Title: Professor G' D' Earle


1
A Primer on Plasma Physics and Arc Discharges
2
Contents
  • Symbol Table
  • Types of Discharges
  • What Is Plasma?
  • Producing and Sustaining Plasmas
  • Mathematical Description of Plasmas
  • Basic Characteristics of Plasmas
  • Measurement Techniques
  • References

The top figure shows a laboratory plasma produced
by a hollow cathode discharge in a vacuum
chamber. The bottom figure shows the aurora
borealis - a plasma produced naturally in the
upper atmosphere.
3
Symbol Table
  • This table defines common parameters used
    throughout this primer.

4
Types of Discharges
  • Discharges can be classified into two broad
    categories self-sustaining and non
    self-sustaining.
  • Glow discharges and arc discharges fall into the
    self-sustaining category, as do corona discharge
    phenomena.
  • Raizer (1991) classifies discharges into 12
    different types

5
Types of Discharges
  • Glow discharges are generally characterized by
  • Low pressures, lt 10 Torr
  • Currents ranging from 1 ?A to 100 mA
  • Weak ionization, 10-6 to 10-8 ions per neutral
    particle
  • Energies less than 1 eV (11,600 K)
  • Arc discharges typically have
  • Pressures up to 1 atmosphere (760 Torr)
  • Unlimited current, usually exceeding 1 A, bright
    emission of visible light
  • 0.1-10 ionization
  • High temperatures, capable of melting containment
    vessels
  • Arc discharges are fast - the gas typically
    becomes 1 ionized in 0.1 ?s - 1 ms, with
    current levels growing by several orders of
    magnitude on the same timescale.

6
Types of Discharges - Emitter Example
  • Quiescent electron emission and arc discharges
    are both easily created near sharp edges that are
    held at different potentials, because the
    potential gradients are largest there.
  • This result can be rigorously derived from
    Maxwells equations, but a heuristic
    understanding may be obtained from the diagram
    below, which shows a device known as a microtip
    emitter.
  • Microtip emitters can be run continuously in
    vacuum for long periods when operated carefully,
    but their geometries are also appropriate for
    producing arc discharges.

When a large potential difference is created
between two closely spaced surfaces the electric
field between them can become very large - this
can produce an arc discharge in which an ionized
(plasma) path forms between the surfaces and
carries current between them. The result is the
microscopic equivalent of a lightning
discharge. The close up view of the emitter tip
(below left) illustrates how this can happen -
electrons congregate on the surface of the tip
because of the proximity of the positively biased
(gate) electrode. These electrons all repel each
other. On the lateral edges of the emitter tip
these repulsive forces lie in the plane of the
surface, but near the atomically sharp tip the
net force will be perpendicular to the surface.
As a result the electrons near the tip are more
easily emitted into the surrounding air, creating
the arc discharge.
7
The Paschen Curve (1)
  • There is a preferred pressure range for arc
    discharges between closely spaced electrodes.
    The important quantities are the product of
    ambient pressure and electrode separation, along
    with the potential difference between the
    electrodes.
  • If the pressure is too low the mean free path in
    the gas becomes too large for efficient
    collisional ionization by the free electrons.
  • If the pressure is too high the mean time between
    collisions is very short, so the ions and
    electrons quickly recombine.
  • The Paschen curve illustrates where the
    conditions are best suited to formation of arc
    discharges.

8
The Paschen Curve (2)
  • The Paschen curves shown in these two plots
    illustrate the voltage differences at which arc
    breakdown occurs for various gases and electrode
    separations.
  • In both cases these voltages are plotted vs. the
    product of the ambient pressure (p in Torr) and
    the separation distance (d in cm) between the two
    electrodes.

9
Practical Uses of Discharges
  • Ionization sources for mass spectrometry,
    electron beam generation, X-ray sources, etc.
  • Arc welders
  • Lighting
  • Sterilization of medical instruments
  • Plasma processing of materials, such as
    semiconductor dry etching
  • Cold pasteurization of food

10
What Is Plasma?
  • Plasma is a gaseous state of matter in which
    enough free energy is present to produce
    physically significant numbers of free ions and
    electrons.
  • These gas populations may be considered to be
    immersed in each other as co-located fluids.
  • The result is a gas with multiple interacting
    constituents, which may include
  • Neutral particles (perhaps with spatially or
    temporally varying molecular or atomic
    composition)
  • Electrons
  • One or more positive ion species
  • One or more negative ion species

11
What Is Plasma?
  • Physically significant numbers of charged
    species means enough ions and electrons to
    exhibit Coulomb forces at least comparable to the
    other forces within the fluid.
  • The charged particles interact through these
    Coulomb forces (FqE), which act over a distance.
  • The effect of small angle Coulomb collisions in a
    plasma always dominate the effects of large angle
    collisions.
  • The chart shows the enormous range of particle
    densities and temperatures over which plasmas can
    exist.

