Title: Semantic Web Introduction


1
Semantic WebIntroduction
2
Outline
  • The current Web
  • What is Semantic Web?
  • How the Semantic Web Will Be Possible?
  • Framework of the Semantic Web

3
Weaving the Web Vision of Tim Berners-Lee
  • The first step is putting data on the Web in a
    form that machines can naturally understand, or
    converting it to that form. This creates what I
    call a Semantic Web (SW) a web of data that can
    be processed directly or indirectly by
    machines-- Tim Berners-Lee Weaving the Web,
    Harper San Francisco, 1999
  • Require that there be a machine-understandable
    semantics for some or all of the information
    presented in the WWW

4
Web Today
  • Information repository.
  • Simplicity.
  • Primarily for human interpretation and use.

5
Current Web for Knowledge Management
  • Search information Keyword-based search
  • Extracting information human browsing and
    reading
  • Automatic agents lack the commonsense knowledge
    required to extract "relevant" from textual
    representations and fail to integrate information
    spread over different source
  • Maintenance
  • keeping collections consistent, correct, and up
    to date requires a mechanized representation of
    semantics and constraints that help to detect
    anomalies
  • Automatic document generation
  • According to user profiles or other relevant
    aspects
  • Require a machine-accessible representation of
    the semantics of these information sources

6
Current Web for Knowledge Management (Cont.)
  • Semantic Web technology will enable structural
    and semantic definitions of documents providing
    completely new possibilities
  • Intelligent search instead of keyword matching
  • Query answering instead of information retrieval
  • Document exchange among departments via ontology
    mappings
  • Definition of customized views on documents

7
Current Web for Web Commerce
  • B2C online store, auction houses, online
    marketplaces
  • Shop-bots visit several stores, extract product
    information, and present to the customer an
    instant market overview
  • Functionality is provided via wrappers written
    for each online store
  • Keyword search regularities in the presentation
    format of stores' Web sites text extraction
    heuristics
  • Efforts time-consuming activity for writing
    wrappers
  • Quality limited product information, error
    prone, incomplete
  • Why most product information on Web sites is
    provided in natural language, and automatic text
    recognition is still a research area with
    significant unsolved problems
  • Require a machine-processable semantics for the
    information provided

8
Current Web for Web Commerce (Cont.)
  • When standard representation formalisms for the
    structure and semantics of data are available
  • Software agents can then be built that can
    understand the product information the Web sites
    provide
  • Meta-online stores can then be constructed with
    little effort, and this technique will also
    enable complete market transparency in various
    dimensions of diverse product properties
  • The low-level programming of wrappers based on
    text extraction and format heuristics will be
    replaced by semantic mappings that translate
    different formats used to represent products and
    can be used to navigate and search automatically
    for the required information

9
Toward Semantic Web
Information repository ? Information-service
provider
10
What Is the Semantic Web?
11
Vision of Tim Berners-Lee for the Future of the
Web
  • Two-part vision
  • Make the Web a more collaborative medium
  • Make the Web understandable, and thus
    processable, by machines
  • Original Web proposal to CERN
  • Relations between information items like
    "includes," "describes,", and "wrote" ? not
    currently captured on the Web
  • Use RDF to capture such relationship

12
Original Web Proposal to CERN
Encompass additional metadata above and beyond
what is currently in the Web. This additional
metadata is needed for machines to be able to
process information on the Web
13
Web vs. Semantic Web
Web
Semantic Web
14
Smart Data
  • How do we create a web of data that machines can
    process?
  • MAKE THE DATA SMARTER
  • The smart data continuum
  • Text and databases (pre-XML)
  • XML documents for a single domain
  • Taxonomies and documents with mixed vocabularies
  • Ontologies and rules

15
The Smart Data Continuum
16
Text and databases
  • Pre-XML
  • The initial stage where most data is proprietary
    to an application
  • The "smarts" are in the application and not in
    the data

17
XML documents for a single domain
  • The stage where data achieves application
    independence within a specific domain
  • Data is now smart enough to move between
    applications in a single domain
  • Example XML standards in the healthcare
    industry, insurance industry, or real estate
    industry

18
Taxonomies and documents with mixed vocabularies
  • Data can be composed from multiple domains and
    accurately classified in a hierarchical taxonomy
  • The classification can be used for discovery of
    data
  • Simple relationships between categories in the
    taxonomy can be used to relate and thus combine
    data
  • Data is now smart enough to be easily discovered
    and sensibly combined with other data

