Planning with Local Search

1
Planning with Local Search

• MERS Seminar Lecture
• March 6, 2003
• Jonathan Kennell

2
Presentation Outline

• Planning Overview
• What is planning? 5 mins.
• Taxonomy of planners 40 mins.(or everything
  you ever wanted to know about planning in
  approximately 40 minutes)
• 5 minute break
• LPG
• Background information (WalkSAT) 10 mins.
• Linear action graphs and precedence graphs 10
  mins.
• WalkPlan planning algorithm 10 mins.
• Example 10 mins.

3
What is Planning?

• Input
• Set of world-states
• Action operators (fn world-state ? world-state)
• Initial world-state
• Goal (possibly a partial state / set of
  world-states)
• Output
• Ordering of actions

From 6.834J POP lecture
4
World State

• Set of facts and their degree of truth
• Examples
• (Student Jonathan) // true
• (Likes Jonathan Golf) // false
• (Graduating Jonathan June) // unknown
• Note lisp notation used extensively in planning
  community
• Most planners dont consider unknown facts

5
Planning Operators

• Fn world-state ? world-state
• Generally use STRIPS format
• Preconditions facts that must be true before
  action can occur
• Effects facts that become true (or false) after
  the action occurs
• Extra properties
• Separate start / invariant / end conditions and
  effects
• Durations
• Resource constraints

(action Move (params ((robot ?r) (location
?a) (location ?b)) (preconds (at ?r ?a))
(effects (and (not (at ?r ?a)) (at ?r ?b))))
6
Mutual Exclusion

• Sometimes planning operators conflict with each
  other we call a pair of conflicting operators
  mutex
• Examples of mutex actions
• Interference A deletes precondition or effect of
  B
• Competing Needs A and B have mutex preconditions
• Planner must ensure no mutex actions co-occur.

7
What is a plan?

• A plan is an ordering of actions that will
  transition the system from the initial state to
  the goal state.

8
Completeness / Consistency / Minimality

• Complete Plan
• A plan is complete IFF every precondition of
  every activity is achieved.
• An activitys precondition is achieved IFF
• The precondition is the effect of a preceding
  activity (support), and
• No intervening step conflicts with the
  precondition (mutex).
• Consistent Plan
• The plan is consistent IFF the temporal
  constraints of its activities are consistent (the
  associated distance graph has no negative
  cycles), and
• no conflicting (mutex) activities can co-occur.
• Minimal Plan
• The plan is minimal IFF every constraint serves a
  purpose, i.e.,
• If we remove any temporal or symbolic constraint
  from a minimal plan,the new plan is not
  equivalent to the original plan

9
Variations on Classical Planning

• Temporal planning
• Actions have durations
• Planning with resources
• Facts can be quantified
• Planning with uncertainty
• Effects / durations of actions not guaranteed

10
Taxonomy of Planners
Planners
11
Forward Chaining / Backward Propagation

• Searches through entire plan-space by
  non-deterministically adding actions to plan
  candidates.
• Advantages
• generative (does not require strategies)
• expressive (can handle time, resources, easily)
• Disadvantages
• Inherently slow (plan-space is enormous)

12
Forward Chaining Example
Familiar tradeoff Efficient pruning methods
versus optimality.
13
Case Study TLPlan

• TLPlan (Temporal Logic Planner) by Fahiem Bacchus
  and Froduald Kabanza
• TLPlan is based on a forward-chaining planner
• TLPlan uses domain-dependent temporal logic to
  prune the search space

14
TLPlan First-order Temporal Logic

• Definition First-order linear temporal logic
• standard first-order logic, plus
• U (until), ? (always), ? (eventually), ? (next)
• Bounded quantifiers
• ?xy? ? ?x . y(x)??(x)
• ?xy? ? ?x . y(x)??(x)
• Example
• ?(on(B,C) ? (on(B,C) U on(A,B)))
• Asserts that whenever we enter a state in which B
  is on C it remains on C until A is on B

15
TLPlan Formula Progression Algorihtm

• The Progress algorithm is used to check control
  strategies as the system searches for a plan.
• Inputs An LTL formula f and a world w (generated
  by forward-chaining)
• Output A new formula f, also expressed as an
  LTL formula, representing the progression of f
  through the world w.
• Algorithm Progress(f,w)
• Case
• f ? is atomic if w entails f, f TRUE,
  else f FALSE
• f f1 ? f2 f Progress(f1,w) ?
  Progress(f2,w)
• f ?f1 f ?Progress(f1,w)
• etc. (see paper for complete algorithm)

16
TLPlan Example
Forward chaining begins
Rules
Etc.
(Any color)
This thread is efficiently guided by the
rules This thread is not guided well since no
rules apply.This results in pure
forward-chaining search.
17
TLPlan Review

• TLPlan has been around in various implementations
  since 1995, although improvements have been made
  as recently as last year.
• TLPlan functions initially as a forward-chaining
  planner, but can use logical rules to guide its
  search and prune unfeasible threads.
• TLPlan was the fastest domain-specific planner in
  the 2002 AIPS competition.

