MasterColor CDM Elite

1
MasterColor CDM Elite
Philips Lighting Company
January 2008
2
The latest in a long line of CDM innovations
MasterColor CDM Elite

• Philips invented its CDM technology in 1994
• Constant RD has lead to many MasterColor
  innovations
• Now, Philips introduces MasterColor CDM Elite
  The Next Generation MasterColor

1994 2000
Now
3
Features versus existing MasterColor
MasterColor CDM Elite

• Improved Design Lumens
• Improved Lumen Maintenance
• Improved Initial Lumen Output
• Improved Color Quality
• Improved Color Rendering
• Improved Red

With MasterColor CDM Elite
Approximate lumen output at 40 of lamp rated
average life with vertical operation of the lamp.
4
Basic information
MasterColor CDM Elite

• CDM 70W T4 T6 in 3000K
• Available
• Universal burning position
• CDM 39W T4 T6 in 3000K
• Planned availability June 08
• Samples available
• Must be operated in vertical position ( 60)
• CDM 150W T6 in 3000K
• Planned availability Q2 2009
• Dimensions, LCL and base are same asexisting
  CDM T6 G12 T4 G8.5
• CDM Elite for use with electronic ballasts
  only
• CDM Elite 39W M130/E
• CDM Elite 70W M139/E
• CDM Elite 150W M142/E

With MasterColor CDM Elite
5
Improved Design Lumens
With MasterColor CDM
With MasterColor CDM Elite
6
Improved Initial Lumens
With MasterColor CDM
With MasterColor CDM Elite
7
Lumen Output Over Time
Approximate lumen output at 40 of lamp rated
average life with vertical operation of the
lamp. Based on operating MasterColor lamps
4,200 hours annually.
8
Lumen Output Over Time
Rated Avg. Life CDM T4 Elite is 12 khrs (Existing
CDM T4 is 10 khrs)
Approximate lumen output at 40 of lamp rated
average life with vertical operation of the
lamp. Based on operating MasterColor lamps
4,200 hours annually.
9
Lumen Output Over Time
Approximate lumen output at 40 of lamp rated
average life with vertical operation of the
lamp. Based on operating MasterColor lamps
4,200 hours annually.
10
Lumen Output Over Time
Rated Avg. Life CDM T4 Elite is 12 khrs (Existing
CDM T4 is 10 khrs)
Approximate lumen output at 40 of lamp rated
average life with vertical operation of the
lamp. Based on operating MasterColor lamps
4,200 hours annually.
11
How does it help the retailer?
Improved Design Lumens

• New installations / remodeling
• Energy savings up to 44
• Lower initial costs by using fewer fixtures
• Upgrade existing CDM to CDM Elite
• Higher light level in store (ambient)
• More focus on merchandise (more accent)
• Dimensions, LCL and base are same
• as existing CDM T6 G12 and T4 G8.5
• Easily adapted into current CDM fixture
  specification

CDM Elite versus existing CDM.
12
Improved Color Quality
With MasterColor CDM
With MasterColor CDM Elite
620 680 NanoMeter Red part of spectrum
13
Improved Color Quality
What does it mean to the retailer?
The color performance of MasterColor CDM Elite
has been even further enhanced

• Improved overall color rendering
• Merchandise looks better
• True skin tones

BEFORE
BEFORE
AFTER
AFTER
14
(No Transcript)
15
Dimming of CDM (Elite) for retail applications

• Dimming of CDM lamps is not recommended since
  this may lead to significant deterioration of
  lamp performance
• Change in color towards blue/green
• Fast lumen depreciation due to severe blackening
  of burneras the electrodes are operated in a
  too cold condition causingexcessive loss of
  electrode material during the dimmed operation
• Life may be shortened since accelerated electrode
  wear increaseselectrode distance leading to a
  rise in the lamp voltage
• High re-ignition peaks may lead to occasional
  extinguishing of dimmed lamps
