pH Responsive Polymer Thin Films

1
pH Responsive Polymer Thin Films
Dan Regan
2
Outline

• Background
• Surface chemistry
• Covalent immobilization
• Photoactive linker
• Procedure
• Piranha cleaning
• Silanization
• Immobilization
• Protonation

• Analysis
• Ellipsometry
• Contact angle measurements
• Atomic Force Microscopy
• Results
• Thickness vs. Molar ratio
• Swelling
• Hydrophilicity
• Reversibility
• Conclusion

3
Miniaturization - Surface Matters!
Increased surface/volume ratio

• Surface property
• Compatibility with reagents
• Reaction yield
• Fluid flow

Smart surface - surface that provides functions
surface energy gradient
molecular recognition
biocompatibility
4
Covalent Immobilization of Polymer Thin Films
5
Immobilization
6
Piranha cleaning

• 73 ratio by volume of H2SO4 to H2O2
• 80o to 90oC for 1.5 hours
• Hot water bath (80o to 90oC) for 1 hour

7
Silanization

• PFPA-silane PTMS

• Prepare solutions at different molar ratios of
  PFPAPTMS
• 10, 110, 130, 170, 1100, 1500
• Relation between number of attachment points and
  degree of swelling observed
• Soak samples for 4 hours

8
Spin coating

• 3 or 4 droplets of P4VP in n-butanol per wafer
• Spin coat
• 2000 rpm
• 60 sec

9
UV irradiation and Solvent extraction

• Place 280nm optical filter over sample
• Irradiate 5 minutes
• Sonicate in
• n-butanol 5 minutes
• Extracts unattached polymer

10
Protonation

• Prepare dilute solution of HCl
• pH 2
• Soak sample 10 minutes

11
Ellipsometry

• Ellipsometer used to measure thickness of

12

• Molar ratio refers to PTMSPFPA-silane

13

• The lower the surface density of PFPA-silane, the
  thinner the film

14

• Covalent immobilization allows film to withstand
  fairly strong acidic conditions (pH 2)

15

• Immobilized polymer films swell at pH 2
• The amount of swelling is independent of the
  surface density of the azide

16
AFM topography image of immobilized film (at
molar ratio 1500) before and after protonation

• Scale 500nm x 500nm
• Surface structure changed after protonation

17
Reversibility

• The protonation process is reversible

18
Contact angle measurements

• Use syringe to place a drop of water on the
  surface
• 2 microliters
• Measure contact angle using contact angle viewer

19

• Films become hydrophilic after protonation

20
Conclusion

• Covalently immobilized P4VP exhibits a pH
  responsive behavior that is reproducible
• Swelling
• Hydrophilicity
• Reversibility
• Future work
• Investigate why the molar ratio of 10 does not
  fit the trend for thickness
• Investigate salt effects on immobilized thin films

21
Protonation with Phosphate Buffer (pH 2)

• Salt on surface made ellipsometry difficult
• When surface was rinsed, apparent that film
  thickness decreased

22
Acknowledgements

• Thanks to
• Dr. Mingdi Yan
• Dr. Li Liu
• Yan Lab John Gann
• Sailaja Chada
• Suji Uppalapati
• Kai Wang
• Melissa Taylor
• Aye Hlaing
• Dr. Raymond Bard

23
Perfluorophenyl Azides (PFPAs)
24
Surface Modification Chemistry
Silica-based substrates
Metallic substrates
