System Management in Challenged Networks

1

• System Management in Challenged Networks
• CENS Seminar November 17th, 2006
• Martin Lukac
• Lewis Girod
• Deborah Estrin
• UCLA CENS - MIT CSAIL

2
Outline

• Meso American Subduction Experiment (MASE) A
  Challenged Network
• Data Delivery
• System Management
• The Future

3
Seismic Deployment Application Requirements

• Extensive 500 Km from Acapulco through Mexico
  City to Tampico
• Dense 1 sensor every 5-10 Km
• High bandwidth Data acquisition rate 3 - 24 bit
  channels at 100Hz each
• Online and Reliable Semi real-time (on the order
  of days), reliable data delivery to UCLA for
  analysis
• Online system management
• Query state, change configuration, update
  binaries
• Can not interfere with data delivery
• Application driven topology application
  determines sensor placement
• Infrastructure does not (Cant rely on
  pre-existing cell or power infrastructure)

MASE Given these requirements, we deployed solar
powered seismic stations equipped with 802.11b
4
18 - A 152 - B 69 - C 77 - D 107 - E 42 -
F 81 - G 202 - H 76 - I 106 - J 95 - K 53 -
L 157 - M
MASE 13 Node Cuernavaca Line
L
K
Data paths
A

• Network topology does not reflect the mostly
  linear physical topology
• Routing and other services can not use physical
  topology

B
A sink Direct inet connection
F
G
D
C
E
H
M
I
J
N
5
How challenged is the MASE network?

• Frequent unpredictable disconnections
• Rainy season sites flood (some 24x7), trees grow
• Wind misaligned antennas
• Equipment malfunction amps burn, voltage
  regulators break
• Poor and unstable links
• Connectivity secondary concern for site selection
• Stretched links highly susceptible to weather and
  environment
• Human effort is a critical resource
• Installation, maintenance, protection

6
Networking support needed for both data
acquisition and system management

• Data delivery Bandwidth driven
• Bandwidth 20-40 of MB per day per station
• Latency get the data eventually, but reliably
• Many to one routing
• System Management Latency driven
• Bandwidth usually less than 10s of KBs
• Latency as fast as possible
• One to all routing and back

7
Well-known limitations of existing techniques

• Data delivery and system management techniques
  designed for wired or always-on-wireless do not
  work well
• Typical tools use TCP to create and maintain an
  end to end session to deliver a stream of data
  over multiple hops
• These are online applications which expect
  reliable links with low latencies
• Patterns of poor links, disconnections, and
  disruptions
• Difficult to obtain and maintain end-to-end
  connections
• Intermittent end-to-end connections insufficient
  to achieve necessary bandwidth and latency

8
Our Contributions

• Real world application and deployment of Delay
  Tolerant Networking (DTN) techniques for data
  delivery
• Disruption Tolerant Shell (DTS) a tool for
  system management on challenged networks that
  performs better than traditional tools

9
Summary

• MASE A Challenged Network
• Poor and erratic links
• Frequent unpredictable disruptions
• Data Delivery
• System Management
• The Future

10
Data Delivery using DTN Techniques

• Buffer data into hour long bundles (1-3 MB)
• Deliberate one hop bundle transfer
• Path to sink determined by best ETX
• Improvement over end-to-end
• Not affected by path disconnections
• Keeps retrying on single link instead of full
  path
• Continual progress being made towards sink
• More efficient use of bandwidth in face of
  disconnections and bottlenecks

A
X
X
B
X
X
C
F
end-to-end
hop-by-hop
11
Upcoming Features

• Currently piggyback data movement log with actual
  data
• No global time stamping of log events
• Want coarse grained global time (one second)
• Will be able to recreate movie of file movement
  for entire network
• Can help spot network problems and bottlenecks
• Upload data to SensorBase.org
• Makes it easy to visualize and browse data
  collection status
• RSS feed can provide access to anyone who wants
  to monitor problems or generic status of network

12
Data Acknowledgement

• Nodes keep their own bundles until ACKed by sink
• Many ways of doing ACKs
• First try for ACK implementation worked
• Push bundle ID into StateSync (disseminates
  information to all the nodes in the network)
• But usage model not quite right too many
  entires, too much churn for StateSync (can
  explain better later)
• Second try
• Use file dissemination feature of DTS to
  distribute ACK list once a day
• Use DTS to remove list once we know all nodes
  have file

13
Summary

• MASE A Challenged Network
• Poor and erratic links
• Frequent unpredictable disruptions
• DTN Style Data Delivery
• Resilient to path disconnections
• Efficient use of bandwidth
• System Management
• The Future

