Title: Wireless Sensor Networks Tutorial


1
Wireless Sensor NetworksTutorial
  • Katia Obraczka
  • Department of Computer Engineering
  • University of California, Santa Cruz
  • May 2006

2
Introduction
3
Main Goals
  • Overview of wireless sensor networks.
  • What are sensor networks?
  • Unique characteristics/challenges, etc.
  • State-of-the-art in sensor networks research.

4
Topics
  • Introduction.
  • Applications.
  • E2E protocols.
  • Routing and data dissemination.
  • Storage, querying, and aggregation.
  • Topology control.
  • Deployment issues.
  • Localization.
  • Time synchronization.
  • Medium access control.
  • Energy models.

5
Introduction
  • What are wireless sensor networks?
  • Unique characteristics/challenges.
  • Basic concepts and terminology.

6
What are wireless sensor networks (WSNs)?
  • Networks of typically small, battery-powered,
    wireless devices.
  • On-board processing,
  • Communication, and
  • Sensing capabilities.

P O W E R
Sensors
Processor
Storage
Radio
WSN device schematics
7
WSN node components
  • Low-power processor.
  • Limited processing.
  • Memory.
  • Limited storage.
  • Radio.
  • Low-power.
  • Low data rate.
  • Limited range.
  • Sensors.
  • Scalar sensors temperature, light, etc.
  • Cameras, microphones.
  • Power.

P O W E R
Sensors
Storage
Processor
Radio
WSN device schematics
8
Why Now?
  • Use of networked sensors dates back to the 1970s.
  • Primarily wired and
  • Centralized.
  • Today, enabling technological advances in VLSI,
    MEMS, and wireless communications.
  • Ubiquitous computing and
  • Ubiquitous communications.

9
Vision Embed the World
  • Embed numerous
  • sensing nodes to
  • monitor and interact
  • with physical world
  • Network these devices
  • so that they can
  • execute more complex task.

Images from UCLA CENS
10
Examples of WSN Platforms
PC-104(off-the-shelf)
UCLA TAG (Girod)
UCB Mote (Pister/Culler)
11
Berkeley Mote
  • Commercially available.
  • TinyOS embedded OS running on motes.

12
Design Challenges
  • Why are WSNs challenging/unique from a research
    point of view?
  • Typically, severely energy constrained.
  • Limited energy sources (e.g., batteries).
  • Trade-off between performance and lifetime.
  • Self-organizing and self-healing.
  • Remote deployments.
  • Scalable.
  • Arbitrarily large number of nodes.

13
Design Challenges (Contd)
  • Heterogeneity.
  • Devices with varied capabilities.
  • Different sensor modalities.
  • Hierarchical deployments.
  • Adaptability.
  • Adjust to operating conditions and changes in
    application requirements.
  • Security and privacy.
  • Potentially sensitive information.
  • Hostile environments.

14
WSN Applications
  • Monitoring.
  • Scientific, ecological applications.
  • Non-intrusiveness.
  • Real-time, high spatial-temporal resolution.
  • Remote, hard-to-access areas.
  • Surveillance and tracking.
  • Reconnaissance.
  • Perimeter control.
  • Smart Environments.
  • Agriculture.
  • Manufacturing/industrial processes.

15
WSN Applications (Contd)
  • UCLA Center for Embedded Networked Sensing
    (CENS) http//www.cens.ucla.edu/.
  • Berkeley Wireless Embedded Systems (WEBS).

16
WSN Applications at UCSC
  • SEA-LABS.
  • CARNIVORE.
  • Meerkats.
  • Yellowstone.

17
Sensor Exploration Apparatus utilizing
Lowpower Aquatic Broadcasting System
18
SEA-LABS
  • Joint work with
  • Don Potts (Professor, Biology)
  • Matt Bromage (PhD student, CE)

19
Mission Statement
  • SEA-LABS strives to engineer a real-time,
    low-cost, low-power consumption environmental
    monitoring system for use in shallow-water reef
    habitats. Our goal is to measure several
    important physical and chemical variables for use
    in laboratory experiments studying the growth and
    calcification of corals and coralline algae.

