CCSM Tutorial

1

Running CCSM
Tony Craig CCSM Software Engineering Group
ccsm_at_ucar.edu
2
Outline

• General review of CCSM
• Setting up and running a simple case
• Datasets
• Production
• Modifying source code
• Errors
• Tools
• Performance

3
Review of CCSM

• Five components / Ten models
• Atmosphere(3) atm, datm, latm
• Ocean(2) ocn, docn
• Land(2) lnd, dlnd
• Ice(2) ice, ice (prescribed mode), ice (mixed
  layer ocean mode), dice
• Coupler(1) cpl
• Communication via MPI between components and
  coupler only
• Each component runs on multiple processors via
  MPI, OpenMP, MPI/OpenMP

4
Component parallelization

• atm MPI, OpenMP, or MPI/OpenMP
• lnd MPI, OpenMP, or MPI/OpenMP
• Ice MPI only
• ocn MPI only
• cpl OpenMP only
• The data models, datm, docn, dice, dlnd, and latm
  serial only, 1 processor

5
Configurations

• A datm, dlnd, docn, dice, cpl
• B atm, lnd, ocn, ice, cpl
• C datm, dlnd, ocn, dice, cpl
• D datm, dlnd, docn, ice, cpl
• F atm, lnd, docn, ice (prescribed mode), cpl
• G latm, dlnd, ocn, ice, cpl
• H atm, dlnd, docn, dice, cpl
• I datm, lnd, docn, dice, cpl
• K atm, lnd, docn, dice, cpl
• M latm, dlnd, docn, ice (ml ocn mode), cpl

6
Resolutions

• atm/lnd/datm/dlnd T42, T31
• ocn/ice/docn/dice gx1v3, gx3, gx3v4
• latm T62
• Scientifically validated combinations
• B, T42_gx1v3 b20.007 control run (test.a1 case)
• B, T31_gx3v4 paleo control run (test.a2 case)

7
Available configurations

8
Platforms

• IBM
• SGI
• Compaq

9
Review of scripts

• Main script (test.a1.run)
• Sets primary ccsm environment variables
• Calls model.setup.csh
• Gets input datasets
• Builds components
• Runs model
• Archives
• Harvests

10
Setting up a simple case

• Use the GUI !!
• The GUI modifies the scripts and creates a new
  case for you
• Input CASE, CSMROOT, CSMDATA, EXEROOT
• Input resolution
• Input configuration (A-M)
• Sets processor layout based on configuration
  (first guess)
• Sets some batch environment variables
• Works well in the NCAR environment, other sites
  require post script-generation tuning

11
Setting up a simple case, without GUI

• Create new case directory under scripts, copy
  over test.a1 files
• Rename file test.a1.run to CASE.run
• Edit CASE, CSMROOT, CSMDATA, EXEROOT,
  ARCROOT
• Edit batch environment parameters
• Edit GRID
• Edit SETUPS
• Edit NTASKS, NTHRDS

12
NTASKS, NTHRDS, batch

• NTASKS are the total number of MPI tasks for
  each component
• NTHRDS are the number of OpenMP threads per MPI
  task
• NTASKSNTHRDS total number of processors for
  each component
• Tuning required to get optimal load balance
• Batch parameters should match processors used,
  consistency important, task_geometry
  (loadleveler) is very powerful

13
Component parallelization

• atm MPI, OpenMP, or MPI/OpenMP
• lnd MPI, OpenMP, or MPI/OpenMP
• ice MPI only, NTHRDS1
• ocn MPI only, NTHRDS1
• cpl OpenMP only, NTASKS1
• The data models, datm, docn, dice, dlnd, and latm
  serial only, 1 processor, NTASKS1, NTHRDS1

14
Main script configuration summary

• B case
• MODELS ( atm lnd ocn ice cpl)
• SETUPS ( atm lnd ocn ice cpl)
• NTASKS ( 8 2 40 8 1)
• NTHRDS ( 4 4 1 1 4)
• datm/dlnd/ocn/ice case
• MODELS ( atm lnd ocn ice cpl)
• SETUPS ( datm dlnd ocn ice cpl)
• NTASKS ( 1 1 64 16 1)
• NTHRDS ( 1 1 1 1 4)

15
RUNTYPE

• Startup - initial startup of model using
  arbitrary initialization
• set CASE, BASEDATE
• Continue - continuation of case, bit-for-bit
  guaranteed, uses model restart files
• set CASE
• Branch - start new case as a bit-for-bit
  continuation of another case, uses model restart
  files, requires continuous date
• set CASE, REFCASE, REFDATE
• Hybrid - start new case, not bit-for-bit
  continuation, uses model initial files in atm and
  land, can change starting date
• set CASE,BASEDATE,REFCASE,REFDATE

