Tracking a High Risk Fluvial Bull Trout

1
Title
Tracking a High Risk Fluvial Bull Trout
Population with Half-duplex Passive
Interrogation
Vince Tranquilli Oregon Department of Fish and
Wildlife Research and Monitoring Program
2
Map
Upper Willamette River Basin
South Fork McKenzie River
3
Project
Cougar Dam Water Temperature Control Project

• Funded by USACE
• modify dam intake for
• water temperature
• draw-down the reservoir
• for 3 - 4 years
• high risk bull trout population
• no fish passage

4
Info. data
Need information - migration timing -
entrainment - abundance
5
Info. data
Need information - migration timing -
entrainment - abundance
Data Sets - radio telemetry - PIT
interrogation Methods apply high risk
population
6
Radio Telemetry
Radio Telemetry
7
Radio Telemetry
Reservoir
Dam
8
HDX PIT tags
Reduce Risk? And, increase sample size
9
HDX PIT tags
TI-RFid
23 mm half-duplex pulsed RF field 134.2
KHz transmits 123.2 KHz 10 reads per second
10
PIT tagging
Tag - shedding - orientation
Fish gt 100 mm FL
11
DO
Remote PIT tag Interrogation Site
12
DO
Detection Efficiency 90 at 200 cfs, N 30
13
DO
Detection Efficiency 73 at 1,000 cfs, N 30
14
DO
Detection Efficiency 73 at 1,000 cfs, N 30
Operating at 12 VDC Increase Performance
15
DO
low impact on fish behavior
16
3 int sites
Fluvial Bull Trout Up and Downstream Movements
17
Detection Efficiency
Min. Detection Efficiencies U Up D Down
U 62, N 26 D 63, N 27
U 81, N 21 D 80, N 20
U 93, N 15 D 93, N 14
18
Spawn
Spawning Escapement Electronic fish counter -
No. of fish - Direction of travel Time lapse
Video - Species Double counting fish?
19
Identify
Add Remote PIT tag Interrogation For
example 113270247 Up Aug. 30 113270247
Down Sep. 9 113270247 Up Sep. 12 113270247
Down Sep. 18
20
Identify
Add Remote PIT tag Interrogation - Identify
individual fish movements - Improve accuracy of
fish count For example 113270247 Up Aug.
30 113270247 Down Sep. 9 113270247 Up Sep.
12 113270247 Down Sep. 18
21
Juvenile but
July of 2001, 115 mm FL
Oct. 2003
Jan. 2004
22
Adult but
Reservoir
Dam
23
Caught below dam
Spawning tributary
24
Caught below dam
25
All PIT 2003
26
RC
27
Spiral Antenna
Highly adaptable system site-specific antenna
designs
28
Reading frame
29
Reading frame
Detection area extends beyond the antenna frame
30
SC
Detection area extends beyond the antenna frame
31
multiple antennas
Multiple antenna sites synchronize or multiplex
32
Wired synch

• Multiple Antenna Sites
• - Wireless synch.
• - Wired synch.

33
Multiplex

• Multiple Antenna Sites
• - Wireless synch.
• - Wired synch.
• - Multiplex

34
Power

• Power
• - access to AC power

35
Power

• Power
• - access to AC power
• - battery swapping

36
Power

• Power
• - access to power line
• - battery swapping
• on-site generation

37
Handheld
Hand-held PIT tag Reader
- 300 - Compatible with FDX / HDX
38
Handheld
Hand-held PIT tag Reader
- 300 - Compatible with FDX / HDX
39
Handheld
Pocket PIT tag Reader
- Compatible with FDX / HDX
40
AcknowledgementsAlex HaroGayle Zydlewski