20
Architecture
21
Implementation
  • P. O. D.
  • Board size 3.0 x 1.5
  • One antenna for both transmit and receive
  • Transmit receive data packets from base station
  • B u o y

22
Current Status
23
CARNIVORE
24
CARNIVORES
  • Joint work with
  • Terrie Williams (Professor, Biology)
  • Dan Costa (Professor, Biology)
  • Roberto Manduchi (Professor, CE)
  • Vladi Petkov (PhD student, CE)
  • Cyrus Bazeghi (PhD student, CE)
  • Matt Ruttinshauser (MS student, CE and Biology)

25
Motivation
  • Need to investigate in more detail the behavior
    of predators.
  • Monitoring their location
  • More importantly, monitoring their activity
    patterns to draw up in depth energy budgets
    (activities such as walking, trotting, galloping
    and eating will be identified)
  • Several questions can be answered
  • Can coyotes assimilate food and run
    simultaneously
  • Do coyotes conserve their energy when hunting to
    prolong the hunting duration
  • What are the human impacts on coyotes with
    respect to the two points above

26
Coyote Network Infrastructure
Coyote-tower data exchange
Coyote-coyote data exchange
Coyote-coyote data exchange
Coyote-tower data exchange
27
Collar Sensor Package
28
Sensor Package Main Board
29
Sensor Package Sister-board
30
Acceleration Preliminary Tests
  • Pippin, a friendly and well trained dog, was used
    to study correlations between behavior and
    acceleration
  • Next 4 slides show freeze frames of Pippin
    running at different speeds with acceleration
    graphs overlaid
  • Different gaits (walk, trot, gallop) clearly
    affect acceleration graphs
  • Higher speeds also identifiable by higher
    amplitudes of acceleration
  • Z-axis is the up down axis, and the one used for
    the brief annotations on the graphs

31
Pippin Treadmill 3mph walk
Period 360 ms
Amplitude (peak to peak) 800 mg
32
Pippin Treadmill 6mph trot
Amplitude (peak to peak) 1750 mg
Period 200 ms
33
Pippin Alongside cart 10mph gallop
Period 400 ms
Amplitude (peak to peak) 1750 mg
34
Pippin Alongside cart 15mph gallop
Period 400 ms
Amplitude (peak to peak) 2500 mg
35
Low Power Considerations
  • Texas Instruments MSP430 microcontroller is very
    low-power versatile.
  • ZigBee radio was designed for sensor applications
    with low power in mind and will not be on at all
    times.
  • GPS module will be turned on only long enough to
    acquire a fix and off interval will be large
    compared to fix-acquisition-interval.
  • SD card consumes significant power only during
    read/write operations which happen very quickly
    and as infrequently as possible.
  • Virtually all system functions are duty cycled
    allowing peripherals to remain on only as long as
    they are needed.

36
Data Handling Considerations
  • Non-fully-connected network.
  • Not all coyotes guaranteed to come in close
    proximity to base station.
  • Collars copy data bundles of other collars in
    proximity to ensure timely transmission to tower
    (messenger coyotes).
  • In absence of intelligent routing, all data is
    copied to all collars.
  • Better routing decision methods based on metrics
    appropriate to this system are being explored.

37
Future Work
  • Data analysis algorithm(s) to extract behavior
    information from raw acceleration data.
  • More efficient routing algorithm.
  • Detailed system power consumption analysis.
  • Trial runs in controlled environment.

38
Meerkats A Power-Aware, Wireless Camera Network
  • Joint work with R. Manduchi, C. Margi, X. Lu, G.
    Zhang, V. Petkov, G. Stanek

Sponsored by NASA, Intelligent Systems Program
39
What is Meerkats?
  • A small southern Africa mongoose.
  • Wireless camera network for surveillance and
    monitoring

40
Why camera networks?
  • Cameras provide richer information.
  • Cameras have wider and longer sensing range.
  • BUT
  • Consume more power.
  • Need more processing and storage.

