Title: Implementing FormBased Codes Arizona Legal Considerations


1
Implementing Form-Based CodesArizona Legal
Considerations
Dustin C. Jones, Esq.Tiffany Bosco, PA
2
Conventional Zoning vs. Form-Based Codes
Form-Based Codes
Conventional Zoning (Euclidean)
Management
Use/Density
Form
Conventional zoning regulates primarily by LAND
USE, DENSITY FAR, SETBACKS, and PARKING. It
assumes that there should be an appropriate
distance between almost all different use types.
Form (the little box) is minimally addressed.
FORM-BASED CODES focus on the design details that
will FORM the type of community that is
envisioned. Therefore the land uses and densities
become subject to the FORM of the desired outcome.
3
Zoning Codes a Brief History
Conventional Zoning Regulations
  • Initial Effort to Protect Health and Safety
  • NYC Comprehensive Zoning Code (1916)
  • Village of Euclid, Ohio et al. v. Ambler Realty
    Company, 272 U.S. 365 (1926),
  • Supreme Court upheld the right of a locality to
    enforce a system of zoning whereby a town or
    community is divided into areas in which specific
    uses of land are permitted
  • Post War Housing Boom
  • Retail Follows Housing
  • Central City Death Rebirth

4
Smart Growth/New Urbanism/TNDs/FBCs
  • Click to edit Master text styles
  • Second level
  • Third level
  • Fourth level
  • Fifth level

As promoted by
F B C I Form- Based Codes Institute
formbasedcodes.org
5
California Addresses FBCs
  • A form-based code is a useful implementation
    measure for achieving certain general plan goals,
    such as walkable neighborhoods and mixed-use and
    transit-oriented development.

6
AB 1268 - July 2004
  • 65302.4. The text and diagrams in the land use
    element that address the location and extent of
    land uses, and the zoning ordinances that
    implement these provisions, may also express
    community intentions regarding urban form and
    design. These expressions may differentiate
    neighborhoods, districts, and corridors, provide
    for a mixture of land uses and housing types
    within each, and provide specific measures for
    regulating relationships between buildings and
    outdoor public areas, including streets.

7
Arizona Regulatory Tools
  • General Plan Goals, Objectives and Policies
  • Design Guidelines
  • Planned Area Development (PAD) Zoning
  • Overlay Zoning
  • Specific Plans

8
City of Goodyear Design Guidelines
Disconnect between Vision and Outcome
9
City of Goodyear Design Guidelines
City of Goodyear Design Guidelines
City of Goodyear Engineering Design Standards
(Transportation Section)
Disconnect between Vision and Outcome
10
  • Arizona Revised Statutes 9-462.01
  • (General Plans Zoning Regulations)
  • All zoning and rezoning ordinances or
    regulations adopted under this article shall be
    consistent with and conform to the adopted
    general plan of the municipality, if any, as
    adopted under article 6 of this chapter. In the
    case of uncertainty in construing or applying the
    conformity of any part of a proposed rezoning
    ordinance to the adopted general plan of the
    municipality, the ordinance shall be construed in
    a manner that will further the implementation of,
    and not be contrary to, the goals, policies and
    applicable elements of the general plan. A
    rezoning ordinance conforms with the land use
    element of the general plan if it proposes land
    uses, densities or intensities within the range
    of identified uses, densities and intensities of
    the land use element of the general plan.

Disconnect between Vision and Outcome
11
How Zoning Defines a One-Block Parcel
Lets Visualize.
Density, Use
FAR (floor area ratio)
Setbacks
12
How Zoning Defines a One-Block Parcel
Density, Use
FAR (floor area ratio)
Setbacks
Parking Requirements
13
How Zoning Defines a One-Block Parcel
Density, Use
FAR (floor area ratio)
Setbacks
Parking Requirements
Max. Building Height
14
How Design Guidelines Define a One-Block Parcel
Design Guidelines generally are NOT regulatory
and encourage focus on form
Density, use
FAR (floor area ratio)
Setbacks
Parking Requirements
Max. Building Height
Frequency of Openings and Surface Articulation
Specified
15
How Form-Based Codes Define a One-Block Parcel
Street types
16
How Form-Based Codes Define a One-Block Parcel
Street types
Build to lines
17
How Form-Based Codes Define a One-Block Parcel
Street types
Build to lines
Number of Floors
18
How Form-Based Codes Define a One-Block Parcel
Street types
Build to lines
Number of Floors
Building types
19
How Form-Based Codes Define a One-Block Parcel
Street types
Build to lines
Number of Floors
Building types
20
Prop 207Private Property
  • A. If the existing rights to use, divide, sell or
    possess private real property are reduced by the
    enactment or applicability of any land use law
    enacted after the date the property is
    transferred to the owner and such action reduces
    the fair market value of the property the owner
    is entitled to just compensation from this state
    or the political subdivision of this state that
    enacted the land use law.

