Sensory Systems

1
Sensory Systems
? ?? ??? ????????ilhoha_at_inje.ac.kribst.inje.ac
.kr ????gt???
2
Sensory Systems

• Sensory Cells Transduction of Stimuli into
  signals for nervous system. Modified neurons
• 1. Chemoreceptors Responding to Specific
  Molecules
• 2. Mechanoreceptors Detecting Stimuli that
  Distort Membranes
• 3. Photoreceptors and Visual Systems Responding
  to Light

3
Figure 45.1 Sensory Cell Membrane Receptor
Proteins Respond to Stimuli
1. Mechanoreceptor
2. Chemoreceptor
3. Photoreceptor
4
Sensory Cells and Transduction of Stimuli

• Sensory cells have
• membrane receptor proteins that detect a stimulus
  and respond by altering the flow of ions across
  the plasma membrane.
• The resulting change in membrane potential causes
  the sensory cell to fire action potentials or to
  change its secretion of a neurotransmitter onto
  an associated neuron that fires action
  potentials.
• The intensity of the stimulus is encoded in the
  frequency of the action potentials produced.

• Simply depolarization events in sensory cell,
  interpreted in different ways according to the
  different places in the CNS.

5
Sensory Cells and Transduction of Stimuli

• Some information is sensed without our being
  conscious of it.
• levels of CO2, blood sugar, and O2. important
  for the maintenance of homeostasis.
• Sensory cells and other types of cells form
  sensory organs, such as eyes, ears, and noses.
• Sensory systems
• the sensory cells the associated structures
  neuronal networks that process the
  information.

6
Sensory Cells and Transduction of Stimuli

• In ionotropic sensory detection, the receptor
  protein itself is part of the ion channel and, by
  changing its conformation, opens or closes the
  channel pore.
• In metabotropic sensory detection, the receptor
  protein is linked to a G protein that activates a
  cascade of intracellular events that eventually
  open or close ion channels.

• The affected receptor ? action potential ?
  nervous system.
• stimulus ? change in the resting membrane
  potential of a sensory cell receptor potential

7
Figure 45.2 Stimulating a Sensory Cell Produces
a Receptor Potential
8
Sensory Cells and Transduction of Stimuli

• Primary sensory cells generate action potentials
  directly. An example is the crayfish stretch
  receptor.
• Secondary sensory cells generate action
  potentials indirectly by inducing the release of
  neurotransmitter.

• Adaptation
• respond less when stimulation is repeated

9
ChemoreceptorsResponding to Specific Molecules

• Chemoreceptors
• detect chemical stimuli.
• Chemoreceptors are responsible for smell and
  taste, and for monitoring internal environmental
  factors such as CO2 and O2 in the blood.
• Corals, for example, can detect protein or even a
  single type of amino acid, causing them to extend
  tentacles in search of food.

10
Figure 45.3 Some Scents Travel Great Distances
(Part 1)

• Pheromones - chemical signals to attract mates.
• Female silkworm moths pheromone (bombykol) from
  glands at the tip of the abdomen, and males have
  its receptors on their antennae.
• A single molecule can stimulate a perceivable
  action potential!! Activated 200 hairs or more /
  second ? looking for female.

11
ChemoreceptorsResponding to Specific Molecules

• Chemoreceptor Olfaction.
• In vertebrates, olfactory sensors in epithelial
  cells at the top of the nasal cavity.
• The axons of these sensors project to the
  olfactory bulb of the brain.
• The dendrites end in olfactory hairs at the
  surface of the nasal epithelium.

12
Figure 45.4 Olfactory Receptors Communicate
Directly with the Brain (Part 1)
13
Figure 45.4 Olfactory Receptors Communicate
Directly with the Brain (Part 2)
14
ChemoreceptorsResponding to Specific Molecules

• Odorants?
• Each olfactory receptor protein particular
  odorant molecules activates a G protein.
• The G protein ? activates an enzyme ? a second
  messenger, such as cAMP.
• The second messenger ? sodium channels open ?
  influx of Na ? depolarizes the membrane ? action
  potential

15
ChemoreceptorsResponding to Specific Molecules

• How to distinguish the odorants?
• The number of odorant molecules vs. the number of
  different receptor proteins.
• Specific receptor protein? Combination?
• Odor, strong ? more odorant molecules

16
ChemoreceptorsResponding to Specific Molecules

• Vomeronasal organ (VNO) is
• a small, paired tubular structure embedded in the
  nasal epithelium.
• Chemoreceptors of the VNO.
• VNO chemoreceptors ? an accessory olfactory bulb
  ? brain region for sexual and other instinctive
  behaviors.
• Detect pheromone (mice)

17
ChemoreceptorsResponding to Specific Molecules

• Gustation
• the sense of taste, depends on clusters of
  sensory cells called taste buds.
• Humans have 10,000 taste buds embedded in the
  epithelium of the tongue.
• Many are in raised papillae, the small bumps on
  human tongues.
• The sensory cells form synapses with dendrites of
  sensory neurons.

