Title: Dr Richard Reilly


1
Lecture 10
  • To insert your company logo on this slide
  • From the Insert Menu
  • Select Picture
  • Locate your logo file
  • Click OK
  • To resize the logo
  • Click anywhere inside the logo. The boxes that
    appear outside the logo are known as resize
    handles.
  • Use these to resize the object.
  • If you hold down the shift key before using the
    resize handles, you will maintain the proportions
    of the object you wish to resize.
  • Dr Richard Reilly
  • Dept. of Electronic Electrical Engineering
  • Room 153,
  • Engineering Building

2
SERIAL COMMUNICATION
  • Computerised control and data management systems
    require extensive digital communication between
    the processor and external devices such as
  •
  •

      keyboards       printers, plotters
connected locally or at some distance
video terminals       A/D converters
computer networks
  • Often rate in digital communication is in the
    order of
  •       a few bytes per second
  • Compare with communication on the data bus
    (million-bytes-per second)

3
SERIAL COMMUNICATION
  • In most cases, more economical to send the 8-bits
    of a data byte
  •       sequentially on a single transmission line
  •       repacking serialised bits into a parallel
    byte at receiving end.
  •
  • Thus information is transmitted where
  •       information normally consists of more than
    one bit
  •       the bits are sent along transmission line
    sequentially
  • ? separated in time rather than in space
    as the case in a parallel interface.

4
SERIAL COMMUNICATION
  • The basic concept of serial communications is
  • a parallel to serial converter at the T/x
  • and
  • a serial to parallel converter at the R/x
  • If sending information sequentially one question.

How do you know the start of a byte of data ?
5
Synchronous and Asynchronous
  • Need method of indicating the start of a byte or
    a word of data.
  •
  • Can divide serial communications into based on
    use of clock signal
  • synchronous and
  • asynchronous
  • Synchronous communication
  • uses clock signal as one of the communication
    signals.
  • Clock signal defines the transitions from one-bit
    to the next and the centre of the bit.

6
Synchronous and Asynchronous
  • Asynchronous communication does not use a clock
    signal as one of the communication signals.
  • Each Rx must generate its own local estimate of
    the clock used at the T/x.
  •
  •
  • Asynchronous uses less signals than synchronous
    communication but is usually slower.
  •

Asynchronous less signals -- slower
7
Synchronous Communication
  • A clock signal defines the bit positions

8
Synchronous Communication
  • Changes on the positive clock edge
  • Þ  on negative clock edge a new bit is latched in
    at R/x side.
  •
  • There is a half-a clock period to allow for
    propagation delay and ringing.

9
Synchronous Communicationwith Frame Sync
  • One means of defining the bits of the serial
    stream that correspond to a byte is to use an
    additional signal known as a frame sync.
  •
  • Hence a communication link could use
  •
  •       TxD Transmit Data line (serial data)
  •       TxFS Frame Sync Transmit
  •       Clk Clock (common to both T/x and R/x)
  •       RxD Receive Data
  •       RxFS Frame Sync Receive
  •       Gnd ground

10
Synchronous Communicationwith Frame Sync
  • A byte wide Frame Sync is high during the period
    of time the data corresponds to bits of the byte.
  • the R/X only clocks in the bits if TxFS is high.

11
Synchronous Communicationwith Frame Sync
  • For Bit Wide Frame Sync ? Frame Sync high only
    for first bit.
  • Hence R/X starts to latch in bits when it
    receives a Frame Sync pulse,
  • then latches in a total of 8 bits (must use an
    internal counter).

12
Serial Connections
  • Term full-duplex is used to describe transmission
    system where
  •       transmission occurs in both directions
    simultaneously
  •       such as a serial transmission with one
    line for each direction.

The half-duplex describes the transmission system
where       transmission occurs in both
directions but only one way at a time       as
would be constrained by a single shared line.
  • If transmission is only in one direction the term
    simplex is used.

13
Serial Connections
  • The T/x and R/x have to be configured for the
    same synchronous communication format.
  • The bit rate
  • Continuous Clock with Frame Sync
  • Byte/Bit Frame Sync
  • Word Length (number of bits sent each time)
  • Electrical connections between the device and the
    serial interface usually conform to a standard
    known as RS-232/V24.
  • this standard not only specifies the voltages but
    also the allocation of pins on the interface

14
How are the two transceivers connected ?
  • The two serial ports are connected by crossing
    over T/x and R/x lines.

15
RS-232
16
RS-232 Cable Lengths
Maximum Length (meters)
Data Rate (bps)
2400
120
4800
60
9600
30
19200
15
38400
7.5
57600
5
115200
2.5
17
Asynchronous Communication
  • With asynchronous serial communications the only
    connections necessary are
  • TxD
  • Rxd
  • Gnd
  • There are no clocks or Frame Syncs connected
    between the two serial ports.
  • As there are no synchronising signals present
  • ? must introduce one !!
  • Additional bits of data are inserted in TxD and
    RxD to allow the serial port to identify the
    first bit

18
Asynchronous Communication
  • The following bits are used.
  •
  • START Bit This is a 0. It is sent just before
    the data bits
  • DATA Bits Usually 7 or 8 data bits (LSB sent
    first)
  • PARITY Bit Used for error correction
  • STOP Bit This is a 1. One or two stops bits
    used after data.
  •
  • Either even or odd parity can be used.
  • The parity bit is chosen so that the number of
    ones in the data bits Parity is even or odd.
  • e.g. 8 data bits, 1 stop bit and even parity.

19
Asynchronous Communication
  • Due to these extra bits that are sent ?
  • Asynchronous transmission tends to be slower than
    synchronous
  • can be 20 of 30 slower
  • high speed transmission tends to use synchronous
    transmission format
  • The R/x must know the bit-rate (usually called
    the baud rate).
  • However, the baud rate is strictly speaking the
    number of pieces of information per second.

20
Asynchronous Communication
  • There are several standard rates of character
    transmission
  • 110, 300, 600, 1200, 2400, 4800, 9600, 19600,
    28800, 57600 bits per second
  •
  • Typically rate would be 9600 bits per second
  • ? each bit has a bit-period of 104 microseconds
  •
  • Using 7-bit ASCII
  • ? 1711 10bits
  • ? 960 characters per second.

21
Asynchronous Communication
  • Asynchronous systems use an external clock that
    is 16 times faster then the Bit rate.
  •
  • When the negative edge of the start pulse arrives
  • ? counts 8 clock cycles to find the approximate
    centre of start pulse
  •
  • The centre of the remaining bits is estimated at
    16 clock cycles intervals.
  •  ? the bit is read at the middle of its bit
    period of the T/X and R/X baud rates are the
    same.
  •
  • As a start bit arrives every byte
  • ? the point in time at which the bit is latched
    is re-synchronised every byte.
  • ? as there is a minimum of one start bit and one
    stop bit, the 1 ? 0 transition at the start bit
    is guaranteed.
