Evolving Toward a Self-Managing Network

1
Evolving Toward a Self-Managing Network

• Jennifer Rexford
• Princeton University
• http//www.cs.princeton.edu/jrex

2
Why is Network Management So Darn Hard?

• Oodles and oodles of complex features
• Many protocols
• Many mechanisms
• Many configurable parameters
• Little guidance for network administrators
• How to select and compose features?
• How to set the configurable parameters?
• Managing boxes, rather than networks
• Routers, switches, firewalls, IDSes, servers,
  etc.
• Low-level, box-specific configuration languages

3
The Enemy is Complexity

• Goal raising the level of abstraction
• Network-level design and configuration
• Composition of protocols and mechanisms
• Idea 1 add abstraction on top
• Compile high-level spec into box configuration
• But, must grapple with inherent complexity
• Idea 2 design system for manageability
• Identify network-level abstractions
• and change the boxes and protocols
• But, must grapple with backwards compatibility

4
Example Border Gateway Protocol

• ASes exchange reachability information
• IP prefix block of destination IP addresses
• AS path sequence of ASes along the path
• Configurable routing policies
• Path selection (which route to use?)
• Path export (who to tell about the route?)

12.34.158.0/24 path (7018,1,88)
12.34.158.0/24 path (88)
88
1
7018
data traffic
data traffic
12.34.158.5
5
Some Things I Hate About BGP

• Routers in an AS have different views
• Effect protocol oscillation and loops
• Point fix testing sufficient conditions
• Routing policy distributed across routers
• Effect routers need to share information
• Point fix complex tagging of BGP routes
• Policy has only an indirect effect on traffic
• Effect selecting the right policy is hard
• Point fix what if tools for traffic
  engineering
• BGP route selection depends on the IGP
• Effect disruptions from small internal changes
• Point fix what if tools to identify risks

6
Interdomain Routing Design for Manageability

• Routing Control Platform
• Represents the AS to others
• Has complete view of candidate routes
• Computes answers for the ASs routers
• Communicates with other ASes
• Using BGP or (ideally) a brand new protocol

Inter-AS Protocol
RCP
RCP
RCP
AS 1
AS 2
AS 3
Physical peering
7
Advantages of RCP Approach

• Lower management complexity
• Complete, network-wide view
• Direct control over the routers
• Single specification of policies and objectives
• Simpler routers
• Much less control-plane software
• Much less configuration state
• Enabling innovation
• New algorithms for selecting paths within an AS
• New approaches to inter-AS routing

8
Deployability Backwards Compatibility using BGP

• Border Gateway Protocol (BGP)
• Protocol messages sent between routers
• Decision logic route-selection process
• Policy configurable rules for path
  selection/export
• The key point is that BGP has
• Complex decision logic and policies
• Yet a simple protocol (and message format)
• Use BGP messages to program the routers

9
Phase 1 Flexible Path Selection in One AS
Before conventional use of BGP in backbone
network
eBGP
iBGP
After RCP learns routes and sends answers to
routers
eBGP
RCP
iBGP
10
Phase 2 AS-Wide Path Selection and Export
Before RCP gets best iBGP routes (and IGP feed)
eBGP
RCP
iBGP
After RCP gets all eBGP routes from neighbors
eBGP
RCP
iBGP
11
Phase 3 Direct Communication Between RCPs
Before RCP gets all eBGP routes from neighbors
eBGP
RCP
iBGP
After ASes exchange routes via RCP
Inter-AS Protocol
RCP
RCP
RCP
iBGP
AS 1
AS 2
AS 3
Physical peering
12
Systems Considerations (NSDI05)

• Reliability
• Problem single point of failure
• Solution replication of RCP components
• Consistency
• Problem inconsistent decisions by replicas
• Solution consistency without inter-replica
  protocol
• Scalability
• Problem storing and computing for all routers
• Solution store each route once and amortize work

13
Example Network Management Applications

• Customer-driven route selection
• Customized load-balancing policies
• Geographic rules for route selection
• Blocking denial-of-service attacks
• Blackhole routes that drop traffic
• Only for routers carrying attack traffic
• Hitless maintenance
• Move traffic away from certain routers
• Before the operators bring down the routers

14
Conclusion

• Network management is too hard
• IP was not designed for management
• Complex, distributed operation of routers
• Must reduce complexity
• Network-wide views and objectives
• Direct control over the data plane
• RCP approach is feasible
• Deployable, scalable, and reliable
• Solves important management problems
• Many interesting open problems

15
Backup Slides
16
Routing Control Platform (RCP)
Routing Control Platform (RCP)
Route Control Server (RCS)
Answers
Options
Topology
OSPF Viewer
BGP Engine

BGP updates
OSPF link-state advertisements
BGP updates


Network
17
Scalability Standard Computing Platform

• Prototype on a high-end PC
• 3.2 GHz Pentium-4 with 8 GB of RAM
• Running the Linux 2.6.5 kernel
• Workload from the ATT backbone
• Replay the BGP and OSPF messages
• Good RCP performance
• Memory usage less than 2GB
• Speed, BGP changes less than 40 msec
• Speed, topology changes 0.1-0.8 seconds

Short answer the system can keep up
18
Reliability Replication and Consistency

• Replication avoid single point of failure
• Multiple RCPs in a network
• Connected at different places
• Consistency no explicit coordination
• Replica has full view of each partition
• Replicas perform the same algorithm on the same
  data, and get the same answer

A, B
A
B
RCP A
RCP B
