Title: II' Dynamic Neuropathology of Cerebral Injury


1
II. Dynamic Neuropathology of Cerebral Injury
2
Cerebral Energy
  • A continuous supply of energy is important for
    maintaining several aspect of brain functioning,
    including
  • membrane potentials and electrochemical
    gradients
  • neurochemical processes responsible for synaptic
    transmission and
  • integrity of intracellular structures and
    membranes.
  • Energy is produced in the brain almost entirely
    from oxidative metabolism of glucose.
  • Oxidative metabolism of glucose yields energy in
    the form of phosphate bonds, the most important
    of which is ATP (adenosine triphosphate).

3
Cerebral Energy
  • Under conditions of aerobic metabolism, not only
    is ATP produced, but CO2 is a resulting
    metabolite that facilitates vasodilation of
    cerebral vessels and increases cerebral blood
    flow.
  • The energy status of any part of the brain is
    reflected by its content of ATP which demands
    more O2.
  • Thus, increasing function results in increasing
    O2 requirements, while decreasing function
    reduces O2 demands.
  • The brain can only store O2 for a few seconds and
    cannot store glucose.

4
Cerebral Energy
  • Therefore, an incessant supply of both glucose
    and O2 is essential for the continuing function
    of the brain.
  • If the energy supply fails completely, rapid and
    dramatic events occur.
  • After a few seconds neuronal function fails
  • After a few minutes, permanent structural damage
    occurs.

5
Hypoxemia
  • Hypoxemia is an abnormal deficiency of O2 in the
    arterial blood.
  • Hypoxemia can result from a variety of pulmonary
    conditions, such as chronic obstructive pulmonary
    disease (COPD), in which an inadequate amount of
    O2 makes it into the arterial blood.
  • With inadequate arterial O2, the brain
    experiences a consequent inadequate level of
    cellular O2, a condition known as hypoxia.

6
Hypoxemia
  • With hypoxia at the cellular level of the brain,
    glucose can only be metabolized by less efficient
    anaerobic means.
  • Anaerobic metabolism of glucose produces less ATP
    as well as metabolites other than CO2.
  • Glucose only partially oxidized results in lactic
    acid, which accumulates in the blood and reduces
    the cells electron transport system.
  • Lysosomes within the neuron cell bodies are
    sensitive to decreases in O2.

7
Ischemia
  • Ischemia refers to a reduced blood supply to the
    brain that deprives the neuronal tissue not only
    of O2 but of glucose as well.
  • The effects of low O2 have been discussed
    (anaerobic metabolism), but low glucose levels
    (hypoglycemia) can contribute to mental
    confusion, dizziness, convulsions, and loss of
    consciousness.
  • Tissue ischemia can damage the blood-brain
    barrierthe special mechanism that permits
    differential passage of certain materials from
    the blood into most parts of the brain.

8
Ischemia
  • This may result in brain edema and a rise in
    intracranial pressure (ICP).
  • Ischemia may also cause a rapid depletion of ATP,
    paralyzing the membrane transport system, and
    allowing accumulation of toxic molecules.
  • Increased tissue toxicity can also disrupt the
    blood-brain barrier, causing the capillary lumens
    to swell shut, further compounding tissue
    ischemia.

9
Cerebral Blood Flow
  • Blood flow, or perfusion, refers to the amount of
    blood that passes through a blood vessel in a
    given period of time.
  • Blood flow is determined by (1) blood pressure
    and (2) resistance, the force of friction as the
    blood travels through blood vessels.
  • The level of blood flow throughout the brain is
    carefully regulated to the metabolic needs of
    different parts of the brain.

10
Cerebral Blood Flow
  • Although the brain receives about 15 of the
    hearts total output, or about 800 ml/min of
    blood, the level of flow through the grey matter
    is much greater than that of the white matter.
  • The difference in the level of flow reflects the
    greater metabolic activity and greater
    vascularity of the grey matter.
  • Moreover, the level of flow also varies between
    different parts of the cerebral cortex, depending
    upon functional demands.

11
Cerebral Blood Flow
  • If PaO2 falls below 50 mm Hg, a distinct increase
    in cerebral blood flow takes place.
  • If PaO2 falls to 30 mm Hg, cerebral blood flow is
    more than doubled.
  • Raising PaO2 above 100 mm Hg causes only slight
    changes in cerebral blood flow.
  • Point to Ponder What is the potential
    consequence of doubled blood flow of hypoxemic
    blood?

