Renal Masses

1
Renal Masses

• Robert D. Thomas MD
• Pediatric Radiology

2
Renal Masses

• Balls
• Cyst
• Hematoma
• Abscess
• Tumor
• Dromedary hump

• Beans
• Duplication/anomaly
• Compensatory hypertrophy
• Hydronephrosis
• Pyelonephritis/edema
• Hematoma
• PCKD
• Tumor
• Vascular occlusion/trauma

3
Renal Masses by Age

• Newborn
• Hydronephrosis
• MCDK
• AR-PCKD
• Anomalies
• Tumors
• Mesoblastic nephroma
• Nephroblastomatosis

• Childhood
• Cysts
• Hydronephrosis, MCDK
• Anomalies
• Hematoma
• Tumors
• Wilms
• Lymphoma
• Angiomyolipomas

4
Hydronephrosis(Bean)

• Calyceal/Pelvic obstruction
• Congenital (intrinsic/extrinsic)
• TB
• Tumor
• Ureter
• Physiologic (full bladder)
• Congenital (1 megaureter, ectopic ureter,
  retrocaval)
• Inflammatory (TB, Crohn, PID, etc)
• Intraluminal (stone, clot, tumor, stricture)

5
Congenital UPJ obstruction

• 1 cause of renal mass in newborn
• Associations
• Ipsilateral reflux
• Lower moiety of duplication
• Most common cause of obstruction with horseshoe
  kidney
• Causes
• Stricture, disordered peristalsis, ischemia,
  redundant urothelium, crossing vessel, etc.

6
Congenital UPJ obstruction

• Imaging
• Mass in plain films
• US dilated pelvo-calyceal system (communicating
  cysts) dilatation-fluid equal to cortical
  thickness
• NM obstructive pattern w/o lasix response
• Pitfalls
• US may underestimate hydro due to
  oliguria/dehydration in newborn
• MCDK may look like UPJ if only a couple cysts
  present

7
(No Transcript)
8
(No Transcript)
9
(No Transcript)
10
(No Transcript)
11
Congenital UPJ obstruction

• Work-up
• VCUG co-existant ipsilateral reflux, urethral
  obstruction, contralateral reflux
• Scintigraphy site of obstruction renal
  function
• obstruction to reflux at UPJ, dilution of
  contrast in dilated renal pelvis, delay in
  drainage from renal pelvis

12
(No Transcript)
13
(No Transcript)
14
(No Transcript)
15
Multicystic Dysplastic KidneyBean or Ball

• Not a true cystic disease
• etiology is severe embryonic obstruction during
  metanephric stage of development
• Soits an obstruction
• Hallmark non-function of the kidney
• Bilaterality not compatible with life due to
  severe pulmonary hypoplasia

16
Multicystic Dysplastic Kidney

• 2nd most common renal mass in newborn
• Types
• Pelvoinfundibular atresias at ureter, pelvis,
  infundibulae
• Most common, grape-like collection of cysts and
  dysplastic glomeruli, atrophied tubules
• Hydronephrotic-atresia of proximal ureter alone
• Uncommon (5)

17
Multicystic Dysplastic Kidney

• Imaging
• US - Isolated cysts without a definable pelvis
  and without normal renal tissue
• IVP lack of function
• NM absence of perfusion lack of function (may
  have minimal activity 24-48hrs)

18
(No Transcript)
19
(No Transcript)
20
Multicystic Dysplastic Kidney

• Work-up
• US frequent contralateral UPJ, reflux,
• VCUG opposite reflux/obstruction
• MAG3, DTPA renogram
• Management
• Usually observation (natural history of
  involution)
• Nephrectomy for GI obstruction/respiratory
  compromise, hypertension
• ?malignancy probably not increased over baseline

21
Solid Renal MassesBeans and Balls!

• Hematoma
• Abscess
• Tumor

22
(No Transcript)
23
R/P mass in Neonate

• Renal
• Hydronephrosis
• Multicystic dysplastic kidney
• Solid
• Wilms tumor?
• Perinephric hematoma?
• Mesoblastic nephroma?
• Lymphoma?
• Adrenal
• Hemorrhage
• neuroblastoma

24
(No Transcript)
25
(No Transcript)
26
(No Transcript)
27
Mesoblastic Nephroma(Fetal renal hamartoma)

• Most common neonatal renal neoplasm
• Present as an asymptomatic mass
• Not Wilms tumor
• Characteristics
• Benign appearing spindle cells with dysplastic
  nephrons
• Large (8-30cm), arise in medulla
• Blends with normal parenchyma
• May penetrate capsule and invade locally
• Rare hypercellular forms may metastasize

28
Mesoblastic Nephroma(Fetal renal hamartoma)

• Imaging
• Non-calcified abdominal mass
• Look like uterine leiomyoma by US
• CT vascular and entrapped collecting system
  excretes contrast

29
(No Transcript)
30
Mesoblastic Nephroma(Fetal renal hamartoma)

• Management
• Nephrectomy
• No chemo or radiation (usually no mets)
• Cellular form
• Age gt3months at surgery are more likely to need
  chemo/radiation

31
Childhood Renal Tumors

• Wilms tumor nephroblastomatosis
• Renal lymphoma/leukemia
• Renal cell carcinoma
• Multilocular cystic nephroma
• Clear cell sarcoma
• Rhabdoid tumor
• Angiomyolipoma (and tuberous sclerosis)

32
(No Transcript)
33
Wilms Tumor

• Most common solid abdominal mass in childhood
• Most common renal malignancy in child
• 8 of all childhood cancer

