MonALISA

1
An Agent Based, Dynamic Service System to
Monitor, Control and Optimize Distributed
Systems
March 2006
Iosif Legrand California Institute of
Technology
2
The MonALISA Framework

• MonALISA is a Dynamic, Distributed Service System
  capable to collect any type of information from
  different systems, to analyze it in near real
  time and to provide support for automated control
  decisions and global optimization of workflows in
  complex grid systems.
• The MonALISA system is designed as an ensemble
  of autonomous multi-threaded, self-describing
  agent-based subsystems which are registered as
  dynamic services, and are able to collaborate and
  cooperate in performing a wide range of
  monitoring tasks. These agents can analyze and
  process the information, in a distributed way,
  and to provide optimization decisions in large
  scale distributed applications.

3
MonALISA is A Dynamic, Distributed Service
Architecture

• The framework is based on a hierarchical
  structure of loosely coupled agents acting as
  distributed services which are independent
  autonomous entities able to discover themselves
  and to cooperate using a dynamic set of proxies
  or self describing protocols.
• An agent-based architecture provides the ability
  to invest the system with increasing degrees of
  intelligence to reduce complexity and make
  global systems manageable in real time. For an
  effective use of distributed resources, these
  services provide adaptability and
  self-organization.

4
The MonALISA Discovery System Services
Fully Distributed System with no Single Point of
Failure
Global Services or Clients
Clients , HL services repositories
Dynamic load balancing Scalability
Replication Security AAA for Clients
Proxies
AGENTS
Distributed System for gathering and Analyzing
Information.
MonALISA services
Distributed Dynamic Discovery- based on a lease
Mechanism and REN
Network of JINI-LUSs Secure Public
5
Monitoring Grid sites, Running Jobs, Network
Traffic and Topology
JOBS
TOPOLOGY
ACCOUNTING
6
Monitoring OSG Resources, Jobs Accounting
Running Jobs
Accounting
42 SITES 4 000 Nodes ( 10 000 CPUs)
Thousands of Jobs 60 000 parameters
7
Monitoring CMS Jobs
Running Jobs per Site
Type of Jobs
Rate for Processing Events per Site
Integrated No. of Events
8
FTP Data Transfer between GRID sites
Total FTP Traffic per VO
9
Monitoring Internet2 backbone Network

• Test for a Land Speed Record
• 7 Gb/s in a single TCP stream from Geneva to
  Caltech

10
The UltraLight Network
BNL ESnet IN /OUT
11
Monitoring The GLORIAD Ring
12
Monitoring Network Topology Latency, Routers
13
Bandwidth Challenge at SC2005
151 Gbs
500 TB Total in 4h
14
Available Bandwidth Measurements

• one-to-one realtime bandwidth estimation.

15
Monitoring the Execution of Jobs and the Time
Evolution
SPLIT JOBS
LIFELINES for JOBS
Summit a Job
DAG
16
ApMon Application Monitoring

• Library of APIs (C, C, Java, Perl. Python) that
  can be used to send any information to MonALISA
  services
• Flexibility, dynamic configuration, high
  communication performance

dynamic reloading
Config Servlet

• Automated system monitoring
• Accounting information

MonALISA hosts
APPLICATION
MonALISA Service
ApMon
APPLICATION
MonALISA Service
ApMon
System Monitoring
No Lost Packages
ApMon configuration generated automatically by a
servlet / CGI script
ApMon Config
load1 0.24
processes 97
pages_in 83
17
End User / Client Agent LISA- Localhost
Information Service Agent

• Authorization
• Service discovery
• Local detection of the hardware and software
  configuration
• Complete end-system monitoring Per-process load,
  I/O and network throughputs, etc.
• End-to-end performance measurements
• Will act as an active listener for all events
  related with the requests generated by its local
  applications.

18
MonALISA agents to create on demand on an
optical path or tree
Discovery Secure Connection
2
3
ML Demon
1
Time to create a path on demand lt1s
independent of the location and the number of
connections
Control and Monitor the switch
Runs a ML Demon gtml_path IP1 IP4 copy file IP4
4
ML proxy services used in Agent Communication
19
Monitoring and Controlling Optical Planes
Controlling
Port power monitoring
20
Monitoring Optical Switches Agents to Create on
Demand an Optical Path
21
The Functionality of the VINCI System
ML proxy services
Layer 3
ROUTERS
Agent
ETHERNET LAN-PHYor WAN-PHY
Layer 2
Agent
Agent
DWDM FIBER
Layer 1
Agent
Agent
Site A
Site B
Site C
22
Vertical Integration of Services
Real Time Correlations Feedback
between Major Layers is Crucial for Dynamic
Load Balancing , Adaptability and
Self-Organization
MPLS/GMPLS/TL1
Networking
Job 31
Farms Data Servers
Job1
Job3
Job2
Job 32
Job
Applications
Note Grid Services will have to Interact
Negotiate with Network Services for Network
Resources
Job
User
On-Demand, Dynamic and Self Adapting use of
networking resources
23
Communities using MonALISA

• Major Communities
• OSG
• CMS
• ALICE
• D0
• STAR
• VRVS
• LGC RUSSIA
• SE Europe GRID
• APAC Grid
• UNAM Grid
• ABILENE
• ULTRALIGHT
• GLORIAD
• LHC Net
• RoEduNET

ABILENE

• Demonstrated at
• SC2003
• Telecom 2003
• WSIS 2003
• SC 2004
• I2 2005
• TERENA 2005
• IGrid 2005
• SC 2005
• CENIC 2006

• MonALISA
• Running 24 X 7 at 250 Sites
• Collecting 250,000 parameters in near real-time

• Update rate of 25,000 parameter updates per
  second
• Monitoring
• 12,000 computers
• gt 100 WAN Links
• Thousands of Grid jobs running con- currently

-
CMS-DC04
-
GRID3
VRVS
ALICE
24
The MonALISA Architecture Provides

• Distributed Registration and Discovery for
  Services and Applications.
• Monitoring all aspects of complex systems
• System information for computer nodes and
  clusters
• Network information WAN and LAN
• Monitoring the performance of Applications, Jobs
  or services
• The End User Systems, its performance
• Video streaming
• Can interact with any other services to provide
  in near real-time customized information based on
  monitoring data
• Secure, remote administration for services and
  applications
• Agents to supervise applications, trigger alarms,
  restart or reconfigure them, and to notify
  other services when certain conditions are
  detected.
• The MonALISA framework is used to develop higher
  level decision services, implemented as a
  distributed network of communicating agents, to
  perform global optimization tasks.
• Graphical User Interfaces to visualize complex
  information