12
Cerebral Blood Flow
  • CO2 is a very potent stimulus of cerebral
    vasodilation, so variations in PaCO2 can cause
    profound changes in cerebral blood flow.
  • Cerebral blood flow doubles when PaCO2 is
    increased from 40 to 80 mm Hg.
  • Cerebral blood flow is halved when PaCO2 drops to
    20 mm Hg.
  • Below 20 mm Hg, PaCO2 has very little effect on
    cerebral blood flow.
  • The flow is probably so low because of tissue
    hypoxia.

13
Cerebral Blood Flow
  • In a variety of pathological situations, the
    response of cerebral blood flow circulation to
    either changes in PaO2 or PaCO2 levels may be
    profoundly altered.
  • When there is a focal disorder, cerebral blood
    flow may fail to increase during low O2.
  • Indeed, blood flow may be increased to the
    surrounding normal area at the expense of the
    fall in flow in the affected area.
  • This is referred to as steal, where the normal
    surrounding areas of the brain are
    hyperperfused while the area in which there is
    some focal damage is actually hypoperfused.

14
Pressure Regulation
  • The brains mechanism for maintaining a constant
    flow of blood despite wide changes in arterial
    pressure is referred to as the autoregulator.
  • Chemocoreceptors and baroreceptors in arterial
    walls cause them to constrict or dilate in
    response to changes in pressure or gas levels.
  • When pressure is reduced, dilation occurs.
  • When pressure is increased, constriction occurs,
    which over the long term can cause increased
    resistance and increased damage to the arterial
    lumen.

15
Pressure Regulation
  • Any factor which alters the ability of the
    cerebral vessels to constrict or dilate
    interferes with the autoregulator.
  • The autoregulator can be impaired or even
    abolished by a wide variety of insults, such as
    ischemia, hypoxia, hypercapnia (?CO2), and brain
    trauma.
  • At arterial systolic (top) pressures below 60 mm
    Hg, as in the case of hemorrhage, vasodilation
    still occurs but the mechanism is no longer
    sufficient to prevent blood flow from falling.

16
Pressure Regulation
  • At acute extreme rises in diastolic (bottom)
    blood pressure over 160 mm Hg, vasoconstriction
    fails and the cerebral vessels become distended.
  • Cerebral blood flow increases, but in the areas
    of vessel distension, there may be breakdown of
    the blood-brain barrier with foci of cerebral
    edema.

17
Reduced Blood Flow
  • When cerebral blood flow is reduced, a
    progressive sequence of events can be
    demonstrated.
  • Initially, electrical function and metabolism
    continue but impaired.
  • From impairment of function follows complete
    failure of electrical activity.
  • At certain critical reductions in blood flow,
    loss of cell homeostasis occurs.
  • When blood flow is reduced to about 30-35 of
    normal values, responses to somatosensory
    information and cortical directives fail.

18
Reduced Blood Flow
  • Cell death becomes inevitable only at even lower
    levels of blood flow.
  • At least in the short term, ischemic
    neurological dysfunction can be reversed by
    restoring blood flow.

19
Intracranial Pressure
  • There are four intracranial constituents
    contained within the noncompliant skull.
  • These are the brain (neurons and neuroglia),
    cerebrospinal fluid (CSF), cerebral blood, and
    extracellular fluid.
  • Glial and neural tissues account for about 70 of
    intracranial contents.
  • CSF, cerebral blood, and extracellular fluid each
    account for another 10 of the total volume.
  • Increased intracranial pressure (ICP) results
    from an addition to the volume of these
    intracranial constituents in excess of
    compensatory capacity.

20
Intracranial Pressure
  • CSF may be squeezed from the cranial subarachnoid
    space and ventricles into the spinal subarachnoid
    space.
  • Cerebral venous blood may be expelled into the
    jugular veins or into the scalp via emissary
    veins.
  • However, past these compensatory mechanisms, any
    increase in blood (e.g., hematoma), extracellular
    fluid (e.g., edema), brain tissue (e.g., tumor),
    or CSF (e.g., hydrocephalus) may induce an
    increase in ICP.
  • The brain can handle some changes in ICP without
    affecting cerebral blood flow if the
    autoregulator is not impaired.