18
Case Study TLPlan

• TLPlan is a temporal forward chaining planner
  that uses temporal logic to help prune the search
  space.
• Temporal logic is an extension of normal
  first-order logic that includes durative
  constructs such as always and eventually,
  etc.
• Goals are specified using temporal logic to
  require not only goal conditions, but goal
  sequences.
• Tells the planner not only what to achieve, but
  how to achieve it
• Any candidate plan that is inconsistent with the
  temporal logic constraints is pruned.

19
Domain Knowledge

• Planning is hard the most general planners are
  extremely slow
• To increase speed, some planners sacrifice
  generality by using domain-specific strategies.
• TLPlan encodes the strategy into the goal
  specification, while other planners decouple the
  goals and the strategies.

20
Forward Chaining Speedup

• Many researches have focused on discovering ways
  to help speedup domain-independent forward
  chaining planners.
• Ex. SAPA by Minh B. Do Subbarao Kambhampati
• Methods focus on estimating plan cost using
• Relaxed plan-graphs
• Estimated remaining cost to goal
• Cost metrics
• Ex. actions, plan duration, etc.

21
Taxonomy of Planners
Planners
22
Plan Graph

• Plan-graph based planners first construct a
  compact representation of the plan-space (the
  plan-graph), and then search that space.
• Plan-graphs contains all possible plans up to a
  certain size, excluding incomplete plans with
  co-occurring binary mutex actions.
• Plan-graphs do not exclude all invalid plans, and
  depending on the domain may yield extremely
  efficient or inefficient results.
• Advantages
• generative
• much faster than most forward-chaining planners
• plan-graph can be generated in polynomial time
  and space
• Disadvantages
• plan-graphs are less expressive (resources and
  time difficult)
• in certain domains, search of plan-graph can be
  very inefficient

23
Forward Chaining vs. Plan Graph
Forward Chaining
Plan Graph
24
Case Study Graphplan
Note the compact structure in this graph its
polynomial in size!
25
Mutex Relationships
26
Case Study LPGP

• Idea
• use Graphplan to identify complete plan (action
  structure)
• then use Linear Programming to determine plan
  consistency and perform scheduling (assign
  durations to actions)
• Advantage
• Two-phase approach accomplishes temporal planning
  with the speed of a plan-graph based planner
• Disadvantages
• Cannot optimize over time (only optimizes over
  makespan)
• Two-phase approach is potentially very
  inefficient
• no temporal conflicts are used to guide Graphplan
  search
• search not incremental LP must be started from
  scratch each time

27
Taxonomy of Planners
Planners
28
Macro Decomposition

• Operates similar to context-free grammar
• planner non-deterministically expands
  macro-activities until all plan actions are
  primitive.
• rules ensure that planner only explores space of
  complete plans
• Planner still must ensure plan consistency.
• Advantages
• Fast
• Disadvantages
• all achieving strategies must be pre-encoded into
  macros
• non-optimal explores restricted plan-space,
  potentially excluding optimal solutions

29
Case Study SHOP2

• SHOP2 by Dana Nau, Hector Munoz-Avila, Yue Cao,
  Amnon Lotem and Steven Mitchell
• SHOP2 works similar to the task-decomposition
  mechanism in Kirk
• SHOP2 problems consist of
• Operators (with preconditions, add-effects and
  delete-effects)
• Methods (rules for how to progress the plan)
• Initial conditions and goals
• SHOP2 is fairly fast, but all plan happenings
  must be pre-designed (at some level) by a
  programmer.
• SHOP2 plans do not support concurrency