12
Producing and Sustaining Plasmas
  • Due to random thermal interactions, any neutral
    gas at finite temperature will contain a few free
    electrons and ions at any given time.
  • To create and sustain a plasma, energy must be
    available to accelerate this small cohort of free
    charged particles so that they collisionally
    ionize other neutral particles with sufficient
    frequency to overcome immediate chemical
    recombination.
  • Common techniques for producing laboratory
    plasmas include
  • Capacitive discharges - Free electrons are
    accelerated by a strong DC electric field
    sustained in vacuum between two flat plates held
    at different potentials.
  • Inductive discharges - Radio frequency fields
    drive current in a coil system adjacent to (or
    immersed within) a gas in a vacuum chamber.
  • Thermionic emission - Large currents are driven
    through filaments made of tungsten or some other
    metal. At sufficiently high filament
    temperatures electrons will be emitted from the
    metallic surface.
  • Hollow cathode discharges - Gas is introduced
    through a short heated tube into a vacuum
    chamber. When the tube is heated to high
    temperatures the combination of photochemical and
    thermal processes can produce weakly ionized
    plasmas.
  • Photochemical discharge - Short wavelength UV
    light irradiates a gas and stimulates ionization.
    Due to large optical depths in rarefied gases
    this technique generally produces weak, low
    temperature plasmas.

13
The Saha Equation
  • The density of ions relative to the density of
    neutral particles in a gas is given by the Saha
    equation, where T is the neutral temperature in
    eV (1 eV11,600 K), the ion and neutral densities
    ni and nn are in m-3, and U is the potential
    energy of the least tightly bound electron in the
    system, also called the ionization energy

14
Plasma Ionization Percentage
  • The chart below shows the fractional ionization
    of an atomic hydrogen gas, which has an
    ionization energy U13.6 eV. Here ntninn, and
    the fractional ionization is given by ?ni/nt.
    The numerical labels on the curves indicate the
    values of log(nt). For reference, log(nt)25 at
    standard atmospheric temperature and pressure.

15
Mathematical Description of Plasmas
  • Kinetic theory equations are necessary for a
    rigorous description of plasmas, but for many
    applications the fluid equations are sufficiently
    accurate, and much simpler to solve.
  • The three equations below apply independently to
    each species in the plasma, with the subscript s
    representing electrons, each ion species, and
    each neutral gas species.
  • The Q and L terms in the continuity equation
    stand for chemical (or other) production and
    loss, respectively. Other variables are as
    defined in the symbol table.
  • For neutral gases the E and VxB terms on the
    right side of equation (2) disappear, and a term
    representing neutral fluid viscosity must be
    added. Note - viscosity is not a well defined
    quantity for plasmas.

16
Mathematical Descriptions of Plasmas
  • In combination with the four Maxwell equations of
    electromagnetism, the equations on the previous
    slide comprise a coupled, nonlinear, closed
    system.
  • Various limiting cases can sometimes be solved
    analytically, but due to the vector nature of the
    variables, the number of scalar equations that
    result, and the complex geometries likely to be
    encountered in practical situations,
    computer-based solutions are necessary for most
    cases of practical importance.
  • Note the similarity of the three equations on the
    previous slide to the three coupled equations of
    neutral fluid mechanics.
  • This similarity implies that all of the wave
    modes and instabilities present in ordinary
    fluids will also exist in plasmas.
  • However, the addition of the Coulomb and Lorentz
    terms, along with the existence of multiple
    co-located species (ions, electrons, and
    neutrals) in even the simplest plasmas, suggests
    that many more wave modes and instabilities will
    exist in the plasma domain.
  • In fact, plasmas are the richest medium yet
    discovered for waves, resonances, and
    instabilities.
  • The amazingly diverse mechanisms for energy
    dissipation that exist within plasmas help to
    explain why the plasma confinement necessary for
    controlled nuclear fusion is such an elusive
    goal. In fact, the only method known to be
    capable of containing high temperature plasmas in
    order to sustain long-lived fusion reactions is a
    strong gravitational potential well (stars).

