Title: JDBC and Java Access to DBMS


1
JDBC and Java Access to DBMS
  • University of California, Berkeley
  • School of Information
  • IS 257 Database Management

2
Lecture Outline
  • Review
  • Object-Relational DBMS
  • OR features in Oracle
  • OR features in PostgreSQL
  • Extending OR databases (examples from PostgreSQL)
  • Java and JDBC

3
Lecture Outline
  • Object-Relational DBMS
  • OR features in Oracle
  • OR features in PostgreSQL
  • Extending OR databases (examples from PostgreSQL)
  • Java and JDBC

4
Object Relational Data Model
  • Class, instance, attribute, method, and integrity
    constraints
  • OID per instance
  • Encapsulation
  • Multiple inheritance hierarchy of classes
  • Class references via OID object references
  • Set-Valued attributes
  • Abstract Data Types

5
Object Relational Extended SQL (Illustra)
  • CREATE TABLE tablename OF TYPE TypenameOF NEW
    TYPE typename (attr1 type1, attr2 type2,,attrn
    typen) UNDER parent_table_name
  • CREATE TYPE typename (attribute_name type_desc,
    attribute2 type2, , attrn typen)
  • CREATE FUNCTION functionname (type_name,
    type_name) RETURNS type_name AS sql_statement

6
Object-Relational SQL in ORACLE
  • CREATE (OR REPLACE) TYPE typename AS OBJECT
    (attr_name, attr_type, )
  • CREATE TABLE OF typename

7
Example
  • CREATE TYPE ANIMAL_TY AS OBJECT (Breed
    VARCHAR2(25), Name VARCHAR2(25), Birthdate DATE)
  • Creates a new type
  • CREATE TABLE Animal of Animal_ty
  • Creates Object Table

8
Constructor Functions
  • INSERT INTO Animal values (ANIMAL_TY(Mule,
    Frances, TO_DATE(01-APR-1997,
    DD-MM-YYYY)))
  • Insert a new ANIMAL_TY object into the table

9
PostgreSQL Classes
  • The fundamental notion in Postgres is that of a
    class, which is a named collection of object
    instances. Each instance has the same collection
    of named attributes, and each attribute is of a
    specific type. Furthermore, each instance has a
    permanent object identifier (OID) that is unique
    throughout the installation. Because SQL syntax
    refers to tables, we will use the terms table and
    class interchangeably. Likewise, an SQL row is an
    instance and SQL columns are attributes.

10
Creating a Class
  • You can create a new class by specifying the
    class name, along with all attribute names and
    their types
  • CREATE TABLE weather (
  • city varchar(80),
  • temp_lo int, -- low
    temperature
  • temp_hi int, -- high
    temperature
  • prcp real, --
    precipitation
  • date date
  • )

11
PostgreSQL
  • Postgres can be customized with an arbitrary
    number of user-defined data types. Consequently,
    type names are not syntactical keywords, except
    where required to support special cases in the
    SQL92 standard.
  • So far, the Postgres CREATE command looks exactly
    like the command used to create a table in a
    traditional relational system. However, we will
    presently see that classes have properties that
    are extensions of the relational model.

12
Inheritance
  • CREATE TABLE cities (
  • name text,
  • population float,
  • altitude int -- (in ft)
  • )
  • CREATE TABLE capitals (
  • state char(2)
  • ) INHERITS (cities)

13
Inheritance
  • In Postgres, a class can inherit from zero or
    more other classes.
  • A query can reference either
  • all instances of a class
  • or all instances of a class plus all of its
    descendants

14
Non-Atomic Values - Arrays
  • The preceding SQL command will create a class
    named SAL_EMP with a text string (name), a
    one-dimensional array of int4 (pay_by_quarter),
    which represents the employee's salary by quarter
    and a two-dimensional array of text (schedule),
    which represents the employee's weekly schedule
  • Now we do some INSERTSs note that when appending
    to an array, we enclose the values within braces
    and separate them by commas.

15
PostgreSQL Extensibility
  • Postgres is extensible because its operation is
    catalog-driven
  • RDBMS store information about databases, tables,
    columns, etc., in what are commonly known as
    system catalogs. (Some systems call this the data
    dictionary).
  • One key difference between Postgres and standard
    RDBMS is that Postgres stores much more
    information in its catalogs
  • not only information about tables and columns,
    but also information about its types, functions,
    access methods, etc.
  • These classes can be modified by the user, and
    since Postgres bases its internal operation on
    these classes, this means that Postgres can be
    extended by users
  • By comparison, conventional database systems can
    only be extended by changing hardcoded procedures
    within the DBMS or by loading modules
    specially-written by the DBMS vendor.