19
Ontologies and rules
  • New data can be inferred from existing data by
    following logical rules
  • Data is now smart enough to be described with
    concrete relationships, and sophisticated
    formalisms where logical calculations can be made
    on this "semantic algebra."
  • This allows the combination and recombination of
    data at a more atomic level and very fine-grained
    analysis of data
  • Data no loner exists as a blob but as a part of a
    sophisticated microcosm
  • Example automatic translation of a document in
    one domain to the equivalent (or as close as
    possible) document in another domain

20
Definition of Semantic Web
  • A machine processable web of smart data
  • Smart data can be further defined as data that is
    application-independent, composeable, classified,
    and part of a larger information ecosystem
    (ontology)
  • An extension of the current web in which
    information is given well-defined meaning, better
    enabling computers and people to work in
    cooperation.
  • An infrastructure enables machines to COMPREHEND
    semantic documents and data.
  • A brain for humankind, which assists the
    evolution of human knowledge as a whole.

21
How the Semantic Web Will Be Possible?
22
Achieving a Semantic Web Requires
  • Developing languages for expressing
    machine-understandable meta-information for
    documents and developing terminologies (i.e.
    namespaces or ontologies) using these languages
    and making them available on the Web
  • Developing tools and new architectures that use
    such languages and terminologies to provide
    support in finding, accessing, presenting, and
    maintaining information sources
  • Realizing applications that provide a new level
    of service to the human users of the semantic Web

23
Languages Two Aspects
  • Languages that provide formal syntax and formal
    semantics to enable automated processing of
    content
  • Languages that provide standardized vocabulary
    referring to real-world semantics enabling
    automatic and human agents to share information
    and knowledge ontologies

24
Formal Languages
  • Layer language model for the Semantic Web
  • HTML just for presentation, not for processing
  • XML separate content and data from presentation
  • The Semantic Web is an XML application
  • RDF defines a syntactic convention and a simple
    data model for representing machine-processable
    semantic of data
  • RDF Schema (RDFS) defines basic ontological
    modeling primitives on top of RDF
  • Ontology Inference Layer (OIL) and DARPA Agent
    Markup LanguageOntology (DAML-ONT) full blown
    ontology modeling language as extension of RDFS

25
Data representation
  • XML addresses only document structure.
  • RDF is a web-enabled language of Subject, Verb,
    Object triples to represent relationships between
    data.
  • Ontology is the specification of a
    conceptualizationdefines terms and relationships
    between them.
  • Logic allows us to reason across the RDF elements.

26
How does XML Fit into the Semantic Web?
  • XML is the syntactic foundation layer of the
    Semantic Web
  • XML guarantees a base level of interoperability
  • XML is built upon Unicode characters and Uniform
    Resource Identifiers (URIs)
  • Unicode allow XML to be authored using
    international characters
  • URI used as unique identifiers for concepts in
    Semantic Web
  • XML is not enough (only syntactic
    interoperability)
  • Sharing XML documents adds meaning to the
    content but, only when both parties understand
    the element name
  • ? ltpricegt12.00lt/pricegt VS. ltcostgt12.00lt/costgt
  • ? Require SW technologies like ontologies

27
RDF and RDFS
  • RDF standard for Web metadata developed by W3C
  • Suitable for describing any Web resources
  • Provide interoperability among applications that
    exchange machine-understandable information on
    the Web
  • An XML application and adds a simple data model
    on top of XML
  • Objects, properties, and values of properties
  • RDFS candidate recommendation
  • Define additional modeling primitives on top of
    RDF
  • Allow the definition of classes (i.e. concepts),
    inheritance hierarchies for classes and
    properties, and domain and range restrictions for
    properties

28
RDF Application Integration Hub
29
Logical Assertions
  • An assertion is the smallest expression of useful
    information
  • Use Resource Description Framework (RDF) to
    capture the association (assertion) between
    subjects and objects
  • How can we use these assertions?
  • The author of a document has written other
    articles on similar topics
  • A well-know authority on the subject has refuted
    the main points of an article
  • Assertions are not free-form commentary but
    instead add logical statements to a resource or
    about a resource