17
Basic Characteristics of Plasmas
  • Plasmas are quasi-neutral at low frequencies, so
    to a very good approximation the macroscopic ion
    and electron number densities (particles/m3) will
    be equal. This characteristic holds because the
    electrostatic forces created in a plasma become
    quite large if the charge densities are unequal,
    so restoring forces quickly reinforce the
    quasi-neutral condition.
  • Plasmas can be described and parameterized by
    several characteristic frequencies. The most
    important of these are the plasma frequency, the
    gyro-frequency, and the upper-hybrid resonance
    frequency.
  • These frequencies are usually easy to observe in
    a plasma. They are often used to determine the
    plasma density and the strength of the magnetic
    field, since the electron plasma frequency is
    proportional to the square root of the number
    density, and the gyro-frequency is proportional
    to the magnetic field strength.

18
Basic Characteristics - Plasma Frequency
  • Consider a slab of plasma in which the electrons
    are (somehow) displaced laterally from the ions.
    Assume for simplicity that there is no background
    magnetic field. On short time scales the massive
    ions can be considered stationary relative to the
    more mobile electrons.
  • A strong electric field will develop to pull the
    electrons back toward the ions. As the electrons
    move back they will overshoot the equilibrium,
    and an oscillation will be set up. This
    oscillation occurs at the electron plasma
    frequency, wpe. The ions undergo a similar
    oscillation, but the ion plasma frequency wpi is
    always much lower and can generally be neglected.

If q is the charge and m is the species mass then
the plasma frequency is given by
19
Basic Characteristics - Gyro Frequency
  • If there is a magnetic field within the plasma
    then the random thermal motions induce Lorentz
    forces (qV x B) that create circular motions of
    the ions and electrons in planes perpendicular to
    the magnetic field lines.
  • The radii of these orbits are called the Larmor
    radii (R, RL or rL), and the frequency of the
    oscillation is called the cyclotron frequency ?c.
    Electrons have a smaller Larmor radius and a
    larger cyclotron frequency than ions.
  • The figure below shows the helical motion of a
    particle that has non-zero parallel and
    perpendicular components of velocity with respect
    to the magnetic field. The central axis of the
    helix defines the locus of the guiding center
    of the particles trajectory.

20
Basic Characteristics - Cutoffs and Resonances
  • The fundamental resonance frequency of a plasma
    immersed in a magnetic field occurs at the upper
    hybrid frequency, which is the square root of the
    sum of the squares of the electron plasma and
    cyclotron frequencies
  • ?UH2 ?pe2 ?ce2
  • Electromagnetic energy incident on the plasma at
    this frequency will be strongly absorbed at this
    resonance.
  • In contrast, the plasma frequency represents a
    cutoff for wave propagation. Electromagnetic
    energy incident on a plasma is strongly reflected
    at this plasma frequency cutoff. This phenomenon
    is used by ham radio operators and
    over-the-horizon radars to achieve long-distance
    propagation in the AM radio band, using
    reflection from the ionosphere.

21
Basic Characteristics - Magnetic Confinement
  • The ratio of kinetic pressure to magnetic
    pressure is defined as ?.
  • ? nKT/(B2/2?o)
  • In high ? plasmas the particles can distort the
    shape of the ambient magnetic field, while in low
    ? plasmas the magnetic field controls the
    distribution of plasma. Magnetic fields are
    therefore useful for constraining plasma motions
    if ? ?? 1.
  • The surface of the sun is a high ? environment,
    while examples of low ? plasmas include
    florescent lights and the ionosphere.

The left panel shows a diffuse plasma emitted
from a hollow cathode source (bright spot at
top). The right panel shows the same plasma
after a magnetic field is imposed along the
vertical axis in the figure.
22
Basic Characteristics - Adiabatic Invariants
  • There are several adiabatic invariants describing
    plasma motion, but only one is robust enough to
    be generally useful. This is the magnetic moment
    ?.
  • The magnetic flux (?) enclosed by the Larmor
    radius of the particle orbit can be written as a
    constant times the magnetic moment, as shown
    below. As a result, ? is also an adiabatic
    invariant of the motion provided that
  • The magnetic field strength and geometry do not
    change over a gyro period
  • No collisions occur within a gyro orbit to modify
    the particles trajectory.

23
Basic Characteristics - Adiabatic Invariants
  • Since ? is conserved, a particle moving parallel
    to a converging magnetic field will gain
    perpendicular energy as the field strength
    increases. Since the total energy is conserved
    the particles speed along B must decrease.
    Eventually the parallel velocity will reach zero
    and the particle will be mirrored - in effect
    reflected from the region of converging field
    lines. Particles with different initial energies
    will mirror at different points along the
    converging field.

