Title: Groundwater Models for Wellhead Protection Areas WHPA


1
Groundwater ModelsforWellhead Protection Areas
(WHPA)
2
Groundwater ModelingContact Information
  • Brant Fisher, DWRP, Environmental Engineer,
  • (517) 335-9187, fisherb_at_state.mi.us
  • Rick Mandle, LWMD, Groundwater Modeling Program
    Manager, (517) 241-9001, mandler_at_state.mi.us
  • Dave Fongers, LWMD, Environmental Engineer,
  • (517) 241-8132, fongersd_at_state.mi.us
  • Internet, groundwater modeling program
  • www.deq.state.mi.us/lwm/water_mgmt/gwater/gwater.
    html

3
WHPA Delineation Guidance
  • This presentation is based on MDEQ-DWRP Guidance
    Document WHP 1-101, August 1998. Additional
    detail is contained in this document.

4
WHPA Delineation Modeling Goals
  • Delineation of a WHPA that
  • Safeguards public health.
  • Is based on site-specific data and technically-
    sound interpretation of site hydrogeological
    conditions.

5
Delineation Process
6
Overview of Delineation Process
  • Assemble available information
  • Conceptualization meeting with MDEQ
  • Develop appropriate delineation approach for
    water supply
  • Field work to obtain better understanding of
    hydrogeologic system
  • Modeling to delineate WHPA
  • Submit delineation report

7
Available Information Sources
  • Aquifer test or water supply reports
  • Water well records
  • Investigations of sites of environmental
    contamination
  • Geologic and topographic maps
  • Nearby WHPA delineations
  • Regional hydrogeological investigations

8
Pre-Meeting Work Products
  • Preliminary potentiometric surface
  • Geologic cross-sections
  • Preliminary WHPA delineation and time-of-travel
    estimates

9
Field Work
  • One aquifer test is required
  • 24 hours for confined aquifer
  • 72 hours for unconfined aquifer
  • Determination of groundwater flow directions and
    hydraulic gradients
  • Possible well installation

10
Delineation Approaches
11
Delineation Approaches
  • Confirmation of Existing Information
  • Direct Determination of Groundwater Flow
    Direction and Hydraulic Gradient
  • Extensive Hydrogeological Investigations

12
Delineation Approaches (cont.)
  • The additional uncertainty associated with a
    simpler approach generally results in a more
    conservatively sized WHPA compared to a more
    elaborate approach.
  • A simple approach will be inadequate for a
    complex flow system.

13
Delineation Approach Confirmation of Existing
Information
14
Confirmation of Existing Information
  • A potentiometric surface map is prepared from
    reported static water levels.
  • Lake levels or river stages may be used if
    appropriate.
  • Static water levels are measured in a sufficient
    number of wells to confirm the potentiometric
    surface.

15
Confirmation of Existing Information (cont.)
  • A simple groundwater flow model is constructed
    and reverse particle tracking is used to identify
    the WHPA.

16
Delineation Approach Direct Determination of
Groundwater Flow Direction and Hydraulic Gradient
17
Direct Determination
  • This approach places a greater emphasis on field
    work to provide a greater number of actual static
    water elevation measurements.
  • Selected wells (12 or more) are surveyed and a
    potentiometric surface generated from the
    observed data.
  • The wells must be generally upgradient of the
    water supply well and suitably distributed.

18
Direct Determination (cont.)
  • Potentiometric surface may be supplemented by
    reported static water levels from water well
    logs.
  • Lake elevations or river stages from topographic
    map may also be used to supplement potentiometric
    surface map.
  • A simple groundwater flow model is constructed
    and reverse particle tracking is used to identify
    the WHPA.

19
Delineation Approach Extensive Hydrogeologic
Investigations
20
Extensive Hydrogeologic Investigations
  • Necessary when groundwater flow system is
    complex.
  • Incorporates features such as rivers, lakes,
    variable aquifer thickness, variable hydraulic
    conductivity, 3-D groundwater flow, or multiple
    aquifers.

21
Extensive Hydrogeologic Investigations (cont.)
  • Extensive dataset is required to define
    groundwater flow system.
  • Because the data requirements exceed the data
    available in most WHPA studies, this approach may
    not be recommended except where the site
    hydrogeology requires this level of effort.

22
Extensive Hydrogeologic Investigations (cont.)
  • Hydrogeologic characterization is incorporated
    into a sophisticated analytical model or
    numerical model program.
  • Properly constructed and calibrated, these models
    can provide an accurate WHPA delineation.
  • Model may also be useful for evaluating future
    groundwater development or well-field management.

