Access Anxiety

1
Access Anxiety

• John F Eidt MD
• Ahsan Ali MD
• Mohammed Moursi MD
• University of Arkansas for Medical Sciences

2
Primary access

• Think before you stick case planning!
• Remember your lead
• Raise the table be comfortable
• Identify topographic landmarks
• Feel pulse
• Fluoroscopic location of femoral head
• Limited amount of lidocaine
• Skin nick
• Micropuncture technique

3
(No Transcript)
4
(No Transcript)
5
(No Transcript)
6
Deep circumflex iliac
Inferior epigastric
CFA
PFA
SFA
7
(No Transcript)
8
21 GA
9
Trouble-shooting

• Microcatheter will not advance

10
Trouble-shooting

• Microcatheter will not advance
• Sheath will not advance

11
Trouble-shooting

• Microcatheter will not advance
• Sheath will not advance
• Stiffer wire (short Amplatz)
• Serial dilators
• New access site

12
Transradial Access for Coronary Angiography and
Angioplasty A Novel ApproachV Y T Lim, C N S
Chan, V Kwok, K H Mak, T H KohSingapore Med J
2003 Vol 44(11) 563-569

• N255
• Radial approach successful 92.2
• One arm hematoma
• No symptomatic radial artery occlusions
• Asymptomatic occlusions 5

13
Eversion endarterectomy complicating radial
artery access for left heart catheterizationCathe
terization Cardiovascular Interventions.
58(4)478-80, 2003

• Case report U Tenn
• No clinical consequence

14
Trouble-shooting

• Microcatheter will not advance
• Sheath will not advance
• Stiffer wire (short Amplatz)
• Serial dilators
• New access site
• Absent pulse

15
Absent pulse

• Bony landmarks
• Vein landmark leave wire in place
• Roadmap
• Contrast
• Wire
• Ultrasound
• Transcutaneous
• Smart needle

16
(No Transcript)
17
(No Transcript)
18
Ultrasound DVD
19
Trouble-shooting

• Microcatheter will not advance
• Sheath will not advance
• Absent pulse
• Antegrade puncture

20
Schneider Endovascular Skills 2nd ed.
21
(No Transcript)
22
(No Transcript)
23
(No Transcript)
24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
(No Transcript)
28
Background data

• 5 million catheterizations per year in US
• 75000 surgical procedures for access site
  complications

29
Access site complications

• Bleeding
• Obstruction
• Infection

30
Access site complications

• Bleeding
• External
• Internal
• Retroperitoneal hematoma puncture above
  inguinal ligament
• Groin hematoma puncture below inguinal ligament
• Pseudoaneurysm
• Obstruction
• Local injury
• Embolism
• Infection
• Local arteritis
• Systemic endocarditis etc

31
Access site hemostasis

• Manual compression
• How long?
• Bed rest?
• Compression devices
• Belt
• C-clamp
• Sand bags

32
Access Site Hemostatic Devices

• Angio-Seal (Market leader 70)
• Perclose ProGlide, Closer, Prostar, Techstar
• Vasoseal (first approved by FDA 1993)
• Duett Vascular Solutions
• Staplers (Medtronic angiolink EVS, Abbott
  Starclose)
• Topicals (Syvek, Chito-seal))

33
Vasoseal Vascular Hemostasis Device

• Datascope Corp, Montvale, NJ
• Approved by FDA September 1995
• 5-8 Fr arteriotomy
• Contraindicated in obese patients (gt2.5 in)
• Extravascular bovine collagen plug 80-100 mg
• 11.5 Fr delivery system
• No repuncture for 4-6 weeks

34
Vasoseal
35
Angio-Seal Hemostatic Puncture Closure Device

• Kensey-Nash Development Corporation(Patent)/ St
  Jude Medical/ Daig Corp distribution
• Approved by FDA Sept 1996
• Intravascular
• 5-8 Fr. Delivery Sheath
• Absorbable anchor (polylactic and polyglycolic
  acid co-polymer) and collagen plug (24 mg.) with
  traction suture
• No contraindication to ipsilateral re-puncture

36
Perclose Techstar and ProstarPercutaneous
Vascular Surgery Systems

• Perclose, Inc., Redwood City CA (John Simpson)
  sold to Abbott 2000
• Approved in April, 1997
• 6,8 and 10 Fr. delivery sheath
• Intravascular
• One or two non-absorbable 3-0 braided sutures
  directly into artery wall
• No contraindication to repuncture

37
Infection guidelines per IFU Whos at risk?

• diabetic patients
• renal dialysis patients,
• obese patients with skin folds,
• patients undergoing prolonged procedures,
• patients with multiple sheath exchanges and
  multiple device exchanges,
• patients with prolonged sheath insertion,
• immunocompromised patients,
• patients with prosthetic heart valves or
  significant valvular lesions,
• patients with prosthetic joints,
• patients with prolonged hospitalization,
• patients with ipsilateral groin access within two
  weeks,
• patients with poor hygiene,
• Patients with co-existent infection at a remote
  body site,
• patients with femoral grafts, and
• home health care patients/nursing home patients.

38
Duett

• Vascular Solutions, Minnetonka, Minn
• Approved June 2000 - 5-9 Fr arteriotomy
• Collagen and thrombin mixture
• Occlusive lt4 Fr balloon intravascular
• Necrosis of muscle in animal model
• Not for use in lt6mm CFA
• No contraindication to repuncture
• One MDR for popliteal thrombosis

39
(No Transcript)
40
(No Transcript)
41
(No Transcript)
42
Surgical Complications
43
Femoral Access Site Complications AngioSeal vs.
Manual Compression (not randomized)
44
Femoral Access Site Complications Perclose vs.
Manual Compression (not randomized)
45
MDRs for Hemostatic Devices thru 9/1999
46
Summary Adverse Events (MDRs)

• Vasoseal - SQ infection rare
• No harm No foul
• risk of graft/ patch infection unknown
• Angio-Seal - arterial occlusion
• anchor should be retrieved
• Perclose - Device/ operator failure requiring
  surgical removal of device
• Infection infected pseudoaneurysm
• New generation Closer may be improved
• Duett - one report of popliteal artery thrombosis
• Sutura - No MDRs at this time
• Biodisc - Europe only

47
Summary

• Arterial occlusive complications were more
  frequent following the use of Angio-Seal in
  comparison to manual compression at our
  institution
• Arterial infectious complications were more
  frequent following the use of Perclose in
  comparison to manual compression at our
  institution
• Vasoseal and Duett have not been associated with
  increased risk of surgical complications in our
  hands

48
Guidelines

• Check peripheral pulses before you start
• Stick CFA
• Use ultrasound for puncture
• Advance wire under fluoroscopy
• Point compression is more effective than diffuse
  compression
• Sandbags are useless
• Spasm is spelled CLOT

49
Guidelines

• Check pulses at the end of case
• Numerous lawsuits for access site complications
• Groin abnormality get ultrasound
• Most small pseudoaneurysms thrombose
• Persistent pseudoaneurysms can usually be treated
  by thrombin injection

50
Guidelines for closure devices

• Have a reason to use (e.g. anticoagulation, large
  sheath)
• Avoid infection (change gloves, fresh drapes,
  antibiotics, sterile technique)
• A-gram femoral artery (all contraindicated if
  other than CFA)
• Know the device be able to trouble shoot
