Title: inter-domain routing, ipv6, and network visualization


1
inter-domain routing, ipv6, and network
visualization
  • giuseppe di battista
  • maurizio patrignani

2
main research topics
  • interdomain routing
  • analysis of the route changes for the incoming
    traffic flows
  • location of the internet routing instabilities
  • modeling of bgp configurations and analysis of
    their stability
  • inference of the customer-provider relationships
  • study of the routing (a)symmetries
  • engineering of the incoming traffic flows
  • discovery of a large(r) as graph
  • integration and visualization of the irr info
  • intradomain routing
  • ospf visualization
  • layer-3 discovery techniques
  • ipv6
  • support for the ipv4-ipv6 transition
  • multi-homing methods
  • network emulation
  • cheap and easy-to-configure test-beds for complex
    networks

3
analysis of the route changes for the incoming
traffic flows
  • development of a web service, called bgplay,
    visualizing the route changes of a prefix in a
    specific time window
  • two running servers at
  • routing information service of the ripe ncc
    (www.ris.ripe.net/bgplay/)
  • route views project of the oregon university
    (www.routeviews.org)
  • each based on the corresponding repository of bgp
    updates
  • an alpha version at roma III university with the
    most recent features

4
bgplay query form
5
(No Transcript)
6
bgplay demo
7
location of the internet routing instabilities
  • monitoring of the network from several vantage
    points
  • each vantage point stores the bgp updates that
    are visible from its location
  • related updates are grouped into events
  • the causes of each event are (if possible)
    identified by studying the evolution of the
    routing over time

8
modeling of bgp configurations and analysis of
their stability
  • study of formal models for the description of bgp
    configurations and behaviors
  • study of the effect of different time sequences
    of the events
  • identification of possible routing instabilities
  • routing stability vs forwarding stability
  • stability of the entire routing information base
    vs stability of the best choice

9
inference of the customer-provider relationships
  • a simple model accounting for customer-provider
    and peer-to-peer relationships only
  • infer the types of relationship between
    autonomous systems by observing the as-paths
    associated with announcements
  • if sensible rules of thumb are followed by
    network operators, each as-path is valley free
  • if rules of thumb are followed by network
    operators, relationships can be efficiently
    inferred

10
inference of the customer-provider relationships
  • if a set of relationships making all as-paths
    valley free does not exist
  • we prove that maximizing the number of valley
    free as-paths is a hard problem
  • we propose heuristics for this problem that
    outperform cutting-edge techniques described in
    literature

11
study of the routing (a)symmetries
  • netviewer web service
  • prototype at www.dia.uniroma3.it/compunet/
  • having at disposal internal and external info
    shows routing asymmetries
  • group prefixes into classes that have the same
    routing
  • in cooperation with caspur and garr

12
example of routing classes
198.150.84.0 198.150.85.0 198.150.87.0
198.150.2.0 198.150.22.0 198.150.38.0
198.150.4.0 198.150.5.0 198.150.6.0
198.150.7.0 198.150.9.0
1st July 2003
13
example of asymmetric routing
1st July 2003
14
engineering of the incoming traffic flows
  • even a limited control of the announcements
    propagation could be used to
  • balance traffic from the upstream providers
  • prefer reliable incoming paths
  • improve internal traffic flows
  • engineering incoming traffic via prepending
  • Integer Linear Programming formulation
  • computational geometry perspective

15
discovery of a large(r) AS graph
  • starting from the bgp updates collected by the
    ris or orv repositories a big picture of the
    internet can be obtained
  • this picture can be enlarged by observing
    unusual bgp traffic
  • bgp updates with peculiar timings
  • bgp updates with peculiar content
  • we can gain extra info by
  • observing unusual bgp updates
  • probing the network with unusual bgp updates
  • for example setting up suitable beacons and
    observing echoes
  • in cooperation with namex

16
integration and visualization of the irr info
  • hermes service
  • available at www.dia.uniroma3.it/hermes/
  • handles a local relational database of routing
    information
  • downloads rpsl information from more than 50
    databases that are individually operated by
    organizations such as verio, cable wireless,
    merit, ripe ncc, apnic, arin, sprint, etc.
  • through a java applet it is possible to navigate
    the repository and obtain information about the
    rpsl objects

17
integration and visualization of the irr info
18
integration and visualization of the irr info
19
integration and visualization of the irr info
20
integration and visualization of the irr info
21
integration and visualization of the irr info
22
integration and visualization of the irr info
23
ospf visualization
  • polyphemous tool
  • downloadable from www.dia.uniroma3.it/polyph/
  • collects routing information using snmp and mibs
  • explores an ospf network at different levels of
    abstraction
  • shows ospf areas an area border routers
  • shows routers and links inside each area
  • provides detailed info about areas, routers,
    interfaces.
  • in cooperation with caspur

24
ospf visualization
25
layer-3 discovery techniques
  • nethunter service
  • available at www.dia.uniroma3.it/nethunt/
  • exploits a collection of traceroute servers
  • explores the surroundings of an ip interface or
    network by performing traceroutes from different
    vantage points
  • uses a logic engine for inferring topologies
  • guess and check approach to asses whether two
    interfaces belong to the same router

26
support for the ipv4-ipv6 transition
  • techniques to detect, and collect information
    about, ipv6-in-ipv4 tunnels (mtu-discovery, dns,
    ip spoofing,)
  • discovered tunnels can be used as vantage
    points to launch third-party tunnel-discovery
    explorations, scaling up the discovery process
  • wide experimentation
  • 6bone tunneled network, garr network, wide
    network, ripe ncc network and ttm test-boxes
  • we assess to what extent 6bone registry
    information is coherent with the actual network
    topology
  • we provide the first experimental results on the
    current distribution of ipv6-in-ipv4 tunnels in
    the Internet
  • in cooperation with garr and ripe ncc

27
multi-homing methods
  • hosts in a multi-homed as receive an ipv6 address
    from each upstream provider
  • how to handle multiple ipv6 addresses?
  • need to take into account traffic loads
  • need to propagate information from the border
    routers to the internal networks
  • need to swap ipv6 addresses without dropping tcp
    connections

28
cheap and easy-to-configure test-beds for complex
networks
  • netkit (network emulator)
  • available at www.netkit.org
  • a linux kernel may run as a user process (user
    mode linux)
  • a network of linux virtual machines may run on a
    single host
  • each linux may be configured to run routing
    daemons (zebra, bird, gated, routed, xorp,
    quagga,)
  • new configurations may be tested before being
    deployed
  • in cooperation with garr

29
concluding remarks
  • a mixed theoretical-technical approach in all
    topics
  • tight relationships with network operators
  • caspur, garr, namex, orv, ripe,
  • research-teaching coupling
  • univ. courses on comp. networks and courses on
    specific technologies for companies and pa

30
thank you!
questions?