30
SHOP2 Example
(defdomain basic-example ( (operator (pickup
?a) () () ((have ?a))) (operator (drop ?a)
((have ?a)) ((have ?a)) ()) (method (swap ?x
?y) ((have ?x)) ((drop ?x) (pickup ?y))
((have ?y)) ((drop ?y) (pickup
?x))))) (defproblem problem1 basic-example
((have banjo)) ((swap banjo kiwi)))
Preconds Delete-effects Add-effects
Condition Strategy
Allows one method todecompose into
multiplepossible subplans, dependingon the
current state
Initial Condition
Start Strategy
31
SHOP2 In Action
(defdomain basic-example ( (operator (pickup
?a) () () ((have ?a))) (operator (drop ?a)
((have ?a)) ((have ?a)) ()) (method (swap ?x
?y) ((have ?x)) ((drop ?x) (pickup ?y))
((have ?y)) ((drop ?y) (pickup
?x))))) (defproblem problem1 basic-example
((have banjo)) ((swap banjo kiwi)))
(defdomain basic-example ( (operator (pickup
?a) () () ((have ?a))) (operator (drop ?a)
((have ?a)) ((have ?a)) ()) (method (swap
banjo kiwi) ((have banjo)) ((drop banjo)
(pickup kiwi)) ((have kiwi)) ((drop kiwi)
(pickup banjo))))) (defproblem problem1
basic-example ((have banjo)) ((swap banjo
kiwi)))
State
(have kiwi)
?
?
(have banjo)
DONE
32
Case Study SHOP2
33
Case Study Kirk TPN Planner
Macro-Activity() l,u
Decomposition 1
Decomposition 2
34
5 Minute Break
35
Presentation Outline

• Planning Overview
• What is planning? 5 mins.
• Taxonomy of planners 40 mins.(or everything
  you ever wanted to know about planning in
  approximately 40 minutes)
• 5 minute break
• LPG
• Background information (WalkSAT) 10 mins.
• Linear action graphs and precedence graphs 10
  mins.
• WalkPlan planning algorithm 10 mins.
• Example 10 mins.

36
Taxonomy of Planners
Planners
37
Local Search WalkSAT

• WalkSAT is a randomized algorithm for solving SAT
  (propositional satisfiability) problems.
• It builds on the DPLL algorithm, but utilizes
  local search and randomness.

38
WalkSAT

• Problem
• Find a satisfying assignment to a logic formula
• (A !B) (B !C) (C !A) (A B
  C)
• WalkSAT
• Pick a random assignment to the variables
• Until formula satisfied (or up to some max of
  iterations),
• Choose an unsatisfied clause and enumerate the
  ways of adjusting the variables in order to
  satisfy it
• With probability p
• Choose the best-utility adjustment
• Else
• Choose a random adjustment

39
WalkSAT Example

• (A !B) (B !C) (C !A) (A B
  C)
• Pick !A, !B, !C
• (A !B) (B !C) (C !A) (A B
  C)
• Options are to switch A, B, or C
• Pick A, !B, !C
• (A !B) (B !C) (C !A) (A B
  C)
• Options are to switch A or C
• Pick A, !B, C
• (A !B) (B !C) (C !A) (A B
  C)
• Options are to switch B or C
• Pick A, B, C
• (A !B) (B !C) (C !A) (A B
  C)
• Formula Satisfied!

40
WalkSAT Discussion

• WalkSAT has proven to be very fast at solving
  complicated SAT problems
• WalkSAT can solve some problems that systematic
  algorithms simply cant handle
• Due to randomness, WalkSAT is incomplete
• WalkSAT may fail to discover a solution

41
Introduction to LPG

• LPG (local search for plan-graphs) by Alfonso
  Gerevini and Ivan Serina
• Blackbox mapped the planning problem to a CSP and
  solved it using a SAT solver.
• LPG unifies the planning and WalkSAT algorithms
  to create the WalkPlan search algorithm.

42
LPG Big Idea

• Big Idea
• Start with a random plan
• While plan is incorrect / inconsistent
• Identify and repair conflict
• Basically the same idea of WalkSAT, but applied
  to a special form of plan-graph

43
Temporal Action Graphs

• Definitions
• Action-graph the subset of a plan-graph
  containing the action layers
• Support a fact is said to be supported if it
  is achieved by some action in the previous action
  layer
• Conflict
• a mutex between two actions
• an action with an unsupported precondition

44
Linearization of Action Graphs

• An Action Graph can be made linear by allowing
  only one action per action layer.
• The layers no longer explicitly represent an
  ordering of time (temporal concurrency is still
  possible)
• The layer ordering simply presents an action
  sequence for the purposes of establishing fact
  support relationships.