16
Lecture Outline
  • Review
  • Object-Relational DBMS
  • OR features in Oracle
  • OR features in PostgreSQL
  • Extending OR databases (examples from PostgreSQL)
  • Java and JDBC

17
Java and JDBC
  • Java is probably the high-level language used in
    most software development today one of the
    earliest enterprise additions to Java was JDBC
  • JDBC is an API that provides a mid-level access
    to DBMS from Java applications
  • Intended to be an open cross-platform standard
    for database access in Java
  • Similar in intent to Microsofts ODBC

18
JDBC Architecture
  • The goal of JDBC is to be a generic SQL database
    access framework that works for any database
    system with no changes to the interface code

Java Applications
JDBC API
JDBC Driver Manager
Driver
Driver
Driver
Oracle
MySQL
Postgres
19
JDBC
  • Provides a standard set of interfaces for any
    DBMS with a JDBC driver using SQL to specify
    the databases operations.

20
JDBC Simple Java Implementation
import java.sql. import oracle.jdbc. public
class JDBCSample public static void
main(java.lang.String args) try //
this is where the driver is loaded
//Class.forName("jdbc.oracle.thin")
DriverManager.registerDriver(new
OracleDriver()) catch (SQLException e)
System.out.println("Unable to load driver
Class") return
21
JDBC Simple Java Impl.
try //All DB access is within the
try/catch block... // make a connection to
ORACLE on Dream Connection con
DriverManager.getConnection(
"jdbcoraclethin_at_dream.sims.berkel
ey.edu1521dev", mylogin",
myoraclePW") // Do an SQL statement...
Statement stmt con.createStatement()
ResultSet rs stmt.executeQuery("SELECT NAME
FROM DIVECUST")
22
JDBC Simple Java Impl.
// show the Results... while(rs.next())
System.out.println(rs.getString("NAME"))
// Release the database
resources... rs.close()
stmt.close() con.close() catch
(SQLException se) // inform user of
errors... System.out.println("SQL Exception
" se.getMessage()) se.printStackTrace(Syst
em.out)
23
JDBC
  • Once a connection has been made you can create
    three different types of statement objects
  • Statement
  • The basic SQL statement as in the example
  • PreparedStatement
  • A pre-compiled SQL statement
  • CallableStatement
  • Permits access to stored procedures in the
    Database

24
JDBC Resultset methods
  • Next() to loop through rows in the resultset
  • To access the attributes of each row you need to
    know its type, or you can use the generic
    getObject() which wraps the attribute as an
    object

25
JDBC GetXXX() methods
SQL data type Java Type GetXXX()
CHAR String getString()
VARCHAR String getString()
LONGVARCHAR String getString()
NUMERIC Java.math.BigDecimal GetBigDecimal()
DECIMAL Java.math.BigDecimal GetBigDecimal()
BIT Boolean getBoolean()
TINYINT Byte getByte()


26
JDBC GetXXX() Methods
SQL data type Java Type GetXXX()
SMALLINT Integer (short) getShort()
INTEGER Integer getInt()
BIGINT Long getLong()
REAL Float getFloat()
FLOAT Double getDouble()
DOUBLE Double getDouble()
BINARY Byte getBytes()
VARBINARY Byte getBytes()
LONGVARBINARY Byte getBytes()

27
JDBC GetXXX() Methods
SQL data type Java Type GetXXX()
DATE java.sql.Date getDate()
TIME java.sql.Time getTime()
TIMESTAMP Java.sql.Timestamp getTimeStamp()







28
Large Object Handling
  • Large binary databytes can be read from a
    resultset as streams using
  • getAsciiStream()
  • getBinaryStream()
  • getUnicodeStream()

ResultSet rs stmt.executeQuery(SELECT IMAGE
FROM PICTURES WHERE
PID 1223)) if
(rs.next()) BufferedInputStream gifData new
BufferedInputSteam(

rs.getBinaryStream(IMAGE)) byte buf
new byte41024 // 4K buffer int len while
((len gifData.read(buf,0,buf.length)) ! -1)
out.write(buf, 0, len)
29
JDBC Metadata
  • There are also methods to access the metadata
    associated with a resultSet
  • ResultSetMetaData rsmd rs.getMetaData()
  • Metadata methods include
  • getColumnCount()
  • getColumnLabel(col)
  • getColumnTypeName(col)

30
JDBC access to MySQL
  • The basic JDBC interface is the same, the only
    differences are in how the drivers are loaded

public class JDBCTestMysql public static
void main(java.lang.String args) try
// this is where the driver is loaded
Class.forName("com.mysql.jdbc.Driver").newInstance
() catch (InstantiationException i)
System.out.println("Unable to load driver
Class") return catch
(ClassNotFoundException e)
System.out.println("Unable to load driver
Class")
31
JDBC for MySQL
try //All DB access is within the
try/catch block... // make a connection to
MySQL on Dream Connection con
DriverManager.getConnection(
"jdbcmysql//dream.sims.berkeley.ed
u/ (this is really one line)
MyDatabase?userMyLoginpasswordMySQLPW")
// Do an SQL statement... Statement stmt
con.createStatement() ResultSet rs
stmt.executeQuery("SELECT NAME FROM DIVECUST")
  • Otherwise everything is the same as in the Oracle
    example
  • For connecting to the machine you are running
    the program on, you can use localhost instead
    of the machine name