Object
OnlineMike
knows
Subject
OnlineMary
age
Each Subject/ Object is a resource
Literal
33
30
Classification Taxonomy
  • We classify things to establish groupings by
    which generalization can be made
  • Downside of classification systems
  • Categories can be arbitrary
  • Membership criteria are often ambiguous
  • Lack rigorous logic for machines to make
    inference from useful for humans browsing for
    information
  • XML Topic Maps (XTM)
  • Example Linnaean classification of a house cat
  • Kingdom Animalia
  • Phylum Chordata
  • Class Mammalia
  • Order Carnivora
  • Family Felidae
  • Genus Felis
  • Species Felis domesticus

31
Ontologies Formal Class Model
  • An ontology is a formal, explicit, specification
    of a shared conceptualization
  • Conceptualization an abstract model of some
    phenomenon in the world that identifies the
    relevant concepts of that phenomenon
  • Explicit the type of concepts used and the
    constraints on their use are explicitly defined
  • Formal ontology should be machine
    understandable
  • Shared an ontology captures consensual
    knowledge. It is not restricted to some
    individual but accepted by a group
  • Ontology examples
  • WordNet (http//www.cogsci.princeton.edu/wn)
    a thesaurus for over 100,000 terms explained in
    natural language
  • CYC (http//www.cyc.com) formal axiomating
    theories for many aspects of common sense
    knowledge

32
Ontologies (Cont.)
  • An ontology is a formal representation of classes
    and relationships between classes to enable
    inference
  • Formal class hierarchies constrained properties
    relations between classes
  • An ontology contain classes, subclasses,
    properties of classes, and relations between
    classes
  • An ontology captures logical information in a
    manner that can allow inference
  • John is a Leader ? John is a Person and John may
    lead an organization
  • Additional formalisms are added to enable
    inference
  • Symmetric property, transitive property
    (hasAncestor)

33
Key Ontology Components
Person Birthdate date Gender char
depiction
knows
published
is-A
worksfor
Resource
Organization
Leader
leads
34
Ontologies (Cont.)
  • Shared formal conceptualizations of particular
    domains.
  • Enable Web-based knowledge processing, sharing,
    and reuse.
  • Provide a common understanding of topics.
  • Ensure that everyone agrees on terms, types,
    constraints, etc.

35
Ontologies (Cont.)
  • Developed in AI to facilitate knowledge sharing
    and reuse
  • Applications knowledge engineering, NLP,
    knowledge representation, intelligent information
    integration, cooperative information systems,
    information retrieval, electronic commerce, and
    KM
  • Why so popular what they promise a shared and
    common understanding of some domain that can be
    communicated among people and application systems
  • Aim at consensual domain knowledge cooperative
    development process

36
Rules
  • With XML, RDF, and inference rules, the Web can
    be transformed from a collection of documents
    into a knowledge base
  • Modus Ponens "If P is TRUE, then Q is TRUE"
  • P is TRUE therefore, Q is TRUE
  • "An apple is tasty if it is not cooked. This
    apple is not cooked. Therefore, it is tasty."
  • SW can use information in an ontology with logic
    rules to infer new information
  • "Let's say one company decides that if someone
    sells more than 100 of our products, then they
    are a member of the Super Salesman Club." ? a
    smart program can now follow this rule to make a
    simple deduction "John has sold 102 things,
    therefore John is a member of the Super Salesman
    club"

37
Using rules to infer the uncleOf Relation
  • If a person C is a male and childOf a person A,
    then person C is a "sonOf" person A
  • If a person B is a male and siblingOf a person A,
    then person B is a "brotherOf" person A
  • If a person C is a "sonOf" person A, and person B
    is a "brotherOf" person A, then person B is the
    "uncleOf" person C

PersonA
PersonB
siblingOf
childOf
uncleOf
PersonC
38
OIL An Ontology Language
  • OIL (http//www.ontoknowledge.org/oil)
  • Ontology Inference Layer or Ontology Interchange
    Language
  • Three requirements for an ontology language
  • It must be highly intuitive to the human user.
  • Given the current success of the frame-based and
    OO modeling paradigm, it should have a frame-like
    look and feel
  • It must have a well-defined formal semantics with
    established reasoning properties in terms of
    completeness, correctness, and efficiency
  • It must have a proper link with existing Web
    languages like XML and RDF, ensuring
    interoperability
  • OIL fulfill the above three requirements