21
Regulatory Tools
  • General Plan Goals, Objectives and Policies
  • Design Guidelines
  • Planned Area Development (PAD) Zoning
  • Overlay Zoning
  • Specific Plans

22
Zoning Entitlement in Arizona
Current Conventional Development
  • General Specific Plan Amendment

Rezoning Development Master Plan
Development Agreements
Design Guidelines
General to Specific
Site Plan Reviews
C.C. R.s
23
Regulatory Tools
  • General Plan Goals, Objectives and Policies
  • Design Guidelines
  • Planned Area Development (PAD) Zoning
  • Overlay Zoning
  • Specific Plans

24
Types of Form-Based Codes?
  • Spatial Classification FBCs are defined around
    (i) districts, neighborhoods and corridors (ii)
    the Transect model (iii) a street-based
    regulatory plan, or (iv) special purpose zones.
  • Regulatory Focus - Regulatory focus de-emphasizes
    land use regulation in favor of rules for
    building form.
  • Use - Emphasis on mixed-use and a mixture of
    housing types.
  • Design - Greater attention to streetscape and the
    design of the public realm and the role of
    individual building in shaping the public realm.
  • Public Participation - Design-focused public
    participation process.
  • Modified from definition by Paul Crawford, AICP

25
Classifying Form-Based Codes
  • Spatial Classifications
  • Based on Transect Zones
  • Based on Building Type or Lot
  • Based on Street type
  • Legal/Regulatory Classifications
  • Mandatory Freestanding FBCs
  • Mandatory Integrated FBCs
  • Voluntary Floating TND Districts
  • Voluntary Planned Area District (PAD)

26
Classifying Form-Based Codes
  • Spatial Classifications
  • Based on Transect Zones
  • Based on Building Type or Lot
  • Based on Street type
  • Legal/Regulatory Classifications
  • Mandatory Freestanding FBCs

27
Mandatory Freestanding Codes
  • Essential Characteristics
  • 1. Mandatory freestanding FBC are distinct in
    format from standard regulatory system, but are
    just as mandatory as all other regulations.
  • 2. They can be distinct in format simply by
    choice, but usually are distinct due to legal
    requirement.
  • 3. Freestanding codes require links to standard
    regulatory document.

28
Mandatory Freestanding Codes
  • Examples
  • California Specific Plans
  • Central Petaluma
  • Isla Vista (Santa Barbara)
  • Cotati Downtown
  • Ventura Downtown
  • Arizona Variety
  • Goodyear City Center Specific Plan
  • Phoenix Downtown Urban Form (????)
  • Avondale City Center Specific Plan (???)
  • Flagstaff Code (?)

29
Mandatory Freestanding Codes
  • Advantages
  • Uniform applicability
  • Greater likelihood that each individual building
    on a block will improve character of that block
  • Provide greatest control over content, format and
    outcome
  • Use of diagrams, graphics, matrices, and photos
  • Customs calibration to unique circumstances
  • Disadvantages
  • Potential conflict with other regulatory codes
    (i.e. building)
  • Political vulnerability (adoption and revocation)

30
Mandatory Freestanding FBC
31
ARS 9-461.08. Authority, scope of specific plans
  • The planning agency may, or if so directed by the
    legislative body shall, prepare specific plans
    based on the general plan and drafts of such
    regulations, programs and legislation as may in
    the judgment of the agency be required for the
    systematic execution of the general plan. The
    planning agency may recommend such plans and
    measures to the legislative body for adoption.
  • B. Specific plans may, in addition to recommended
    zoning ordinances and subdivision regulations,
    include
  • Regulations determining the location of buildings
    and other improvements with respect to existing
    rights-of-way, floodplains and public facilities.
  • 2. Regulations of the use of land, buildings and
    structures, the height and bulk of buildings and
    structures and the open spaces around buildings
    and structures.
  • 3. .

32
Avondale Specific Plan
33
Classifying Form-Based Codes
  • Spatial Classifications
  • Based on Transect Zones
  • Based on Building Type or Lot
  • Based on Street type
  • Legal/Regulatory Classifications
  • Mandatory Freestanding FBCs
  • Mandatory Integrated FBCs

34
Mandatory Integrated Codes
  • Essential Characteristics
  • Integral to existing development codes
  • Do not require rezoning of property
  • Typically establish overlay zoning which
    supersedes underlying zones
  • Replaces or supplements underlying zoning
    district with form-based standards
  • Similar to freestanding FBC, but embedded rather
    than separate document

