Scheduling with Constraint Programming

1
Scheduling with Constraint Programming

• February 24/25, 2000

2
Today

• Optimization
• Scheduling
• Assessment

3
Review

• Constraint programming is a framework for
  integrating three families of algorithms
• Propagation algorithms
• Branching algorithms
• Exploration algorithms

4
S E N D M O R E M O N E Y
S ? 9 E ? 4..7 N ? 5..8 D ? 2..8 M ?
1 O ? 0 R ? 2..8 Y ? 2..8
E 4
E ? 4

S ? 9 E ? 5..7 N ? 6..8 D ? 2..8 M ?
1 O ? 0 R ? 2..8 Y ? 2..8
E 5
E ? 5
S ? 9 E ? 5 N ? 6 D ? 7 M ? 1 O ? 0 R
? 8 Y ? 2
S ? 9 E ? 6..7 N ? 7..8 D ? 2..8 M ?
1 O ? 0 R ? 2..8 Y ? 2..8
E ? 6
E 6


5
Using OPL Syntax
enum Letter S,E,N,D,M,O,R,Y var int lLetter
in 0..9 solve alldifferent(l) lS ltgt 0
lM ltgt 0 lS1000 lE100
lN10 lD lM1000
lO100 lR10 lE lM10000
lO1000 lN100 lE10 lY search
forall(i in Letter ordered by increasing
dsize(li)) tryall(v in 0..9)
li v ?All Solutions Execution ? Run
6
Today

• Optimization
• Scheduling
• Assessment

7
Optimization

• Modeling define optimization function
• Propagation algorithms identify propagation
  algorithms for optimization function
• Branching algorithms identify branching
  algorithms that lead to good solutions early
• Exploration algorithms extend existing
  exploration algorithms to achieve optimization

8
Optimization Example

• SEND MOST MONEY

9
SEND MOST MONEY

• Assign distinct digits to the letters
• S, E, N, D, M, O, T, Y
• such that
• S E N D
• M O S T
• M O N E Y holds and
• M O N E Y is maximal.

10
Modeling

• Formalize the problem as a constraint
  optimization problem
• Number of variables n
• Constraints c1,,cm ? ?n
• Optimization constraints d1,,dm ? ?n ?2?n Given
  a solution a, and an optimization constraint di ,
  the constraint di(a)? ?n contains only those
  assignments b for which b is better than a.

11
A Model for MONEY

• number of variables 8
• constraints
• c1 (S,E,N,D,M,O,T,Y)? ?8 0 ? S,,Y ? 9
• c2 (S,E,N,D,M,O,T,Y)? ?8
• 1000S 100E 10N D
• 1000M 100O 10S T
• 10000M 1000O 100N 10E Y

12
A Model for MONEY (continued)

• more constraints
• c3 (S,E,N,D,M,O,T,Y)? ?8 S ? 0
• c4 (S,E,N,D,M,O,T,Y)? ?8 M ? 0
• c5 (S,E,N,D,M,O,T,Y)? ?8 SY all
  different
• optimization constraint

• d (s,e,n,d,m,o,t,y) ?
• (S,E,N,D,M,O,T,Y)? ?8
• 10000m 1000o 100n 10e y
• lt 10000M 1000O 100N 10E Y

13
Propagation Algorithms

• Identify a propagation algorithm to implement the
  optimization constraints
• Example SEND MOST MONEY
• d (s,e,n,d,m,o,t,y) ?
• (S,E,N,D,M,O,T,Y))? ?8??8
• 10000m 1000o 100n 10e y
• lt 10000M 1000O 100N 10E Y
• Given a solution a, choose propagation algorithm
  for d(a).

14
Branching Algorithms

• Identify a branching algorithm that finds good
  solutions early.
• Example SEND MOST MONEY
• Idea Naïve enumeration in the order M, O,
  N, E, Y.
• Try highest values first.

15
Exploration Algorithms

• Modify exploration such that for each solution a,
  corresponding optimization constraints are added.
• Two strategies
• branch-and-bound continue as in original
  exploration
• restart optimization after each solution, start
  from the root.

16
Using OPL Syntax
enum Letter M,O,N,E,Y,S,D,T var int lLetter
in 0..9 minimize lM10000 lO1000
lN100 lE10 lY subject to
alldifferent(l) lS ltgt 0 lM ltgt 0
lS1000 lE100 lN10 lD
lM1000 lO100 lR10
lE lM10000 lO1000 lN100
lE10 lY search forall(i in
Letter) tryall(v in 0..9 ordered by
decreasing v) li v ?All
Solutions Execution ? Run
17
Experiments with MONEY
MONEY Search
MONEY Optimization
18
Today

• Optimization
• Scheduling
• Assessment

19
Scheduling

• Scheduling Problems
• Propagation Algorithms for Resource Constraints
• Branching Algorithms
• Other Constraints
• Exploration Algorithms
• Literature

20
Scheduling Problems

• Assign starting times (and sometimes durations)
  to tasks, subject to
• resource constraints,
• precedence constraints,
• idiosyncratic and other constraints, and
• an optimization function, typically to minimize
  overall schedule duration.

