Title: Gilbert, Smith, Melbourne


1
An experimental study of soil-arch interaction in
masonry arch bridges
intro
Matthew Gilbert Colin Smith (University of
Sheffield, UK)Clive Melbourne Jinyan Wang
(University of Salford, UK)sponsored by
Gilbert, Smith, Melbourne Wang Universities of
Sheffield Salford
IABMAS conference Porto, July 2006
2
contents
  • why is soil important?
  • limitations of existing analysis methods
  • the experimental study

3
why is soil important?
4
why is soil important? 2
  • however
  • limited range of fill types have been tested
  • spandrel walls obscure our view of soil response
  • the rigid abutments used in the lab. may be
    unrepresentative

5
soil in real arch bridges
as taken from trial pits
or taken through core holes from below
6
soil in real arch bridges
mixed
granular
clay
7
how is soil modelled at present?
  • i.e. common to use rather crude indirect models

Dispersion of applied load e.g. 21 or
Boussinesq
Passive fill pressures e.g. borrowed from
retaining wall theory
8
example passive restraint modelled using bar
elements
  • RING 1.5 / 2.0 - http//ring.shef.ac.uk
  • existing analysis programs calibrated using a
    limited dataset (e.g. granular fill rigid
    abutments)
  • urgently need high quality experimental data so
    that better soil models can be developed

9
new test facility Salford University
  • key features
  • very stiff tank
  • transparent, low-friction sides

10
backfilling
11
instrumentation
  • displacement transducers
  • soil pressure cells
  • acoustic gauges

12
(No Transcript)
13
applied load
14
bridge 1 limestone fill free abutments
15
bridge 1 limestone fill free abutments
16
bridge 2 clay fill free abutments
17
bridge 2 clay fill free abutments
18
bridge 2 clay fill free abutments
19
Load deflection response
20
Perth Penetrometer results
field data
21
enhanced soil model example
  • currently trialling the use rigid-plastic finite
    elements
  • simple robust problem formulation
  • parameters just c and ?
  • other approaches also being investigated
  • (being developed as part of EPSRC funded project
    at Sheffield)

22
compare with experimental
23
conclusions
  • soil can significantly increase the ultimate
    capacity of an arch bridge
  • however, soil-arch interaction is poorly
    understood
  • especially when clay fill and free abutments
  • a new test rig has been designed to enable
    collection of high quality data
  • the acquired data is being used to help develop
    improved analysis models