41
Meerkats Goal
  • Maximize performance as well as network lifetime.
  • However, these introduce conflicting
    requirements.
  • Approach efficient resource management.
  • Complementary to efforts targeting design of
    low-power platforms.

42
Resource Management
Bit rate Delay
Activation rate Processing type Duty cycle
design Abstraction level Synchronization
SENSING PROCESSING TRANSMISSION
Performance QoS Lifetime
Power
System parameters
43
Meerkats hardware
  • Stargate boards
  • XScale PXA255 CPU (400MHz)
  • 32M flash, 64M DRAM.
  • Running Stargate v. 7.3 (embedded Linux).

44
Meerkats hardware (contd)
  • Orinoco Gold 802.11b wireless network card.
  • QuickCam Pro 4000 camera (USB port).
  • Used at 320x240 resolution.
  • Custom 2-cell Li-Ion 7.4 Volt, 1 Ah battery
  • Connected to daughter board.
  • DC-DC regulator to 5 Volts.

45
Meerkats Node
46
Networking
  • MAC IEEE 802.11b.
  • Dynamic Source Routing (DSR) Johnson et al..
  • Source routing data packets carry route
    information.
  • Useful for future QoS control.
  • Plan is to extend DSR to perform alternate path
    routing for QoS requirements.
  • UDP and TCP at the transport layer.
  • UDP used to send out alarms.
  • TCP used to send out images.

47
Node Operation
  • Duty cycle based.
  • Nodes alternate between sleep, low-power- and
    active states.
  • Better energy efficiency.
  • But how about performance?

48
Event Detection
  • Goal
  • Capture and transmit at least one image of any
    moving body in any cameras field of view.
  • Current scheme
  • Periodic image acquisition
  • Node-to-node wire-trapping
  • Motion analysis highly desirable.

49
Foreground Detection
  • Background subtraction
  • Build model of stationary background.
  • Detect pixels unlikely to belong to background.

background
new image
foreground
subimage to be transmitteed
50
Power Consumption Characterization
  • Goal
  • Predict the systems lifetime.
  • I.e., how long a node will last if engaged in
    specific activities?
  • Representative elementary tasks and duty
    cucles.

51
Baseline Duty Cycle
52
Wire-tripping Duty Cycle
MASTER
53
Whats next?
  • Performance analysis.
  • Miss rate given arrival rate, trajectory,
    activation rate, etc.
  • QoS alternate path routing.
  • Synchronization issues.

54
Whats next?
  • Ongoing work on energy consumption prediction.
  • Question
  • Given our energy consumption characterization,
    can we predict amount of energy left at a future
    point in time based on past activity?
  • Approach probabilistic models of power
    consumption state space and transitions.

55
Power Consumption State Space
6. SEND ALERT/ DESCRIPTOR
1. SLEEP
3. TAKE PICTURE
2. LISTEN
5. PROCESS PICTURE
4. COMPRESS/ TRANSMIT
From other nodes
From sink
56
Yellowstone Project
  • Senior design project.
  • Sensor network to monitor volcanic activity in
    Yellowstone National Park.
  • Scientists want to observe temperature variations
    spatially and temporally.
  • Detect relevant events.
  • E.g., geiser eruption.

57
Design Considerations
  • Low power.
  • Visually and environmentally non-intrusive.
  • Withstand wildlife and harsh environment.
  • Data available readily and in real-time.
  • Robust, self-managing, and self-healing.

58
System Architecture
  • Multi-tier network.
  • Sensing and relay nodes.
  • Modularity and extensibility.

59
Current Status
  • System under implementation.
  • Semi-functional working prototype.
  • Sensing, processing, sending and receiving data.
  • Still working on the wireless communications
    capabilities.
  • Demonstration scheduled for final project
    presentations in the beginning of June.
  • Real deployment scheduled for Summer 2006.
Write a Comment
User Comments (0)
About PowerShow.com
