Transportation Slides

1
Transportation in a Supply Chain

• Chapter 9

2
Purpose of TransportationHow do you select
transportation option (object)?

3
Select from among many providers

4
Transportation Drivers

• How important is transportation cost?
• What are the modal options?
• You need to know
• Properties of various transportation options
• What determines Costs?
• What are their performance characteristics?
• What is the interface between shipper, carrier
  and receiver?
• What are some ways you can utilize transportation
  options?
• How do you decide which option to use?

5
How important is transportation costs?

6
Graphical Presentation
7
Truck Transportation cost to increase
dramatically.

• Turnover rate
• 119 per year for van drivers
• 4.5 if driver home every night
• Salaries
• 35,000 to 70.000
• Hours of Service rule changes
• 50 hours a week driving
• 35 hours loading, unloading and waiting
• Now all hours are on the 10 hour/day work week
• 3-5 increase in trucks on highway each year
• Fuel costs

8
New pressures on rail

• Shift of trailers and container to rail
• Increase in number of containers importing goods
  into US
• Increase demand for land bridge between West and
  East coast
• Large number of retiring rail workers

9
Airlines in severe cost crunch

• Older airlines have high wage rates developed
  during regulated era
• Competition from smaller startups with younger
  crews
• Limited airport capacity

10
Transportation Cost for specific product
11
What are the modes and types within mode?

12
Modes

• Water
• Maritime
• RO-RO
• Container can hold from 2500 to 6500 containers
  on one ship
• Tankers
• Oil-bulk-ore
• Ocean Going Barge
• Intercostal
• River
• Rail
• Class I
• Class III
• Short Haul - serves a few communities
• Private company owns railroad to serve its own
  plant

13
Coal River Traffic
14
River Container Traffic
15
Modes

• Truck
• For hire
• Private
• Air
• Airlines
• Commuters
• Taxis
• Freight
• Parcels

16
Local Delivery
17
Pipeline

• Petroleum
• Other Natural gas minerals
• Products that can be sent
• 38 grades of gasoline
• 7 grades of karosine
• 16 grades of home heating oil and diesel
• 1 grade of transmix
• 29 products are fungible not unique to shipper
  shipper will get same product but not actual
  product shipped

18
Pipeline quantities

• Large lines
• 75,000 to 3,200,000 barrels
• Small lines
• 2,500 to 350,000 barrels
• 1 barrel 42 US gallons
• Travel speed 3- 5 mph
• 14 to 24 days from Houston to NYC
• 18.5 days average

19
Number of Carriers

• Air
• Rail
• Water
• Motor
• Pipeline
• Transportation in Knoxville

20
What are the characteristics of each mode?

21
How important is each?
22
Cost by Mode

23
Visualization of Revenue/ton mile

24
Volume Summary 1998
25
How can you understand cost structure of each
mode?

26
Cost Structure

• Fixed Capacity Cost Incurred whether the firm
  operates or not - typically less than 15
• Right of way
• Airport contracts
• Capital equipment
• Variable Capacity Cost Incurred when operated
  whether anyone uses it or not
• Equipment maintenance
• Fuel
• Operating crew
• Direct Delivery Cost Incurred when people or
  goods are actually transported - typically less
  than 10
• Meals
• Travel agents commission

27
Economic of Capacity Organizations

• Fixed capacity cost fix regardless of activity
  level
• Scheduled capacity cost fixed regardless of
  load factor
• Out-of-pocket cost cost vary with load factor
• How does this structure affect the way the firm
  operates?

28
Joint and Common Costs

• Joint If you provide service you incur both
  costs return trip
• Common costs cost are common to all people
  using service

29
What are carrier concerns?

• Load balancing Why?
• Stable demand Why?
• Capacity Utilization Why?
• Handling Why?
• Consolidation, Disaggregation Why?
• Liability Why?
• Special services young children, COD, special
  delivery, negotiable bills of laden
• Compatibility of loads

30
Characteristics - Rail

• Leave car you load
• Must go to right of way or build one to where you
  want it to go
• Carload shipments
• Build not schedule trains
• Major cost and delay is switching yards
• 60,000 to 80,000 pound per car/ 100 Plus cars per
  train
• Containers can be loaded quickly
• Bulk Material loaded quickly

