Other Research Aircraft

1
(No Transcript)
2
Other Research Aircraft

• DC-8 (with MTP)
• ER2, WB57
• HALO (2009?)
• UK BAe-146
• Smaller jets (Learjets, Falcon, etc)
• Commercial aircraft (esp. in special programs)
• Turboprop aircraft with wind-sensing (but
  altitude limitation)
• NCAR C-130, P3s, etc.
• King Air, Merlin, etc.
• Many more ... but need a quality wind-sensing
  system

3
G-V Characteristics

• Certified flight to 51,000 ft climb to 41,000 ft
  fully loaded
• Max. range near 6000 n mi (gt10,000 km)
• 12-person crew satellite comm. system
• Wind-sensing
• radome-port system with dual INS/GPS and
  differential GPS
• to be added all-weather gust system, laser
  velocimeter, higher-quality INS/GPS

4
Observing Gravity Waves Using Research Aircraft

• In Situ Measurements
• Wind
• horizontal wind
• vertical wind
• turbulence characterization
• Pressure (including high-resolution for
  perturbations)
• Temperature and air density
• Fluxes
• Tracers (q, ozone, CO, aerosol conc., etc)

5
Observing Gravity Waves Using Research Aircraft

• Remote Measurements
• Microwave Temperature Profiler (MTP)-2007
• Aerosol-Backscatter Lidar (HSRL)-2008
• GPS full-spectrum receiver-2008
• Future
• Cloud Radar-2009
• Remote sensing of wind
• DIAL lidar(s)

6
Anticipated Accuracies
(for all, resolution is much better so changes of
perhaps 10 of these values can be measured
reliably)

• Horizontal wind 0.5 m/s
• Vertical wind lt0.5 m/s
• Temperature 0.3C
• Pressure 0.3 mb?
• MTP 1-2K, 100 m vertical

7
What Capabilities Are New?

• Altitude and range (and plans for routine
  operation at UT/LS altitudes)
• High-quality wind system (with GPS corrections)
  and flux-measuring system
• Temperature profiling (soon)
• Pressure-sensing system capable of measuring
  pressure fluctuations with high resolution (via
  differential GPS and special attention to
  calibration of p measurements)

8
MTP measurements from DC-8 in SOLVE (from MJ
Mahoney)
375K
15
airflow
325K
p. altitude km
10
9
GPS Full-Spectrum Receiver

• Enables the aircraft to perform like a LEO
  satellite
• occultation soundings at locations selected for
  coverage
• ability to measure path-integral time delay in
  directions of a set of satellites, from above
  most water vapor
• potential uses in conjunction with the MTP

10
GPS
11
Tracers

• In addition to the basic parameters of the wave,
  it is possible to measure many tracers that are
  steady on the time scale of the wave
• water vapor
• ozone
• CO
• particle concentration
• etc.

12
Pressure Measurements

• Aircraft all measure pressure and fly by
  reference to a constant pressure
• Normally, measured pressure fluctuations can't be
  distinguished from altitude changes
• GPS systems now provide a high-resolution
  reference altitude, valid (with diff. GPS) to ca.
  10 cm.
• Opportunity to measure pressure fields with high
  spatial resolution (from D-value measurements)

13
Measurement Opportunity

• In a gravity wave, can measure
• fluctuations u',v',w',T',p' (and hence density')
• T profiler will provide N and H (or sounding)
• linear theory constraints these amplitudes,
  dependent on k,l,m,N,H,f
• With all measured except mvertical wavenumber,
  have highly constrained solution that provides m,
  vertical propagation, etc.

14
Example (over Utah)
15
Another Example
16
Polarization Relations
(approx.)
Expect vertical and horizontal amplitudes to be
similar, and (for typical conditions seen in
TREX) p fluctuations to be around 0.5 mb. The
corresponding D-value changes are around 20 m,
and so are measurable with the combined
GPS/pressure system.
17
Another Example
18
Variance Spectrum, w
19
Variance Spectrum, w
20
Variance Spectrum, u
21
Observing Opportunities

• Long ferry legs at UT/LS altitudes provide
  opportunities for assembling climatology.
  (Example TREX flown from Colorado, ferry legs to
  California)
• Aircraft showed good flight characteristics in
  turbulence (although experience limited)
• Above-cloud observations possible (and some will
  be accumulated routinely). Opportunity to
  characterize turbulence