21
Example Building a Bridge
Show Problem
Animate Solution
Gantt Chart

• Resource constraints
• Example a1 and a2 use excavator, cannot overlap
  in time
• Precedence constraints
• Example p1 requires a3, a3 must end before p1
  starts

22
Modeling

• Indices
• Task begin,a1,a2,a3,a4,a5,a6,p1,...,end
• Constants duration of tasks
• duration begin0, a14, a22,...
• Variables represent each task with a finite
  domain variable representing its starting time.
• Activity at in Task(durationt)
• at.start is finite domain variable
  representing the starting time of at

23
Precedence Constraints

• For each two tasks t1, t2, where t1 must precede
  t2, introduce a constraint
• at1.start at1.duration ? at2.start
• In OPL, just write
• at1 precedes at2

24
Resource Constraints

• For each two tasks t1, t2 that require a unary
  resource r, we have the constraint
• at1.start at1.duration ?
• at2.start
• \/ at2.start at2.duration ?
• at1.start
• But many constraints and weak propagation.
• Thus, introduce global resource constraints.

25
Scheduling

• Scheduling Problems
• Propagation Algorithms for Resource Constraints
• Branching Algorithms
• Other Constraints
• Exploration Algorithms
• Literature

26
Global Resource Constraints in OPL

• Declare resource
• UnaryResource excavator
• Require resource
• aa1 requires excavator
• aa2 requires excavator...
• All requires constraints on a resource together
  form a global resource constraint.

27
Propagation Disjunctive Resource

• For all tasks t1, t2 using the same resource
• at1.start at1.duration ?
• at2.start
• \/ at2.start at2.duration ?
• at1.start
• Weakest but most efficient form of propagation
  for unary resources.

28
Propagation Edge finding

• For a given task t and set of tasks S, all
  sharing the same unary resource , find out
  whether t can occur
• before all tasks in S,
• after all tasks in S,
• between two tasks in S,
• and infer corresponding basic constraints.

29
Propagation Task Intervals

• Notation est(t) earliest starting time
• lct(t) latest completion time
• For two tasks t1 and t2 where est(t1)?est(t2) and
  lct(t1) ? lct(t2), the task interval I(t1,t2) is
  defined
• I(t1,t2) t est(t1) ? est(t) and
• lct(t) ? lct(t2)
• Perform edge finding on all task intervals.

30
Task Intervals Example
A
B
C
D
I(A,B) A,B,C I(C,D) B,C,D
31
Which Edge Finder?

• As usual, trade-off between run-time of
  propagation algorithm and strength of
  propagation. Edge finding can be expensive
  depending on what tasks are considered.
• Recent edge finders have complexity n2 for one
  propagation step, where n is the number of tasks
  using the resource.
• Edge finding based on task intervals can be
  stronger than these, but typically have
  complexity n3 .

32
Specifying Propagation Algorithms

• OPL fixes propagation for unary resources to an
  (undisclosed) edge-finding algorithm.
• For discrete (non-unary) resources, the user can
  choose between default, disjunctive and
  edgeFinder when declaring a resource
• DiscreteResource
• crane(3) using edgeFinder

33
Demo Propagation for Unary Resources
Bridge
34
Scheduling

• Scheduling Problems
• Propagation Algorithms for Resource Constraints
• Branching Algorithms
• Other Constraints
• Exploration Algorithms
• Literature

35
Branching Algorithms Serializers

• Simple enumeration techniques such as first-fail
  are hopeless for scheduling.
• Use unary resources to guide branching.
• For two tasks t1, t2 sharing the same resource,
  use the constraints
• t1.start t1.duration ? t2.start
• and
• t2.start t2.duration ? t1.start
• for branching.

36
Which Tasks To Serialize?

• Resource-oriented serialization Serialize all
  tasks of one resource completely, before tasks of
  another resource are serialized.
• Most-used-resource serialization
• Global slack
• Local slack
• Task-oriented serialization Choose two suitable
  tasks at a time, regardless of resources.
• Slack-based task serialization (see later)

37
Most-used-resource Serialization

• Most-used-resource serialization serialize
  first the resource that is used the most.
• Let T be a set of tasks running on resource r.
• demand(T) ?t?T t.duration
• Let S be the set of all tasks using resource r.
• demand(r) demand(S),
• Serialize the resource r with maximal demand(r)
  first.