45
Example Linear Action Graph
A B C
A B C
A B C
A B C
A B C
A plan-graph consists of alternating fact layers
and action layers.
The actions alone constitute an action graph.
LPG operates directly on the action graph
structure, inserting and removingactions from
various action layers as it repairs incomplete
plans.
46
Example Temporal Action Graph
47
Conflicts and Repair

• An incomplete plan is manifested as an action
  graph with conflicts.
• Example conflicts with resolution (repair)
  strategies

Conflict Description Conflict Resolution Strategies
Permanent mutex between two actions in the same action layer Remove one of the actions
Precondition mutex between two actions in the same action layer Remove one of the actions
Precondition mutex between two actions in the same action layer Add support for one of the mutex preconditions
Unsupported precondition for an action in an action layer Add an action to the previous action layer that achieves the unsupported precondition
Unsupported precondition for an action in an action layer Remove the action whose preconditions are not satisfied
48
LPG Algorithm
LPGs WalkPlan Planning Algorithm

• LPG
• Generate an initial dummy plan, P, either
• Randomly
• By adding actions to support all facts ignoring
  mutexes, or
• Via some front-end plan generator
• Randomly choose a conflict in the action-graph,
  C
• Identify all possible ways of resolving C and
  evaluate them using the action evaluation
  function
• Resolution techniques include removing one of
  two mutex actions, adding a supporting action for
  an unsupported fact, or removing an action that
  has an unsupported precondition
• If a conflict resolution has cost 0, the plan is
  complete
• Note The action evaluation function uses
  Lagrange multipliers to dynamically weight the
  different factors in the action evaluation
  function
• If a resolution introduces no new conflicts,
  apply it and go to step (2)Else,
• with probability p, randomly choose a resolution,
  apply it and go to step (2)
• with probability 1-p, choose the lowest cost
  conflict resolution, apply it and go to step (2)
• Note The resolution step includes a mechanism
  for extending the plan-graph

Generate Initial Plan
Choose Conflict
Resolve Evaluate
Resolution Selection
49
LPG Example
A B C
A B C
A B C
A B C
A B C
Permanently mutex actionsin the same action
layer(resolved by removing one of the two
actions)
Unsupported precondition(resolved by adding
achievingaction at previous action layer)
Unsupported precondition(resolved by removing
theconflicting action)
Unsupported precondition(resolved by adding
achievingaction at previous action layer)
Initial Conditions ( nil ) Goals ( A, B, C
) Actions A0 preconds ( nil ) effects ( A ) A1
preconds ( A ) effects ( A, B ) A2 preconds ( A,
B ) effects ( C )
Note No-ops are propagated during conflict
resolution
Initial dummy plan
Identify conflict
Resolve conflict
Plan complete
50
LPG Analysis

• Advantages
• LPG is fast four orders of magnitude faster
  than the leading optimal planners
• LPG is domain-independent
• LPG can easily handle resources and durative
  actions
• Disadvantages
• LPG is randomized, so plans are not usually
  optimal and often contain extraneous actions
• LPG includes option to continue searching for
  multiple solutions, in the hope of finding better
  plans
• While maintaining expressivity, LPG sacrifices
  optimality for speed.

51
AIPS 2002 Results (subset)
Planner Problems Solved Problems Attempted Success Ratio Capabilities
SHOP2 2nd place (hand-coded) 899 904 99 (Strips, Numeric, HardNumeric, SimpleTime, Time, Complex)
TLPlan 1st place (hand-coded) 894 894 100 (Strips, Numeric, HardNumeric, SimpleTime, Time, Complex)
LPG 1st place (fully-automated) 372 428 87 (Strips, Numeric, HardNumeric, SimpleTime, Time)
52
Summary

• Planning is hard!
• We want planners that
• are fast
• are domain-independent
• are optimal
• handle durative actions / resources / uncertainty
• Want a speedup?
• Sacrificing expressivity helps
• Sacrificing optimality helps more
• Sacrificing generality helps the most
• LPG is todays best planner than is
  domain-independent, expressive, and fast to
  achieve speed, it sacrifices optimality and uses
  local search.

53
Planning References

• Planning in general
• Russell and Norvig, Artificial Intelligence A
  Modern Approach, section IV, Prentice Hall 2nd
  edition (December 20, 2002)
• AIPS International Planning Competition, 2002
• http//www.dur.ac.uk/d.p.long/competition.html
• Graphplan
• A. Blum and M. Furst, Fast Planning Through
  Planning Graph Analysis, Artificial
  Intelligence, 90281300 (1997).
• www.cs.cmu.edu/avrim/graphplan.html
• LPG
• A. Gerevini and I. Serina, Planning through
  Stochastic Local Search and Temporal Action
  Graphs, technical report from Universita degli
  Studi di Brescia, November, 2002.
• prometeo.ing.unibs.it/lpg/
