Title: CEREBELLUM


1
CEREBELLUM
Dr Hina Khalil Malik Department of Anatomy Fatima
Jinnah Dental College
2
Anatomy
Seen from feet
  • Located dorsal to pons and medulla
  • In posterior fossa under tentorium cerebelli
  • Lobes
  • Floccular Nodular(small fluffy mass)
  • Anterior
  • Posterior

Anterior lobe (H)
Posterior lobe (I)
3
Flattened Cerebellum
  • Longitudinally separated into hemispheres and
    cortices
  • Median (Vermis)

4
Cerebellum
Paramedian
Primary Fissure
Median
Horizontal Fissure
5
STRUCTURE
  • Gray matter, cortex intercerebellar nuclei
  • White matter

6
(No Transcript)
7
Cellular layer
8
FUNCTIONAL AREA
  • Cortex
  • Intermediate zone
  • Lateral zone

9
(No Transcript)
10
Cerebellar Nuclei
  • Dentate nucleus
  • Largest, communicates through cerebellar peduncle
  • Carries information important for coordination of
    limb movements (along with the motor cortex and
    basal ganglia)
  • Emboliform nucleus (medial side of the nucleus
    dentatus)
  • Regulates movements of ipsilateral extremity
  • Globose nucleus
  • Regulates movements of ipsilateral extremity
  • Fastigial nucleus
  • Regulates body posture
  • Is related to the flocculo nodular lobe

11
WHITE MATTER
  • 3 groups of fibers
  • Intrinsic
  • Afferent-middle inf cereb peduncle
  • Efferent

12
  • Climbing fibers
  • Mossy fibers
  • FUNCTIONAL UNIT OF THE CEREBELLAR CORTEX

13
Dentate Nucleus
Dentate Nucleus
Pontine Projections
Superior Cerebellar Peduncle
Pons
14
Cerebellar peduncle
  • Superior-midbrain
  • Middle-pons
  • Inferior-medulla

15
CEREBELLAR NERVE FIBERS
  • Afferent fibers
  • i. from the cerebral cortex
  • ii. from the spinal cord
  • iii. others ( red nucleus tectum)
  • Efferent fibers

16
i.Cerebellar afferent fibers from the cerebral
cortex
  • 3 pathways
  • Corticopontocerebellar
  • Cerebro-olivocerebellar
  • Cerebroreticulocerebellar

17
1.Corticopontocerebellar pathway
  • Info From Pontine Nuclei (via middle cereb
    peduncle) From Opposite Cerebral Cortex, Visual
    and Auditory Inputs
  • To Opposite Cerebellar Hemisphere
  • Conveys control

18
2.Cerebro-olivocerebellar pathway
  • Info From Spinal Cord Through Olivary N to
    Contralateral Cerebellar Hemisphere via inf cereb
    peduncle
  • Source of Climbing Fibers for Direct Input to
    Cerebellum
  • Conveys control

19
3.Cerebroreticulocerebellar pathway
  • Info From Cerebral Cortices (sensorimotor areas),
    through the reticular formation through inf
    middle cereb peduncle
  • Control of voluntary movement

20
ii. Afferent fibers from the spinal cord
  • 1.Anterior spinocerebellar tract
  • -Info from the muscles joints (receptors) via
    sup cereb peduncle to the cerebellarcortex
  • 2. Posterior spinocerebellar tract
  • -Info from the muscles joints (receptors) via
    inf cereb peduncle to the cerebellarcortex

21
  • 3.Cuneocerebellar tract
  • -Conveys info of the muscles and joints of the
    upper limb and upper part of the thorax via the
    inf cereb peduncle to the cerebellar cortex
  • 4. Vestibulocerebellar Tract
  • Info From Semicircular Canals utricle/saccule
    Through Inferior Peduncle to the flocculonodular
    lobe via the inf cereb peduncle
  • Conveys info of head position and movement

22
  • iii. Other afferent fibers
  • -Conveys info from the midbrain ( red nucleus
    tectum) to the cerebellar cortex

23
Cerebellar efferent fibers
24
Efferent Pathways
  • 3 pathways
  • Globose-Emboliform-Rubral pathway
  • Dentothalamic pathway
  • Fastigial Vestibular pathway
  • Fasigial Reticular pathway

25
Efferent Pathways
  • Arise From Cerebellar Nuclei
  • Dentate nucleus (influences ipsilateral motor
    activity)
  • Emboliform nucleus ()
  • Globose Nucleus ()
  • Fastigial Nucleus
  • Through Superior Cerebellar Peduncle to
  • Red Nucleus (Brainstem)
  • -Thalamus
  • -Motor Cortex

26
  • Through Inferior Cerebellar Peduncle to
  • lateral vestibular nucleus ( influences
    ipsilateral extensor muscle tone)
  • Reticular formation (influences ipsilateral
    muscle tone)

27
Afferent and Efferent Projections
Thalamus
Red nucleus
Superior Cerebellar Peduncle
Middle Cerebellar Peduncle (pontocerebellar
fibers)
Inferior Cerebellar Nucleus (olivocerebellar
fibers)
28
(No Transcript)
29
FUNCTION
  • The cerebellum has several main functions
  • coordinating skilled voluntary movements by
    influencing muscle activity,
  • controlling equilibrium and muscle tone through
    connections with the vestibular system and the
    spinal cord and its gamma motor neurons.
  • there is a somatotopic organization of body parts
    within the cerebellar cortex.
  • In addition, the cerebellum receives collateral
    input from the sensory and special sensory
    systems.The vermis tends to control
    coordination and muscle
    tone of the trunk, whereas each cerebellar
    hemisphere controls motor coordination and muscle
    tone on the same side of the body.