31
Characteristics - TL

• You load at your docks
• Container or van or reefer or specialized vehicle
• Accessible everywhere
• Direct, inexpensive, allow for DOT rules drive
  10 hour days
• Hard to find drivers Young people frequently do
  not want to drive
• Load balance avoid deadheading
• Scheduling
• Specialized Equipment
• Vans
• Reefers
• Specialized

32
Characteristics - LTL

• Have shipments waiting or trailer spotted
• Time delay and expense of Break Bulk terminals
• Problem mixing freight
• Driver problem

33
LTL vs TL operations

• Volume Move

• Small Shippments

Shipper
Shipper
Local Pickup
Sorting Hub
Direct Truck Load Shipment
Line Haul
Receiver
Sorting Hub
Local Delivery
Receiver
34
Rules of Thumb for LTL Costs

• Delivery costs to locations 200 miles or more
  will average 1.00 per mile.
• Delivery costs in the city will average up to
  3.00 per mile.

35
Characteristics - Maritime

• Heavy shift to containers, roll on-roll off or
  bulk
• Limited number of carriers, wait until they hit
  port, load and leave
• Transfer cost at port - 100/continer at
  Charleston you must get to port
• Travel around capes or through canals
• 1200 to 1800 to transport container across
  ocean

36
Two types of containers

• Rail, truck, ship,
• Medium value cargo
• Aircraft
• Plane specific,
• Light
• High value cargo

37

38
Container Advantage

• Security
• Seals on latches
• Only serial number on container
• Safety
• Metal boxes strong and protect cargo
• Workers are not near cargo

39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
(No Transcript)
43
(No Transcript)
44
(No Transcript)
45
(No Transcript)
46
Characteristics - pipeline

• Material critical pour point critical
• Pigs separate commodities but must be sequenced
• Slow but no weather problems
• Cheap
• Large initial investment
• Must have continuous flow volume limited

47
Pipeline Construction

48
Characteristics - air

• Light items
• Packing and size limitations
• Must get to airport and load
• Flight schedules
• Expensive
• Limitations on what can be shipped oxygen
  canister on Air Florida
• Weather restrictions
• Small containers typically not compatible with
  other containers

49
Characteristics parcel carriers

• Size limitations
• Home delivery 1.4 attempts
• Expensive
• Outstanding tracking
• Post Office is lowest cost last mile carrier
• Airborne airships from lands end to nearest post
  office for final delivery

50
One Lands End Shipping Mode

• Combination Move by Contain using multi modes

Lands End
Containers to Airport
Air to nearest city
Truck container to local post office
Post Office Delivery to home
Customer
51
Characteristics - Intermodal

• Allows advantages of each mode
• Transfer cost expensive and time consuming
• Require intermodal facilities rail-truck,
  water-rail-truck
• Usually require a broker or specialty firm to
  coordinate

52
Legal forms

• Through back to regulation
• Private Haul material they own
• Exempt Exempt from regulation
• Common Must transport for all at published
  rates
• Contract Contracts with a limited number of
  shippers Krogers, Burger King
• Who they can serve
• Liability standard

53
Liability Standard

• Liable for cargo
• Act of God
• Earthquake
• Act of Public Enemy
• Bombing by Enemy
• Terrorism raises interesting question
• Act of Government
• Quarantine of shipment
• Default of Shipper or Owner
• Inadequate packaging
• Inherent Nature of the Goods

54
What is role of land bridge?

• Water to port
• Rail to major port
• Water to rest of trip
• Common Routes

55
Why is containerization important?

• Containerization
• Palletizing
• RORO
• Intermodal (What is critical factor?)

56
Agencies

• Brokers
• Shippers Association
• Freight Forwarders
• Intermodal Marketing companies
• What is their function?

57
Direct Shipments
58
Milk Runs from Suppliers
59
(No Transcript)
60
Example of Software Calculations

• Truck Routing
• Identify the distance matrix
• Identify the savings matrix
• Assign Customers to vehicles or routes
• Sequence customers within routes
• Truck loading software

61
Your responsibility

• Understand the relationship between inventory,
  facilities, transportation and information system
  to serve customer expectations.
• I should be able to give a situation and you
  should be able to tell me what to change to
  respond

62
Local Delivery
63
Coal River Traffic
64
(No Transcript)
65
Ocean Going Barge
66
Intercoastal waterway bridge
67
Mississippi River Tow
68
Container Train
69
Rail switching yard (hub)
70
Load Container Ship
71
Loading Coal (Bulk)
72
Pipeline Pig
73
Eurasian Land Bridge