16
Coupler namelist

• Stop_option ndays, nmonths, newmonth, halfyear,
  newyear, newdecade
• Stop_n integer (ndays, nmonths)
• Rest_freq ndays, monthly, quarterly, halfyear,
  yearly
• Rest_n integer (ndays)
• Diag_freq daily, weekly, biweekly, monthly,
  quarterly, yearly, ndays
• Diag_n integer (ndays)
• info_bcheck integer

17
Data Sets

• Types
• Grid files, binary
• Namelist input, ascii
• Initial datasets, binary/netcdf
• Restart datasets, binary
• History datasets, netcdf
• Log files, ascii
• inputdata directory
• This is usually pointed to by CSMDATA

18
Data Flow, Input

• Everything is copied to EXEROOT
• Tools and scripts attempt to automate most of the
  get input files
• Main script variables include CSMDATA, LFSINP,
  LMSINP, MACINP, RFSINP, RMSINP

19
Data Flow, Output

• Output files are moved out of EXEROOT
• Harvesting is a separate process
• Writing of restart files coordinated by the
  coupler
• Writing of history files is not coordinated
  between components, monthly average is default
• Main script variables include LMSOUT, MACOUT,
  RFSOUT

Scripts
EXEROOT
Mass Store
ARCROOT
archiving
harvesting
20
Log Files

• Each component produces a log file,
  model.log.LID
• LID is a system date stamp
• Date stamps are the same on all log files for a
  run
• Log files are written into the EXEROOT/model
  directories during execution
• Log files are copied to SCRIPTS/logs at the end
  of a run
• There are separate stdout and stderr that
  sometimes contain output information

21
Archiving, ccsm_archive

• Means moving model output to a separate area on a
  local disk, ccsm_archive
• Local disk area is set by ARCROOT in the main
  script
• Benefits
• Allows separation of running and harvesting
• Mass storage availability does not prevent
  continued execution of the model
• Allows users to run in volatile temporary space
• Supports simple harvesting in a clustered
  machine environment (like nirvana)

22
Harvesting, CASE.har

• Means copying model output to the local mass
  store
• Separate script in scripts/CASE, CASE.har
• Typically submitted in batch, can also be run
  interactively
• Submitted by main script after model run, off by
  default
• Sources ccsm_joe for important environment
  variables
• Harvests all files in ARCROOT/atm,lnd,ocn,ice,cp
  l
• Verifies accurate copy on mass store before
  removing
• Can scp files to remote machines

23
Exact Restart

• CCSM can stop and restart exactly
• The coupler controls the frequency of restart
  file writes
• Restart files guarantee bit-for-bit continuity at
  a checkpoint boundary
• rpointer files are updated in the scripts/CASE
  directory after each run

24
Restart file management (1)

• ccsm_archive
• In scripts/CASE
• Called from main script after model run is
  complete, commented out by default
• ARCROOT/restart contains the latest full set of
  restart files
• ccsm_archive copies full set of restart datasets
  into ARCROOT/restart after each run
• ccsm_archive then tars up that restart set into
  the ARCROOT/restart.tars directory
• These tar files can be large, regular clean up
  required

25
Restart file management (2)

• ccsm_getrestart
• In scripts/tools
• Called from main script before model run starts,
  commented out by default
• Copies the latest set of restart files from
  ARCROOT/restart to the appropriate directories
• To backup model run to previous model date
• Assumes both ccsm_archive and ccsm_getrestart
  have been active in the main script
• Delete all files in ARCROOT/restart
• Untar an ARCROOOT/restart.tars file into
  ARCROOT/restart
• Resubmit

26
Auto-Resubmit

• RESUBMIT file in scripts/CASE directory
• contains a single integer
• If the integer is gt0, main script resubmits
  itself and decrements the integer
• Runaway jobs
• FIRST! set value in RESUBMIT file to 0
• Attempt to kill running jobs

27
Production

• Modify coupler namelist in cpl.setup.csh, set run
  length and restart frequency, turn down
  diagnostic frequency, set info_bcheck to 0.
• Run a startup, hybrid, or branch case RUNTYPE
• Transition to continue RUNTYPE
• Turn on archiving, harvesting, and
  ccsm_getrestart
• Edit RESUBMIT file to initiate auto-resubmission

28
Monitoring a run

• Monitor the batch jobs using llq, bjobs, qstat
• Verify that runs complete successfully, check for
  timing information at the end of a log file
• Tail -f EXEROOT/cpl/cpl.log
• If runs are not succeeding,
• tail each log file
• grep for ENDRUN in atm and lnd log files
• Check stdout and stderr files for component
  messages or system messages
• Look for core files in EXEROOT/model
• Look for zero length files in EXEROOT/model
• Check email