34
Wilms Tumor

• Demographics
• Malefemale
• 1 familial
• 7.8 per 1,000,000 children
• Peaks between 2.5 to 3 years
• 80 occur between 1-5 years
• Presentation
• Asymptomatic mass most common
• Other pain, hematuria, hypertension, fever

35
Wilms Tumor

• Associated conditions
• 8 have overgrowth disorders, genital anomalies,
  aniridia
• Drash, Beckwith-Wiedemann, Soto, NF, KTW, Bloom,
  WAGR, 45X, etc
• 5 bilateral higher incidence of above
• These childrens siblings have a 30 chance of
  development of Wilms
• Nephroblastomatosis (Wilms precursor)

36
Wilms Tumor

• Nephroblastoma (Wilms in situ)
• Rests of metanephric blastema persisting after
  34-36 weeks gestational age
• Present in most cases of bilateral Wilms, 15
  unilateral disease
• Intralobular NR
• Younger age
• Drash sporadic aniridia
• Metachronous Wilms
• Perilobular NR
• BWS, Tr18, hemihypertrophy
• Synchronous Wilms

37
Wilms Tumor

• Nephroblastomatosis
• ImagingAppearance
• Nodules
• Subcapsular hypodense plaques
• US iso, hypo, hyperechoic (relatively
  insensitive)
• CT w contrast better for surveillance
• MRI ? Able to distinguish Wilms from
  nephroblastomatosis

38
(No Transcript)
39
(No Transcript)
40
NR versus Wilms at MRI

• NR
• Plaque-like
• Ovoid
• Lenticular
• Homogeneous on all sequences
• Hypotense post gad

• Wilms
• Round/spherical
• Heterogeneous pre gad
• Heterogeneous post contrast

41
(No Transcript)
42
(No Transcript)
43
Nephroblastomatosis

• Treatment
• Confluent disease treated with chemotherapy

44
(No Transcript)
45
Wilms Tumor

• Pathology
• Solid, necrosis, hemorrhage, 15 calcifications
• Capsule usually intact
• Invades nodes, veins, rarely urothelium
• Decreasing 10s
• 10 renal vein invasion
• 10 IVC extension
• 10 right atrial extension

46
Wilms Tumor

• Pathology
• 5 bilateral
• 7 unilateral and multicentric
• Metachronous cases may occur up to 10 years later
• 10 unfavorable histology

47
Wilms Tumor

• Pathology
• Lung mets up to 20 at diagnosis
• Liver mets 10 of patients
• Bone mets rare (lytic)
• Bilateral tumors may have different grades of
  histology (favorable vs unfavorable)

48
Wilms Tumor

• Staging
• I limited to kidney, completely resected
• II- outside kidney, completely resected
• III confined to abdomen
• IV hematogenous mets
• V bilateral initial/during treatment

49
(No Transcript)
50
Wilms Tumor - Radiology

• Nitwits (NWTS) dont agree on optimal imaging
  nonsense like IVPs persist
• IVP distortion of collecting system,
  non-function (vascular compression)
• US
• CDS excellent for venous tumor thrombi in IVC
• Echotexture similar to liver
• Sharply marginated

51
(No Transcript)
52
(No Transcript)
53
(No Transcript)
54
Wilms Tumor - Radiology

• CT
• 15 contain calcifications
• Round, hetergeneous, low density
• Displaces vessels, does NOT encase (DDX from
  neuroblastoma)
• Best for opposite kidney evaluation, nodes, lungs

55
(No Transcript)
56
Wilms Tumor-Radiology

• MRI
• Becoming preferred over CT
• Prolonged T1 and T2, heterogeneous post gad
• Excellent for NR of 4 mm size
• Angio
• Plays a role for partial nephrectomy

57
(No Transcript)
58
Wilms Tumor - Surveillance

• Patients with syndromes associated with Wilms
• US easiest, MRI may be best
• Arbitrary 3-6 month scans
• Continue until about 10 years old (lt1 incidence
  after 10)

59
Wilms Tumor - Treatment

• Overall survival now 90
• gt90 survival _at_ 2 yrs with favorable histology,
  surgery, chemo and radiation
• High mortality with unfavorable histology

60
(No Transcript)
61
Renal Lymphoma

• Usually late in NHL
• Nodules, masses, diffuse infiltration
• Unilateral/bilateral
• US hypoechoic
• CT hypodense
• Leukemia usually diffuse/bilateral

62
(No Transcript)
63
(No Transcript)
64
(No Transcript)
65
Multilocular Cystic Nephroma

• Indistinguishable from cystic partially
  differentiated nephroblastoma/cystic Wilms
• Young boys and adult women
• Anechoic cysts with regular septa
• Rx - nephrectomy

66
(No Transcript)
67
Clear Cell Sarcoma

• Identical age group to Wilms
• Very aggressive
• Not distinguishable from Wilms by imaging
• Bone mets common

68
(No Transcript)
69
Other lesions to ponder

• Simple cyst
• Were considered rare prior to ultrasound
• But, the differential diagnosis is
• Prior trauma or infection
• Obstructed upper pole moiety of duplication
• Early presentation of familial cystic disease

70
(No Transcript)
71
(No Transcript)
72
(No Transcript)
73
(No Transcript)
74
(No Transcript)
75
Other lesions to ponder

• Duplication
• Hematoma/renal trauma
• Pyelonephritis
• Focal bacterial
• Xanthogranulomatous
• Autosomal recessive polycystic kidney dz
• Infantile form

76
(No Transcript)
77
(No Transcript)
78
(No Transcript)
79
(No Transcript)
80
(No Transcript)
81
(No Transcript)
82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
(No Transcript)
86
(No Transcript)
87
(No Transcript)
88
(No Transcript)