14
System Management

• Existing management tool remote shell (ssh)
• Modified management tool Disruption Tolerant
  Shell
• Asynchronous remote shell to all nodes in network
  simultaneously
• Provides node management capabilities when
  end-to-end connections are unavailable or fail
• Ensures that commands will succeed as long as
  there is eventually a connection between a node
  and any other node that already has the command

df h ls /opt/dts/file_mover wc
A
E
B
C
D
F
Commands
Responses
15
Extra Fun Features of DTS

• Guaranteed in order execution from source node
• Reboot and crash safe
• Implicit feed back on nodes and links spot
  bottlenecks, dead nodes
• Execute a command on individual nodes
• Push a file to all nodes
• Distribute new script or component

16
Upcoming Features

• Web interface
• Command line interface is nice for me
• Takes a bit of getting used to
• Web interface more intuitive for asynchronous
  model
• Constant feeds of frequently executed commands
• Disk space, file counts, q330/gurlap status, link
  quality
• SensorBase.org
• Accountability log load all commands and
  responses and metadata for those
• DTS analysis and implicit network feedback just
  point and click

17
Reliable State Synchronization
A

• StateSync reliable and efficient
  publish-subscribe mechanism
• Implements a broadcast dissemination protocol
• Published data is scoped
• DTS publishes commands and responses one hop
• Works well for applications that require
• Reliable delivery
• Have a few Kbytes of data to share
• Data has lifetime that is long compared to system
  latency requirements
• Suitable for DTN since it does not use end-to-end
  connections

PUBLISH
Commands
Responses
SYNCHRONIZE
B
PUBLISH
Commands
Responses
SYNCHRONIZE
C
PUBLISH
Commands
Responses
18
DTS latency results

• Compare latency of DTS to parallel ssh
• DTS is faster 90 of the time, comparable to the
  rest
• DTS reaches 100 of nodes
• ssh requires retries from the source node
• Latency can vary by day, but DTS always faster or
  comparable to ssh

19
What makes DTS better than ssh?
A

• StateSync data model tables of key value pairs
• DTS has a command table and response table
• Each node republishes a command and response
  tables one hop
• Logging mechanism
• Do not republish whole table
• Only send changes to tables small amount of
  information
• More efficient use of bandwidth in face of
  disconnections
• Retransmission protocol
• Keeps retrying on individual links
• Not affected by path disconnections
• No overhead of creating and maintaining
  end-to-end connection

Cmd A-1
Resp A-1-A
Resp A-1-A
Cmd A-1
Resp A-1-B
Resp A-1-C
B
Resp A-1-A
Cmd A-1
Cmd A-1
Resp A-1-A
Resp A-1-B
Resp A-1-B
Resp A-1-C
Resp A-1-C
20
Future of StateSync

• StateSync allows data to be published N hops
• When publish N hops, not end to end but expect
  data path (the flow) to be maintained with
  refresh beacons
• If refreshes from source or node in flow stop,
  statesync will not propagate information
• Not idea for frequent disconnections
• DTS publishes data one hop
• Gets around problem by republishing another nodes
  data as its own
• Statesync only publishes one hop
• Tweaks
• Allow flows to be propagated even when no refresh
  from source or node along data path
• Tunable latency parameters
• Report metrics about itself
• DTS can then publish data N hops
• Lowers RAM usage, lowers number of packets

21
Site Installation

• Mexico Xyoli Pérez-Campos, Mario Islas Herrera,
  Oscar Martínez Susano, Jorge Soto, Aida Quezada
  Reyes, Arturo Iglesias, Lizbeth Espejo, Luis
  Antonio Placencia Gómez, Luis Edgar Rodriguez,
  Fernando Greene

USA Paul Davis, Allen Husker, Igor Stubailo,
Richard Guy, Sam Irving, Martin Lukac, Alma
Quezada, Steve Skinner, Irving Flores
22
Our Contributions

• Real world application and deployment of Delay
  Tolerant Networking (DTN) techniques for data
  delivery
• Disruption Tolerant Shell (DTS) a tool for
  system management on challenged networks that
  performs better than traditional tools

23
Summary

• MASE A Challenged Network
• Poor and erratic links
• Frequent unpredictable disruptions
• DTN Style Data Delivery
• Resilient to path disconnections
• Efficient use of bandwidth
• System Management
• DTS viable tool for system management for
  challenged networks
• The Future

24
Whats Next?

• Have a tool that works
• Understand conceptually why it works better
• We have a high level analysis per link bandwidth
• Network is being pulled out in Feburary

25
Work in Progress

• Need better network characterization
• Long-Distance 802.11b Links Performance
  Measurements and Experience, K. Chebrolu, B.
  Raman, S. Sen ITT Kanpur, Mobicom 2006
• Use their driver to collect per packet received
  signal strength, silence value, MAC packet type
  subtype, CRC check succeeded or not, MAC address
  information, MAC sequence number information
• Is our network different then theirs? Antennas,
  chipsets are the same. Our network is not always
  way up high and do not have good link quality
  all the time.
• Coordinated IP level dumps on entire network
• Cant stop data flow
• Synchronize dumps between nodes
• Coordinate with driver information
• How do the long links affect the transfers?
• Huge hidden terminal problem, does rts/cts seem
  to help?

