Processes

1
Processes

• Chapter 3

2
Major topics in this chapter

• Communication takes place among processes.
• The concept of a process originates from the
  field of operating systems where it is generally
  defined as a program in execution.
• Clients and servers are important processes in
  distributed systems.
• Multithreading is an important technique for
  constructing client and server processes.
• General-purpose object servers form the basic
  means for implementing distributed objects.
• Process migration -- moving processes between
  different machines -- can help in achieving
  scalability and in dynamically configuring
  clients and servers.
• A software agent is yet another type of process.
  Multiagent systems consist of a collection of
  equally-important software agents that
  collectively attempt to reach a common goal.

3
Threads

• The granularity of processes as provided by the
  operating systems is too coarse to the
  construction of efficient distributed
  applications.
• Operating systems use processes to achieve
  concurrency transparency multiple independent
  processes share the same CPU and other system
  resources without inadvertently affecting the
  correctness of each others behavior.
• This concurrency transparency comes at a high
  price
• Process creation is expensive. The OS must
  allocate a complete independent address space and
  initialise memory segments by
• zeroing a data segment,
• copying the associated program into a text
  segment, and
• setting up a stack segment for temporary data.
• Switching the CPU between processes is expensive
  as well
• saving CPU context (register values, program
  counter, stack pointer, etc)
• modifying registers for MMU and invalidating
  address translation caches and
• swapping processes between RAM and disk.

4
Threads

• A finer granularity in the form of multiple
  threads of control per process makes it much
  easier to build distributed applications and to
  attain better performance.
• A thread is similar to a process in the sense it
  can also be seen as the execution of a (part of
  a) program.
• In contrast to processes, a thread context often
  consists of the CPU context, and no attempt is
  made to achieve a high degree of concurrency
  transparency concurrency control among multiple
  threads in the same process is left entirely to
  programmers.
• Implications of the multithreading approach
• Potential performance gain.
• Development of multithreaded applications require
  additional intellectual effort

5
Thread Usage in Nondistributed Systems
In a single-threaded process, whenever a
blocking system call is executed, the process as
a whole is blocked.

• Context switching as the result of IPC

6
Advantages of multithreading

• Blocking one thread does not block the whole
  process, thus improving system efficiency.
• It becomes possible to exploit parallelism when
  executing the multithreaded program on a
  multiprocessor system.
• Inter-thread communication can be significantly
  cheaper than IPC since there is no context switch
  between user mode and kernel mode (which is very
  expensive).
• Many applications are simply easier to structure
  as a collection of cooperating threads.
• E.g., for a word processor, separate threads can
  be used for handling user input, spelling and
  grammar checking, document layout, index
  generation, etc.

7
Approaches of implementing threads

• A thread package contains operations to
• create and destroy threads, as well as
  operations on
• synchronisation variables, e.g. mutexes and
  condition variables.
• A user-level thread library has the advantage of
  being cheap to create and destroy threads, to
  switch thread context. A major disadvantage is
  that invocation of a blocking system call will
  block the entire process to which the thread
  belongs (tricks exist to overcome those problems
  but none of them are satisfactory)
• OS kernel supported threads do not have these
  troubles but there is a high price to pay
  threads creation, deletion, synch., and context
  switching will have to be carried out by the
  kernel.

8
Thread Implementation

• Combining kernel-level lightweight processes and
  user-level threads.

9
Multithreaded clients

• Threads have the property of allowing blocking
  system calls without blocking the entire process.
  This property makes threads particularly
  attractive to distributed systems since its
  property of makes it much easier to express
  communication in the form of maintaining multiple
  logical connections at the same time.
• Developing a web browser as a multithreaded
  client makes it easy to support the browsers
  multiple concurrent activities
• e.g., local display and multiple simultaneous
  connections to the server.
• If the server is replicated, downloading data via
  multiple connections can be carried out in
  parallel, thus improving performance.

10
Multithreaded Servers (1)
Multithreading not only simplifies server
code but also makes it much easier to explore
parallelism to attain high performance.

• A multithreaded server organized in a
  dispatcher/worker model.

11
Multithreaded Servers (2)

• Three ways to construct a server.

12
The X-Window System
A major task of most clients is to interact
with a human user and a remote server.

• The basic organization of the X Window System

13
Client-Side Software for Distribution Transparency

• A possible approach to transparent replication of
  a remote object using a client-side solution.

