Designing a Tractor Lift

1
Designing a Tractor Lift

• Engineers in Development

Final Presentation Tuesday, December 14, 530 PM
2
Client

• Mark Novak
• AgrAbility Project
• 460 Henry Mall
• UW Madison
• Madison, WI 53706
• menovak_at_wisc.edu

3
Problem Overview

• Farmers are an essential part of our economy.
• The average age of a farmer is 53.
• As the average age of farmers increases, so does
  the number of farmers with disabilities.
• It is difficult for many of these farmers to get
  into the cab of their tractors.
• Some forms of aid do exist, but they are often
  inadequate or too expensive.

4
Problem Statement

• Our task is to design a mounted platform lift
  that will safely transport a farmer with limited
  mobility from ground level to the tractor cab.
  The lift needs to be safe, reliable, and
  accessible by a non-disabled person.

5
Criteria

• Safe
• Reliable
• Durable
• Cost-efficient
• Easily operated by one person
• Allows people without limited mobility to access
  the tractor
• Motor operated by tractor battery

6
Brainstorming Systems
7
Brainstorming Platform
8
Our Design Overview

• Our design was made to be used with the John
  Deere 9420T tractor series.

The lift will ride up the stairs using a power
screw and a guide rail.
9
Our Design Safety

• The platform has safety rails.
• The grip-strut floor prevents slipping.
• The kill switch braking system prevents an
  accident incase something breaks.

• The extending platform ensures that the farmer
  does not need to step over large gaps.

10
Our Design Reliability

• The power screw has been proven to be very
  reliable and long-lasting.
• Guide rail keeps the weight distributed.
• The weather resistant materials drastically
  reduce wear and tear over time.

• Our design doesnt have a lot of
  parts, so there is less that can go wrong.

11
Our Design Versatility

• The lift is usable by both handicapped and
  non-handicapped people.
• A person with limited mobility would ride the
  lift up using the controls on the lift.
• A person without limited mobility would walk
  through the lift and up the stairs.
• Controls in the cab of the tractor can be used to
  raise or lower the lift for ground clearance.

12
Pictures of Final Design
2D view of platform with dimensions
2D view of lift with dimensions
13
Pictures of Final Design
Front View
Side View
14
(No Transcript)
15
Testing the Lift

• Methods of Testing
• Amount of Weight the lift is able to hold
• Should be at least 500 lbs in real life
• Speed of the lift
• Should be roughly 10 seconds
• Results of Testing
• We found that the lift would easily be able to
  lift the necessary weight.
• The speed was approximately 14 seconds, which was
  found to be a good, safe speed.
• Difficulties of the testing process.
• The weight was difficult to scale down to our
  model.
• Our model was a lower quality then the real life
  model (plastic stairs).

16
Pricing

• 6ft Power Screw 1,100
• Powder Coating. 600
• Piping..160
• 26x26 Platform...150
• 5HP Motor...400
• Miscellaneous.500
• Electronics
• Nuts and Bolts
• Total estimated Cost of parts...2,910

17
Pros and Cons
18
Conclusion

• It is necessary that farmers are allowed to
  continue their farming.
• Tractor lifts are vital for some farmers to do
  this.
• Our lift is a safe reliable alternative to what
  is on the market now.

19

• Questions?
• Comments?