38
Slack-based Resource Serialization

• Let T be a set of tasks running on resource r.
• supply(T) lct(T) - est(T)
• demand(T) ?t?T t.duration
• slack(T) supply(T) - demand(T)
• Let S be the set of all tasks using resource r.
• slack(r) slack(S), S is set of all task
  running on r.
• Global slack serialization Serialize resource
  with smallest slack first

39
Local-Slack Resource Serialization

• Let Ir be all task intervals on r. The local
  slack is defined as min slack(I) I ? Ir
• Local slack serialization Serialize resource
  with smallest local slack first. Use global slack
  for tie-breaking.

40
Which Tasks Are Serialized?

• Ideas
• Use edge finding to look for possible first tasks
  (and last tasks)
• Choose tasks according to their est, lst (lct,
  ect).

41
Task-oriented Serialization

• Among all tasks using all resources, select a
  pair of tasks according to local/global slack
  criteria and other considerations, regardless
  what resources are serialized already.
• Provides more fine-grained control at the expense
  of runtime for finding candidate task pairs among
  all tasks.

42
Programming Branching Algorithms in OPL

• Scheduling-specific try constructs
• tryRankFirst(u,a) activity a comes first
• tryRankLast(u,a) activity a comes last
• rank(u) serialize all tasks using u
• Reflective functions for unary resources
• isRanked(Unary) 1 if the resource is ranked
• nbPossibleFirst(Unary)
• number of activities that can
  come first
• globalSlack(Unary) global slack of u
• localSlack(Unary) local slack of u

43
Example Task-oriented Serialization in OPL

• while not isRanked(tool) do
• select(r in Resources not isRanked(toolr))
• select(t in tasksr
• not isRanked(toolr,at)
• tryRankFirst(toolr,at)

44
Demo Serialization Algorithms
Bridge
45
Scheduling

• Scheduling Problems
• Propagation Algorithms for Resource Constraints
• Branching Algorithms
• Other Constraints
• Exploration Algorithms
• Literature

46
Other Scheduling Constraints

• Discrete resources
• DiscreteResource crane(3)
• a requires(2) crane
• a consumes(1) crane
• Reservoirs
• Reservoir plumbing(3,1)
• a requires(2) plumbing
• a consumes(2) plumbing
• a provides(2) plumbing
• a produces(2) plumbing

47
Exploration Algorithms

• Usually branch-and-bound using minimization of
  the starting time of an end task
• minimize aend.start subject to ...
• Lower-bounding Prove the non-existence of a
  solution with aend.start ? n, add constraint
  aend.start gt n increase n by ?.
• Upper-bounding Find solution with aend.start
  n, add constraint aend.startltn decrease n by
  ?.

48
Literature

• Van Hentenryck The OPL optimization programming
  language, 1999
• Constraint Programming Tutorial of Mozart, 2000
  (www.mozart-oz.org)
• Applegate, Cook A computational study of the
  job-shop scheduling problem, 1991
• Carlier, Pinson An algorithm for solving the
  job-shop scheduling problem, 1989
• Various papers by Laburthe, Caseau, Baptiste, Le
  Pape, Nuijten, see Overview paper

49
Today

• Optimization
• Scheduling
• Assessment

50
Assessment Dont Use It!

• Dont use constraint programming for
• Problems for which there are known efficient
  algorithms or heuristics. Example Traveling
  salesman.
• Problems for which integer programming works
  well. Example Many discrete assignment problems.
• Problems with weak constraints and a complex
  optimization function. Example Timetabling
  problems.

51
Assessment Do Use It!

• Use constraint programming for
• Problems for which integer programming does not
  work (linear models too large).
• Problems for which there are no efficient
  solutions available.
• Problems with tight constraints, where
  propagation can be employed. Example ACC 97/98.
• Problems for which strong branching algorithms
  exist. Example Scheduling with unary resources.

52
Myths Debunked

• A fad! Constraint programming has been used
  successfully in a number of application areas,
  most spectacularly in scheduling
• Universal! More failure stories than success
  stories.
• All new! Many ideas come from AI search and
  Operations Research. In particular, the important
  ideas for scheduling come from OR.
• Artificial Intelligence! All quite earthly
  algorithms. Constraint programming systems
  provide framework for different kinds of
  algorithms to interact.

53
The Future

• Constraint programming will be added in OR as a
  standard technique for solving combinatorial
  problems, along with local search.
• Constraint programming techniques will be tightly
  integrated with integer programming and local
  search.
• Look at the Workshop on Integration of AI and OR
  Techniques for Combinatorial Optimization
  Problems (www.uni-paderborn.de/CP-AI-OR)
