WIND ERODIBILITY OF BIOSOLIDS AMENDED SOILS: A STATUS REPORT

1
WIND ERODIBILITY OF BIOSOLIDS AMENDED SOILS A
STATUS REPORT
John Tatarko USDA-ARS Wind Erosion Research
Unit Manhattan, Kansas Nikki Stefonick Metro
Wastewater Reclamation District Denver, Colorado
2

• A consortium of 57 local governments in the
  Denver metro area.
• Treat more than 165 million gallons of wastewater
  a day.

• 52,000 acres of agricultural land 65 miles
  east of Denver, Colorado.

3

• 1 to 3 dry tons/acre depending on background
  nutrients, crop, and yield goal

4
(No Transcript)
5
(No Transcript)
6
(No Transcript)
7

• Objectives
• Determine fraction of biosolids in wind eroded
  material compared to that of the adjacent
  biosolids amended land.
• Determine wind erodibility of cultivated soils as
  influenced by applied biosolids.

8

• Objective 1
• Wind erosion catchers are located on two sites
  from December through May.
• Biosolid applications
• 3 and 5 (2005-2006)
• 4 and 5 (2006-2007)
• Catcher and adjacent source soils are collected
  to determine organic matter and available heavy
  metal content.

9
(No Transcript)
10
Figure 1. Layout of field BSNE sediment sampler
clusters in relation to source soil sample
locations.
11
Figure 2. Sediment flux (kg m-2) by height for
measured data and fitted equation for 4
January, 2006 storm at site DC343.
12

• Objective 2
• Five sites at Metrogrow Farms established in
  December, 2005 on wheat-fallow rotations.
• Biosolids applications
• 0, 1, 2, 3, and 5
• Wind erodibility measurements
• (3 replicates, sampled quarterly)
• aggregate stability
• soil surface roughness
• aggregate size distribution

13
Table 2. Physical and chemical characteristics
of wind erodibility study sites.
14
Table 3. Biosolids applications and organic
matter at wind erodibility study sites.
15
(No Transcript)
16
(No Transcript)
17
Figure 3. Oriented roughness (mm) on sample date
at each site with varying number of biosolids
applications.
18
Figure 4. Random roughness (mm) on sample date
at each site with varying number of biosolids
applications.
19
(No Transcript)
20
Figure 5. Erodible fraction (lt0.84 mm) of
aggregates on sample date at each site with
varying number of biosolids applications.
21
Figure 6. Geometric mean diameter (mm) of
aggregates on sample date at each site with
varying number of biosolids applications.
22
Conclusions
Disclaimer This study is ongoing and
statistical analysis is not complete. Only
general trends can be observed from the data
collected thus far.
23
Conclusions

• Oriented Roughness
• tends to decrease with time (i.e., precipitation)
• higher and more recent applications had highest
  roughness and retained it longer
• no applications had the lowest roughness

24
Conclusions

• Random Roughness
• low roughness compared to oriented
• higher and more recent applications had highest
  and retained it longer
• no applications tended to degrade the fastest

25
Conclusions

• Aggregate Size Distribution
• tend towards smaller size over time
• higher and more recent applications had larger
  aggregates
• no applications tended to smaller sized
  aggregates

26
Summary

• erodibility tends to increase with time after
  planting (i.e., with precipitation)
• biosolids effects are temporary
• less erodibility for most recent applications
• no applications tended to highest erodibility

27
