Westinghouse Electric Company The Nuclear
Renaissance is Here!
Aris Candris Senior Vice President Nuclear Fuel
Business Unit MIT Nuclear Engineering
Dept November 19, 2007
2
Agenda

• Westinghouses role in the commercial nuclear
  industry
• Fuel technology advances and challenges
• Career opportunities

3
Nuclear Energy Safe, Clean And Cost-Effective
Nuclear power must continue to be part of the
global energy solution.
4
Westinghouse Electric Company

Westinghouse Electric Company provides fuel,
services, technology, plant design, and equipment
to utility and industrial customers in the
worldwide commercial nuclear electric power
industry
Westinghouse Electric Company Headquarters -
Energy Center Monroeville, Pennsylvania, USA
Nearly 50 percent of the nuclear power plants in
operation worldwide, and nearly 60 percent in the
United States, are based on Westinghouse
technology
5
Three Core Businesses
Nuclear Fuel Single-source fuel provider for PWR,
BWR, VVER, AGR, and Magnox reactors worldwide
Nuclear Power Plants Specializing in the
technology of new nuclear power plants and
component manufacturing
Nuclear Services Maintenance, repair and
replacement of equipment provider of engineering
services and methods for the design, operation
and safety of nuclear power plants worldwide
6
Toshiba and Westinghouse
7
Evolution to Generation III Beyond
8
Countries Expressing Interest In New Nuclear
Oceana Australia New Zealand
Americas Argentina Brazil Canada Chile United
States
Europe Belgium Bulgaria Czech
Republic France Germany Hungary Italy Lithuan
ia Netherlands Poland Romania
Slovakia Slovenia Spain Switzerland Turkey United
Kingdom Finland Sweden
Africa South Africa Egypt Morocco Nigeria
Asia China India Indonesia Japan South
Korea Taiwan Vietnam
Other Belarus Russia Ukraine Middle East
9
Current Westinghouse Advanced Reactor Portfolio

AP1700?
NP2010
Ready now
AP1000
NGNP
Ready after 2013
PBMR
GNEP
Ready after 2016
IRIS
10
Westinghouse Fifteen-YearInvestment in Passive
Technology
11
The AP1000 Is Different

• We have addressed the sins of the past Licensing
  risk, Technology Risk, Design Risk, Construction
  Risk

• No licensing risk licensing complete prior to
  construction
• No technology risk reliance on proven
  technology
• No design risk design complete prior to
  construction
• All of the above reduce construction periods

12
Safe Economical Design
UtilityNew Plant Requirements
U.S. NRCRequirements
CurrentPlants
AP1000Results

• Dramatically safer design
• Simpler design, higher reliability
• Less equipment to maintain
• Increased operating margins
• Smaller staff, which is further reduced by
  automation from advanced process controls

1 x 10-4
5 x 10-5
lt1 x 10--5
5 x 10-7
Core Damage Frequency per Year
13
The Leading Choice For New U.S. Nuclear
14
PBMR Nuclear Gas Turbine

• National Strategic Project in South Africa
• High-temperature gas-cooled reactor (900ºC)
• High thermal efficiency
• Recuperative Brayton Cycle
• 400 MWth/165 MWe
• On-line refueling (gt95 capacity factor)
• Maintenance outage once every 6 years
• Metallic materials provenin LWR applications

15
PBMR Safety Concept

• Ceramic coated fuel particles provide primary
  radionuclide barrier
• Helium gas a single phase coolant
• Low power density and large thermal capacity
• Core decay heat removed passively by conduction
  and natural circulation cavity cooling system
• Passive heat transfer and high fuel temperature
  capability preclude core melt
• Added safety margins allow siting in closer
  proximity to public

PBMR Fuel Pebble Design
Pebble Fuel Spheres
16
IRIS International Reactor Innovative and Secure

• Advanced integral light water reactor
• 335 MWe/module
• Innovative, simple design
• Enhanced Safety-by-Design
• International team
• Recognized by Global Nuclear Energy Partnership
  (GNEP) as grid appropriate reactor
• Anticipated competitive economics
• Cogeneration (desalination, district heating)
• NRC pre-application underway
• Design Certification testing program underway
• Interest expressed by several countries
• Projected deployment target 2015 to 2017

17
A Broad Product Line
Combustion Engineering PWR
Westinghouse PWR
German PWR
Boiling Water Reactors
VVER

• 14x14
• 15x15
• 17x17

• 16x16
• 14x14

• 16x16
• 18x18

• 10x10

• 9-Grid
• 16-Grid

18
Nuclear Fuel Challenges

• More aggressive operational strategies
• Doubled cycle lengths (from 12 to 24 months)
• Increased power density as a result of plant
  power uprates
• Ever-increasing discharge burnups (70 GWd/Tn)
• Increasingly heterogeneous cores (including U/MOX
  cores)
• Advanced fuel designs to meet increased focus on
  fuel economics and reliability
• Highly heterogeneous fuel concepts
• Extensive use of burnable absorbers
• Increased intolerance to unwelcome events
• Zero fuel failure expectations
• Almost perfect cycle length predictions
• Within 1 - 2 days after a 2 year-cycle

19
Leaking Fuel Mechanisms Worldwide PWR Fuel
Rods from 1995 through 2006
20
Leaking Fuel Mechanisms Worldwide BWR Fuel Rods
from 1995 through 2006
21
Next Generation PWR Fuel Design
22
Optima 3 BWR Fuel
ZIRLO Channels
SVEA-96 Optima3 BWR Fuel
Simplified design
Triple Wave Debris Filter
23
Cladding evolution
Zr-4
Low-tin Zr-4
ZIRLO
Optimized ZIRLO
Reduced corrosion and hydrogen pickup
Next Gen Material
Year
24
Physics Modeling

• Computational tools for three different type of
  applications
• Fuel Bundle and Core Design
• Safety Analyses
• Core Monitoring
• Physics to be modeled
• Neutron/gamma transport
• Fuel depletion
• Thermal-hydraulics
• Fuel performance
• These are often tightly inter-related, complex
  phenomena requiring sophisticated computational
  models

25
BEACON Core Monitoring System Enhance Core and
Reactor Performance

• Fuel Cycle Costs
• More Optimum core designs
• Operations
• Improvements in Tech. Specs. (Elimination /
  Simplification)
• Simplified Operations
• Maximum Operating Space Available
• Faster Power Escalation
• Reduced Number of Flux Maps (Moveable or fixed)
• Reduced OM Costs
• Core Design
• Reduces Core Follow Support Requirements
• Reduce Operations Data Package Needs
• Permits Focus On Important Issues
• Economic fuel designs

Improved Fuel Utilization
Significantly Increased Operational Flexibility
Reduced Support Requirements
26
Westinghouse Global DiverseTo Reflect And
Serve The Nuclear Industry
Worldwide Locations 9500 employees
Rock Hill, SC
Tokyo
Kobe
Paris, Marseille, Lyon, France
Pretoria, RSA
27
The Staffing Challenge This Fiscal Year
Hiring Trend

• 1300 hires represent about 17 of the March 2007
  headcount.

28
Career Opportunities

• We will consider all MIT nuclear engineering
  students who are interested in full time or
  intern opportunities
• If you are interested, please visit
  www.westinghousenuclear.com, click the Careers
  icon and apply
• Position 4465 (new graduate engineer)
• Position 4565 (intern)
• For additional information, please contact Dallas
  Frey at freygd_at_westinghouse.com or 412.374.5042.

29
Questions and Answers
For information about careers, please visit
www.westinghousenuclear.com
Thank you!