35
Mandatory Integrated Codes
  • Examples
  • Overlay Zones
  • South Miami Hometown Overlay (downtown)
  • Naples Fifth Avenue South Overlay (downtown)
  • Goodyear Gateway Overlay
  • Zoning Districts
  • West Palm Beach (downtown)
  • Fort Myers Beach (redevelopment zoning district)
  • Downtown Kendall (greyfield conversion)
  • Miami 21 (citywide code)
  • Downtown San Diego Community Plan (ordinance)

36
Mandatory Integrated Codes
  • Advantages
  • Uniform applicability
  • Less political vulnerability
  • Establish concepts that can expanded upon
  • Disadvantages
  • Existing code may not be conducive to FBC
  • Challenging to integrate to every section of code
  • Ongoing integration even after adoption

37
ARS 9-461.08. Authority, scope of specific plans
  • The planning agency may, or if so directed by the
    legislative body shall, prepare specific plans
    based on the general plan and drafts of such
    regulations, programs and legislation as may in
    the judgment of the agency be required for the
    systematic execution of the general plan. The
    planning agency may recommend such plans and
    measures to the legislative body for adoption.
  • B. Specific plans may, in addition to recommended
    zoning ordinances and subdivision regulations,
    include
  • Regulations determining the location of buildings
    and other improvements with respect to existing
    rights-of-way, floodplains and public facilities.
  • 2. Regulations of the use of land, buildings and
    structures, the height and bulk of buildings and
    structures and the open spaces around buildings
    and structures.
  • 3. .

38
Classifying Form-Based Codes
  • Spatial Classifications
  • Based on Transect Zones
  • Based on Building Type or Lot
  • Based on Street type
  • Legal/Regulatory Classifications
  • Mandatory Freestanding FBCs
  • Mandatory Integrated FBCs
  • Voluntary Floating TND Districts

39
Voluntary Floating District Codes
  • Essential Characteristics
  • Voluntary
  • Authorized but not imposed on specific properties
  • Use is triggered by developer application
  • Site-level details are negotiated during rezoning
    process
  • Approval is site specific and no bearing on other
    properties

40
Floating Zone Codes
  • Examples
  • TND Zoning Codes
  • Towns, Villages, Countryside Plan St. Lucie,
    FL
  • Model TND Code, Wisconsin
  • TND Codes, Dade Jackson, FL
  • TND Code, Columbus, OH
  • Chico, CA
  • Goodyear, AZ (drafting)

41
Voluntary Floating TND District
  • Advantages
  • Politically easier to adopt
  • Simply offering another choice to developers
  • Dont cause existing buildings, lots or uses to
    become nonconfomring
  • Approval process may differ and expedite reviews
  • Disadvantages
  • Can be entirely ignored by development community
  • Allow great projects unlikely to change current
    character
  • Site specific
  • Ignore regional issues, street networks, character

42
Classifying Form-Based Codes
  • Spatial Classifications
  • Based on Transect Zones
  • Based on Building Type or Lot
  • Based on Street type
  • Legal/Regulatory Classifications
  • Mandatory Freestanding FBCs
  • Mandatory Integrated FBCs
  • Voluntary Floating TND Districts
  • Voluntary Planned Area District (PAD)

43
Menlo Park Mercado District Tucson, AZ
REGULATING PLAN
  • Two Regulating Areas
  • Town Center
  • Neighborhood General

44
(No Transcript)
45
(No Transcript)
46
Menlo Park Mercado District Tucson, AZ
BUILDING (URBAN) FORM STANDARDS (Town Center
Area)
47
Menlo Park Mercado District Tucson, AZ
BUILDING (URBAN) FORM STANDARDS (Neigh. General)
48
Menlo Park Mercado District Tucson, AZ
FRONTAGE TYPES
49
Menlo Park Mercado District Tucson, AZ
ARCHITECTURAL STANDARDS
50
Menlo Park Mercado District Tucson, AZ
PERMITTED LAND USES - Last Page of the Code
(Last, and yes, one of the least)
51
(No Transcript)
52
City Pointe Avondale, AZ
53
City Pointe Avondale, AZ
CONCEPTUAL DEVELOPMENT PLAN
  • Two Regulating Areas
  • Town Center
  • Neighborhood General

54
City Pointe Avondale, AZ
CONCEPT BUIDLING FORM PLAN
55
City Pointe Avondale, AZ
MIXED USE AREA DEVELOPMENT STANDARDS
56
City Pointe Avondale, AZ
MIXED USE AREA DEVELOPMENT STANDARDS
57
City Pointe Avondale, AZ
PRELIMINARY STUDIES MAIN STREET
PARKWAY
58
Regulatory Tools
  • General Plan Goals, Objectives and Policies
  • Design Guidelines
  • Planned Area Development (PAD) Zoning
  • Overlay Zoning
  • Specific Plans

59
Implementing Form-Based Codes
Dustin C. Jones, Esq.Tiffany Bosco, PA
Write a Comment
User Comments (0)
About PowerShow.com