21
Intracranial Pressure
  • However, if the autoregulator is impaired because
    of some pathological condition (see slide 28),
    much smaller increases in ICP can be tolerated
    before the sufficient reduction in cerebral blood
    flow may produce neurological dysfunction.
  • In multiple trauma, hypotension from other organ
    injuries may further narrow the difference
    between mean arterial pressure and ICP.
  • In other words, since raised ICP is common in
    brain trauma and since trauma impairs the
    autoregulator, it should not be surprising that
    ischemic brain damage is also found.

22
Brain and Water Edema
  • The brain has a high water content 80 in grey
    matter and 70 in white matter, where the fat
    content is higher.
  • The majority of brain water is intracellular, but
    extracellular fluid volume makes up as much as
    10 of the intracranial space.
  • Brain water is derived from the blood and
    ultimately returns to it by reentry at the venous
    ends of the capillaries.
  • Relatively little brain water passes through the
    CSF, but this route may be more important when
    edema is present.

23
Brain and Water Edema
  • Edema refers to an increase in tissue fluid
    content that results in increased tissue volume.
  • Two different forms of cerebral edema are
    recognized vasogenic and cytotoxic edema.
  • Vasogenic edema is the most common cause of brain
    edema and results from disruption of the
    blood-brain barrier.
  • Fluid is allowed to flow out of the cerebral
    vessels into the extracellular space.
  • In other words, the origin or genesis of the
    edema is in the vessel (vaso).
  • This form of edema largely affects the white
    matter and is the most common kind of edema
    encountered after HI.

24
Brain and Water Edema
  • Cytotoxic edema, on the other hand, is
    intracellular swelling of neurons and glia in
    grey matter, with a concomitant reduction of
    brain extracellular space.
  • It occurs in hypoxia, after cardiac arrest, or
    asphyxia because the ATP dependent
    sodium-potassium pump allows sodium and water to
    accumulate within the cells.
  • In other words, the cell (cyto) becomes toxic
    from the accumulation of sodium and water within
    the cell.

25

Morphological and Neurochemical Changes
  • The most characteristic morphological change in
    the brains of AD patients is the formation of
    neurofibrillary tangles.
  • Neurofibrillary tangles are an intracellular
    abnormality, involving the cytoplasm of nerve
    cells.

26
Neurofibrillary Tangles
  • Neurofibrillary tangles consist of paired
    filaments twisted around one another in a helical
    fashion that course throughout the cytoplasm.

27
Neurofibrillary Tangles
  • In Alzheimer's disease, neurofibrillary tangles
    are generally found in the neurons of the
    cerebral cortex and are most common in the
    temporal lobe structures, such as the hippocampus
    and amygdala.
  • Spared cortical areas are seen in dark blue.

28
Neuritic Plaques
  • Neuritic or senile plaques are extracellular
    abnormalities.
  • They consist of a dense central core of amyloid,
    surrounded by a halo and a ring of abnormal
    neurites (degenerated axon terminals and
    preterminals).

29
Neuritic Plaques
  • They are found in the same brain centers as FTS,
    especially in the outer half the cortex where the
    number of neuronal connections is greatest.

30
Neuritic Plaques
  • A slide showing NFTs (in black) and senile
    plaques (in brown).
  • Neurons containing NFT eventually die.

31
Granulovacular Degeneration (GVD)
  • GVD is a descriptive term that refers to the
    presence of fluid-filled space and granular
    debris within nerve cells.
  • Like NFTs and neuritic plaques, GVD has a
    predilection for the hippocampal formation, and
    are significantly related to the presence of
    dementia

32
Lewy Bodies
  • Lewy bodies are structures located within the
    cytoplasm of neurons that characteristically have
    a circular and dense protein core surrounded by a
    peripheral halo.
  • They have often been likened to a sunflower--a
    dense central core of circular shaped structures
    with a rim of radiating filaments.

33
Lewy Bodies
  • These kind of Lewy bodies are usually found in
    brainstem locations, such as the substantia nigra
    and the locus ceruleus , and may appear singlely
    or multiply within a neuron.
  • In other locations, such as the cerebral cortex,
    they are often more elongated, and usually
    lacking the peripheral halo around the central
    core.

