Cuckoo: Replication Policies

1
CuckooReplication Policies Load Shedding
Algorithms

• Raja Sambasivan

Andrew Klosterman Greg Ganger PARALLEL DATA
LABORATORY Carnegie Mellon University
2
Motivation An Overloaded NFS Server
C
D

• NFS Servers export filesystems
• Clients mount exported filesystems

3
Motivation An Overloaded NFS Server
C
D

• Common solutions to relieve load
• Buy a better server
• Move responsible data to another server

4
Motivation Whats a Cuckoo to do?

• It should dynamically identify heavily accessed
  data
• Automatically copy to other servers to allow
  load-shedding
• A Replication Policy is responsible for this
  operation
• It should automatically identify most work
  intensive ops
• Offload to other servers with replicas when busy
• A load-shedding algorithm is responsible for this
  operation

Objective Identify simple replication policies
and load shedding algorithms that will allow us
to offload large amounts of work from a NFS server
5
Replication in Cuckoo

• Cuckoo must determine what to replicate from
• The replication policy in use
• Access traces received from NFS servers
• Replication is performed periodically
• Assumed replication period of one day for
  analysis
• Short-Lived Objects Created between replications
• Long-Lived Objects Exists at beginning of
  replication
• What objects should the planner replicate?
• Replicate only most utilized objects
• Replicate objects whose replicas can be synced
  easily

6
Replication Policies Most Popular RO Policy

• Simple and presents no consistency issues
• Define popularity by number of ops seen

7
Replication Policies Most Popular RO Policy

• This is not a good replication policy
• Can only offload up to 12 of all operations
• Can only offload about 1 of all bytes
  transferred
• Most operations accounted for are metadata ops
• Offloading metadata ops not important
• Work intensive operations are probably not
  metadata ops
• Lessons Learned
• Tune replication policies for data objects
• Operation level granularity is not sufficient
• Number of ops seen is not a good ranking scheme

8
Replication Policies Data Objects

• Many long-lived objects have file data that is
  mostly RO
• Visible if viewing location of unique bytes
  read/written
• Considerable data is read from these objects

A 100 RO object
RO Portion
A mostly RO object
RW Portion
RO Portion
Green area sees no write ops Red area sees
read/write ops
9
Replication Policies Data Objects

• Many long-lived objects have file data that is
  mostly RO
• Considerable data is read from these objects

10
Replication Policies ROF/RWP Policy

• Mostly RO objects are the sweet spot for Cuckoo
• They are used in the ROF/RWP replication policy
  by
• Ranking data objects by bytes read
• Replicating data objects that have
• Large fraction of total bytes read from RO
  sections (ROF)
• High proportion of bytes read vs. bytes written
  in RW sections (RWP)

11
Replication Policies ROF/RWP Policy

• Mostly RO objects are the sweet spot for Cuckoo
• They are used in the ROF/RWP replication policy
  by
• Ranking data objects by bytes read
• Replicating data objects that have
• Large fraction of total bytes read from RO
  sections (ROF)
• High proportion of bytes read vs. bytes written
  in RW sections (RWP)

Bytes Offloadable1K Objects Replicated DEAS
02/02/03
Bytes Written 37.2
Offloadable Bytes Read 62.2
Unoffloadable Bytes Read 0.6
12
Summary

• We have identified a replication policy that
• Is capable of offloading a small fraction of all
  ops
• Can offload a large amount of data read
• We would like more traces
• That are busier
• That show accesses to more than one server
• Come see our posters!

13
Related Work/Products

• Rainfinity RainStorage. http//www.rainfinity.com

• Scott Baker and John H. Hartmann. The Mirage NFS
  Router. University of Arizona Computer Science
  Technical Report TR-02-04. November, 2002.
• Daniel Ellard, Jonathan Ledlie and Margo Seltzer.
  Passive NFS Tracing of Email and Research
  Workloads. USENIX File and Storage Technologies
  Conference, pages 203-216, San Francisco,
  California. March, 2003.
• Daniel Ellard, Michael Mesnier, Eno Thereska,
  Gregory R. Ganger, and Margo Seltzer.
  Attribute-Based Prediction of File Properties.
  Harvard Computer Science Technical Report
  TR-16-03. December, 2003.
