Title: Heart and Neck Vessels


1
Heart and Neck Vessels
  • Week 8

2
Introduction
  • Heart normally pumps between 4 6 L of
    blood/minute cardiac output (CO)
  • CO SV X R e.g. 5.6 L 70 mL X 80 bpm
  • Heart can alter CO to adapt to metabolic needs of
    body
  • Preload afterload affect hearts ability to ?
    CO.

3
Circulation
Figure 17-1. p. 498.
4
The Precordium
5
Internal Anatomy of the Heart
6
Direction of Blood Flow (19-5)
7
Internal Position/Surface Landmarks of the Heart
8
Preload Afterload
  • Preload is a function of
  • Volume of venous return
  • Length to which ventricular muscle is stretched
    at end of diastole
  • Starlings Law gt the stretch gt contraction
  • Heart muscle contractility
  • Afterload is a function of
  • Opposing pressure ventricle must generate to open
    aortic valve against higher intraaortic pressure
  • Resistance from PVS that ventricle must pump
    against.

9
Preload and Afterload
10
Cardiac Cycle
  • Blood fills ventricles - pressure ?
  • Atria contract - AV valves slam shut
  • Ventricle contracts bl. forced into PA aorta
  • Pressure ? in those vessels SL valves shut
  • All 4 valves are closed ventricles relax,
    meanwhile atria have been filling with bl.
  • Atrial pressure becomes gt than ventricular AV
    valves open
  • Blood fills ventricles pressure ? ...

11
The Cardiac Cycle During Diastole and Systole
  • http//www.coursewareobjects.com/objects/hao/anim/
    13-001ap.htm

12
The Cardiac Cycle
13
Events of the Cardiac Cycle
  • http//www.coursewareobjects.com/objects/hao/anim/
    13-002ap.htm

14
Heart Sounds
  • S1 caused by closure of AV valves loudest at
    apex
  • S2 caused by closure of SL valves loudest at
    base
  • S3 caused by ventricular vibrations during
    early diastole due to resistant ventricles
    occurs immediately after S2
  • S4 caused by ventricular vibrations at end of
    diastole due to noncompliant ventricles occurs
    just before S1.

15
Heart Sounds
16
Murmurs
  • Turbulent blood flow result in gentle blowing,
    swooshing sound
  • Causes
  • Velocity of blood increases
  • Viscosity of blood decreases anemia
  • Structural defects
  • Characteristics of Sound
  • Frequency, intensity, duration, timing.

17
Conduction
  • Automaticity - SA node
  • SA node ? R L atria ? AV node ? Bundle of His ?
    R L bundle branches ? Purkinje fibres ?
    ventricles
  • ECG Waves
  • P wave atrial depolarization
  • PR interval
  • QRS complex ventricular depolarization
  • T wave ventricular repolarization.

18
Cardiac Electrical Activity
  • http//www.coursewareobjects.com/objects/hao/anim/
    13-005ap.htm

19
Conduction System of the Heart
20
Aging Changes
  • Systolic BP ?
  • L ventricle wall thickness ?
  • ? in pulse pressure as systolic BP ?
  • No change in resting HR
  • Cardiac output at rest is not changed
  • ? ability of heart to alter CO on demand
  • ? in arrhythmias ectopic beats more common
  • Tachycardic rhythms less tolerated
  • Incidence of cardiovascular disease ?.

21
Subjective Data Collection
  • Chest pain
  • Dyspnea
  • Orthopnea
  • Cough
  • Fatigue
  • Cyanosis or pallor
  • Edema
  • Nocturia
  • Past cardiac history
  • Family cardiac history
  • Personal habits (cardiac risk factors)
  • Medications.

22
Objective Exam
  • Start with general survey - general physical
    appearance skin colour, body structure,
    mobility (position, posture gait), behaviour
    (distress, pain)
  • Take pulse and BP
  • Start from periphery move towards heart
  • Perform PVS assessment starting with arms (will
    take next)
  • Assess neck vessels
  • Assess precordium.

23
Neck Vessels Exam
  • GENTLY palpate carotid artery on both sides
  • Auscultate carotid artery on both sides
  • Inspect jugular veins for distention
  • Position person supine at 30 to 45 degree angle
  • Remove pillow to avoid neck flexion, turn head
    slightly away, direct strong light towards side
    of neck to highlight pulsations
  • Note external jugular veins overlying the
    sternomastoid muscle pulsations should flatten
    disappear at about 45o angle
  • Note pulsation of internal jugular at sternal
    notch.

24
Blood Vessels of the Neck (19-10)
25
Precordium
  • Inspect precordium, inspect apical impulse
  • Palpate apical impulse
  • Palpate across precordium for unusual pulsations,
    thrills, vibrations
  • Auscultate.

26
Taking a Carotid Pulse
27
Palpate Apical Impulse
28
Point of Maximal Impulse (PMI)
  • http//www.coursewareobjects.com/objects/hao/anim/
    13-006ap.htm

29
Auscultation of Heart
  • Auscultate in Z pattern including
  • Aortic valve area 2nd R intercostal space
  • Pulmonic valve area 2nd L intercostal space
  • Tricuspid valve area L lower sternal border 5th
    intercostal space
  • Mitral valve area L midclavicular line, 5th
    intercostal space
  • Listen to S1 and S2 at all locations, one sound
    at a time.

30
Aucultatory Areas
31
Cardiac Ausculatory Landmarks
  • http//www.coursewareobjects.com/objects/hao/video
    /13-0041vp.htm

32
Auscultation of Heart Valves
  • http//www.coursewareobjects.com/objects/hao/anim/
    13-009ap.htm

33
Cardiac Auscultation with Diaphragm and Bell
http//www.coursewareobjects.com/objects/hao/video
/13-0061vp.htm http//www.coursewareobjects.com/o
bjects/hao/video/13-0071vp.htm
34
On Auscultation
  • Note rate and rhythm any pulse deficit
  • Identify S1 and S2
  • Assess S1 and S2 separately
  • S1 louder at Apex
  • S2 louder at Base
  • Listen for extra heart sounds S3 or S4
  • Listen for murmurs.

35
The Third Fourth Heart Sounds (Abnormal S3 S4)
  • http//www.coursewareobjects.com/objects/hao/audio
    /13-005sp.htm
  • http//www.coursewareobjects.com/objects/hao/audio
    /13-007sp.htm

36
Stenotic and Regurgitant Valvular Defects
  • http//www.coursewareobjects.com/objects/hao/anim/
    13-010ap.htm
  • http//www.coursewareobjects.com/objects/hao/anim/
    13-011ap.htm

37
Blood Work Associated with Heart Function
Oxygenation
  • Hb or Hgb
  • female 120 160 g/L
  • male 140 180 g/L
  • Hct
  • female 0.36 0.46
  • male 0.37 0.49
  • RBC
  • female 3.8 4.8
  • male 4.2 5.4
  • pH 7.35 7.45
  • pO2 75 100
  • pCO2 35 45
  • SaO2 96 100
  • Cl 100 106 mmol/L
  • Na 135 145 mmol/L
  • K 3.5 5.0 mmol/L.

38
Dev. Considerations - Aging
  • Rise in systolic BP
  • Widening of pulse pressure
  • Increase in orthostatic hypotension
  • Care when palpating carotid artery
  • More difficult to palpate apical pulse
  • S4 more common without disease
  • Systolic murmurs common
  • Occasional premature beats common.

39
Clinical Portrait of Congestive Heart Failure
