Earth System Modeling Infrastructure

1
Earth System Modeling Infrastructure
Cecelia DeLuca/ESMF-NCAR March 31-April 1,
2009 CHyMP Meeting
2
Outline

• Elements of interoperability platforms
• Integrating across elements
• Summary

3
Elements of interoperability platforms

• Tight coupling tools and interfaces
• - hierarchical and peer component relationships
• - frequent, high volume transfers on high
  performance computers
• Loose coupling tools and interfaces- generally
  peer-peer component relationships- lower volume
  and infrequent transfers on desktop and
  distributed systems
• Science gateways- browse, search, and
  distribution of model components, models, and
  datasets- visualization and analysis services-
  workspaces and management tools for
  collaboration
• Metadata conventions and ontologies- ideally,
  with automated production of metadata from models
• Governance- coordinated and controlled
  evolution of systems

4
Tight coupling tools and interfaces

• Examples
• Earth System Modeling Framework (ESMF) - NASA,
  NOAA, Department of Defense, community weather
  and climate models, U.S. operational numerical
  weather prediction centers (HPC focus)
• http//www.esmf.ucar.edu
• Flexible Modeling System (FMS) NOAA precursor
  to ESMF, still used at the Geophysical Fluid
  Dynamics Laboratory for climate modeling
• http//www.gfdl.noaa.gov/fms/
• Space Weather Modeling Framework (SWMF)
  NASA-funded, used at the University of Michigan
  for space weather prediction

5
How coupling tools work

• Users wrap their native data in framework data
  structures
• Users adopt standard calling interfaces for a set
  of methods that enable data exchange between
  components
• Development toolkits help users with routine
  functions (regridding, time management, etc.)

6
ESMF Standard interfaces

• Three ESMF component methods Initialize, Run,
  and Finalize (I/R/F)
• Each can have multiple phases
• Users register their native I/R/F methods with an
  ESMF Component
• Small set of arguments

call ESMF_GridCompRun (myComp, importState,
exportState,clock, phase, blockingFlag, rc)
7
ESMF Distributed data representation

• 1. Representation in index space (Arrays)
• Simple, flexible multi-dimensionalarray
  structure
• Regridding via sparse matrix multiply
  withuser-supplied interpolation weights
• Scalable to 10K processors - no
  globalinformation held locally
• 2. Representation in physical space (Fields)
• Built on Arrays some form of Grid
• Grids are logically rectangular, unstructured
  mesh, or observational data streams
• Regridding via parallel on-line interpolation
  weight generation, bilinear or higher order
  options
• Intrinsically holds significant amounts of
  metadata -
• dynamic, usable for multiple purposes, limited
  annotation required

Supported Array distributions
8
ESMF Coupling options

• Generally single executable for simpler
  deployment
• Push mode of data communication is very efficient
• Coupling communications can be set up and called
  in a coupler, or called directly from within
  components (for I/O, data assimilation)

• Hierarchical components for organization into
  sub-processes
• Recursive components for nesting higher
  resolution regions
• Coupling across C/Cand Fortran
• Ensemble management

ESMF-based hierarchical structure of GEOS-5
atmospheric GCM
9
ESMF Performance portability

• ESMF is highly performance portable, low (lt5)
  overhead
• 3000 regression tests run on 30
  platform/compiler combinations nightlySee
  http//www.esmf.ucar.edu/download/platforms
• Newer ports include native Windows, Solaris
• Using TeraGrid Build and Test Service to simplify
  regression testing

Performance at the petascale Scaling of the
ESMF sparse matrix multiply, used in regridding
transformations, out to 16K processors. (ESMF
v3.1.0rp2) Plot from Peggy Li, NASA/JPL Tested
on ORNL XT4, -N1 means 1 core per node.
ASMM Run-Time Comparison
msec
10
ESMF Higher order interpolation techniques in
CCSM

• ESMF higher order interpolation weights were used
  to map from a 2-degree Community Atmospheric
  Model (CAM) grid to a POP ocean grid (384x320,
  irregularly spaced)
• 33 reduction in noise globally in quantity
  critical for ocean circulation compared to
  previous bilinear interpolation approach
• ESMF weights are now the CCSM default