34
Lewy Bodies
  • They are distinctive neuronal inclusions, thought
    to be the result of altered neurofilament
    metabolism and/or transport due to neuronal
    damage and subsequent degeneration, causing an
    accumulation of altered cytoskeletal elements.
  • F. H. Lewy first described Lewy bodies in 1912.

35
Lewy Bodies
  • They were first linked to idiopathic Parkinson's
    disease, but more recently, it has been noted
    that Lewy bodies may be seen in several different
    neurodegenerative processes, including diffuse
    Lewy body disease, Alzheimer's disease, and
    idiopathic Parkinson's disease.

36
Picks Bodies
  • Ultrastructuraly, Pick bodies consist mostly of
    bundles of disorganized straight filaments, which
    may be mixed with coiled fibrils.
  • PB are homogeneous and smooth-edged, and the
    large majority are round or ovoid, although some
    are occasionally flame-shaped.

37
Picks Bodies
  • In addition to Pick bodies, the cerebral cortex
    in Pick's disease may contain neurons with
    distended cytoplasm called "ballooned cells" or
    "Pick cells.
  • In Picks disease, there is extensive neuron loss
    and gliosis concentrated in the outer third of
    the cerebral cortex.
  • Some authorities believe Pick cells represent
    deafferented neurons.

38
Picks Bodies
  • In Picks disease the frontal and temporal lobes
    are most affected with brain cells in these areas
    found to be abnormal and swollen.
  • When these typical features are not seen on post
    mortem examination but the same areas of the
    brain are affected by cell death, the case may be
    described as Picks syndrome or frontotemporal
    dementia.

39
III. Structural Neuropathology of Cerebral Injury
40
Categories of Brain Injury
  • CHI to the brain results in two categories of
    brain injury, primary and secondary.
  • Primary injury occur immediately following impact
    and is related to instantaneous events directly
    caused by the blow.
  • The resultant tissue disruption is usually
    permanent, and does not respond to pharmacologic
    or physiologic manipulations.
  • It frequently constitutes the limiting factor for
    the most idea recovery.
  • Extensive primary injury presupposes a poor
    outcome, regardless of medical and rehabilitative
    therapy.

41
Categories of Brain Injury
  • Secondary injury occurs as a result of
    epiphenomena causally related to the primary
    injury.
  • Impact disruption of large dural or cortical
    vessels often lead to epidural or subdural
    hematomas.
  • Disruption of capillaries or disturbance of
    vascular endothelial membranes during the
    original impact may lead to vasogenic cerebral
    edema.
  • As both hematoma and edema constitute mass
    effect, they raise intracranial pressure and may
    result in brain shift and cerebral hypoperfusion.
  • Brain herniations represent shift of the normal
    brain through or across regions to another site
    due to mass effect.

42
Schematic of Brain Injury
43
Herniation
  • The cranial cavity is partitioned by the
    tentorium cerebelli and falx cerebri.
  • When a part of the brain is compressed by an
    extrinsic lesion, such as a subdural hematoma, or
    is expanded because of a contusion or other
    intrinsic pathology, it is displaced (herniates)
    from one cranial compartment to another.

44
Herniation
  • Three major herniations can occur, either alone
    or in combination.
  • Subfalcial herniation is displacement of the
    cingulate gyrus from one hemisphere to the other,
    under the falx cerebri.

The left cingulate gyrus has herniated under the
falx.
45
Herniation

shift of the uncus into the suprasellar cistern
as well as a subfalcine shift to the right.
46
Herniation
  • Acute foramen magnum herniation clinically can be
    catastrophic as the brains extrudes through the
    foramen magnum.
  • Increased pressure within the posterior fossa
    will result in herniation of the cerebellar
    tonsils into the foramen magnum and compression
    of the medulla.

47
Secondary Injury
  • Hypoperfusion and herniation lead to further
    brain damage in the form of pressure necrosis and
    infarction, often remote from the site of the
    primary injury.
  • Secondary lesions, unlike primary ones, are
    potentially avoidable if they are caught quickly
    and amenable to treatment, such as surgical
    evacuation of hematoma and edema therapy.

48
Skull-Brain Interface
  • The frontal lobes sit in the anterior fossa of
    the cranial cavity region of the skull.
  • The anterior lateral aspects of the frontal bone
    swing around each of the frontal lobes,
    encapsulating them.

