Congruence of Triangles

1
Congruence of Triangles

• (NCTM standard) All grades 3-5 should explore
  congruence and similarity of shapes.
• Notation
• stands for segment AB,
• stands for ray from A to B (A is the fixed
  point)

2

• represent the angle ABC
• represents the triangle ABC
• If two line segments AB and CD are equal in
  length we say segment AB is congruent to segment
  CD and write it as .
• if two angles and are
  equal in measure we say the two angles are
  congruent and write it as

3

• Two triangles and are said to
  be congruent if and only if there is a one to one
  correspondence between the respective sides and
  angles such that the corresponding angles and
  sides are congruent. We denote this by
  .

4

• Properties of Congruence
• (SAS) Side Angle Side - If two sides and the
  included angle of a triangle are congruent,
  respectively, to two sides and the included angle
  of another triangle, then the triangles are
  congruent.

5

• (ASA) Angle Side Angle - If two angles and the
  included side of a triangle are congruent,
  respectively, to two angles and the included side
  of another triangle, then the two triangles are
  congruent.

6

• (SSS) Side-Side-Side - If three sides of a
  triangle are congruent, respectively to three
  sides of another triangle, then the two triangles
  are congruent.

7
Examples

• Show that the triangles below are congruent to
  each other.
• 1.

8

• (NCTM standard- grades 6-8 learn deductive and
  inductive arguments concerning geometric ideas
  and relationships, such as congruence and
  similarity, and the Pythagorean relationship.
• Make students recognize that reasoning and proof
  are essential and powerful parts of mathematics.

9
Similarity of Triangles

• Two triangles and are
  said to be similar if and only if all
  corresponding sides are proportional and all
  corresponding vertex angles are congruent. We
  denote this by

10
(No Transcript)
11

• Properties of Similar triangles-
• Two pairs of corresponding sides are
  proportional and their included included angles
  are congruent (SAS similarity)
• Two pairs of corresponding angles are congruent
  (AA similarity)
• All three pairs of corresponding sides are
  proportional. (SSS similarity)

12

• http//animal.discovery.com/games/shapeshifter/sha
  peshifter.html