Interpolation noise in the derivative of the
zonal wind stress
Interp. noise
grid index in latitudinal direction
Black bilinear Red higher-orderESMF
v3.1.1 Green higher order ESMF v4.0.0
11
HAF
ESMF Model map
SWMF
Legend Ovals show ESMF components and models that
are at the working prototype level orbeyond.
GAIM
CCSM4
Dead atm
Data atm
POP Ocean
NOAA Department of Defense University NASA Departm
ent of Energy National Science Foundation ESMF
coupling complete ESMF coupling in
progress Component (thin lines) Model (thick
lines)
Dead ocean
Data ocean
Stub ocean
CICE ice
Dead ice
Data ice
Stub ice
FIM
CLM
Dead land
Data land
Stub land
Ice sheet
Strat Chem
GEOS-5
Param Chem
GEOS-5 Atm Dynamics
GOCART
FV Cub Sph Dycore
GEOS-5 GWD
GEOS-5 FV Dycore
Tracer Advection
Land Info System
GSI
GEOS-5 Atm Physics
GEOS-5 Hiistory
GEOS-5 Atm Chem
GEOS-5 Aeros Chem
GEOS-5 Surface
GEOS-5 Topology
GEOS-5 Moist Proc
GEOS-5 Lake
GEOS-5 Turbulence
GEOS-5 Land Ice
WRF
POP
ROMS
MOM4
UCLA AGCM
SWAN
CICE
COAMPS
MITgcm
MITgcm Atm
MITgcm Ocean
pWASH123
ADCIRC
NCOM
HYCOM
12
Loose coupling tools and interfaces

• Examples
• OpenMI
• http//www.openmi.org
• Web service approaches
• Coupling options
• Generally multiple executable
• Pull mode of data communication simple but not
  efficient(ask for a data point based on
  coordinates)
• Generally peer-peer component relationships
• Coupling across multiple computer languages
  (Python, Java, C, etc.)

13
Science gateways access centers

• Examples
• Earth System Grid (ESG) DOE, NCAR, NOAA
  support, used to distribute Intergovernmental
  Panel on Climate Change data and for climate
  research
• http//www.earthsystemgrid.org
• Hydrologic Information System (HIS) - NSF
  funded, used to enhance access to data for
  hydrologic analysishttp//his.cuahsi.org
• Object Modeling System (OMS) - USDA effort, used
  for agricultural modeling and analysishttp//java
  forge.com/project/1781

14
Metadata conventions and ontologies

• Examples
• Climate and Forecast (CF) conventions - spatial
  and temporal properties of fields used in weather
  and climate
• http//cf-pcmdi.llnl.gov
• METAFOR Common Information Model (CIM) large
  EU-funded project, climate model component
  structure and properties (including technical and
  scientific properties) http//metaforclimate.eu
• WaterML Schema for hydrologic data developed by
  the Consortium of Universities for the
  Advancement of Hydrologic Science
  (CUAHSI)http//his.cuahsi.org/wofws.html

15
Governance

• Pervasive issue in community modeling
• Divergent effects of
• Multiple institutions
• Geographic dispersion
• Multiple domains of interest (working groups)
• Must be balanced by strong integration body -
  strategies
• Meets frequently enough to affect routine
  development (quarterly)
• Meets virtually to get sufficient representation
• Includes user and other stakeholder
  representatives
• Authorized to prioritize and set development
  schedule
• Supported by web-based management tools

16
Integrating across interoperability elements

• Examples from the Curator project (NSF and NASA)
• Automated output of CF and CIM XML schema from
  ESMF (tight coupling ontology)
• Ingest of ESMF-generated schema into ESG,
  propagation into tools for search, browse,
  inter-comparison and distribution of model
  components and models(tight coupling ontology
  science gateway)
• Implementation of dataset trackback in ESG that
  connects datasets with detailed information about
  the models used to create the data
• (tight coupling ontology science gateway)
• Implementation of personal and group workspaces
  in ESG
• (science gateway governance)

17
Integrating across interoperability
elements(cont.)

• Translation of ESMF interfaces into web services
  to enable invocation of ESMF applications from a
  science gateway, and enable data and metadata
  from the run to be stored back to the
  gateway(tight coupling loose coupling
  science gateway ontology, new TeraGrid funding)

Web service interface
Loosely coupled components
ESMF interface
Tightly coupled HPC components
Issue of switch from push to pull data
interactions
18
Screenshot Component trackback
19
Screenshot Faceted search
20
Summary

• Cross-domain interoperability platforms have
  multiple elements
• Many of these elements already exist
• Integration activities (such as Earth System
  Curator) are the next focus

Image courtesy of Rocky Dunlap, Georgia Institute
of technology
