Title: Advanced Java Applications


1
Advanced JavaApplications
  • Shon Vick
  • CMSC 331

2
Networking
  • Using the networking capabilities provided in the
    Java environment is quite easy
  • We will see how to use Sockets

3
Sockets
  • Lower-level network communication
  • Client uses some service
  • Server - provides some service
  • TCP provides a reliable, point-to-point
    communication channel for client-server apps

4
What Is a Socket?
  • A socket is one endpoint of a two-way
    communication link between two programs
    running on the network.
  • A socket is bound to a port number so that the
    TCP layer can identify the application that data
    is destined to be sent.

5
How do Sockets work?
  • A server runs on a specific computer and has a
    socket that is bound to a specific port number.
  • Client knows the hostname and port of server and
    tries to make a connection request

6
Connection established
  • If the server accepts the connection it gets a
    new socket bound to a different port.
  • It needs a new socket (and consequently a
    different port number) so that it can continue to
    listen to the original socket

7
How does Java support Sockets
  • The java.net package provides a class, Socket,
    that implements one side of a two-way connection
    between your Java program and another program on
    the network
  • It also includes the ServerSocket class, which
    implements a socket that servers can use to
    listen for and accept connections to client

8
Echo Echo Echo
import java.io. import java.net.
public class EchoClient public
static void main(String args)
throws IOException
Socket echoSocket null
PrintWriter out null
BufferedReader in null //
9
Establish the Socket connection

Output
Port
Host
try echoSocket new Socket(avatar ",
7777) out new PrintWriter(echoSocket.getOutp
utStream(), true) in new
BufferedReader(new
InputStreamReader(echoSocket.getInputStream()))
catch
Input
10
Need to Catch Exceptions
catch (UnknownHostException e)
System.err.println("Don't know about host
avatar.") System.exit(1) catch
(IOException e) System.err.println("Couldn
't get I/O for "
"the connection to avatar.")
System.exit(1)
11
Simple Socket Example
Set up a mechanism to read from standard input
BufferedReader stdIn new
BufferedReader(
new InputStreamReader(System.in))
String userInput
while ((userInput stdIn.readLine()) ! null)
out.println(userInput)
System.out.println("echo "
in.readLine())
Read from standard input
Write to Server
Output whats read back from Server
12
Close up Shop on Client side
out.close( ) in.close( ) stdIn.close(
) echoSocket.close( )
13
Basic Steps
  • Open a socket.
  • Open an input stream and output stream to the
    socket.
  • Read from and write to the stream according to
    the server's protocol.
  • Close the streams.
  • Close the socket.

14
Same Basic Steps
  • This client program is straightforward and simple
    because the Echo server implements a simple
    protocol
  • Even with more complicated protocols such as HTTP
    server, your client program while more
    complicated will follow the same basics as this
    simple example

15
Server
  • A server must open a SeverSocket
  • ServerSocket server new ServerSocket( 7777 )
  • Call accept on that socket creating a new socket
  • Socket socket server.accept()
  • Socket acts as socket from client

16
If a socket is a pipe
  • We could conceptualize this like so

Ports
Client
Server
The things flowing through the Plumbing
The Socket Plumbing
17
The Answer Is ..
  • A Number of things can conceptually flow through
    the pipe
  • We will focus on two
  • Objects
  • Characters from a String
  • We looked at several examples last time
  • The first was a simple echo program a very
    simple protocol give me back what I gave you
    (Strings)
  • We also looked at simpleprotocol example
    (Protocol Objects)

18
Objects flow through the Pipe
  • Let first address the case where we want to have
    objects flowing over the pipe
  • Must have at least the following mechanisms for
  • Objects to be written by the server
  • Objects to be read by the client

19
The newprotocol Client
public class Client Socket socket new
Socket( "127.0.0.1", 9999 ) //
ObjectInputStream input new
ObjectInputStream(socket.getInputStream() )
// read using serialization NewProtocol
protocol (NewProtocol)(input.readObject() )
System.out.println(Protocol protocol)
socket.close()
20
The newprotocol Server
class ThreadedSocket extends Thread // here is
where all the real work is done. private Socket
socket ThreadedSocket( Socket socket )
this.socket socket //
ObjectOutputStream output new
ObjectOutputStream(socket.getOutputStream() )
output.writeObject( protocol )
21
Reading and Writing Objects
  • An ObjectOutputStream writes primitive data types
    and graphs of Java objects to an OutputStream.
  • The objects can be read (reconstituted) using an
    ObjectInputStream.
  • General Mechanism
  • This works for the sockets as was just shown but
    is actually more general
  • Persistent storage of objects can be accomplished
    by using a file for the stream.