Vinayak analyzed received signal strength (RSS)
for a single source-destination pair in the UNAM
line. Max RSS -46dBm (83 of data) Min RSS
-81dBm (10 of data) Difference of 35dB Max/Min
for IIT-Kanpur's -70dBm / -90dBm Difference of
20dB Next do this on Cuernavaca line. Maybe it
will have higher variation than that of
UNAM. High variation might be from inter-link
interference since RTS-CTS is off See what
RTS-CTS does. If still high link variation, then
Mexico network is intrinsically different
from that in India. May be our network is in
between Boston's urban Roofnet and Kanpur's rural
network?
26
New Applications

• DTS and DTN ideas/techniques can (must?) be
  applied to two new CENS applications
• GeoNet
• SHM (Structure Health Monitoring)

27
GeoNet Rapidly Deployable Challenged Network

• Platform to support high data rate rapidly
  deployed large-scale WSN
• Deploy 100-1000 nodes after event at a
  separation of 0.5-1Km
• Software tools for rapid deployment
• Must make real time decision about sensor
  location vs. network connectivity tradeoff
• Need as much feedback from network as possible
• Power efficient platform such as LEAP needs
  appropriate software architecture.
• Network time synchronization when no GPS
  available
• Data deliver system management
• Take advantage of dual radios?

28
SHM

• SHM framework to improve safety and reliability
  of aerospace, civil and mechanical infrastructure
  by detecting damage before it reaches a critical
  state
• Initially targeting tall buildings
• Still a challenged network
• Building structure (walls, ceilings), people,
  other networks, stuff

29
Thank you!

• mlukac_at_cs.ucla.edu

Demo!
Thanks to Igor and Derek for all the pictures and
diagrams!
Teotihuacan, 2006
30
MASE Wireless Seismic Station
15 dBi YAGI or 24 dBi Parabolic 2.4GHz
antenna 70 watt solar panel, GPS mast and guy
wires Quanterra Q330 24-bit digitizer sensor
controller 2.4GHz amp car battery CDCC (CENS
Data Communication Controller) Guralp 3T
seismometer
31
Following slides prepared by Roy Clayton
(CalTech) and Igor Stubailo (UCLA CENS)
Science!
32
The Middle America Subduction Experiment (MASE).
Why Mexico? Slab detachment theory.

• A subduction zone is an area on Earth where two
  tectonic plates meet and move towards one
  another, with one sliding underneath the other
  and moving down into the mantle, at a speed of
  several inches per year.
• Typically, an oceanic plate slides underneath a
  continental plate, and this often creates a zone
  with many volcanoes and earthquakes.

B
Ferrari, 2004, Geology
33
Similarities of Mexico City and Los Angeles
locations

• LA and Mexico City are major centers of commerce
  which sit upon compliant sedimentary basins.
• Both are subject to damaging earthquakes and how
  earthquakes excite resonant shaking

34
Great potential of high station density

• Achieve 20 times better resolution than before.
• Provide visualization of the upper mantle and the
  subduction process, coast to coast across Mexico.
• The data collected is very valuable to scientists
  in seismology, geodesy, geochemistry, geology,
  computational geodynamics, geophysics, and others

35
Russian Event (Kamchatka) April 20, 2006, M7.7
36
First results detect flat slab with receiver
functions
Rob Clayton, Caltech, 2006
37
Related Work

• P. Levis, N. Patel, D. E. Culler, and S.
  Shenker.Trickle A self-regulating algorithm for
  code propagation and maintenance in wireless
  sensor networks. NSDI 2004
• Whitehouse, C. Sharp, E. Brewer, and D. Culler.
  Hood a neighborhood abstraction for sensor
  networks. MobiSYS '04
• A. Vahdat, D. Becker. Epidemic Routing for
  Partially-Connected Ad Hoc Networks. Duke
  Technical Report CS-2000-06
• K. Fall. A Delay-Tolerant Network Architecture
  for Challenged Internets. SIGCOMM 2003
• DTNRG (http//www.dtnrg.org)

38
Related Work

• Sensor network epidemic dissemination and state
  synchronization
• P. Levis, N. Patel, D. E. Culler, and S.
  Shenker.Trickle A self-regulating algorithm for
  code propagation and maintenance in wireless
  sensor networks. NSDI 2004
• Whitehouse, C. Sharp, E. Brewer, and D. Culler.
  Hood a neighborhood abstraction for sensor
  networks. MobiSYS '04
• Lots of ideas from all the DTN work
• K. Fall. A Delay-Tolerant Network Architecture
  for Challenged Internets. SIGCOMM 2003
• DTNRG (http//www.dtnrg.org)
