibboleth profile

26
Delivery of Attributes

• Why?
• Growing number of applications need attributes
• Direct access to ldap, business DBs?
• Shibboleth provides applications with standard,
  easy to use interface
• Shibboleth provides management interface for
  policy
• Applications are using attributes
• For access control
• To build user profiles
• To obtain a persistent identifier for each user
• Differentiating constituencies (applicants vs
  alums vs (faculty, student, staff)

27
Delivery of Attributes

• Identify Attribute Sources
• Publicly available (ldap?)
• Confidential (ldap, SQL)
• Identify Which Attributes are Available
• Involvement of stakeholders?
• Process to update this list
• Define New Business Processes
• How does an SP Request an Attribute?
• Who decides whether they can have it?

28
Delivery of Attributes

• Define New Policies
• SPs responsibility with respect to received
  attributes
• Proper handling
• Who at the site has access to the log files.
• Dare we speak the word -- auditing?
• New Technical Roles
• Who reconfigures the IdP
• Attribute Authority connectors
• Attribute definitions
• Attribute Release Policies

29
Delivery of Attributes

• Help Desk
• Problem resolution flow, when user denied access
  to departmentally-based application
• Who can see whether user has correct attributes?
• Students working on the help desk?
• Staff supporting IdM?
• Process for getting the user the correct
  attributes
• Does user contact the System of Record Office?
• Contact Points in the departments that are using
  the SSO?

30
Levels of Assurance (LoA)

• Classify the requirements of an application
• Assign confidence levels for the ID Proofing and
  Electronic Authentication Processes
• Define mapping between Reqs and Confidence
• As simple as a number (Levels 1,2,3,4).
• Define confidence in terms of application
  requirements and you can use the same value for
  both.
• An ID of LoA 4 can access Apps at 1-4

31
What is a Federation?

• A collection of organizations, having implemented
  some form of Identity Management, where
  Credential Service Providers (CSP, Universities)
  and Service Providers (SP, Content Providers)
  agree to rules of engagement (policy and
  attributes) using federating software
  (Shibboleth, SAML, PKI)

32
What is a Federation? (Continued)

• Sounds simple? It can be. It can be made really
  complex, really fast.
• www.nmi-edit.org for more info
• CSPs and SPs retain control over their
  environments (identity data and access ctrl)
• www.InCommonFederation.org
• Approx 37 participants (9/06), Launched 4/2005
• Inqueue.internet2.edu
• Testing/Playground for InCommon
• gt225 participants (9/06) and GOING AWAY!

33
Shibboleth and Federation

• Its real, uses SAML
• Open source, freely available
• Takes between 3 hours and 3 years to install --
  depending on IdM infra
• In production at many schools
• For internal apps external Univ vendors
• shibboleth.internet2.edu
• www.incommonfederation.org

34
Federated Authentication

• Why?
• Scholarship is now done via the Net..
• Both teaching and Research
• Access to Federated websites offered by US
  Federal Govt agencies (and lots of other Federal
  govts!)
• Grant management
• Student Financial Aid
• Access to Partners is
• Simplified
• More flexible
• Under better control
• More secure. (but why?)

35
Low Hanging Fruit

• Find the low hanging fruit for services needing
  shibboleth.
• IIS support (Duke did not have it until Shib)
• External Services to your Institution
• Willing partners, working with friends in the
  beginning makes for successful deployment.
• Keep it simple, in the beginning

36
Technology Threads

• Web versus
• Easy is usually not - spend time with SPs to make
  sure they really understand. Give SPs test IDs
  so they dont have to run IdP.
• SAML under the covers
• Details are solvable - but only until known
• Assumptions will kill you.

37
Policy Threads

• You can make this as complex as you like
• Its not about Shib - its about Apps gaining
  access to attributes - only the attributes the
  Apps need.
• Privacy? Yes.
• Limiting Data Exposure? Yes.
• Distributing versus Distributed Data
• More dynamic/responsive services
• 1 Hour turn-around for NetID provisioning _at_ Duke

38
SPs - Selling It!

• If you take the time to sell Shib to your SPs it
  benefits us all. We win and they win!
• No more one-off solutions for each sale
• SPs dont need to issue identities/passwords
• Less Help Desk support for password issues
• Open Source and Open Standards
• SAML based - ties into futures for AuthN/AuthZ
  where SP wont need to change
• Federated Model -- forward looking for Higher Ed
• Dont pay for the development - HE already did
  the hard work in this space and SPs reap benefits

39
Adoption in the GlobalHigher Education Space

• Belgium
• France
• Spain
• The UK
• Australia
• New Zealand?
• The US

• Finland
• Sweden
• Denmark
• Germany
• Switzerland
• Greece
• The Netherlands

40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
Additional Slides Not Presented
44
The Europeans Prioritized Vendor List

• Elsevier Science Direct
• EBSCO
• JSTOR
• OVID (OvidWeb and WebSPIRS)
• Thomson Science
• Springer (Metapress)
• Exlibris (Metalib, sfx)
• EZProxy
• Wiley
• Taylor and Francis
• Thomson Gale
• Blackwell
• Institute of Physics Publishing
• Proquest
• Muse (Johns Hopkins)
• Nature (Highwire)
• OUP Oxford University Press
• American Chemical Society

45
Other Vendors

• TurnItIn
• Music (Napster, CDigix)
• MSDN Academic Allliance
• http//msdn.microsoft.com/academic/
• American Education Services
• http//www.aessuccess.org/
• The US Federal Government E-Authentication
  Initiative
• http//www.cio.gov/eauthentication/

46
Yet More Others

• GridShib
• http//gridshib.globus.org/
• LionShare
• http//lionshare.its.psu.edu/

47
InCommon -- the US Higher Ed / Research Federation

• http//www.incommonfederation.org/
• U.S. Higher Ed and its Partners
• Self-organizing
• Heterogeneous
• Policy Entrance bar intentionally set low
• IC doesnt impose lots of rules and standards
• Access to E-Authn may change this.

48
InCommon Requirements

• Common Attributes
• Software Guidelines
• www.incommonfederation.org/ops/softguide.html
• Transparency of Policy and Practices
• Legal Agreement
• No Indemnification
• Limited Liability
• General Liability Insurance
• Annual Fee

49
What Does InCommon Provide

• Trust Management
• Private Certificate Authority
• Revocation Process
• Metadata management and distribution
• WAYF
• Business relationships between members are
  separate

50
New Business Processes

• ARP Management
• Local users/groups requesting Attribute Release
  to remote SPs
• See ShARPE
• How do local SPs apply for membership in IC?
• How to ensure policy adherence of local SPs
• Role of central IT/audit
• Help desk problem resolution in a Federated
  world
• Responding to remote sites reporting suspected
  abuse

51
Shibboleth 2.0

• Advances with SAML 2.0 specification
• Convergence with commercial Liberty and SAML
  products
• Interoperable privacy mechanisms now in the
  standard (transient and federated/persistent IDs)
• Single Logout
• NameID Change/Term Management
• Enhanced Client or Proxy (ECP) Profile
• Advances with Shibboleth 2.0
• Authentication processing in the box
• Shibboleth 2.1 -- N-tier?
• New Liberty Spec and errata to SAML 2.0
• Composed into https//authdev.it.ohio-state.edu/tw
  iki/bin/view/Shibboleth/WebServices
