Title: David Sanders MD, MSc, FRCSC


1
Fractures of the Talus and Subtalar Dislocations
  • David Sanders MD, MSc, FRCSC
  • London Health Sciences Centre
  • University of Western Ontario
  • London, Ontario, Canada
  • Created March 2004 Revised August 2006

2
Outline
  • Talar Neck Fractures
  • Anatomy
  • Incidence
  • Imaging
  • Classification
  • Management
  • Complications
  • Talar body, head and process fractures
  • Subtalar dislocations
  • Classification
  • Management
  • Outcomes

3
Anatomy
  • Surface 60 cartilage
  • No muscular insertions

4
Blood Supply
  • Arterial supply
  • Artery of tarsal canal
  • Artery of tarsal sinus
  • Dorsal neck vessels
  • Deltoid branches

medial
lateral
Inferior view of talus, showing vascular
anastomosis
5
Vascularity
  • Artery of tarsal canal supplies majority of talar
    body

Side View
Top View
Deltoid Branches
Superior Neck Vessels
Artery of Tarsal Canal
Posterior tubercle vessels
Artery of Tarsal Canal
Superior Neck Vessels
Posterior tubercle vessels
Artery of Tarsal Sinus
Artery of Tarsal Sinus
6
Incidence
  • 2 of all fractures
  • 6-8 of foot fractures
  • Importance due to high complication rates
  • avascular necrosis
  • post-traumatic arthritis
  • malunion

7
Mechanism of Injury
  • Hyperdorsiflexion of the foot on the leg
  • Neck of talus impinges against anterior distal
    tibia, causing neck fracture
  • If force continues
  • talar body dislocates posteromedial
  • often around deltoid ligament

8
Injury Mechanism
  • Previously called aviators astragalus
  • Usually due to motor vehicle accident or falls
    from height
  • Approximately 50 have multiple traumatic
    injuries

9
Biomechanics
  • Theoretical shear force across talar neck
  • 1200 N during active motion
  • Swanson 1992

10
Imaging
  • Complex 3-D structure
  • Multiple plain film orientations

Canale View
11
Canale View
  • Ankle plantarflexion
  • 15 degree pronation
  • Tube 15 degree off vertical

Canale View
12
CT Scan
  • Can be a useful assessment tool
  • Confirms truly undisplaced fractures
  • Demonstrates subtalar comminution, osteochondral
    fractures

13
MRI Scan
  • Primary role in talus injuries is to assess
    complications, especially avascular necrosis
  • May be poor quality if extensive hardware present

Zone of osteonecrosis following distribution of
Artery of Tarsal Canal
14
Talar Neck Fractures Classification
  • Hawkins 1970
  • Predictive of AVN rate
  • Widely used

15
Hawkins 1
  • I undisplaced
  • AVN 0 13

16
Hawkins 2
  • Displaced fracture
  • Subtalar subluxation
  • A) fracture line enters subtalar joint
  • B) subtalar joint intact
  • AVN 20 50

17
Hawkins 3
  • Subtalar and ankle joint dislocated
  • Talar body extrudes around deltoid ligament
  • AVN 83 100

18
Hawkins 4
  • Incorporates talonavicular subluxation
  • Rare variant
  • Complex talar neck fractures which do not fit
    classification can be included

19
Classification
  • Comminution
  • An important additional predictor of results,
    especially regarding
  • Malunion
  • Subtalar joint arthritis

20
Goals of Management
  • Immediate reduction of dislocated joints
  • Anatomic fracture reduction
  • Stable fixation
  • Facilitate union
  • Avoid complications

21
Treatment of Talar Neck Fractures
  • Emergent reduction of dislocated joints
  • Stable internal fixation
  • Choice of fixation and approach depends upon
    personality of fracture

22
Treatment of Talar Neck Fractures
  • Post operative rehabilitation
  • Sample protocol
  • Initial immobilization, 2-6 weeks depending upon
    soft tissue injury and patient factors, to
    prevent contractures and facilitate healing
  • Non weight-bearing, Range of Motion therapy until
    3 months or fracture union

23
Hawkins I Fracture
  • Options
  • Non-Weight-Bearing Cast for 4-6 weeks followed by
    removable brace and motion
  • Percutaneous screw fixation and early motion

24
Hawkins II, III, and IV Fractures
  • Results dependent upon development of
    complications
  • Osteonecrosis
  • Malunion
  • Arthritis

25
Case Example
  • 29 yo male
  • ATV rollover
  • Isolated injury LLE

26
(No Transcript)
27
Diagnosis
  • Hawkins 3 talar neck fracture
  • Associated comminution, probably involving medial
    column and subtalar joint

28
Controversies for this Case
????
  • Surgical timing
  • Closed reduction
  • Surgical approach
  • Fixation

29
Surgical Timing
  • Emergent reduction of dislocated joints
  • Allow life threatening injuries to take priority
    and resuscitate adequately first