18
Figure 45.5 Taste Buds Are Clusters of Sensory
Cells
19
ChemoreceptorsResponding to Specific Molecules

• Receptor proteins in the microvilli bind specific
  molecules. This causes the release of
  neurotransmitters to the dendrites of associated
  sensory neurons.
• Taste buds are replaced every few days, but the
  associated neurons live on.
• Taste buds can distinguish sweet, salty, sour,
  and bitter tastes.
• Recently the savory meaty taste umami has been
  added to the list of distinguishable tastes.

20
MechanoreceptorsDetecting Stimuli that Distort
Membranes

• Mechanoreceptors
• sensitive to mechanical forces
• skin sensations and sensing blood pressure.
• Physical distortion of a mechanoreceptors plasma
  membrane causes ion channels to open.
• The rate of the action potentials is related to
  the strength of the stimulus.

• Fingertips sensitive finer spatial
  discrimination, much more dense mechanoreceptors

21
Figure 45.6 The Skin Feels Many Sensations
Skin - diverse mechanoreceptors
Non-hairy skin
Low frequency
Higher frequency
22
MechanoreceptorsDetecting Stimuli that Distort
Membranes

• Stretch receptors
• Position of its limbs and stresses on its
  muscles and joints.
• 1. muscle spindles in muscle
• muscle tone.

2. Golgi tendon organ tendons and ligaments.
prevent excessive force
23
Figure 45.7 Stretch Receptors Are Activated when
Limbs Are Stretched (Part 1)
24
Figure 45.7 Stretch Receptors Are Activated when
Limbs Are Stretched (Part 2)
25
MechanoreceptorsDetecting Stimuli that Distort
Membranes

• Hair cells - mechanoreceptors.
• Each hair cell has a set of stereocilia
  (microvilli).
• When the stereocilia are bent in one direction,
  receptor potential becomes more negative when
  they are bent in the other direction, it becomes
  more positive.
• When the membrane potential becomes more
  positive, the hair cell releases a
  neurotransmitter to the sensory neuron associated
  with it, and the sensory neuron sends action
  potentials to the CNS.

26
MechanoreceptorsDetecting Stimuli that Distort
Membranes

• Hair cells are found in the lateral line system
  of fishes, providing information about movement
  through the water and moving objects that cause
  pressure waves in water.
• Semicircular canals and the vestibular apparatus
  in the mammalian inner ear use hair cells to
  detect position and orientation of the head, as
  well as acceleration produced by movement.

27
Figure 45.8 The Lateral Line System Contains
Mechanoreceptors
28
Figure 45.9 Organs in the Inner Ear of Mammals
Provide the Sense of Equilibrium (Part 1)
29
Figure 45.9 Organs in the Inner Ear of Mammals
Provide the Sense of Equilibrium (Part 2)
30
MechanoreceptorsDetecting Stimuli that Distort
Membranes

• Auditory systems
• Use mechanoreceptors to convert pressure waves
  into action potentials.
• Pinnae collect sound waves and direct them into
  the auditory canal, which leads to the middle
  inner ear.
• The eardrum (tympanic membrane) covers the end of
  the auditory canal and vibrates in response to
  pressure waves.
• Pressure on both sides of the eardrum
  equilibrates because the Eustachian tube allows
  airflow.

31
Figure 45.10 Structures of the Human Ear (Part 1)
32
MechanoreceptorsDetecting Stimuli that Distort
Membranes

• Ossicles (the malleus, incus, and stapes) to oval
  window. 20 times amp.
• Behind the oval window is the fluid-filled inner
  ear. Movements of the oval window result in
  pressure changes in the inner ear.
• The inner ear, cochlea
• three parallel canals
• two membranes, Reissners membrane and the
  basilar membrane.

33
Figure 45.10 Structures of the Human Ear (Part 2)

• The organ of Corti rests on the basilar membrane.
• The organ of Corti contains hair cells whose
  stereocilia are in contact with the tectorial
  membrane.

