BCP-38 demo

• Alan Barrett
• Geert Jan de Groot
• cast of thousands

2
Agenda

• BCP-38 DNS DDOS demo
• Build spoofed packet traffic generator
• be the bad-behaving customer
• Configure the network to filter
• be the responsible ISP

3
Basic network
DNS request
Client
DNS
DNS response
4
Network diagram
DNS
VICTIM
R
PC
.
Row B
Row C
Row J
5
Step 1 install and run software

• Download packet spoofing software
• Configure
• RunMore details on next pages

6
1(a) Download packet spoofing software

• cd HOME
• mkdir spoofing-demo cd spoofing-demo
• ftp 196.200.222.1
• login as anonymous
• cd /pub/e2/bcp38
• binary
• mget (enter a to get all files)

7
1(b) Configure

• From your PC, ping the IP address of your router
• ping -c 1 ip.ad.re.ss
• Find out and write down the MAC address of your
  router
• arp -an
• Edit spoof_script and change
• TABLE_ROW
• ROUTER_MAC

8
1(c) Run the spoofer

• chmod 755 spoof_script tcpreplay
• Start the generator (as root)
• ./spoof_script

9
Step 2 Observe spoofed packets and responses

• Instructors use tcpdump to capture traffic on
  backbone.
• Observe the spoofed packets, and responses to
  them.

10
Step 3 Enable unicast reverse-path filtering
(URPF)

• Login to router
• Configure
• interface fastEthernet0/0
• ip verify unicast reverse-path
• For all destinations that are routed outwards
  through this interface, incoming traffic in the
  opposite direction is allowed.

11
Step 4 See that it worked

• Observe that the tcpdump display stops showing
  spoofed packets
• show ip interface fastEthernet0/0
• Near the end, see verification drops

12
URPF variant for multi-homed customer

• ! access-list 42 will permit the routes
• ! that would otherwise fail the test
• ! (e.g. downlink through a different ISP)
• ip access-list 42 permit 192.0.2.0 0.0.0.255
• interface fastEthernet0/0
• ip verify unicast reverse-path 42

13
Another variant Filtering using access-group

• ! access-list 123 permits all packets
• ! from the customer
• ip access-list 123 permit ip 192.0.2.0 0.0.0.255
  0.0.0.0 255.255.255.255
• interface fastEthernet0/0
• ip access-group 123 in
• This is less efficient and more difficult to
  configure
