Multielectrode Array

1
Multielectrode Array

• Membrane Biophysics
• 9 November 2007
• John Corthell and Kristal Tucker

2
Two broad categories of multielectrode recordings

• In vivo - KT
• Recording and stimulation
• Acute and Chronic
• Heart, CNS, PNS and Retina
• In vitro - JC
• Organotypic and primary dissociated cultures
• Heart, CNS, PNS, and retina

3
Roadmap

• History
• Applications
• Techniques
• Representative articles

4
Brain-Computer Interface
Scott 2006.
5
Chronic in vivo recordings
Musallam et al 2007
6
Electrode fabrication
Musallam et al 2007
7
Array insertion
Musallam et al 2007
8
Data capture and analysis
Musallam et al 2007
9
Variable depth arrays
Sato et. al. 2007
10
(No Transcript)
11
(No Transcript)
12
Hochberg et al 2006
13
Hochberg et al 2006
14
Hochberg et al 2006
15
Hochberg et al 2006
16
Hochberg et al 2006
17
Hochberg et al 2006
18
Hochberg et al 2006
19
In vitro multielectrode array history

• Gross, in 1979, first developed an array based on
  semiconductor technology
• Regehr et al., 1989-first applied Aplysia, Hirudo
  (leech) and Helisoma (snail) cells to
  multielectrode array (MEA) chip for long-term
  recording
• Masuda et al., in 1983, applied a linear
  electrode array to myoneural junctions

20

• Linear electrode array recording

21
Multielectrode array recording
22
In vitro multielectrode applications

• Olfactory processing-Christensen et al., 2000
• Long-term recording-Regehr et al., 1989
• Circadian rhythms-Abraham et al., 2005
• Neuromuscular junction activity-Masuda et al.,
  1983
• Network analysis
• Long-term potentiation
• Synaptic interaction

23
Organotypic Slice Culture

• A different type of cell culture that works with
  MEAs and preserves some circuitry (but not
  exactly native-synaptic rearrangement)
• Ideal for long-term recording, as a culture can
  last from 3-4 weeks for recording to several
  months, depending on prep

Duport et al., 1999
24
(No Transcript)
25
Organotypic Slice Cultures, cont.

• Slice cultures preserve 3-dimensional area for
  electrode preparation
• Simple to prepare-remove brain (no more than
  60s), place into cold solvent, cut into 425?m
  thick slices, place onto MEA with media

• Spinal cord prep, from Bio-Rad website

26
Fabrication

• Commercially available, so you dont have to make
  one yourself
• TiNtitanium nitride

27
Fabrication-MED

• MED is newer than MEA-MED is a planar
  multielectrode array
• MED is an attempt to lengthen recording time from
  previous MEAs

28
MEA/MED Usage

• Hooked up to amplifier, A/D converter, and
  computer
• Typically software programs allow for recording
  and stimulation near-simultaneously
• Cells are usually grown in culture dish over the
  MEA, but can be organotypic

• Works like most electrophysiology
  recordings-difference is previous work to set up
  array and post-experiment work to analyze data

29
Views of MEA chamber and amplifier
plate -PP-probe pin -SC-stimulus
connector -RA-recording area
30
MEA other techniques

• MEA is often used in conjunction with other
  techniques, such as Ca imaging
• MEA measures extracellular changes (as you cannot
  patch), so some things (like post-synaptic
  potentials and Ca flux) are missed

• Optical recording techniques (identifying
  individual cells) are used with MEA to alleviate
  this

31
Other shortcomings

• MEA biochips are expensive to manufacture (may
  change with time), so researchers will clean the
  chip to attempt to salvage the product for future
  use (250-350)
• Continued cleaning will result in degradation of
  chip until readings are no longer reliable

32

• Granados-Fuentes et al., Olfactory bulb neurons
  express functional, entrainable circadian
  rhythms. European J. Neuroscience, 19 898-906,
  2004.

33
MEA and setup

• Per1 transgenic rats (yes, rats) underwent
  bulbectomy from E15-P37, cells were dispersed
  onto MEAs
• MEAs had 60 electrodes, spaced 200?m apart, with
  10?m tips (purchased from Germany)
• SCN explants used as controls (P1-P7)

• Cultures were covered with a membrane and
  transferred to a recording incubator
• Recorded from 4 cultures for at least 5 days
  simultaneously
• Used to establish spontaneous activity

34

• Recording apparatus from inside the incubator

neuro.gatech.edu/groups/ potter/realtimedac.html
35
Other techniques used

• Locomotor activity measured in normal vs.
  bulbectomized rats
• Per1 activity measured by bioluminescence (Per1
  gene is linked to luciferase gene light from
  fireflies, add luciferin, and protein product
  will light up) from a photomultiplier tube
• Temperature entrainment via incubator

36
Results

• Per1 expression in OB
• Start showing rhythm at E19

37

• Top-firing of OB neuron
• Bottom-firing of SCN control
• OB neurons that fired rhythmically were found in
  the mitral cell layer but not the granule cell
  layer

38

• Left axis is Firing Frequency
• Different cells in the same culture can have
  different firing rhythms

39

• Top-Mitral
• Bottom-Granule

40

• Removal of OB has no effect on running wheel
  behavior
• Temperature changes work as zeitgebers
  (entraining signals) for OB culture cells

41
Conclusions from paper

• There is a rhythm of activity and Per1 expression
  in the olfactory bulb neurons of the mitral cell
  layer
• This rhythm begins at E19 and matures over the
  first week postnatal
• These oscillating neurons can have different
  rhythms from one another in the same culture

42
Conclusions from in vitro MEA

• Most modern MEA is the MED-the planar MEA biochip
• Grow cells on biochip or use organotypic culture
  to study
• Can be used to simultaneously record and
  stimulate extracellularly
• Must be cared for-expensive
• Should be used with other techniques to
  compensate for shortcomings