34
Figure 45.10 Structures of the Human Ear (Part 3)
35
MechanoreceptorsDetecting Stimuli that Distort
Membranes

• What causes the basilar membrane to flex?
• The cochlea is filled with fluid and the upper
  and lower canals are connected at the distal end.
  Pressure waves displace the fluid in the upper
  canal of the cochlea.
• Instead of traveling all the way around the
  canals, the waves of fluid cross the basilar
  membrane, causing it to flex.
• High frequency causes the basilar membrane
  nearest the oval window to flex.
• Low frequency causes flexing farther down the
  membrane.

36
Figure 45.11 Sensing Pressure Waves in the Inner
Ear (Part 1)
22,000 Hz
3,000 Hz
37
MechanoreceptorsDetecting Stimuli that Distort
Membranes

• Deafness has two general causes
• Conduction deafness is loss of function of the
  tympanic membrane or ossicles of the middle ear.
  The ossicles stiffen with age causing loss of
  ability to hear high frequency sound.
• Nerve deafness is caused by inner ear or auditory
  pathway damage, including damage to hair cells.
• Loud music or noises can cause damage to hair
  cells. This damage is cumulative and permanent.

38
Photoreceptors and Visual Systems Responding to
Light

• Photosensensation
• the sensitivity to light.
• It ranges from the ability to orient to the sun
  to the ability to see.
• Rhodopsins photosensitivity molecules in all
  animal species. a family of pigments

39
Photoreceptors and Visual Systems Responding to
Light

• Rhodopsin molecules can absorb photons of light
  and undergo shape changes.
• Rhodopsin molecules consist of a protein called
  opsin and a light-absorbing group,
  11-cis-retinal.
• When 11-cis-retinal absorbs a photon, it changes
  to all-trans-retinal, which changes the
  conformation of the opsin. This change signals
  detection of light.

• The all-trans back to cis- form of retinal.
  photoexcited rhodopsin ? membrane potential.

40
Figure 45.12 Rhodopsin A Photosensitive Molecule
41
Photoreceptors and Visual Systems Responding to
Light
42
Figure 45.13 A Rod Cell Responds to Light

• A rod cell is a modified neuron.

rhodopsin
Dark depolarize
mitochondria
Light hyperpolarize
43
Photoreceptors and Visual Systems Responding to
Light

• When light is absorbed by rhodopsin, it becomes
  photoexcited and activates a G protein called
  transducin.
• The activated transducin activates a
  phosphodiesterase, which converts cGMP to GMP.
• cGMP keeps sodium channels open in light, GMP
  levels rise and channels close.

44
Figure 45.14 Light Absorption Closes Sodium
Channels (Part 1)
45
Figure 45.14 Light Absorption Closes Sodium
Channels (Part 2)
46
Photoreceptors and Visual Systems Responding to
Light

• The advantage of this system is that it amplifies
  the signal.
• Each single photon can cause activation of
  several hundred transducin molecules, which in
  turn, activate many phosphodiesterase molecules.
• A single photon can close a huge number of sodium
  channels.

47
Figure 45.15 Ommatidia The Functional Units of
Insect Eyes

• Arthropods have compound eyes consisting of many
  optical units called ommatidia.

48
Photoreceptors and Visual Systems Responding to
Light

• Both vertebrates and cephalopod mollusks have
  highly evolved eyes.
• Vertebrate eyes are fluid-filled spheres bound by
  tough connective tissue called sclera.
• A transparent cornea in the front allows light
  passage.
• Inside the cornea is the pigmented iris, which
  controls the amount of light that can enter.
• The pupil is the region where light enters.
• The lens makes fine adjustments in the focus of
  images on the photosensitive retina at the back
  of the eye.

49
Figure 45.16 Eyes Like Cameras
50
Photoreceptors and Visual Systems Responding to
Light

• The most sensitive area of the retina is the
  fovea.
• The lenses allow the eyes to focus light.
• Fishes, amphibians, and reptiles focus by moving
  the lenses of their eyes closer to or farther
  from their retinas.
• Mammals and birds alter the shape of the lens to
  focus.

51
Figure 45.17 Staying in Focus
52
Photoreceptors and Visual Systems Responding to
Light

• The shape of the lens changes due to the action
  of two structures.
• Connective tissue surrounding the lens keeps it
  spherical, but suspensory ligaments pull it into
  a flatter shape.
• Ciliary muscles counteract the pull of the
  ligaments and allow the lens to become round.
• The flatter lens is able to focus distant images
  but not nearer ones, which need the light-bending
  properties of the round lens to bring close
  images into focus.
• Lenses become less elastic with age and we lose
  the ability to focus on objects close at hand.