49
Skull-Brain Interface
  • Arising medially in the anterior cranial fossa is
    the crista galli, a bony protuberance originating
    from the ethmoid bone.
  • It partially separates the anterior ventral
    aspect of both frontal lobes and provides an
    anchor for the falx cerebri.

50
Skull-Brain Interface
  • The middle cranial fossa that bounds the temporal
    lobes is formed by the temporal bone, laterally,
    and the greater wing of the sphenoid bone,
    anteriorly and medially.
  • The sphenoid wing and ethmoid bone are quite
    irregular, jagged, and rough in some locations.

51
Skull-Brain Interface
  • With cerebral trauma, it is quite common for
    contusions (bruising) to occur in cerebral
    regions adjacent to these skull regions where
    there is the greatest brain-bone interface.
  • The most common neuropathological consequence is
    damage to the hippocampus and other medial
    temporal lobe limbic structures, resulting in
    post-traumatic memory disorder and emotional
    behavior changes.

52
Skull-Brain Interface
  • Superficial bruising of dural crests are
    frequently found in frontal and temporal regions
    regardless of the site or direction of initial
    impact.

53
Primary Impact Damage
  • CHI typically gives rise to contusions and
    lacerations on or within the surface of the
    brain.
  • Strictly speaking, lacerations are lesions that
    break the pia mater, while contusions leave the
    pia mater intact.
  • Lacerations are usually found on the superficial
    crests of the gyri of the cerebral hemispheres,
    but they may penetrate the whole thickness of the
    cortex and extend into the subcortical white
    matter.

54
Primary Impact Damage
  • Lacerations are hemorrhagic lesions which may
    lead to edema and necrosis within the brain.
  • They usually heal and leave yellow-brown atrophic
    scars that are easily recognized on autopsy.

55
Primary Impact Damage
  • The lesions seen here are the result of extensive
    blunt force trauma to the head in a vehicular
    accident.
  • Mainly the gyri are affected with hemorrhage from
    contusions and lacerations.

56
Primary Impact Damage
  • Potential sites for cerebral contusion following
    CHI include
  • Site of impact
  • Sites diametrically opposite site of impact
  • Frontal and temporal lobe crests and
  • Surface lesions of the upper borders of the
    hemispheres.
  • Primary brain injuries can be caused by both
    acceleration dependent and non-acceleration
    dependent factors.
  • The majority of CHIs involve acceleration
    dependent mechanisms.

57
Acceleration Dependent Factors
  • There are two common types of acceleration
    translational acceleration and angular
    acceleration.
  • Translational acceleration results when the
    resulting pathway of force applied to a ridge
    body passes through the bodys center of gravity,
    the body will assume linear acceleration along
    the direction of the force.
  • If the resulting force pathway does not pass
    through the bodys center of gravity, the body
    rotates around its own center of gravity.
  • This is called angular acceleration.

58
Acceleration Dependent Factors
  • Pure angular acceleration only exists if the body
    is simultaneously acted upon by two opposing
    forces of equal magnitude directed at opposite
    sides of the center of gravity.
  • If a single linear force does not pass through
    the center of gravity, two pathways will result.
  • The one passing through the center of gravity
    will produce translational acceleration.
  • The one passing perpendicular to the center of
    gravity will cause angular acceleration.
  • In other words, the body spins around its own
    center of gravity while at the same time
    traveling linearly.

59
Acceleration Dependent Forces
60
Acceleration Dependent Forces
  • Most impact forces are unpaired and produce
    combined rotational and linear motions.
  • The observed cranial movement is always a
    combination of both translation and rotation.
  • Some degree of rotation always occurs around the
    foramen magnum, because of the how the head is
    attached to the cervical spine.
  • The traumatized brain always includes inseparable
    markings of both translational and rotational
    trauma.

61
Translational Trauma
  • Pure translational trauma is exemplified by a
    sharply dealt blow to the occiput of a stationary
    but movable head.
  • The head will rapidly accelerate forward.
  • Because of inertia, the brain will lag behind
    until it is pushed forward by the advancing
    skull.
  • This lagging results in differential movements of
    the brain and a skull.
  • The delicate cortex is rubbed against rough
    surfaces of the dura-lined skull base.