The bottom panel shows the field lines associated
with a magnetic bottle geometry, which can be
easily created with Helmholtz coils. As plasma
ions and electrons move into the constricted
region (s2) they encounter the equivalent of a
potential gradient, which causes the magnetic
mirroring effect.
24
Basic Characteristics - Debye Shielding
  • If a test charge qT is introduced into a plasma,
    the ions and electrons in the plasma will
    redistribute themselves according to the sign of
    the charge.
  • The Debye length (?D) is simply the e-folding
    distance for the potential field ?(r) that forms
    around such an object. This potential sheath
    region effectively shields the rest of the
    plasma from the test charge, so that only the
    particles near the test charge react to its
    presence.
  • Ions and electrons have different Debye lengths,
    owing to their greatly different masses (
    corresponding mobility). The overall Debye
    length is a combination of the two (see below),
    but in practice the ion Debye length is
    negligible if Te gtgt Ti.
  • Cs is the thermal sound speed in the plasma, so
    an alternative definition of the Debye length is
    the distance a particle traveling at the thermal
    speed moves in the time associated with the
    electron plasma frequency oscillation.
  • A plasma can be quantitatively defined as a gas
    in which the number of charged particles
    occupying a sphere with radius equal to the Debye
    length is much greater than one.

25
Basic Characteristics - Guiding Center Drifts
  • Particles in plasma can be tracked by following
    the motions of their guiding centers, with the
    under-standing that the gyro-motions are
    superimposed on these guiding center
    trajectories.
  • If a body force F is applied to a magnetized
    plasma, the effect on the charged particles is to
    move with a drift velocity given by w(FxB)/qB2.
  • The formulas at the right give the most important
    guiding center drifts for ions and electrons in a
    plasma.
  • Note that if an electric field is imposed on the
    plasma, the ions and electrons will drift
    together in the same direction, so no net current
    will result.

26
Basic Characteristics - Diffusion
  • Plasma particles undergo diffusion in response to
    density or temperature gradients, but the
    classical understanding of diffusion is modified
    in this case because of the electrostatic forces
    between ions and electrons.
  • In general the electrons have much larger thermal
    speeds (vs2KTs/ms), so they will diffuse faster
    than the ions. This sets up an electric field
    that retards the electrons and speeds diffusion
    of the ions.
  • The net effect is called ambipolar diffusion,
    where the diffusion coefficient is a hybrid value
    involving the electron temperature and the ion
    mass and collision rate (note that Te is
    generally much larger than Ti).
  • In the equations below, lmfp is the mean free
    path between collisions.

27
Basic Characteristics - Collisions
  • Collision frequencies in plasmas are quite
    difficult to define quantitatively because of the
    wide range temperatures and densities at which
    plasmas exist, coupled with the fact that each
    species has three different collision
    frequencies
  • Collisions with neutrals
  • Collisions with electrons
  • Collisions with ions
  • The simplest case to quantify is the collision
    frequency between charged species and neutrals,
    which is the most important collision term in low
    temperature, low density plasmas.
  • In this special case we obtain the result
  • ?sn nn?s(KTs/ms)1/2
  • where ?s is the scattering cross section, the
    subscript s refers to the charged species, and
    the subscript n refers to the neutral species.
  • For electrons the scattering cross section is
    approximately 4x10-15 cm2 at all temperatures
    below 3000 K, while for ions it varies from
    about 50x10-15 cm2 at 10 K to about 5x10-15 cm2
    at 1000 K.

28
Waves in Plasmas
  • A very large number of wave modes exist in a
    plasma.
  • The dispersion relations (? vs. k) for the most
    important of these are given in the list shown
    here.
  • The electromagnetic ion modes are analogous to
    waves on a plucked string, where the string in
    this case is a magnetic field line.
  • The Alfven velocity in these ion wave equations
    is defined by vA2 B2/(nimi?o).
  • The study of plasma waves becomes very complex,
    because the various modes can couple to one
    another under proper conditions.

29
Waves in Plasmas
  • For mathematical simplicity the fast propagating
    electromagnetic waves are often considered to
    comprise four separate modes, called the X, O, R,
    and L mode waves.
  • The X and O modes propagate perpendicular to B,
    while the R and L modes propagate along B.
  • The actual ray-path of a wave is the
    superposition of the X, O, R, and L modes at any
    point in space.
  • Because of the free charge in a plasma, the phase
    velocities of the fast electromagnetic modes can
    exceed the speed of light.
  • The dispersion relation that describes the
    propagation of all four fast modes is known as
    the Appleton-Hartree equation.

30
Appleton-Hartree Equation
  • Define ? to be the propagation angle relative to
    the magnetic field (so ?0 implies propagation
    parallel to B).
  • Define nck/? as the index of refraction, where c
    is the speed of light in vacuum, k is the
    wavenumber, and ? is the wave frequency.
  • The equations below then describe the propagation
    of all four of the fast electromagnetic modes.

