Whats new in Visual Studio'NET 2005

1
Whats new in Visual Studio.NET 2005
Michael V. Ekedahl University of Nevada, Reno
2
Session Overview

• Changes to the Integrated Development Environment
• Improvements to Windows Forms
• Changes to the .NET Framework
• Visual Basic language enhancements
• Enhancements and changes to controls
• An improved Help system
• Changes to Data Management

3
Whats new with the IDE (1)

• Edit and Continue support has been added
• A return from VB 6
• Exception assistant
• Gives help to solve exceptions when they are
  thrown
• A better Immediate window
• Design-time expression evaluation
• Task list and Error list are factored into two
  windows
• IDE is more configurable
• Project organization has changed

4
Whats new with the IDE (2)
In-place property editing
5
Whats new with the IDE (3)
Code snippets create templates for common tasks
6
Whats new with the IDE (4)
Autocorrect typographical errors
7
Whats new with the IDE (5)
Docking tips
8
Whats new With Forms (1)

• Property selection
• The Visual Basic 6.0 Forms collection is back (in
  a way)
• My.Forms supplies a reference to each declared
  form
• A default form instance is also created
• A bit of history from VB 6
• A few new events

9
Whats new With Forms (2)
Snap lines make control alignment a snap
10
Whats new with the .NET Framework (General)

• 64-bit platform support
• IO has been enhanced to read and write data using
  GZIP compression
• The new GZipStream class
• The SerialPort class allows us to access serial
  ports and communicate with serial devices

11
Whats new with the .NET Framework (Networking 1)

• There is SMTP support to send and receive e-mail
  messages
• Attachments and carbon copies are supported
• SmtpClient class has methods to send messages
  (Send, SendAsync)
• Messages themselves are managed as MailAddress,
  Message, MailAttachment

12
Whats new with the .NET Framework (Networking 2)

• FTP support has been added through
• Methods of System.Net.FtpMethods
• And My.Computer.Network
• Ping is supported through System.Net.NetworkInform
  ation.Ping and My.Computer.Net.Ping

13
Whats new with Visual Basic (1)

• Unsigned whole number types are supported as in
• lblSByte.Text System.SByte.MaxValue
• lblUShort.Text System.UInt16.MaxValue
• lblUInteger.Text _
• System.UInt32.MaxValue
• lblULong.Text System.UInt64.MaxValue
• Partial classes allow a class to be split between
  multiple physical files
• Designer generated code and developer created
  appears in separate files

14
Whats new with Visual Basic (2)
Several new templates have been added
15
Whats new with Visual Basic (3)

• Generics provide the means to create strongly
  typed lists such as an ArrayList
• Generics for List, Dictionary, SortedDictionary,
  Queue and Stack are supported
• Performance of generics is better because objects
  are strongly typed
• Dim PersonList As New List(Of Person)
• PersonList.Add(New Person("Joe", 23))

16
Whats new with Visual Basic (4)

• Visual Basic now supports operator overloading
• Existing operators are overloaded as in
• Dim p1 As New Point(10, 10)
• Dim s1 As New Size(20, 20)
• Dim pResult As Point p1 s1
• Its also possible to create overloaded operators
  for custom classes

17
Whats new with Visual Basic (5)

• The Using statement eliminates the need to
  finalize objects
• Create a class instance in the Using statement
• Scope of class instance is the Using block
• Using f As New Font("Arial", 12)
• ' Statements that use f
• End Using

18
Whats new with Visual Basic (6)

• The Continue statement skips to the next
  iteration of a loop
• The IsNot operator is simplifies syntax Thus,
• Dim t As TextBox Nothing
• If Not (t Is Nothing) Then
• becomes
• If t IsNot Nothing Then

19
Whats new with Visual Basic (7)

• In Visual Studio 2003, CType and DirectCast were
  used to convert types
• Exceptions would be thrown if the type could not
  be converted
• TryCast attempts a cast and returns Nothing if
  the type cannot be converted
• Dim p As Person
• p TryCast(SomeObject, Person)
• If p IsNot Nothing Then
• ' Statements
• End If