39
DAML-ONT Another Ontology Language
  • DAML-ONT (http//www.daml.org)
  • Funded by the U.S. DARPA
  • Sill in an early stage of development and lacks a
    formal definition of its semantics

40
Tools
  • Formal languages to express and represent
    ontologies
  • Editors and semiautomatic construction to build
    new ontologies
  • Reusing and merging existing ontologies (ontology
    environment)
  • Reasoning services (instance and schema
    inferences that enable advanced query answering
    service, support ontology creation, and help map
    between different terminologies)
  • Annotation tools to link unstructured and
    semi-structured information sources with metadata
  • Tools for information access and navigation that
    enable intelligent information access for human
    users
  • Translation and integration services between
    different ontologies that enable multi-standard
    data interchange and multiple view definitions
    (especially for B2B electronic commerce)

41
Ontology Editors
  • Help human knowledge engineers build ontologies
  • Ontology development and maintenance
  • Define concept hierarchies, attributes for
    concepts, axioms and constraints
  • Inspect, browse, codify, and modify ontologies
  • GUI
  • Conform to existing standards in Web-based
    software development
  • Example Protégé (Stanford)

42
Protégé Editor
43
Semi-Automatic Ontology Constructor
  • Manually building ontologies is time-consuming
  • Tools that learn ontologies from natural language
    exploit the interaction constraints on the
    various levels (morphology, syntactic, semantic,
    pragmatics, background knowledge) in order to
    discover new concepts and stipulate relationships
    among concepts
  • These tools combine machine learning, information
    extraction, and linguistic techniques to extract
    relevant concepts, build is-a hierarchies, and
    determine relationships among concepts

44
Semi-Automatic Ontology Constructor Text-To-Onto
  • KM group of the Institute AIFB, Karlsruhe
    University
  • Learn ontologies from text
  • Select a relevant corpus of domain texts (NLP
    texts or HTML texts)
  • Use domain lexicon to perform domain-specific
    parsing
  • Existing knowledge structures (ex. A taxonomy of
    concepts) are incorporated as background
    knowledge
  • Discover new knowledge structures, which are then
    captured in the ontology modeling module to
    expand the existing ontology

45
Text-To-Onto
46
Ontology Environment
  • Reuse existing ontologies to save time and labor
  • Must allow adaptation and merging of existing
    ontologies to make them fit for new tasks and
    domains
  • Operations for combining ontologies ontology
    inclusion, restriction, and polymorphic
    refinement
  • Use ontologies in different formats, reorganize
    taxonomies, resolve name conflicts, browse
    ontologies, edit terms
  • Example Chimaera (Stanford) merging and
    diagnosing (and evolving) ontologies

47
Chimaera
48
Reasoning Services
  • Reasoning over instances of an ontology
  • Derive a certain value for an attribute applied
    to an object
  • Powerful support in formulating rules and
    constraints and answering queries over schema
    information
  • Used to answer queries about the explicit and
    implicit knowledge specified by an ontology
  • Help to build ontologies
  • Example Ontobroker (Ontoprise,
    http//www.ontoprise.de)

49
Reasoning Services (Cont.)
  • Reasoning over concepts of an ontology
  • Automatically derives the right position for a
    new concept in a given concept hierarchy
  • Help to build ontologies
  • Example FaCT (Fast Classification of
    Teminologies) (Manchester University) derive
    concept hierarchies automatically

50
Annotation Tools
  • Ontologies can be used to describe a large number
    of instances
  • Annotation tools help the knowledge engineer to
    establish such links via
  • Linking an ontology with a database schema or
    deriving a database schema from an ontology (in
    cases of structured data)
  • Deriving an XML DTD, an XML schema, and an RDF
    schema from an ontology (in case of
    semi-structured data)
  • Manually or semi-automatically adding ontological
    annotation to unstructured data

51
The Ontology-Learning Process
52
Tools for Information Access and Navigation
  • Low-level navigation now clicking on links and
    using keyword searches
  • Keyword-based search retrieves irrelevant
    information that uses a particular word in a
    different meaning from the one intended, and it
    may miss relevant links in which different words
    than the keyword are used to describe the content
    for which the user is searching
  • Navigation is supported only by predefined links
    current navigation technology does not support
    clustering and linking of pages based on semantic
    similarity
  • Query responses require human browsing and
    reading to extract the relevant information from
    the information sources returned
  • Burden Web users with an additional loss of time
    and seriously limits information retrieval by
    automatic agents