53
Photoreceptors and Visual Systems Responding to
Light

• The retina includes layers of cells that process
  visual information from the photoreceptors and
  produce an output signal that is transmitted via
  the optic nerve.
• Light must pass through all the layers of cells
  before photons are captured by rhodopsin.
• There are two types of vertebrate photoreceptors
  cones and rods.
• Rod cells are more sensitive to light. Cone cells
  respond to different wavelengths of light for
  color vision.
• Cones also provide the sharpest vision. The fovea
  has only cone cells.

54
Photoreceptors and Visual Systems Responding to
Light

• Humans have three kinds of cone cells One type
  absorbs violet and blue wavelengths, one absorbs
  green, and one absorbs yellow and red.
• The human fovea has about 160,000 cone cells per
  square millimeter a hawk has 1,000,000.
• Hawks also have two foveas per eye and can see
  both their flight path and the ground below.
• There are no photoreceptors where blood vessels
  and bundles of axons going to the brain pass
  through the back of the eye. This creates a blind
  spot on the retina.

55
Figure 45.19 Absorption Spectra of Cone Cells
56
Photoreceptors and Visual Systems Responding to
Light

• The human retina is organized into five layers of
  cells.
• Cells at the front of the retina are ganglion
  cells. They fire action potentials and their
  axons form the optic nerves.
• The photoreceptor cells are at the back of the
  retina. Ganglion cells and photoreceptors are
  connected by bipolar cells.
• Photoreceptor cells ? bipolar cells ? ganglion
  cells

57
Figure 45.20 The Retina
58
Photoreceptors and Visual Systems Responding to
Light

• Horizontal cells connect neighboring pairs of
  photoreceptors and bipolar cells.
• This provides a means for the lateral flow of
  information.
• Amacrine cells connect neighboring pairs of
  bipolar cells and ganglion cells.
• These help make eyes more sensitive to small but
  rapid changes.

59
Photoreceptors and Visual Systems Responding to
Light

• Each ganglion cell has a well-defined receptive
  field, which consists of a specific group of
  photoreceptor cells.
• This integrates the light signal into one output.
• The receptive field of a ganglion cell can be
  divided into two concentric areas, called the
  center and the surround.

60
Photoreceptors and Visual Systems Responding to
Light

• There are two kinds of receptive fields
  on-center and off-center.
• Ganglia with on-center receptive fields are
  maximally excited by light falling on the center.
• Ganglia with off-center receptive fields are
  maximally stimulated by light falling on the
  surround.
• Center effects are always stronger than surround
  effects.
• The photoreceptors in the center of the receptive
  field of a ganglion cell are connected to that
  ganglion via bipolar cells.

61
Figure 45.21 What Does the Eye Tell the Brain?
(Part 1)
62
Figure 45.21 What Does the Eye Tell the Brain?
(Part 2)
63
Sensory Worlds Beyond Human Experience
Other animals?

• Some species can see infrared and ultraviolet
  light.
• One of the seven photoreceptors in each
  ommatidium of a fruit fly is sensitive to
  ultraviolet light.
• Some flowers have patterns that are invisible to
  humans but can be seen by flies.
• Pit vipers have pit organs, one in front of each
  eye, which can sense and locate infrared
  radiation in total darkness.

64
Sensory Worlds Beyond Human Experience
Other animals?

• Elephants can communicate with infrasound, sounds
  below the range of human hearing.
• The advantage of using low frequency sound to
  communicate is that it carries over very long
  distances.

65
Sensory Worlds Beyond Human Experience
Other animals?

• Echolocation is sensing the world through
  reflected sound.
• Dolphins, bats, and whales can use noises to
  echolocate.
• They generate sounds at frequencies above human
  hearing.
• These animals use muscles in the middle ear to
  dampen their sensitivity to sound while they are
  emitting sounds in order to protect their
  hearing.
• To hear the returning echoes, they relax the
  muscles.

66
Sensory Worlds Beyond Human Experience
Other animals?

• Some fish can sense electric fields.
• Lateral lines of some species, such as catfish,
  contain electroreceptors.
• These enable the fish to detect weak electric
  fields, which helps them locate prey.
• Some fishes, such as electric fish, can use
  electric fields to navigate. Rocks, plants, and
  other structures disrupt their field and are
  interpreted.
