Maj Brian Schroeder

1
Winter T-PARCWC-130J

• Maj Brian Schroeder

2
WC-130J Capabilities
3
Overview

• Tasked Missions
• Observations
• Capabilities/Range
• Limiting Factors
• Crew Cycle
• Operating Cost/Benefits

4
Tasked Missions

• Plan of the Day
• Issued daily by CARCAH _at_ NHC
• Informs of location/time of mission
• Identifies track (example)
• Alaska 2009 Deployment
• Mid-Jan to Mid-Feb
• Supporting the 2009 Winter Storm Reconnaissance
  Program

5
Example Winter Storm Track
Drop
Recco
Recco obs taken between each point Drops
accomplished at each point
6
Observations

• Recco (Horizontal)
• Taken at standard pressure levels
• 250/300/400mb height in winter storms
• High Density (HDOB)
• Continuously gathered record every 30sec
• Dropwindsonde (Vertical)
• Full profile from FL to SFC
• Dropped from standard pressure levels

7
Recco Example
97779 19304 20155 80200 30500 07042 08069 /3142
40525 RMK AF306 1206A FELIX OB 16 SWS
026KTS
8
Dropwindsonde Example
UZNT13 KNHC 040547 XXAA 54068 99143 70817 04541
99941 26609 19033 00/// ///// ///// 92150 25203
19533 85892 21001 21026 70572 18856 88999 77999
31313 09608 80533 61616 AF309 1306A FELIX
OB 10 62626 EYE SPL 1433N08173W 0537 MBL WND
20032 AEV 00000 DLM WND 20 526 941757 WL150 19533
075 XXBB 54068 99143 70817 04541 00941 26609
11850 21001 22794 19825 33772 20450 44715 18457
55704 19857 66697 18056 21212 00941 19033 11850
21026 22786 22026 33757 20016 44697 27010 31313
09608 80533 61616 AF309 1306A FELIX OB 10
62626 EYE SPL 1433N08173W 0537 MBL WND 20032
AEV 00000 DLM WND 20 526 941757 WL150 19533 075
9
SFMR
Located outboard of 4 engine
10
HD Data(Includes SFMR Wind/RR)
30 sec data, 20 lines per message Time Lat
Lon P(A) Ht SLP T Td
WD/WS PW SW RR
185800 1413N 07851W 6965
02865 9697 115 115 214093 095 091 000 185830
1415N 07853W 6951 02823 9626 120 120 208083 093
092 002 185900 1416N 07854W 6983 02734 9561 131
131 201049 058 080 004 185930 1417N 07856W 6972
02718 9516 148 122 179022 032 044 002 190000
1417N 07858W 6967 02716 9491 165 113 136004 014
031 003 190030 1417N 07900W 6971 02729 9507 164
118 001030 038 031 004 190100 1417N 07900W 6971
02729 9534 157 129 005047 056 041 024 190130
1418N 07902W 6926 02844 9539 196 107 006068 078
085 019 190200 1420N 07903W 7000 02773 9566 199
114 015081 082 096 023
11
SFMR
SFMR data may be questionable at high altitude
due to algorithm assumptions Reliability of data
undetermined in winter environment High altitude
data acquired during Summer T-Parc but results
not yet reported.
12
Capabilities/Range

• Synoptic max Altitude is 34,000 ft
• (highest practicable in winter storms)
• Range
• Max 13.5 hour _at_ 30,000 ft 4,200nm
• 1 hour transit time to/from track and then 6-10
  hours along track
• Dependent upon assigned track

13
Limiting Factors

• Maintenance
• Dual tasking
• One crew and one aircraft

14
Operating Cost

• Cost
• 100 operational hours for 30 days 250K
• 200 operational hours for 60 days 500K

15
Benefits WSRP

• Objective
• Improve forecasts of significant winter weather
  events through targeted observations in data
  sparse Northeast Pacific Ocean
• Adaptive approach to collection of observational
  data
• Only prior to significant winter weather
  events of interest
• Only in areas that influence high impact event
  forecasts
• Results
• (Past 9 yrs) 70 of targeted numerical
  weather predictions improve
• 10-20 error reduction for high impact event
  forecasts
• 12-hour gain in predicting high impact events
  earlier warnings possible

16
Additional Information

• SatCom Ground Station at Guam or JTWC
• How do we obtain tasking (CARCAH)
• Possible alternate staging areas
• Buoy drops
• Duration - 30 or 45 or 60 days
• When do you want us on-station

17
Questions?
18
Contact Info
Maj Brian Schroeder 817 H. Street Suite
207 Keesler AFB, MS 39534 DSN 597-3407/Comm (228)
377-3407 brian.schroeder_at_keesler.af.mil