53
Tools for Information Access and Navigation
(Cont.)
  • Low-level navigation now (Cont.)
  • Keyword-based document retrieval fails to
    integrate information spread over different
    sources
  • Current retrieval services can retrieve only
    information that is directly represented on the
    Web. No further inference service is provided for
    deriving implicit information that must be
    derived from the explicit text
  • Ontologies can
  • Support IR based on the actual content of a page
  • Help user navigate information space based on
    semantic concepts
  • Enable advanced query answering and information
    extraction services, integrating heterogeneous
    and distributed information sources enriched by
    inferred background knowledge

54
Hyperbolic Browsing Interface
Semantic Information Visualization
55
Automatically Generated Semantic Structure Map
56
Translation and Integration Services
  • Current B2B the heterogeneity of product
    descriptions on Web sites and the exponentially
    increasing effort that must be devoted to mapping
    these heterogeneous descriptions as the number of
    Web sites increases
  • Effective and efficient CM of heterogeneous
    product catalogues is critical for the success of
    B2B
  • Mapping heterogeneous descriptions
  • Different representations of product catalogs
    must be merged
  • XML with DTD1 ?? XML with DTD2
  • Different vocabularies used to describe products
    must be merged
  • Languages, concepts, attributes, values and value
    types

57
Applications
  • Applications for Knowledge Management
  • On-To-Knowledge
  • SwissLife (http//www.swisslife.ch)
  • British Telcom (http//www.bt.com/innovations)
  • Enersearch (http//www.enersearch.se)
  • Applications for B2C
  • Semantic Edge (http//www.semanticedge.com)

58
Web Services
  • Web services are software services identified by
    a URI that are described, discovered, and
    accessed using Web protocol
  • Web services consume and produce XML
  • Furthering the adoption of XML, or more smart
    data
  • As Web services proliferate, they are more
    difficult to discover ? using SW technologies to
    solve the Web service discovery problem
  • Enabling Web services to interact with other Web
    services

59
Semantic Web services and agents
  • Automation tasks
  • Service discovery
  • Service comparison
  • Service execution
  • Service composition and interoperation
  • What should be markup?
  • Web services
  • User constraints and preferences
  • Agent procedure

60
Framework of Semantic Web
61
Semantic Web Principles
  • Everything is identifiable
  • Any abstract thing can have a URI.
  • Partial information
  • Anyone can say anything about anything.
  • Dont expect global consistency.
  • Evolution
  • Allow effective combination of the independent
    work of diverse communities.
  • Minimalist design
  • Make the simple things simple, and the complex
    things possible.

62
What achieves the Semantic Web?
  • Knowledge representation
  • Ontology Logic Inference Learning
  • Semantic Web services
  • Agents

63
Semantic interoperability
64
Proofs exchange between agents
65
Trust
  • Add semantics to make trust determination better
  • You may want to allow access to information if a
    trusted friend vouches (via a digital signature)
    for a third party
  • Digital signatures are crucial to the "web of
    trust"
  • By allowing anyone to make logical statements
    about resources, smart applications will only
    want to make inferences on statements that they
    can trust
  • Verifying the source of statements is a key part
    of SW

66
Semantic Web wave
67
Who are involved?
  • Artificial intelligence
  • The web
  • Databases
  • Agents
  • Theoretical computer science and logic
  • Systems
  • Computational linguistics and pattern recognition
  • Document engineering and digital libraries
  • Human-computer interfaces
  • Social and human sciences

68
Discussions
  • The Semantic Web is not a separate Web but an
    extension of the current one.
  • Markup makes data computer-interpretable,
    use-apparent, and agent-ready.
  • The Semantic Web will break out of the virtual
    realm and extend into our physical world.
  • Ubiquitous knowledge and computing
  • Can you imagine the Semantic Web A brain for
    humankind?

69
References
  • http//www.w3.org/2001/sw/
  • http//www.semanticweb.org/
  • Semantic Web-enabled Web services
    (http//swws.semanticweb.org)
Write a Comment
User Comments (0)
About PowerShow.com