30
Closed Reduction?
  • May be very useful, particularly if other life
    threatening injuries preclude definitive surgery
  • Difficult in Hawkins 3 and 4 injuries

31
Closed Reduction Technique
  • Adequate sedation
  • Flex knee to relax gastrocs
  • Traction on plantar flexed forefoot to realign
    head with body
  • Varus/valgus correction as necessary

32
Closed Reduction Example
33
External Fixation
  • Limited roles
  • Multiply injured patient with talar neck fracture
    in whom definitive surgery will be delayed
  • Temporizing measure to stabilize reduced joints

34
Surgical Approaches Options
  • 1 incision techniques
  • Anteromedial or
  • Anterolateral
  • Problem difficult to visualize talar neck and
    subtalar joint without significant soft tissue
    stripping
  • Benefit potentially less skin injury

35
Surgical Approaches Options
  • 2 incision technique
  • Anteromedial and direct lateral
  • Problem 2 skin incisions, close together
  • Benefit excellent fracture visualization at
    critical sites of reduction and subtalar joint

36
1st Approach Anteromedial
  • Medial to TA and Anterior Compartment contents
  • Make incision more posterior for talar body
    fractures to facilitate medial malleolar
    osteotomy

37
1st Approach Anteromedial
  • Provides view of neck alignment and medial
    comminution

38
2nd Approach Direct Lateral
  • Tip of Fibula directly anterior
  • Mobilize EDB as sleeve
  • Protect sinus tarsi contents

39
2nd Approach Direct Lateral
  • Visualizes Anterolateral alignment and subtalar
    joint
  • Facilitates Placement of Shoulder Screw

40
Protect the Skin Post Op
41
Fixation Options
  • Stable Fixation to allow early motion is the goal
  • 1200 N stress across talar neck during early
    motion
  • (Swanson JBJS 1992)

42
Surgical Tactics Fixation
  • Anterior
  • Partial threaded screws
  • Fully threaded screws
  • Mini-fragment plates
  • Posterior
  • Lag screws

Implant selection depends upon injury, degree of
comminution, bone quality
But should be strong enough to withstand motion
43
Posterior to Anterior Fixation
  • stronger than anterior to posterior fixation with
    2 screws
  • Able to withstand the theoretical shear force of
    active motion (Swanson, JBJS 1992)
  • Screws perpendicular to fracture site

44
Anterior Screw Fixation
  • Non-comminuted fractures
  • Easy to insert under direct visualization and no
    cartilage damage
  • Displaced type 2 3 A-P screws including medial
    buttress fully threaded cortical screws and
    lateral shoulder screws

45
Anterior Screw Fixation
  • Comminuted fractures
  • Buttress screw comminuted column compression
    screws through non-comminuted column
  • Mini-fragment screws for osteochondral fragments
  • Consider Titanium for MRI

46
Anterior Plate Fixation
  • Comminuted fractures
  • Medial and / or lateral mini-fragment plates

47
Complications
  • AVN
  • Malunion
  • Nonunion
  • Arthritis

48
AVN Incidence after Talus Fracture
  • Canale (1972)
  • I 15
  • II 50
  • III 85
  • IV 100
  • Behrens (1988)
  • Overall 25
  • Ebraheim/Stephen (2001)
  • Overall 20

49
AVN Diagnosis
  • Hawkins Sign Xray finding 6-8 weeks post
    injury
  • Presence of subchondral lucency implies
    revascularization

50
AVN Imaging
  • Plain radiographs sclerosis common, decreases
    with revascularization
  • MRI very sensitive to decreased vascularity

51
AVN Treatment
  • Precollapse
  • Modified WB
  • PTB cast
  • Compliance difficult
  • Efficacy unknown
  • Postcollapse
  • Observation
  • Blair fusion if symptomatic

52
Malunion Incidence
  • Common up to 40
  • Most often Varus

53
Malunion Diagnosis
  • Varus hindfoot, midfoot supination on clinical
    exam
  • Dorsal malunion on Xray

54
Malunion
  • Mechanical effects known
  • gt 3 degrees decreased ROM
  • (Daniels TR, JBJS 1996)
  • gt 2mm altered subtalar contact forces
    (Sangeorzan
  • J Orthop Res 1992)

55
Clinical Effect of Malunion
  • Malunion
  • More pain
  • Less satisfaction
  • Less ankle motion
  • Worse functional outcome