62
Translational Trauma
  • A not so pure example of translational trauma
    occurs when the accelerating head hits some
    unyielding surface, like a windshield.
  • The skull decelerates to a sudden halt, but the
    brain continues to plunge forward at its
    accustomed velocity until it too is stopped by
    the frontal skull.
  • This site of initial brain impact with the skull,
    termed the impact pole, causes the coup lesion.
  • The exact sequence of events reverses direction,
    and the brain lags behind the skull moving in the
    opposite direction.

63
Translational Trauma
  • The resulting injury at the antipole, at the site
    directly opposite the impact pole, is called the
    contrecoup lesion.
  • The deceleration process, in both directions,
    often takes several oscillations before the brain
    achieves zero velocity.
  • The repeated slamming of the brain at the impact
    pole and antipole results in contusive coup and
    contrecoup lesions.
  • The brain also pulls away from the skull at the
    antipole, causing greater tissue displacement and
    greater contrecoup injury.
  • Moreover, the brain-skull interface will undergo
    several pendular swings, as the head rotates
    around its vertical axis.

64
Translational Trauma
  • The cortex rubs repeatedly against the sharp
    dural edges of the falx, the sphenoid ridge, and
    the jagged floor of the anterior cranial fossa.
  • As a result, severe lacerations are often seen on
    the orbital frontal cortices and the tips of the
    frontal and temporal lobes (see slide 18).
  • With translational trauma the force applied to
    the skull is distributed over an appreciable area
    of the brain.

65
Rotational Trauma
  • Rotational trauma depends on shearing strainthe
    displacement of one point relative to another as
    a consequence of the stress per unit area.

66
Rotational Trauma
  • During angular acceleration of the head, the
    brain will initially remain stationary while the
    skull rotates.
  • Eventually, the brain is dragged along by
    friction forces over the bony prominences of the
    anterior and middle fossa floors.
  • The brain matter dragged over their prominences
    is subjected to parallel shearing, causing
    cortical contusions.
  • The location of these surface shearing sites
    corresponds to the basal frontal and temporal
    lobes, the cingulate gyrus, the temporal poles,
    and the frontal poles.
  • The inferior surface of the occipital lobes
    usually escapes injury.

67
Rotational Trauma
  • The neurons and glia suffer damage with even
    slight distortion of shape.
  • Cell to cell and cell to axon shearing leads to
    multiple tearing of neural elements throughout
    the deep portions of the brain.

68
Rotational Trauma
  • Instead of cortical lesions, intracranial
    hemorrhages, or raised intracranial pressure,
    there is diffuse white matter lesions in the form
    of axon retraction balls from widespread axonal
    transection.

69
Rotational Trauma
  • Shearing lesions have a predilection for the
    grey-white matter junctions around the basal
    ganglia, the ventricles, the superior cerebellar
    peduncles, the corpus callosum, and the fiber
    tracts of the brainstem.

70
Non-Acceleration Dependent Factors
  • Clinical head injuries not involving acceleration
    of the skull are rare.
  • A typical example is the car mechanic lying in
    the grease pit when the car falls on his
    supported head.
  • A less pure example is the individual whose
    head is hit directly on the vertex by a falling
    object.
  • In both cases, there is no head movement, and the
    energy is usually diffuse causing extensive
    fractures but little brain injury.

71
Impression Trauma
  • If an object falls on the vertex of the head, the
    initial loading of forces results in inward
    bending of the skull at a relatively small impact
    point.
  • When the loading is exhausted, the elasticity of
    the skull forces it to recover its initial
    configuration.

72
Impression Trauma
  • The inertia of the skull causes it to overshoot
    its initial contour, like a spring suddenly
    released from a compressed state.
  • When the overshoot occurs, the brain is pulled
    away from the skull, and the tissue is displaced
    creating a coup lesion at the point of impact.

73
Ellipsoidal Deformation
  • In the case of a fronto-occipital impact of the
    supported head, the impact will momentarily
    convert the ellipsoidal skull into a sphere, by
    lengthening the bitemporal axis and shortening
    the fronto-occipital axis.
  • Portions of the brain located along the collision
    axis will move to the center because of the
    shortening of the axis.

74
Ellipsoidal Deformation
  • Those portions parallel to the vertical axis will
    move away from the center.
  • Thus, destructive shearing strains will occur in
    and around the center of the brain.
  • The ventricular walls and part of the corpus
    callosum abutting against the lateral ventricles
    may be particularly vulnerable to this type of
    central shearing.

