Trends in US Poultry Housing for Energy Conservation

1
Trends in US Poultry Housing for Energy
Conservation

• John W. Worley
• Associate Professor
• University of Georgia

2
Co-authors

• Mr. Michael Czarick
• Biological and Agricultural Engineering
• University of Georgia
• Dr. Brian Fairchild
• Poultry Science
• University of Georgia

3
Overview

• Background
• Energy Saving Technologies
• Survey Results
• Conclusions - Needs

4
Growth in Broiler Production in Southeastern US
5

• Reasons for regional growth
• Low-cost land, labor, and housing
• Synergy with cow-calf operations Restoration of
  depleted crop lands
• Low-cost housing meant
• Natural Ventilation
• Cheap construction
• Little or no insulation or powered ventilation

6
Evolution of birds and housing

• Improvements in genetics and nutrition
• Improvements in buildings
• Better buildings necessary for better bird
  performance

7
Energy efficiency

• Has always been considered
• Low historic energy prices
• Recent changes
• Energy now on Front Burner

8
Objectives

• Quantify expected energy savings from eight
  technologies (per house)
• Determine present and projected adoption rate by
  industry (poll)
• Estimate potential energy savings attributable to
  these technologies (sample and industry-wide)

9
Energy Saving Technologies

• Tunnel Ventilation
• Allows greater bird densities and improves bird
  performance
• No energy savings recognized in this report

10
Energy Saving Technologies

• Electronic Controllers
• Tighter control of desired temperature
• Improved bird environment and performance
• No energy savings recognized in this report

Exhaust Fans
Heaters
11
Energy Saving Technologies - Gas

• House Tightness
• Allows control of entering air (winter
  conditions)
• Curtain Flaps one example of tightening
• O.1 static pressure with one 48-inch fan
• Projected 15 gas savings

12
Energy Saving Technologies - Gas

• Solid Walls
• Reduces leaks and conductive heat flow
• Savings depend on size of opening and R-value of
  solid wall
• Can be solid wall on both sides or North side
• Projected 15 gas savings

13
Energy Saving Technologies - Gas

• Circulation Fans
• Reduces heat stratification
• Increases bird comfort while reducing gas
  consumption
• Savings depend on type of heat and management
  (10 to 30)
• Projected 20 gas savings

14
Energy Saving Technologies - Gas

• Litter Treatments
• Reduce pH of litter
• Reduces ammonia emissions
• Reduces required ventilation during brooding
• Projected 20 gas savings

15
Energy Saving Technologies - Gas

• Wider Houses
• Reduces exposed wall area per bird
• Usually thicker walls (increased R value)
• 50 ft wide or wider
• Projected 15 gas savings

16
Energy Saving Technologies - Electricity

• High efficiency exhaust fans
• Combination of efficient motors and housing
• Cone exhaust is indicator of efficiency
• Projected 15 savings based on EER improvement
  from 19 to 22 (Typical range of 16 to 24 for
  poultry ventilation fans)

17
Summary of Expected Savings
Technology Estimated Savings
House Tightness 15 (gas)
Solid Walls 15 (gas)
Circulation Fans 20 (gas)
Litter Treatments 20 (gas)
Wider Houses 15 (gas)
Hi-Eff. Exhaust Fans 15 (electric)
Note Gas savings are multiplicative, not additive
18
Survey Results

• Sent survey to 20 complexes in GA, SC, and AL
• Received 11 replies (all from GA)
• Replies represent 806 million broilers per year
• 64 of production in Georgia
• 9.5 of total US production
• 6218 houses (projected 6418 by 2010)

19
(No Transcript)
20
(No Transcript)
21
(No Transcript)
22
Conclusions

• Energy savings is recognized by the industry as
  important
• Technologies have had varying degrees of
  acceptance
• The need for education and further demonstration
  of technologies still exists
• Circulation fans, hi-eff. exhaust fans, and wider
  housing show the greatest potential for future
  savings