20
Whats new with Visual Basic (8)

• The following application-level events are
  supported in the partial class named
  MyApplication
• Shutdown fires after all forms are closed
• Startup fires just before the startup form is
  created
• StartupNextInstance fires when a single instance
  application is started that is already running
• NetworkAvailabilityChanged fires when the network
  becomes available or unavailable
• UnhandledException fires in case of any exception
  that has not active handler

21
Whats new with the .NET Framework (My)

• The My keyword references objects to
• Get to resource files with My.Resources
• Get information about the local computer with
  My.Computer
• My.Computer.Info gets configuration information
• My.Computer.Registry gets to the registry
• Communicate with the network using
  My.Computer.Network
• Interact with the current application using
  My.Application
• Print easily with My.Computer.DefaultPrinter

22
Whats New with the .NET Framework (My)

• Factory methods get a reference to a form as in
  My.Forms.Form1
• A reference to the WebService proxy can be
  obtained through My.WebServices making it easy to
  find the supported members
• Multimonitor support is included as in
• Dim s As Screen()
• Dim r As Rectangle
• s System.Windows.Forms.Screen.AllScreens
• r s(0).WorkingArea

23
Whats new in Controls (1)

• MenuStrip control replaces the MainMenu control
• The functionality is similar
• The implementation differs significantly
• Images are now supported on menu items
• Images are stored in resource files
• Pascal case menu naming is automatic
• DataGridView control displays data in a tabular
  format
• The control works in a bound or unbound mode
• Custom cell and column types are supported

24
Whats new in Controls (2)

• SplitContainer control is made up of two panels
  separated by a movable bar
• SplitContainers can be nested
• Great for drill-down interfaces
• Replaces the Splitter control
• MaskedTextBox provides simple to use input
  validation

25
Whats new in Controls (3)

• FlowLayoutPanel and TableLayoutPanel give us Java
  layout capabilities
• FlowLayoutPanel contents can be adjusted
  horizontally or vertically
• Contents may be clipped
• TableLayoutPanel
• A grid composed of rows and columns
• Controls can be nested
• The grid is dynamic

26
Whats new in Controls (4)

• FolderBrowserDialog allows simple folder
  selection
• SelectedPath property contains the folder
  selected by the user

27
Whats new in Controls (5)

• WebBrowser control provides simple browser
  capabilities
• WebBrowser1.Navigate("file//c/foo.htm")

28
Whats new in Help (1)

• The Help system has been overhauled
• Topic pages can be expanded or collapsed
• How to help is task based instead of feature
  based
• More code examples are included
• Its easy to copy sample code

29
Whats new in Help (2)

• JavaDoc like documentation is supported
• We refer to them as XML comments
• XML comments appear in tooltips

30
Whats new with Data Management (Introduction)

• ADO.NET 2.0 supersedes ADO.NET 1.0
• Seamless integration with SQL Server
• Creating bound controls is much easier
• The DataSet and DataTable classes are similar to
  those found in Visual Studio 2003
• The DataGridView control replaces the DataGrid
  control

31
Data Sources Window
Data Sources Windowshows data sourcesavailable
to the project
Server data, local data, Web services, and
custom business objects can be data sources
32
Dataset Designer
33
The DataNavigator Class

• Supplies a data navigation and data manipulation
  user interface for bound controls
• Supports navigation and editing methods
• Custom logic must be implemented to perform
  editing actions
• Binds to a DataConnector

34
The DataConnector Class

• Its the plumbing to
• Bind to a data source
• And connect the data source to the forms control
  instances
• Once bound, the DataConnector provides all record
  navigation and editing facilities

35
The TableAdapter Class

• TableAdapters are designer generated components
• They are analogous to strongly typed data
  adapters
• A TableAdapter can contain multiple SELECT
  statements instead of just one

36
The Visual Studio Team System

• Team Architect
• Application modeling and deployment modeling
• Team Developer
• Code analysis and profiling
• Team Test
• Load testing and unit testing

37
Release Schedule

• Beta 1 has been released
• Community Technology Previews are being released
  monthly
• Beta 2 should be available late March
• Final software available this fall?
• Longhorn will enter beta this fall too
