The Doogie mouse

1
The Doogie mouse
2
Synaptic plasticity

• Both electrical and chemical synapses can change
  temporally and spatially.
• Changes in synaptic efficacy is synaptic
  plasticity.
• Chemical synapses undergo metabolic regulation to
  maintain homeostasis (Ex ACh).
• Changes in synaptic efficacy (change in amplitude
  of response) should last.

3
Synaptic efficacy

• Synaptic facilitation (posttetanic potentiation)
  follows tetanic stimulation of presynaptic
  neuron.
• Synaptic depression (or antifacilitation)
• Both affect the amount of NTs released.
• Habituation is a decrease in the sensitivity of a
  synapse.
• Sensitization is prolonged enhancement of a
  synapse to stimulation.

4
Figure 12.22 Synaptic facilitation and
antifacilitation
5
Figure 12.23 Habituation and sensitization in
Aplysia gill withdrawal (Part 1)
6
Figure 12.23 Habituation and sensitization in
Aplysia gill withdrawal (Part 2)
7
Behavioral sensitization

• Changes in EPSP are correlated with changes in
  the quanta of NT released.
• Habituation is a progressive long-lasting
  inactivation of Ca2 channels.
• Sensitization occurs at the sensory-to-motor
  synapse.
• Presynaptic facilitation underlies behavioral
  sensitization
• Presynaptic facilitation is caused by an influx
  of Ca2
• In Aplysia 5-HT increases the amount of cAMP in
  the sensory terminals which phosphorylates the K
  channels and leads to a decrease in the K
  current.

8
Figure 12.24 A model of Aplysia sensitization
9
Short term and long term effects

• Short term habituation lasts about an hour.
• Requires changes in synaptic mechanisms
• Long term habituation can persist for up to 3
  weeks.
• Requires protein synthesis
• High levels of cAMP activate cAMP-dependent
  protein kinase which activates gene transcription
  via cAMP response element-binding protein (CREB).
• Habituation and sensitization are nonassociate
  learning.

10
Figure 12.25 Classical conditioning in Aplysia
11
LTP in hippocampus

• Long term potentiation is a long lasting
  enhancement of synaptic transmission following
  intense stimulation.
• You need many presynaptic neurons to depolarize
  the postsynaptic CA1 cell.
• Any synapse that is active while the postsynaptic
  cell is strongly depolarized will be potentiated
  for hours (in slices), weeks (in vivo).

12
Hebbian learning

• Learning depends on the pre and postsynaptic
  cells being depolarized at the same time.
• Neurons that fire together wire together.
• A synapse that undergoes a long term change in
  strength is called a Hebbian synapse

13
Figure 12.26 Long-term potentiation in the
hippocampus (Part 1)
14
Figure 12.26 Long-term potentiation in the
hippocampus (Part 2)
15
Hippocampal LTP

• Depends on 2 glutamate receptors--N-methyl-D-aspar
  tate (NMDA) receptors and non-NMDA receptors.
• Non-NMDA receptors produce fast EPSPs.
• NMDA receptors only work when the cell is
  depolarized

16
Figure 12.27 Induction and maintenance of LTP in
the hippocampus (Part 1)
17
Figure 12.27 Induction and maintenance of LTP in
the hippocampus (Part 2)
18
The Doogie Mice

• Joe Tsien and coworkers engineered a mouse that
  over expressed the juvenile subunit of NMDA
  receptors.
• Juvenile subunit remains open longer and allows
  more calcium to enter.
• Doogie mice remember novel stimuli longer and
  learn more easily