56
Malunion Rx
  • Calcaneus osteotomy
  • Possible midfoot osteotomy
  • Tendo Achilles Lengthening

57
Post Traumatic Arthritis
  • Incidence of post-traumatic arthritis
  • 30-90

58
Post-Traumatic Arthritis
  • Most commonly involves Subtalar joint
  • Rx Arthrodesis

59
Nonunion
  • Uncommon, even with AVN
  • Delayed Union very common
  • Frequently results in late malalignment

60
Talar Body Fractures
  • Treatment strategy and outcomes similar to talar
    neck fractures
  • Medial or Lateral Malleolar Osteotomy frequently
    required

61
Medial Malleolar Osteotomy
  • Predrill and pretap malleolus
  • Osteotomy aims for medial corner of mortise
  • Osteotome to crack cartilage helps avoid mortise
    malalignment

62
Talar Body Fibula Fracture
  • Visualize body through the fibula fracture

63
Talar Body Case Example
  • 58 year old female
  • 4 week old fracture
  • Missed initially

64
Case, contd
  • Extensive comminution into subtalar joint
  • Fragments very small

65
Selected Rx Primary Arthrodesis
Tricortical bone graft to reconstitute talar
height
66
Osteochondral Injuries
  • Frequently encountered with talus neck and body
    fractures
  • Require small implants for fixation
  • Excise if unstable and too small to fix

67
Osteochondral Injuries
68
Osteochondral Fragment Repair
Large fragment repaired, small fragment excised
69
Talar Head and Process Fractures
  • Treat according to injury
  • Operate when associated with joint subluxation,
    incongruity, impingement or marked displacement
  • Fragments often too small to fix and require
    excision

70
Case Example Talar Head Fracture
  • Talar head injury
  • Subtle on plain x-ray

71
Talar Head Fracture, continued
  • CT demonstrates subtalar injury and subluxation

72
Treatment of Talar Head Fracture
  • Required 2 incisions to debride subtalar joint
    from lateral approach, and reduce / stabilize
    fracture from medial side

73
Lateral Process Example
  • Usually require CT scan
  • Often excised due to size of fragments
  • Difficult to achieve union

74
Lateral Talar Process Fractures
  • Snowboarders fracture
  • Mechanism may occur from inversion (avulsion
    injury) or eversion and axial loading (impaction
    fracture)
  • Often misdiagnosed as ankle sprain
  • Best results if treated early, either by
    immobilization, ORIF or fragment excision
  • If diagnosed late consider fragment excision as
    attempts to achieve union often fail

75
Posterior Talar Process Fracture
  • 2 components medial and lateral tubercle
  • Groove for FHL tendon separates the two tubercles
  • Differentiate fracture from os trigonum well
    corticated, smooth oval or round structure

76
Posterior Talar Process Fractures
  • Medial tubercle fracture Cedells fracture
  • Lateral tubercle Shepherds fracture
  • Treatment immobilize or excise

77
Subtalar Dislocations
  • Spectrum of injuries
  • Relatively Innocent
  • Very Disabling

78
Classification
  • Usually based upon direction of dislocation
  • Medial dislocation 85 , low energy
  • Lateral dislocation 15 , high energy

79
Other Important Considerations
All have prognostic significance
  • Open vs Closed
  • High or low energy mechanism
  • Stable or unstable post reduction
  • Reducible by closed means or requiring open
    reduction
  • Associated impaction injuries

80
Important Distinction
  • Total talar dislocation, or pan talar dislocation
  • Results from continuation of force causing
    subtalar dislocation
  • High risk of AVN, usually open, poor prognosis

Open pantalar dislocation with skin loss showing
Imperfect reduction Result was AVN and
pantalar fusion
81
Management of Subtalar Dislocation
  • Urgent Closed reduction
  • Adequate sedation
  • Knee flexion
  • Longitudinal foot traction
  • Accentuate, then reverse deformity
  • Successful in up to 90 of patients

82
Open Reduction
  • More likely after high energy injury
  • More likely with lateral dislocation
  • Cause
  • soft tissue interposition (Tib post, FHL,
    extensor tendons, capsule)
  • bony impaction between the talus and navicular

83
Rehabilitation
  • Stable injuries
  • 4 weeks immobilization
  • Physio for mobilization
  • Unstable injuries
  • Usually dont require internal fixation once
    reduction achieved

84
Outcome of Subtalar Dislocations
  • Less benign than previously thought
  • Subtalar arthritis
  • Up to 89 radiographically
  • Symptomatic in up to 63
  • Ankle and midfoot arthritis less common

85
Summary
  • Talar Neck Fractures
  • Anatomy
  • Incidence
  • Imaging
  • Classification
  • Management
  • Complications
  • Talar body, head and process fractures
  • Subtalar dislocations
  • Classification
  • Management
  • Outcomes

If you would like to volunteer as an author for
the Resident Slide Project or recommend updates
to any of the following slides, please send an
e-mail to ota_at_aaos.org
Return to Lower Extremity Index
E-mail OTA about Questions/Comments
Write a Comment
User Comments (0)
About PowerShow.com