14
Servers General Design Issues
3.7

• Client-to-server binding using a daemon as in DCE
• Client-to-server binding using a superserver as
  in UNIX

15
Other Design Issues

• Interrupting a Server
• Abruptly exit the client application, which will
  automatically break the connection to the server,
  which will eventually tear down the old
  connection.
• Use a separate server control endpoint to which
  the client sends out-of-band data.
• Send the out-of-band data using the same
  connection through which the client is sending
  the ordinary data. E.g., TCP.
• Stateless servers do not keep information on the
  state of its client.
• A Web server is stateless.
• Stateful servers does maintain information on its
  clients.
• E.g., a file server may allow a client to keep a
  local copy of a file (even for update). Such a
  server needs to keep track of the relationship
  between files and clients . This approach can
  improve the performance of read and write
  operations as perceived by clients.

16
Object Servers

• An object server acts as a place where objects
  live.
• An object server does not provide a specific
  service.
• Specific services are provided by the objects
  managed by the server.
• Objects may share neither code nor data.
• Good for security and for different
  implementations.
• Objects of the same class may share code.
• More efficient.
• Policies of threading
• One thread one server
• One thread one object
• One thread per method invocation
• requires concurrency control inside objects

17
Object Adapter (1)

• Organisation of an object server supporting
  different activation policies.

18
Object Adapter (2)
/ Definitions needed by caller of adapter and
adapter /define TRUEdefine MAX_DATA 65536 /
Definition of general message format /struct
message long source / senders identity
/ long object_id / identifier for the
requested object / long method_id /
identifier for the requested method /
unsigned size / total bytes in list of
parameters / char data / parameters as
sequence of bytes / / General definition of
operation to be called at skeleton of object
/typedef void (METHOD_CALL)(unsigned, char
unsigned, char) long register_object
(METHOD_CALL call) / register an object
/void unregister_object (long object)id) /
unregister an object /void invoke_adapter
(message request) / call the adapter /

• The header.h file used by the adapter and any
  program that calls an adapter.

19
Object Adapter (3)
typedef struct thread THREAD / hidden
definition of a thread / thread CREATE_THREAD
(void (body)(long tid), long thread_id)/
Create a thread by giving a pointer to a function
that defines the actual // behavior of the
thread, along with a thread identifier / void
get_msg (unsigned size, char data)void
put_msg(THREAD receiver, unsigned size, char
data)/ Calling get_msg blocks the thread
until of a message has been put into its //
associated buffer. Putting a message in a
thread's buffer is a nonblocking // operation.
/

• The thread.h file used by the adapter for using
  threads.

20
Object Adapter (4)

• The main part of an adapter that implements a
  thread-per-object policy.

21
Reasons for Migrating Code

• The principle of dynamically configuring a client
  to communicate to a server. The client first
  fetches the necessary software, and then invokes
  the server.

22
Models for Code Migration

• Alternatives for code migration.

23
Migration and Local Resources
Resource-to machine binding
Process-to-resource binding
GR Establish system wide, global reference.
MV move resource CP copy the value of the
resource. RB rebind process to local resource

• Actions to be taken with respect to the
  references to local resources when migrating code
  to another machine.

24
Migration in Heterogeneous Systems
3-15

• The principle of maintaining a migration stack to
  support migration of an execution segment (strong
  mobility) in a heterogeneous environment

25
Overview of Code Migration in D'Agents (1)
proc factorial n if (n ? 1) return 1
fac(1) 1 expr n factorial expr n
1 fac(n) n fac(n 1) set number
tells which factorial to compute set machine
identify the target machine agent_submit
machine procs factorial vars number script
factorial number agent_receive receive
the results (left unspecified for simplicity)

• A simple example of a Tel agent in D'Agents
  submitting a script to a remote machine (adapted
  from gray.r95)

26
Overview of Code Migration in D'Agents (2)
all_users machines proc all_users machines
set list "" Create an initially empty list
foreach m machines Consider all hosts in
the set of given machines agent_jump
m Jump to each host set users exec
who Execute the who command append
list users Append the results to the list
return list Return the complete list
when done set machines Initialize the set
of machines to jump toset this_machine Set to
the host that starts the agent Create a
migrating agent by submitting the script to this
machine, from where it will jump to all the
others in machines. agent_submit this_machine
procs all_users -vars machines -script
all_users machines agent_receive receive
the results (left unspecified for simplicity)

• An example of a Tcl agent in D'Agents migrating
  to different machines where it executes the UNIX
  who command (adapted from gray.r95)

27
Implementation Issues (1)

• The architecture of the D'Agents system.

28
Implementation Issues (2)

• The parts comprising the state of an agent in
  D'Agents.

29
Software Agents in Distributed Systems

• Some important properties by which different
  types of agents can be distinguished.

30
Agent Technology

• The general model of an agent platform (adapted
  from fipa98-mgt).

31
Agent Communication Languages (1)

• Examples of different message types in the FIPA
  ACL fipa98-acl, giving the purpose of a
  message, along with the description of the actual
  message content.

32
Agent Communication Languages (2)

• A simple example of a FIPA ACL message sent
  between two agents using Prolog to express
  genealogy information.