75
Concussion
  • On of the continuing puzzles in head injury is
    the pathological basis for the phenomenon of
    concussion.
  • The person becomes briefly unconscious after a
    blow to the head, recovers consciousness, and
    goes on to make an apparently perfect recovery.
  • The pathogenesis is unknown (probably chemical
    and physiological abnormality).
  • There is no gross or microscopic abnormality.
  • Loss of consciousness implies interference with
    the function of the reticular system in the
    brainstem.

76
Concussion
  • Features of concussion that also suggest
    brainstem dysfunction are changes in blood
    pressure, pulse rate, and respiration.
  • Concussion is thought to result from minor
    structural and biochemical changes of brainstem
    nuclei.

77
Post-Traumatic Complications
  • Residual disability or new developing
    complications (e.g., seizure disorder
    hydrocephalus) may be related to impact damage,
    to various early secondary pathological
    processes, or to later events, such as scarring
    or adhesions of brain tissue or blockage of CSF
    pathways.
  • Some of the post-traumatic complications are
    caused by diffuse (widespread) injury other by
    focal (limited) injury.
  • The most severe form of diffuse damage is the
    chronic or persistive vegetative state, affecting
    about 5 of head injury survivors.

78
Post-Traumatic Complications
  • In cases where there is extensive neocortical
    necrosis, the cause is not so much the severity
    of the injury, but a consequence of resuscitation
    following cardio-respiratory arrest.
  • In cases where there is extensive subcortical
    white matter shearing, the cause is the severity
    of the initial impact damage.
  • In either case, the cortex has been rendered
    functionally inactive by widespread severe
    destruction of brain tissue.

79
Post-Traumatic Complications
  • Focal injuries, such as contusions or hematomas
    will often leave residual focal neurological
    deficits such as hemiplegia (paralysis of one
    half side of the body), hemiparesis (weakness of
    one half side of the body) hemianopsia (loss of
    one half of the visual field), aphasia (disorders
    of language, both receptive and expressive).
  • Cranial nerve abnormalities often arise when
    cranial nerves are damaged when the skull is
    fractured or when the brain is thrown about
    during acceleration/deceleration injury.

80
Post-Traumatic Complications
  • Some common occurrences are damage to the
    olfactory (CN I) nerve after basilar skull
    fracture, resulting is anosmia, a partial or
    total loss of the sense of smell.
  • Damage to the optic nerve (CN II) may lead to
    transient loss of vision.
  • Damage to the facial (CN VII) nerve after
    temporal bone fracture may produce facial
    paralysis and
  • Damage to the vestibulocochlear nerve (CN VIII)
    after basilar fracture in which otorrhea or
    hematotympanum is present, may affect hearing as
    well as vestibular function.

81
Post-Traumatic Complications
  • There is a definite risk of developing a chronic,
    recurring seizure disorder after significant head
    trauma.
  • The following factors significantly raise the
    probability of developing post-traumatic
    epilepsy
  • 1. depressed skull fracture with dural tear
    (gt50)
  • 2. penetrating wounds (gt50)
  • 3. Amnesia of gt than 24 hours
  • 4. Time after injury that first seizure occurs
    a. Immediate (little chance of becoming chronic)
    b. 1st week (33) and c. 1st 8th week (70).

82
Post-Traumatic Complications
  • Seizures can first appear many years after an
    accident.
  • They are usually focal and more difficult to
    treat than idiopathic epilepsy.
  • Post-traumatic epilepsy is a chronic disorder,
    with only a 40 cure rate after 5 years.
  • Post-traumatic syndrome (PTS) is the most common
    and probably most complex sequelae of HI.
  • The basic elements of the syndromes are headache,
    dizziness, difficulty concentrating, and a host
    of vague behavioral symptoms such as anxiety,
    depression, and nervous instability.

83
Post-Traumatic Complications
  • This syndrome is more common with slight trauma
    than serious.
  • The syndrome usually lasts a few weeks to a few
    months, with symptoms gradually disappearing only
    to be exacerbated by strenuous physical activity,
    emotional stress, or the use of alcohol.
  • Patients in highly physical or stressful jobs
    should be warned that symptoms might recur when
    they return to work.
  • Rest and symptomatic treatment are usually
    required.
Write a Comment
User Comments (0)
About PowerShow.com