22
File example
  • For example to write an object that can be read
    by the example in ObjectInputStream

FileOutputStream ostream new FileOutputStream(f
oo.bar") ObjectOutputStream p new
ObjectOutputStream(ostream) p.writeInt(12345) p.
writeObject("Today") p.writeObject(new
Date()) p.flush() ostream.close()
23
The read counterpart
FileInputStream istream new
FileInputStream(" foo.bar ")
ObjectInputStream p new ObjectInputStream(istrea
m) int i p.readInt() String
today (String)p.readObject() Date date
(Date)p.readObject() istream.close()
24
The Needed Java Framework
  • Only objects that support the java.io.Serializable
    interface can be written to streams.
  • The class of each serializable object is encoded
    including the class name and signature of the
    class, the values of the object's fields and
    arrays, and the closure of any other objects
    referenced from the initial objects
  • This relates to introspection/reflection which we
    will discuss shortly

25
More about the Framework
  • The default deserialization mechanism for objects
    restores the contents of each field to the value
    and type it had when it was written.
  • Marshalling of Objects (Serialize)
  • Un marshaling of Object (Serialize)

26
Deserialization Object Reflection
  • Fields declared as transient or static are
    ignored by the deserialization process.
  • References to other objects cause those objects
    to be read from the stream as necessary.
  • Graphs of objects are restored correctly using a
    reference sharing mechanism.
  • New objects are always allocated when
    deserializing, which prevents existing objects
    from being overwritten

Reflection
27
Reflection Allows
  • Determination of the class of an object.
  • Creation of an instance of a class whose name is
    not known until runtime.
  • Obtaining information about a class's modifiers,
    fields, methods, constructors, and superclasses.
  • Determination of constants and method
    declarations that belong to an interface

28
Reflection Also Allows
  • Allows one to get and set the value of an
    object's field, even if the field name is unknown
    to your program until runtime.
  • Allows one to invoke a method on an object, even
    if the method is not known until runtime.
  • Create a new array, whose size and component type
    are not known until runtime, and then modify the
    array's components.

29
Examining Classes
  • A way to get information about classes at runtime
  • For each class, the Java Runtime Environment
    (JRE) maintains an immutable Class object that
    contains information about the class. A Class
    object represents, or reflects, the class
  • To get this information you need to get the Class
    object that reflects the class

30
Retrieving Class Objects
  • You can retrieve a Class object in several ways
  • Class c foo.getClass() // for some object
    named foo
  • Bar b new Bar()
  • Class c b.getClass()
  • Class s c.getSuperclass()

31
Other Ways of Retrieving Class Objects
  • If you know the name of the class at compile
    time, you can retrieve its Class object by
    appending .class to its name

Class c java.awt.Button.class
  • You can also use the Class.forName static method

Class c Class.forName(commandNameToken)
32
Getting the Class Name
  • Every class in the Java programming language has
    a name. When you declare a class, the name
    immediately follows the class keyword
  • At runtime, you can determine the name of a Class
    object by invoking the getName method. The String
    returned by getName is the fully-qualified name
    of the class.
  • A good home study question Given an instance
    prints the names of the classes its inheritance
    hierarchy from least specific to most specific
    excluding Object

33
An Example
import java.lang.reflect. import java.awt.
class SampleName public static
void main(String args) Button
b new Button() printName(b)
static void
printName(Object o) Class c
o.getClass() String s
c.getName() System.out.println(s
)
Need Reflection Package To Do this
34
Selected References
  • Advanced Techniques for Java Developers,Berg
    Fritzinger, Wiley, 1999 Chapter 4
  • http//java.sun.com/docs/books/tutorial/networking
    /index.html
  • The Java Programming Language , K.Arnold and J.
    Gosling , Addison-Wesley , 1996
  • Java in a Nutshell , D. Flanagan, O'Reilly and
    Associates
  • http//java.sun.com/products/jdk/1.2/docs/

35
More References
  • The Java Programming Language , K.Arnold and J.
    Gosling , Addison-Wesley , 1996
  • Java in a Nutshell , D. Flanagan, O'Reilly and
    Associates
  • http//java.sun.com/products/jdk/1.2/docs/