23
Modeling Considerations
24
Choice of Model
  • Model selection is up to consultant.
  • Model must be documented, tested and accepted by
    hydrogeological community.
  • Model must be appropriate for site
    hydrogeological conditions.
  • We would prefer a Windows-based software package.

25
Submitting Digital Files
  • You are required to submit numerical model
    datasets in digital format.
  • Model datasets can be sent via e-mail, ftp site,
    or disk (floppy, jaz, zip, or CD).
  • MODFLOW datasets should include both the generic
    MODFLOW format and the pre-processor format (e.g.
    Visual MODFLOW, .vmf).

26
Submitting Digital Files (cont.)
  • We use the datasets to evaluate model simulations
    included in the delineation report.
  • Models are re-run to assess the impact of
    parameter uncertainty on WHPA delineation.

27
Professional Judgement
  • The accuracy of computer modeling is no better
    than the accuracy of the data used in the
    analysis.
  • Always question modeling results.
  • Do the model results agree with your
    understanding of the site hydrogeology and
    sound hydrogeological principles?
  • Is your understanding of the site hydrogeology
    reasonable?

28
Professional Judgement
  • Interpolated potentiometric surfaces
  • A single hydraulic head measurement may result
    in an unrealistic contour.

29
Professional Judgement
  • Interpolated potentiometric surfaces
  • Removing suspect data point smooths
    potentiometric surface contours.

30
Interpolated Potentiometric Surfaces
  • Interpolation schemes may result in WHPA width
    which narrows upgradient.
  • Judgement should be used to maintain a more
    uniform WHPA width.

31
Data Variability
  • Data variation is caused by uncertainty in the
    appropriate data value or by physical reality.
  • Where there is significant variation in a model
    parameter value, do not use an average value. Use
    the range of values, which reflect data
    variability, to bracket delineation results.

32
Data Variability
33
Data Variability
34
Data Variability
35
Use of textbook valuesfor model parameters
  • Transmissivity, hydraulic conductivity, aquifer
    thicknesses, and the hydraulic gradient must be
    based on site-specific measurements.
  • Textbook values for other parameters, such as
    porosity, may be acceptable.
  • Where textbook values are used, they should be
    used conservatively.

36
Modeled Pumping Rate
  • The modeled pumping rate must represent the
    average day of the peak month.
  • A higher rate may used if increased demand is
    anticipated.
  • The annual average or the maximum pump capacity
    should not be used.

37
Use 10-year Particle Tracking
  • WHPA delineations are based on 10-year reverse
    particle tracking.
  • Study area boundaries should extend well beyond
    the 10-year time of travel.

38
Use 10-year Particle Tracking
39
Accounting for Uncertainty
  • In spite of our efforts, there is a lot we dont
    know about the hydrogeological conditions at a
    site.
  • Account for uncertainty when delineating WHPA.
  • We may include a buffer surrounding the
    delineated WHPA to account for uncertainty in the
    hydrogeological data.

40
A Word About Particle Tracking
  • WHPA is delineated using particle tracking.
  • Particle Tracking is advective transport only -
    does not account for contaminant dispersion or
    diffusion.
  • Because of dispersion and diffusion,
    contamination outside a WHPA defined by particle
    tracking can impact a well.

41
Particle Tracking and Dispersion (cont.)
42
Particle Tracking and Dispersion (cont.)
43
Particle Tracking and Dispersion (cont.)
44
Some Friendly Advice
  • Dont oversimplify a complicated hydrogeologic
    system.
  • Reported static water levels are probably wrong.
    Use them with caution.
  • Question the reasonableness of potentiometric
    surface - especially an interpolated surface.

45
More Friendly Advice
  • Interpreted conditions from aquifer test must
    match hydrogeology and delineation method.
  • Use the right pumping rate. The pumping rate
    should be the average daily rate of the peak
    month.

46
Still More Friendly Advice
  • Questions or concerns which arise during the WHPA
    delineation process can be addressed at any time
    by contacting DEQ staff. Dont wait until after
    the first report submittal.
  • Working together during the delineation process
    will minimize resubmittals.

47
Finally
  • Consider upgrading delineation capabilities
  • Windows-based software
  • Numerical Modeling
  • Evaluate impact of dispersion on WHPA delineation.

48
  • MDEQ, LWM, 1999
