Molecular Identification and Strain Typing of MRSA

1
Molecular Identification and Strain Typing of MRSA

• John W. Longshore, Ph.D., FACMG
• Director, Molecular Pathology
• Carolinas Pathology Group
• Carolinas Medical Center

2
Topics to be Covered

• Laboratory detection of MRSA
• Traditional culture
• Molecular detection
• mecA
• Strain typing
• PFGE
• REP-PCR
• Summary

3
Culture Detection of MRSA

• Clinical and Laboratory Standards Institute
  (CLSI) recommends
• Cefoxitin disk screen test
• Latex agglutination test for PBP2a
• 6 ug/ml oxacillin in Mueller-Hinton agar with 4
  NaCl

4
Advantages of MRSA PCR

• Rapid Identification of carriers
• 2 hours PCR
• 24-72 hours Culture
• Swift implementation of appropriate interventions
• Limits unnecessary preemptive isolation
• Limits unnecessary antibiotic use
• Identifies MRSA in mixed populations
• Methicillin resistant coagulase negative Staph
• mecA negative Staph

5
MRSA PCR

• Two FDA cleared products
• BD GeneOhm (Infectio Diagnostic)
• Cepheid GeneXpert
• Runs on Cepheid SmartCycler
• Real-time PCR
• Samples type is direct nasal swab
• Detects gene sequence at the junction of the
  SCCmec and orfX gene
• Kit based product that can be used with minimal
  specialized training

6
MRSA PCR Procedure

• Specimen preparation
• Concentration
• Lysis-DNA extraction
• Reconstitution of molecular reagents
• Real-time PCR
• Automated results
• Full run time lt 2 hours

7
(No Transcript)
8
(No Transcript)
9
Smart Cycler Instrument
10
Quantification and Dynamic Range
11
Real-time Analysis
12
MRSA PCR vs. Culture
PPV 94 NPV 98 Detection limit 325 MRSA per
swab
13
MRSA Strain Typing

• MRSA is a clonal organism
• Very useful for epidemiology
• Strain types between patients
• Monitor trends in types
• Track seasonal outbreaks
• Database of samples for long term studies
• Trace infection source
• Patient-Patient / Patient-Caregiver
• Determine if HA or CA MRSA

14
USA Strain Types

• Large study by CDC in 2003
• Sma I digested bacterial DNA
• 1000 MRSA isolates
• Determine CA vs. HA strains
• Eight major strain types in US
• CA USA 300 and 400
• Resistant to beta-lactams and erythromycin
• USA 100 most common type (44)
• Multiresistant
• USA 700 both HA and CA

15
Resolution of Typing Methods
16
Strain Typing Methods
17
Pulsed Field Gel Electrophoresis
18
PFGE Results
19
Repetitive Sequence PCR
20
REP PCR Protocol
21
Bacterial Barcodes MRSA Typing

• Based on REP PCR technique
• Minimal tech hands on time
• Relies upon either traditional culture or PCR for
  MRSA status prior to analysis
• Cant distinguish MSSA from MRSA
• MRSA library based upon CDC USA PFGE types
• Highly reproducible

22
DiversiLab MRSA Library

• USA 100
• USA 200
• USA 300
• USA 400
• USA 500
• USA 600
• USA 700
• USA 800
• USA 900
• USA 1000
• USA 1100
• USA 1200
• Brazil
• Iberian

• 2
• 3
• 3
• 3
• 2
• 2
• 2
• 1
• 1
• 2
• 2
• 1
• 2
• 2

23
DNA LabChip Microfluidic Electrophoresis
24
Agilent 2100 System
25
Strain Typing Workflow
26
DiversiLab Results
27
(No Transcript)
28
(No Transcript)
29
Top Match
30
(No Transcript)
31
(No Transcript)
32
Careful Interpretation!
USA 100
USA 800
33
Cluster Analysis
34
Why Utilize Molecular Testing?

• Rapid diagnosis
• Cost effective
• Highly specific
• Improved patient care
• Provides ultimate resolution
• No outside interference from medication or
  treatments can alter the testing results