29
Modifying source code

• Modifying files in the ccsm models directory is
  not recommended
• Create directories under scripts/CASE
• src.atm, src.lnd, src.ocn, src.ice, src.cpl
• Copy subset of model source code to these
  directories and modify it
• Has highest priority with respect to build
• Benefits include
• Release source code remains unmodified and
  available
• Allows implementation of case dependent code
  modifications

30
Multiple Machine Support

• Should run on blackforest, babyblue, and ute out
  of the box
• Other machines include seaborg, nirvana, eagle,
  falcon, cheetah
• Supported platforms are indicated in OS, SITE,
  MACH, ARCH environment variables in the main
  script
• See also scripts/tools/test.a1.mods.MACH for
  suggested changes to test.a1.run for other
  machines.

31
Running on a New Machine

• Main script
• Set batch queue commands
• Add new OS, SITE, MACH, ARCH options
• Set standard CCSM path names, CSMROOT,
• Harvester submission issues
• Set data movement variables, LMSINP,
• Harvester script
• May require modification
• Tools
• May need to modify ccsm_msread, ccsm_mswrite
• Build
• Modify models/bld/Macros.OS file

32
ccsm_joe

• Created by main script
• Updated every time the main script runs
• Case dependent
• Records important ccsm environment variables
• Can be sourced by other scripts to inherit ccsm
  environment variables

33
Interactive/Batch Issues

• Can run main script interactively
• Typically used to build and pre-stage initial
  data
• Uncomment exit command in main script to stop
  the script before script starts ccsm execution
• Batch environment highly site dependent
• NQS
• Loadleveler
• LSF
• PBS

34
Common Errors (1)

• Model wont build
• Try rebuilding clean
• Remove all obj directories, these are
  OBJROOT/model/obj which is normally equivalent
  to EXEROOT/model/obj
• When rebuilding, make sure SETBLD is true in
  main script
• Model wont continue due to restart problem
• Determine cause of problem quota, hardware,
  script, zero length files, rpointer problems
• Fix if possible
• Back up to latest good restart dataset
• Rerun

35
Common Errors (2)

• Ice model stops due to mp transport error
• Double ndte in ice.setup.csh ice model namelist
• Back up to latest good restart dataset
• Run past previous stop date
• Reset ndte value
• Ocean model non-convergence
• Add about 10 to the number of model
  timesteps/hour in ocn.setup.csh, DT_COUNT
• Back up to latest good restart dataset
• Run past previous stop date
• Reset DT_COUNT
• Non-convergence on first timestep is special case

36
Tools

• Under scripts/tools
• ccsm_getfile hierarchical search for file
• ccsm_getinput hierarchical search for input
  file
• ccsm_msread copies a file from local mass store
• ccsm_mswrite copies a file to local mass store
• ccsm_checkenvs echo ccsm environment variables,
  used to created ccsm_joe
• ccsm-getrestart copies restart files from
  ARCROOT/restart to appropriate EXEROOT and
  scripts/CASE directories

37
Performance

• This is complicated!
• Issues
• Performance of components and system as a
  function of resolution and configuration
• Scalability of individual components, scaling
  efficiency of individual components
• Task/Thread counts
• Components sharing nodes, overloading nodes with
  multiple components, overloading threads,
  overloading tasks
• Load balance of coupled system

38
Component Timings
39
CCSM Load Balancing

• 40 ocean
• 32 atm
• 16 ice
• 12 land
• 04 cpl
• 104 total

processors
53.2
8.6
40.4
6.2
15.0
9.4
3.0
10.0
10.0
3
2
5
55
Timings in seconds per day
40
Component/Hardware layout

• Machine, set of nodes
• Nodes, group of processors that share memory
• Processors, individual computing elements
• General rules
• Do not oversubscribe processors, place only 1 MPI
  task or 1 thread on each processor
• Minimize the number of nodes used for a given
  component and processor requirement
• Multiple components can share a node as long as
  there is no oversubscription of processors
• Test several decompositions, layouts, task/thread
  combinations to try to optimize performance

41
Summary

• CCSM is a complicated multi-executable climate
  model, expect there to be spin-up time
• CCSM is a scientific research code
• There are many possible components,
  configurations, platforms, and resolutions we
  are unable to test everything
• Users are responsible for validating their
  science
• NCAR can help with software/configuration
  problems, ccsm_at_ucar.edu
• Please report bugs, fixes, improvements, and
  ports to new hardware, so we can incorporate
  those changes! ccsm_at_ucar.edu