31
Waves in Plasmas
  • A CMA diagram can be used to help visualize or
    predict the wave modes that will be excited in
    various conditions.
  • Consider the magnetic field that permeates the
    plasma to lie along the Y-axis.
  • A given frequency is represented as a point on
    the plot. The diagram in the region containing
    the point shows the wave modes that exist in that
    frequency regime, and the shapes of the figures
    give the relative values of the phase velocities
    in each direction relative to B.
  • Recall that waves are reflected at cutoffs, and
    absorbed at resonances.

32
Measurement Techniques
  • A Langmuir probe is the oldest and simplest form
    of in-situ plasma diagnostic. It is simply a
    wire inserted into the plasma that can be biased
    to some potential.
  • The diagram on the left (below) shows a set up
    in which such a biased probe is inserted into a
    plasma. The graph on the right shows the current
    collected by the probe wire as a function of its
    potential. The sense of the Y-axis label is such
    that positive values of probe current correspond
    to electrons being collected on the probe.
  • The probe voltage at which no net current is
    collected is called the floating potential (Vf),
    and the point labeled Vp is the plasma potential
    (which is difficult to measure in practice
    because the curve doesnt generally show such a
    sharp break point there).
  • The slope of the curve between Vf and Vp is
    inversely related to the electron temperature.
  • The electron current greatly exceeds the ion
    current because of the higher thermal velocity.
  • The relationship Vp-Vf 2-3 KTe/q generally
    holds.
  • Fitting a theoretical function to such a Langmuir
    curve allows estimation of the plasma density and
    electron temperature.

33
Plasma Measurement Techniques
  • In addition to Langmuir probes, measurements in
    plasmas can be made using the following
    techniques
  • Coherent and incoherent scatter (radar-like
    techniques) to measure Te, Ti, N, and Vs.
  • Optical resonance and absorption techniques to
    determine plasma densities, temperatures, and
    Doppler shifts (line of sight motion).
  • Interferometry to measure average line of sight
    density.
  • Energetic particle detectors and thermal plasma
    detectors to measure the distribution functions
    vs. energy.

34
Concluding Comments
  • This primer has attempted to present in a compact
    form the basic principles of plasma physics, with
    no attempt at derivations.
  • Many interesting but esoteric phenomena, such as
    plasma stability, Landau damping of waves, and
    soliton formation, have been omitted.
  • Much more information is readily available on
    all of the topics and phenomena described herein.
  • The reference list on the next slide provides a
    listing of source materials that can
    significantly extend the basic introductory
    material presented here.

35
References
  • Bellan, Paul M., Fundamentals of Plasma Physics,
    Cambridge University Press, 2006.
  • Bittencourt, J. A., Fundamentals of Plasma
    Physics, Springer Science and Business Media,
    LLC, 2004.
  • Chandrasekhar, S., Plasma Physics, University of
    Chicago Press, 1960.
  • Chen, Francis F., Introduction to Plasma Physics,
    Plenum Press, 1974.
  • Goeckner, M., G. D. Earle, L. Overzet, and J.
    Maynard, Electron confinement on magnetic field
    lines, IEEE Trans. On Plasma Science, 33, 436,
    doi 10.1109/ TPS.2005.844960, 2005.
  • Gurnett, D. A., and A. Bhattacharjee,
    Introduction to Plasma Physics, Cambridge
    University Press, 2005.
  • Ichimaru, S. Basic Principles of Plasma Physics -
    A Statistical Approach, W. A. Benjamin Inc.,
    1973.
  • Johnson, E. E., R. I. Desourdis, G. D. Earle, S.
    C. Cook, and J. C. Ostergaard, Advanced
    High-Frequency Radio Communications, Artech
    House, Boston, 1997.
  • Krall, Nicholas, and Alvin W. Trivelpiece,
    Principles of Plasma Physics, San Francisco
    Press, 1986.
  • Nasser, E., Fundamentals of Gaseous Ionization
    and Plasma Electronics, John Wiley Sons, 1971.
  • National Research Council, Plasma Science From
    Fundamental Research to Technological
    Applications, National Academy Press, ISBN
    0-309-05231-9, 1995.
  • Nicholson, D., Introduction to Plasma Theory,
    John Wiley and Sons, 1983.
  • Raizer, Yuri P., Gas Discharge Physics,
    Springer-Verlag, 1991.
  • Schmidt, George, Physics of High Temperature
    Plasmas, Academic Press, 1979.
Write a Comment
User Comments (0)
About PowerShow.com
